Centrix D20 User manual

HDVS IP CAMERA
D20 & D50
User Manual

Table of Contents
1. Overview ................................................................................................................................. 3
1.1 Features ....................................................................................................................... 3
1.2 Package Contents....................................................................................................... 4
1.3 Camera Dimensions ................................................................................................... 5
1.4 Connectors................................................................................................................... 6
2. Camera Cabling..................................................................................................................... 7
2.1 Connect Power ............................................................................................................ 7
2.2 Connect Ethernet Cable ............................................................................................. 7
2.3 Connect Alarm I/O....................................................................................................... 7
3. System Requirements ......................................................................................................... 8
4. Access Camera ..................................................................................................................... 9
5. Setup Video Resolution..................................................................................................... 13
6. Conguration Files Export / Import................................................................................ 14
Appendix A: Technical Specications......................................................................................... 15
Appendix B: Delete the Existing DC Viewer ............................................................................... 19
Appendix C: Setup Internet Security........................................................................................... 20
Appendix D: Video Resolution..................................................................................................... 21
2M- Quad Streams .................................................................................................................. 21
2M- Triple Streams .................................................................................................................. 25
2M- Dual Streams.................................................................................................................... 27
2M- Single Stream................................................................................................................... 27
2M Real time / 3M / 5M- Quad Streams.................................................................................. 28
2M Real time / 3M / 5M- Triple Streams.................................................................................. 33
2M Real time / 3M / 5M- Dual Streams ................................................................................... 36
2M Real time / 3M / 5M- Single Stream................................................................................... 37

3
1. Overview
The IP Camera features decent low light performance, high resolution up to 5 Mega-
pixel, various video resolution combination, multiple video compression formats, etc.
It supports true day / night and 3DNR function, which display clear images in low light
conditions. Moreover, the proprietary SPQ (Smart Picture Quality) function allows de-
livering quality images especially under intensive motion and low light conditions. With
the built-in IR LED module, the IP Camera makes visibility in nearly total darkness.
With H.264 High / Main / Baseline prole and MJPEG video compression formats sup-
port, it is benecial for optimization of bandwidth and network resources. Video quad-
stream support allows various surveillance applications and facilitates working with other
back-end devices.
1.1 Features
 Progressive Scan CMOS Sensor
 Quad Streams Compression: H.264 Baseline / Main/ High Prole + MJPEG
 Multi-language Support
 Tampering Alarm
 Remote Zoom & Focus (Motorized Lens)*
 Wide Dynamic Range
 Motion Detection
 Privacy Masks
 Smart Picture Quality / 3D Noise Reduction
 Vertical View Mode (Image rotation by 90 degrees)
 Smart IR Mode
 Network Failure Detection
 Day/Night (ICR)
 IR LED Module (working distance up to 25m)*
 Micro SD support
 BNC analog output
 ONVIF Support
(*) Optional

4
1.2 Package Contents
Please check the package contains the following items listed below.
Camera Package Contents
Lightweight Fixed Dome IP Camera
Power Terminal Block Security Torx
Self Tapping Screws
(×4) Plastic Screw Anchors
(×4)
Rubber Washers (×6)
CD
(bundled software and
documentation)
Quick Guide

5
1.3 Camera Dimensions
The IP Dome Camera’s dimensions are shown below.

6
1.4 Connectors
The diagram below shows the IP Dome Camera’s reset button and various connectors.
Denition for each connector will be given as follows.
No. Connector Pin Denition Remarks
1Reset Button - Restore to factory default
2BNC -Analog Video Output
3
Alarm I/O
2
3
4
1GND (Input－)
Alarm connection
Input＋
Output－
Output＋
4
Audio I/O
2
3
4
1 Output (L)
Two-way audio transmission
Output
(R)
GND
Input
5 Power
DC 12V
1Power
Power connection
2Reserved
3GND
AC 24V
1Power-1
2Earth GND
3Power-2
6 RJ-45 -10/100 Mbps Ethernet / PoE

7
2. Camera Cabling
Please follow the instructions below to complete IP Camera connection.
2.1 Connect Power
Please refer to Section: Connectors. Alternatively, connect the Ethernet cable to the
camera’s PoE port and plug the other end of the cable into a PoE switch.
NOTE: If using PoE, make sure Power Sourcing Equipment (PSE) is in use
in the network.
2.2 Connect Ethernet Cable
Use of Category 5 Ethernet cable is recommended for network connection; to have best
transmission quality, cable length shall not exceed 100 meters. Connect one end of the
Ethernet cable to the RJ-45 connector of the IP Dome Camera, and the other end of the
cable to the network switch or PC.
NOTE: In some cases, you may need use an Ethernet crossover cable
when connecting the IP Dome Camera directly to the PC.
Check the status of the link indicator and activity indicator LEDs; if the LEDs are unlit,
please check LAN connection.
Green Link Light indicates good network connection.
Orange Activity Light ashes for network activity indication.
2.3 Connect Alarm I/O
The camera equips one alarm input and one relay output for alarm application. Refer to
alarm pin denition below to connect alarm devices to the IP Camera if needed.
PIN 1: GND (Input-)
PIN 2: Input+
PIN 3: Output-
PIN 4: Output+

8
3. System Requirements
To perform the IP Camera via web browser, please ensure your PC is in good network
connection, and meet system requirements as described below.
Items System Requirement
Personal Computer
1. Intel®Pentium® M, 2.16 GHz or
Intel®CoreTM2 Duo, 2.0 GHz
2. 2 GB RAM or more
Operating System Windows VISTA / Windows XP / Windows 7
Web Browser Microsoft Internet Explorer 6.0 or later
Firefox
Chrome
Safari
Network Card 10Base-T (10 Mbps) or 100Base-TX (100 Mbps) operation
Viewer ActiveX control plug-in for Microsoft IE

9
4. Access Camera
For initial access to the IP Camera, users can search the camera through the installer
program: DeviceSearch.exe, which can be found in “DeviceSearch” folder in the sup-
plied CD.
Device Search Software Setup
Step 1: Double click on the program Device Search.exe. After its window appears,
click on the <Device Search> button on the top side.
Step 2: The security alert window will pop up. Click on <Unblock> to continue.
Device Search
Step 3: Click on <Device Search> again, and all the nding IP devices will be listed in
the page. The IP Camera’s default IP address is: 192.168.0.250.
Step 4: Double click or right click and select <Browse> to access the camera directly
via web browser.
Step 5: Then the prompt window of request for entering default username and pass-
word will appear for login to the IP Dome Camera.
The default login ID and password for the Administrator are:
Login ID Password
admin admin
NOTE: ID and password are case sensitive.
NOTE: It is strongly advised that administrator’s password be altered for
the security concerns. Refer to Full HD Multiple Streams IP Camera Menu Tree
for further details.

10
Additionally, users can change the IP Camera’s network property, either DHCP or Static
IP directly in the device nding list. Refer to the following section for changing the IP
Camera’s network property.
Example of Changing IP Camera’s Network Property
Users can directly change an IP Camera’s network property, ex. from static IP to DHCP,
in the nding device list. The way to change the IP Camera’s network property is speci-
ed below:
Step 1: In the nding device list, click on the IP Camera that you would like to change
its network property. On the selected item, right click and select “Network Setup.”
Meanwhile, record the IP Camera’s MAC address, for future identication.
Step 2: The “Network Setup” page will come out. Select “DHCP,” and press
“Apply” button down the page.
Step 3: Click on <OK> on the Note of setting change. Wait for one minute to re-search
the IP Camera.
Step 4: Click on the <Device Search> button to re-search all the devices. Then select
the IP Camera with the correct MAC address. Double click on the IP Camera, and the
login window will come out.
Step 5: Enter User name and Password to access the IP Camera.
Installing DC Viewer Software Online
For the initial access to the IP Camera, a client program, DC Viewer, will be automati-
cally installed to your PC when connecting to the IP Camera.
If the Web browser doesn’t allow DC Viewer installation, please check the Internet secu-
rity settings or ActiveX controls and plug-ins settings (refer to Section: Internet Security
Settings) to continue the process.
The Information Bar (just below the URL bar) may come out and ask for permission to
install the ActiveX Control for displaying video in browser. Right click on the Information
Bar and select <Install ActiveX Control…> to allow the installation.

11
The download procedure of DC Viewer software is specied as follows.
Step 1: In the DC Viewer installation window, click on <Next> to start installation.
Step 2: The status bar will show the installation progress. After the installation is com-
pleted, click on <Finish> to exit the installation process.
Step 3: Click on <Finish> to close the DC Viewer installation page.
Once the DC Viewer is successfully installed, the IP Camera’s Home page will be able
to correctly display as the gure below.
Vari-focal Model
Viewer Window
Live Video Panel
Video Format
Selection
Display Mode
Web Recording Button
Video Compression Info
Video Streaming Pause Button
Snapshot Button
Speaker Button
Talk Button
Main Tabs Languages Selection
Time Display

12
Motorized Model
Image and Focus Adjustment
The image displays on the Home page when successfully accessing to the IP Camera.
Adjust zoom and focus as necessary to produce a clear image.
Note: Please refer to Full HD Multiple Streams IP Camera Menu Tree for more but-
ton function detail.
Viewer Window
Live Video Panel
Video Format
Selection
Display Mode
Web Recording Button
Video Compression Info
Video Streaming Pause Button
Snapshot Button
Speaker Button
Talk Button
Main Tabs Languages Selection
Time Display

13
5. Setup Video Resolution
Users can setup Video Resolution on Video Format page of the user-friendly browser-
based conguration interface.
Video Format can be found under this path: Streaming> Video Format.
The default value of Video Resolution is as below:
2M H.264- 1920 x 1080 (15 fps) + H.264- 1280 x 720 (30 fps)
2M Real time
H.264- 1920 x 1080 (30 fps) + H.264 720 x 480 (30 fps)
3M
5M
For more Video Resolution combination detail, please refer to Appendix: Video Resolu-
tion. Click on <Save> to conrm the setting.

14
6. Conguration Files Export / Import
To export / import conguration les, users can access the Maintenance page on the
user-friendly browser-based conguration interface.
The Maintenance setting can be found under this path: System> Maintenance.
Users can export conguration les to a specied location and retrieve data by upload-
ing an existing conguration le to the IP Camera. It is especially convenient to make
multiple cameras having the same conguration.
Export
Users can save the system settings by exporting the conguration le (.bin) to a speci-
ed location for future use. Click on the <Export> button, and the popup File Download
window will come out. Click on <Save> and specify a desired location for saving the
conguration le.
Upload
To copy an existing conguration le to the IP Camera, please rst click on <Browse> to
select the conguration le, and then click on the <Upload> button for uploading.

15
Appendix A: Technical Specications
Camera
2M
2M Real-time
Image Sensor
1/2.7” Progressive CMOS
Effective Pixels
1920(H) x 1080(V)
Minimum Illumination
0.2 lux (Color)
0.02 lux (B/W)
White Balance
Manual / AWB / ATW
Shutter Speed
1~ 1/10000 sec.
Lens
Vari-focal / Motorized
Vari-focal / Motorized / 3x AF
Focal Length 3 ~ 9 mm
F Number Vari-focal / Motorized- F1.2
3x AF- F1.2 (Wide); F2.1 (Tele)
FOV Vari-focal / Motorized- 103.5° (Wide) ; 34.3° (Tele)
3x AF- 92.93° (Wide) ; 30.9° (Tele)
Operation
Multiple Languages English / French / German / Italian / Korean / Simplified Chinese /
Traditional Chinese / Russian
Image Setting
Backlight Compensation
On / Off
White Balance
Auto / Manual
Noise Reduction (3D)
On / Off
Wide Dynamic Range
On / Off
Privacy Mask
On / Off
Brightness
Manual
Exposure
Auto / Manual
Sharpness
Manual
Contrast
Manual
Saturation
Manual
Hue
Manual
Digital Zoom
Support
Motion Detection
On / Off
Privacy Mask Type
Color
ICR
Auto / On / Off / Smart
ICR + IR LED*
Auto / LED On / LED Off / Smart IR / Light Sensor
Tampering Alarm
On / Off
Audio
Two-way Audio
Line in, Line out
Compression
G.711 / G.726
Network
Interface
RJ-45, 10/100 Mbps Ethernet
Video Compression
H.264 / MJPEG
Video Streaming
Dual Streams- H.264 + H.264 / MJPEG
Quad Streams- H.264 + H.264 + H.264 + H.264/ MJPEG
Video Resolution H.264- Full HD 1080P / SXGA / HD 720P / XGA / SVGA / D1 / VGA / CIF
MJPEG- Full HD 1080P / SXGA / HD 720P / XGA / SVGA / D1 / VGA / CIF
Protocol IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP, DHCP,
PPPoE, UPnP, IGMP, SNMP, QoS, ONVIF
Security
HTTPS / IP Filter / IEEE 802.1x
Alarm
Input
1 Set
5V 10kΩpull up
Output
1 Set
Photo Relay Output 300V DC/AC
Event Notification
HTTP / FTP / SMTP
Micro SD
microSDHC 32GB support
Supported Web Browser
Internet Explorer (6.0+) / Chrome / Firefox / Safari
User Account
20
Password Levels
User and Administrator
Lens

16
Mechanical
*Built-in IR
Illuminator
Working distance
Up to 25m
Wavelength
850 nm
Number of LEDs
24
LED Indicator
Power / Link / ACT
Connectors
Alarm
4 Pin Terminal Block
Power
3 Pin Terminal Block
Ethernet
RJ-45
Analog Video
1.0 Vp-p / 75 Ω, BNC
Audio
Line in, Line out
General
Operating Temperature
-10°C ~ 50°C (14°F ~ 122°F)
Humidity
10% ~ 90%, No Condensation
Dimension
∅149 x 131 mm (∅5.9 x 5.2 in.)
Weight
700 g (1.5 lb)
Power Source
DC 12V / AC 24V / PoE
Power Consumption
System: 5 W
(Built-in IR Illuminator: +3 W, Motorized Lens: +3.6 W)
Regulatory
CE / FCC / RoHS
(*) Optional

17
Camera
3M
5M
Image Sensor
1/2.7” Progressive CMOS
Effective Pixels
2048(H) x 1536(V)
2592(H) x 1944(V)
Minimum Illumination
0.2 lux (Color)
0.02 lux (B/W)
TBD
White Balance
Manual / AWB / ATW
Shutter Speed
1~ 1/10000 sec.
Lens
Lens
Vari-focal / Motorized
Vari-focal / Motorized
Focal Length
3~9 mm
3.6 ~ 9 mm
F Number
F1.2
F1.8
FOV
103.5° (Wide) ; 34.3° (Tele)
100° (Wide) ~ 40° (Tele)
Operation
Multiple Languages English / French / German / Italian / Korean / Simplified Chinese /
Traditional Chinese / Russian
Image Setting
Backlight Compensation
On / Off
White Balance
Auto / Manual
Noise Reduction (3D)
On / Off
Wide Dynamic Range
On / Off
Privacy Mask
On / Off
Brightness
Manual
Exposure
Auto / Manual
Sharpness
Manual
Contrast
Manual
Saturation
Manual
Hue
Manual
Digital Zoom
Support
Motion Detection
On / Off
Privacy Mask Type
Color
ICR
Auto / On / Off / Smart
ICR + IR LED* Auto / LED On / LED Off / Smart IR / Light Sensor
Tampering Alarm
On / Off
Audio
Two-way Audio
Line in, Line out
Compression
G.711/G.726
Network
Interface
RJ-45, 10/100 Mbps Ethernet
Video Compression
H.264 / MJPEG
Video Streaming
Single Stream- 2048 x 1536
Single Stream-
2592 x 1944 / 2048 x 1536
Dual Streams- H.264 + H.264 / MJPEG
Quad Streams- H.264 + H.264 + H.264 + H.264/ MJPEG
Video Resolution
H.264- 2048 x 1536 (3M)
H.264- 2592 x 1944 (5M) /
2048 x 1536 (3M)
H.264- Full HD 1080P / SXGA / HD 720P / XGA / SVGA / D1 / VGA / CIF
MJPEG- Full HD 1080P / SXGA / HD 720P / XGA / SVGA / D1 / VGA / CIF
‘Protocol IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP,
DHCP, PPPoE, UPnP, IGMP, SNMP, QoS, ONVIF
Security
HTTPS / IP Filter / IEEE 802.1x
Alarm
Input 1 Set
5V 10kΩpull up
Output
1 Set
Photo Relay Output 300V DC/AC
Event Notification
HTTP / FTP / SMTP
Micro SD
microSDHC 32GB support
Supported Web Browser
Internet Explorer (6.0+) / Chrome / Firefox / Safari
User Account
20
Password Levels
User and Administrator

18
Mechanical
Built-in IR
Illuminator*
Working distance
up to 25 m
Wavelength
850 nm
Number of LEDs
24
LED Indicator
Power / Link / ACT
Connectors
Alarm
4 Pin Terminal Block
Power
3 Pin Terminal Block
Ethernet
RJ-45
Analog Video
1.0 Vp-p / 75 Ω, BNC
Audio
Line in, Line out
General
Operating Temperature
-10°C ~ 50°C (14° ~ 122° F)
Humidity
10% ~ 90%, No Condensation
Dimension
∅149 x 131 mm (∅5.9 x 5.2 in.)
Weight
700 g (1.5 lb)
Power Source
DC 12V / AC 24V / PoE
Power Consumption System: 5 W
(Built-in IR Illuminator: +3 W, Motorized Lens: +3.6 W)
Regulatory
CE / FCC / RoHS
(*) Optional

19
Appendix B: Delete the Existing DC Viewer
For users who have installed the DC Viewer in the PC previously, please rst remove the existing
DC Viewer from the PC before accessing to the IP Camera.
Deleting the DC Viewer
In the Windows <Start Menu>, activate <Control Panel>, and then double click on <Add or Remove
Programs>. In the <Currently installed programs> list, select <DCViewer> and click on the button
<Remove> to uninstall the existing DC Viewer.
Deleting Temporary Internet Files
To improve browser performance, it is suggested to clean up the all the les in the Temporary Inter-
net Files.
The procedure is as follows:
Step 1: Click on the <Tools> tab on the menu bar and select <Internet Options>.
Step 2: Click on the <Delete> button under <Browsing history> section. Then click on the
<Delete Files> button under the <Temporary Internet les> section.
Step 3: A conrmation window will pop up. Click on <Yes> to start deleting the les.

20
Appendix C: Setup Internet Security
If ActiveX control installation is blocked, please either set Internet security level to default or change
ActiveX controls and plug-ins settings.
Internet Security Level: Default
Step 1: Start the Internet Explorer (IE).
Step 2: Click on the <Tools> tab on the menu bar and select <Internet Options>.
Step 3: Click on the <Security> tab, and select <Internet> zone.
Step 4: Down the page, click on the <Default Level> button and click on <OK> to conrm the set-
ting. Close the browser window, and restart a new one later to access the IP Camera.
ActiveX Controls and Plug-ins Settings
Step 1: Repeat Steps 1~3 of the previous section above.
Step 2: Down the page, click on the <Custom Level> button to change ActiveX controls
and plug-ins settings. The Security Settings window will pop up.
Step 3: Under <ActiveX controls and plug-ins>, set ALL items (as listed below) to <Enable> or
<Prompt>. Please note that the items vary by IE version.
ActiveX controls and plug-ins settings:
1. Allow previously unused ActiveX controls to run without prompt.
2. Allow Scriptlets.
3. Automatic prompting for ActiveX controls.
4. Binary and script behaviors.
5. Display video and animation on a webpage that does not use external media player.
6. Download signed ActiveX controls.
7. Download unsigned ActiveX controls.
8. Initialize and script ActiveX controls not marked as safe for scripting.
9. Run ActiveX controls and plug-ins.
10. Script ActiveX controls marked safe for scripting.
Step 4: Click on <OK> to accept the settings and close the Security Settings window.
Step 5: Click on <OK> to close the Internet Options screen.
Step 6: Close the browser window, and restart a new one later to access the IP Camera.
