Centrix Q50 User manual

HDVS IP CAMERA
Q50
User Manual

Table of Contents
1. Overview ................................................................................................................................. 3
1.1 Features ....................................................................................................................... 3
1.2 Package Contents....................................................................................................... 4
1.3 Dimensions .................................................................................................................. 5
1.4 Connectors................................................................................................................... 6
1.5 Cable Denition (Optional)......................................................................................... 7
2. Camera Cabling..................................................................................................................... 8
2.1 Connect Power ............................................................................................................ 8
2.2 Connect Ethernet Cable............................................................................................. 8
3. System Requirements ......................................................................................................... 9
4. Access Camera ................................................................................................................... 10
5. Setup Video Resolution..................................................................................................... 15
6. Conguration Files Export / Import................................................................................ 16
Appendix A: Technical Specications......................................................................................... 17
Appendix B: Delete the Existing DC Viewer ............................................................................... 19
Appendix C: Setup Internet Security........................................................................................... 20
Appendix D: Video Resolution..................................................................................................... 21
Quad Streams......................................................................................................................... 21
Triple Streams ........................................................................................................................ 26
Dual Streams.......................................................................................................................... 29
Single Stream ......................................................................................................................... 30

3
1. Overview
The Fisheye IP Camera is a high resolution surveillance solution featuring 360 Degree
Panorama View that allows users to monitor a wide angle surveillance environment with-
out blind spot with just one Camera. The Camera not only delivers clear images through
multi-streaming video, its lens with up to 5 Mega-pixel high resolution image also pro-
vides panorama function with quad view that enables four different assigned angles im-
ages to display simultaneously for monitoring.
Furthermore, it has built-in IR LED and true day/night IR cut lter for supreme night time
images. With compact outlook and rugged housing, the easy installing and weatherproof
ability offers users to apply the Camera in various kinds of IP surveillance environment
exibly such as hotel, hospital, retailer store, parking lot, and factory, etc.
1.1 Features
 Progressive Scan CMOS Sensor
 5M resolution
 Dual Streams, Full HD 1080P real-time + D1 real-time
 Quad Streams support
 Quad Streams Compression:
H.264 Baseline / Main / High Prole + MJPEG
 360° Panorama View
 ePTZ
 Quad View
 Tampering Alarm
 Wide Dynamic Range
 Motion Detection
 Privacy Masks
 Day / Night (ICR)
 IR LED Module
 Built-in MIC & Speaker
 Weatherproof (IP66 International)*
 Micro SD support
 ONVIF support
(*) Optional

4
1.2 Package Contents
Please check the package contains the following items listed below.
Fisheye IP Camera Self-tapping screws
(×3)
Plastic Anchors
(×3)
Security Screw
(×1)
Security Torx Power Terminal
Block (x1) Quick Guide CD
NOTE: The type of the supplied self-tapping screws is mainly for softer substrate
/ material installation such as wood. For other installation environment such as cement
wall, it is required to pre-drill and use plastic anchors before fastening the supplied self-
tapping screw on the wall.
All In One Cable (Optional)

5
1.3 Dimensions
The IP Camera’s dimensions are shown below.

6
1.4 Connectors
Please remove the security screws and the cover to reach the connectors.
The diagram below shows the IP Camera’s connectors and reset button. Denition for
each will be given as follows.
No. Connector Pin Denition Remarks
1 Power*
DC 12V
1 Power
Power connection
2 Reserved
3GND
AC 24V
1 Power-1
2Earth GND
3 Power-2
2 RJ-45 -10/100 Mbps Ethernet / PoE
3Alarm & Audio I/O* -Please refer to the Alarm & Audio I/O in the table un-
der Cable Denition
4Reset Button -
Restore to default setting
Press the button with a proper tool
5Micro SD Card Slot - For video recording storage
*All in One Cable is required for Power, Alarm and Audio I/O utilization.

7
1.5 Cable Denition (Optional)
No. Connector Pin Denition Remarks
1Audio I/O
Pink Line In
Two-way audio transmission
Green Line Out
2
Alarm
(4-Pin Terminal Block)
1ALM_IN –
Alarm connection
2ALM_IN +
3ALM_OUT –
4ALM_OUT +
3
Power DC Jack - DC 12V Power connection
Power Wires
Red AC 24V (+) Remove DC Jack connec-
tor head, and apply AC 24V
with Red and Black wires (as
shown in the diagrams below).
Black AC 24V (–)
4Alarm & Audio I/O
1GND
Two-way audio transmission /
Alarm connection
2 Line In
3Line Out
4 -
5ALM_IN –
6ALM_IN +
7ALM_OUT –
8ALM_OUT +
5 Power Wires
Red
DC 12V (+) /
AC 24V (+) Power connection
Black
DC 12V (–) /
AC 24V (–)

8
2. Camera Cabling
Please follow the instructions below to complete IP Camera connection.
2.1 Connect Power
Please refer to Section: Connectors. Alternatively, connect the Ethernet cable to the
camera’s RJ-45 port and plug the other end of the cable into a PoE switch.
NOTE: If PoE is used, make sure Power Sourcing Equipment (PSE) is in
use in the network.
2.2 Connect Ethernet Cable
Use of Category 5 Ethernet cable is recommended for network connection; to have best
transmission quality, cable length shall not exceed 100 meters. Connect one end of the
Ethernet cable to the RJ-45 connector of the IP Camera, and the other end of the cable
to the network switch or PC.
NOTE: In some cases, Ethernet crossover cable might be needed when
connecting the IP Camera directly to the PC.
Check the status of the link indicator and activity indicator LEDs. If the LEDs are unlit,
please check LAN connection.
Green Link Light indicates good network connection.
Orange Activity Light ashes for network activity indication.

9
3. System Requirements
To perform the IP Camera via web browser, please ensure the PC is in good network
connection, and meet system requirements as described below.
Items System Requirement
Personal Computer
Minimum :
1. Intel® Core™ i5-2430M @ 2.4 GHz
2. 4 GB RAM
Recommended:
1. Intel® Core™ i7-870 @ 2.93 GHz
2. 8 GB RAM
Operating System Windows VISTA / Windows XP / Windows 7
Web Browser Microsoft Internet Explorer 6.0 or later
Firefox
Chrome
Safari
Network Card 10Base-T (10 Mbps) or 100Base-TX (100 Mbps) operation
Viewer ActiveX control plug-in for Microsoft IE

10
4. Access Camera
For initial access to the IP Camera, users can search the camera through the installer
program: DeviceSearch.exe, which can be found in “DeviceSearch” folder in the sup-
plied CD.
Device Search Software Setup
Step 1: Double click on the program Device Search.exe. After its window appears,
click on the <Device Search> button on the top side.
Step 2: The security alert window will pop up. Click on <Unblock> to continue.
Device Search
Step 3: Click on <Device Search> again, and all the nding IP devices will be listed in
the page. The IP Camera’s default IP address is: 192.168.0.250.
Step 4: Double click or right click and select <Browse> to access the camera directly
via web browser.
Step 5: Then the prompt window of request for entering default username and
password will appear for logging in to the IP Camera.
The default login ID and password for the Administrator are:
Login ID Password
admin admin
NOTE: ID and password are case sensitive.
NOTE: It is strongly advised that administrator’s password be altered for
the security concerns. Refer to Full HD Multiple Streams IP Camera Menu Tree
for further details.

11
Additionally, users can change the IP Camera’s network property, either DHCP or Static
IP, directly in the device nding list. Refer to the following section for changing the IP
Camera’s network property.
Example of Changing IP Camera’s Network Property
Users can directly change an IP Camera’s network property, ex. from static IP to DHCP,
in the nding device list. The way to change the IP Camera’s network property is speci-
ed below:
Step 1: In the nding device list, click on the network Speed Dome Camera that is
wished to change its network property. On the selected item, right click and
select <Network Setup>. Meanwhile, record the IP Camera’s MAC address, for
future identication.
Step 2: The <Network Setup> page will come out. Select <DHCP>, and click on <Ap-
ply> button down the page.
Step 3: Click on <OK> on the Note of setting change. Wait for one minute to re-search
the IP Camera.
Step 4: Click on the <Device Search> button to re-search all the devices. Then select
the IP Camera with the correct MAC address. Double click on the IP Camera,
and the login window will come out.
Step 5: Enter User name and Password to access the IP Camera.

12
Installing DC Viewer Software Online
For the initial access to the IP Camera, a client program, DC Viewer, will be automati-
cally installed to the PC when connecting to the IP Camera.
If the Web browser doesn’t allow DC Viewer installation, please check the Internet se-
curity settings or ActiveX controls and plug-ins settings (refer to Section: Setup Internet
Security) to continue the process.
The Information Bar (just below the URL bar) may come out and ask for permission to
install the ActiveX Control for displaying video in browser. Right click on the Information
Bar and select <Install ActiveX Control…> to allow the installation.
The download procedure of DC Viewer software is specied as follows.
Step 1: In the DC Viewer installation window, click on <Next> to start installation.
Step 2: The status bar will show the installation progress. After the installation is com-
pleted, click on <Finish> to exit the installation process.
Step 3: Click on <Finish> to close the DC Viewer installation page.
Once the DC Viewer is successfully installed, the IP Camera’s Home page will be able
to correctly display as the gure below.

13
Ceiling Mount Installed Camera

14
Wall Mount Installed Camera
Note: Please refer to Full HD Multiple Streams IP Camera Menu Tree for more but-
ton function detail.
Viewer Window
Live Video Panel
Video Format
Selection
Display Mode
Web Recording Button
Video Compression Info
Video Streaming Pause Button
Snapshot Button
Speaker Button
Talk Button
Main Tabs Languages Selection
Time Display

15
5. Setup Video Resolution
Users can setup Video Resolution on Video Format page of the user-friendly browser-
based conguration interface.
Video Format can be found under this path: Streaming> Video Format.
The default value of Video Resolution is: H.264 2592 x 1994 (12 fps) + H.264 720 x 480
(12 fps). For more Video Resolution combination detail, please refer to Appendix: Video
Resolution. Click on <Save> to conrm the setting.

16
6. Conguration Files Export / Import
To export / import conguration les, users can access the Maintenance page on the
user-friendly browser-based conguration interface.
The Maintenance setting can be found under this path: System> Maintenance.
Users can export conguration les to a specied location and retrieve data by upload-
ing an existing conguration le to the IP Camera.
Export
Users can save the system settings by exporting the conguration le (.bin) to a speci-
ed location for future use. Click on the <Export> button, and the popup File Download
window will come out. Click on <Save> and specify a desired location for saving the
conguration le.
Upload
To copy an existing conguration le to the IP Camera, please rst click on <Browse> to
select the conguration le, and then click on the <Upload> button for uploading.

17
Appendix A: Technical Specications
Camera
W8
Image Sensor
5M Progressive CMOS
Effective Pixels
2592(H) x 1944(V)
Minimum illumination 0.2 lux (Color) @ F2.8
0.02 lux (B/W) @ F2.8
White Balance
Manual / AWB / ATW
Shutter Speed
1 ~ 1/10k sec.
Lens
Lens
Stereo Projection Type
1/2.5" Fisheye Lens
Focal Length
1.05 mm
F Number
F2.8
FOV
180° @ Full Resolution
Operation
Multiple Languages English / French / German / Italian / Korean / Simplified Chinese /
Traditional Chinese / Russian
Image Setting
Backlight
Compensation
On / Off
White Balance
Auto / Manual
Noise Reduction (3D)
On / Off
Wide Dynamic Range
On / Off
Privacy Mask
On / Off
Brightness
Manual
Exposure
Auto / Manual
Sharpness
Manual
Contrast
Manual
Saturation
Manual
Hue
Manual
Digital Zoom
Support
Motion detection
On / Off
Privacy Mask Type
Color
ICR
Auto / LED On / LED Off / Smart IR / Light Sensor
Tampering Alarm
On / Off
Audio Type Built-in Speaker (Max. 2W Mono) /
Microphone or Two-way Audio (Line in / Line out)*
Compression
G.711 / G.726
Network
Interface
RJ-45, 10/100 Mbps Ethernet
Video Compression
H.264 Baseline / Main Profile / High Profile / MJPEG
Video Streaming
Single Stream: 2592 x 1944 (12 fps)
Single Stream: 2048 x 1536 (15 fps)
Simultaneous H.264 1080p (25/30 fps) + MJPEG D1 (25/30 fps)
Simultaneous H.264 1080p (25/30 fps) + H.264 D1 (25/30 fps)
Quad Streams
Video Resolution H.264
5M (2592 x 1944) / 3M (2048 x 1536) / Full HD 1080P / SXGA /
HD 720P / XGA / SVGA / D1 / VGA / CIF
MJPEG
Full HD 1080P / SXGA / HD 720P / XGA / SVGA / D1 / VGA / CIF
Protocol
IPv4/v6, TCP/IP, UDP, RTP, RTSP, HTTP, HTTPS, ICMP, FTP, SMTP,
DHCP, PPPoE, UPnP, IGMP, SNMP, QoS, ONVIF
Security
HTTPS / IP Filter / IEEE 802.1x
Alarm*
Input 1 Set
5V 10kΩpull up
Output 1 Set
Photo Relay Output 300V DC / AC
Event Notification
HTTP / FTP / SMTP
Micro SD
microSDHC 32GB support
Supported Web Browser
Internet Explorer (6.0+) / Chrome / Firefox / Safari
User Account
20
Password Levels
User and Administrator

18
Mechanical
Built-in IR
Illuminator
Working Distance
5 m
Wavelength
850 nm
Number of LEDs
6
Lens Mounting
M12 Fisheye Lens
Connectors
Alarm & Audio
8 Pin Terminal Block, Pitch 2.5 mm
Power
3 Pin Terminal Block
Ethernet
RJ-45
All in one Cable*
Audio I / O
Line in / Line Out
Alarm 4 Pin Wire Cables
Power DC 12V DC Jack
AC 24V
Power Wire Cables AC 24V (+), AC 24V (-)
General
Operating Temperature
-10°C ~ 50°C (14°F ~ 122°F)
Humidity
10% ~ 90%, No Condensation
Weatherproof Standard
Rugged Camera- IP66
Dimension
Ø 149 x 45.8 mm (Ø 5.87 x 1.80 in.)
Weight
350 g (0.77 lbs)
Power Source
DC 12V* / AC 24V* / PoE
Power Consumption
Max. 12W
Regulatory
CE / FCC / RoHS
(*) Optional

19
Appendix B: Delete the Existing DC Viewer
For users who have installed the DC Viewer in the PC previously, please rst remove the existing
DC Viewer from the PC before accessing to the IP Camera.
Deleting the DC Viewer
In the Windows <Start Menu>, activate <Control Panel>, and then double click on <Add or Remove
Programs>. In the <Currently installed programs> list, select <DC Viewer> and click on the button
<Remove> to uninstall the existing DC Viewer.
Deleting Temporary Internet Files
To improve browser performance, it is suggested to clean up the all the les in the Temporary Inter-
net Files.
The procedure is as follows:
Step 1: Click on the <Tools> tab on the menu bar and select <Internet Options>.
Step 2: Click on the <Delete> button under <Browsing history> section. Then click on the
<Delete Files> button under the <Temporary Internet les> section.
Step 3: A conrmation window will pop up. Click on <Yes> to start deleting the les.

20
Appendix C: Setup Internet Security
If ActiveX control installation is blocked, please either set Internet security level to default or change
ActiveX controls and plug-ins settings.
Internet Security Level: Default
Step 1: Start the Internet Explorer (IE).
Step 2: Click on the <Tools> tab on the menu bar and select <Internet Options>.
Step 3: Click on the <Security> tab, and select <Internet> zone.
Step 4: Down the page, click on the <Default Level> button and click on <OK> to conrm the set-
ting. Close the browser window, and restart a new one later to access the IP Camera.
ActiveX Controls and Plug-ins Settings
Step 1: Repeat Steps 1~3 of the previous section above.
Step 2: Down the page, click on the <Custom Level> button to change ActiveX controls
and plug-ins settings. The Security Settings window will pop up.
Step 3: Under <ActiveX controls and plug-ins>, set ALL items (as listed below) to <Enable> or
<Prompt>. Please note that the items vary by IE version.
ActiveX controls and plug-ins settings:
1. Allow previously unused ActiveX controls to run without prompt.
2. Allow Scriptlets.
3. Automatic prompting for ActiveX controls.
4. Binary and script behaviors.
5. Display video and animation on a webpage that does not use external media player.
6. Download signed ActiveX controls.
7. Download unsigned ActiveX controls.
8. Initialize and script ActiveX controls not marked as safe for scripting.
9. Run ActiveX controls and plug-ins.
10. Script ActiveX controls marked safe for scripting.
Step 4: Click on <OK> to accept the settings and close the Security Settings window.
Step 5: Click on <OK> to close the Internet Options screen.
Step 6: Close the browser window, and restart a new one later to access the IP Camera.
