CERTIFIED 060-3732-6 User manual

IMPORTANT:
Please read this manual carefully before operating this snowblower
and save it for reference.
INSTRUCTION
MANUAL
22" (56 CM) 2-STAGE SNOWBLOWER
model number 060-3732-6 | Contact us: 1-844-428-7277
WARNING
MACHINE IS WITHOUT ENGINE OIL, PROPERLY FILL ENGINE OIL
PRIOR TO USE TO PREVENT ENGINE DAMAGE.

CONTACT INFORMATION
model no. 060-3732-6 | contact us 1-844-428-7277
2
For problems or questions, DO NOT RETURN TO STORE. Please
contact one of our Customer Service Agents who would be happy
to assist you.
Read and understand this instruction manual thoroughly before using
the product. It contains important information for your safety as well as
operating and maintenance advice.
Keep this instruction manual for future use. Should this product be passed on
to a third party, this instruction manual must be included.
For Customer Assistance Please Call:
1.844.428.7277

3
TABLE OF CONTENTS
SAVE THESE INSTRUCTIONS
This manual contains important safety and operating instructions. Read all instructions and
follow them with use of this product.
Contact Information....................................................................2
Table of Contents ........................................................................3
Safety Information ......................................................................4
General Safety .........................................................................................4
Preparation For Use .................................................................................4
Safe Handling of Gasoline .......................................................................4
Operation .................................................................................................5
Clearing a Clogged Discharge Chute .......................................................6
Maintenance and Storage .......................................................................6
Safety Definitions ................................................................................... 7
Safety Symbols........................................................................................ 7
Operation Symbols ..................................................................................8
Features..................................................................................... 10
Know Your Snowblower ..........................................................................10
Engine....................................................................................................10
Assembly.....................................................................................12
Unpacking ...............................................................................................12
Additional Parts......................................................................................12
Tools Required.........................................................................................12
Assembly Parts.......................................................................................12
Assembly.................................................................................................15
Wheels and Shoes.................................................................................15
Handle ...................................................................................................15
Speed Control Connecting Lever..........................................................16
Self-Drive Control Wire And Auger Control Wire ..................................16
Snow Discharge Support ...................................................................... 17
Snow Discharge Chute.......................................................................... 17
Discharge Chute Rotation Lever ..........................................................18
Operation ................................................................................... 19
Before Operation.....................................................................................19
Check the General Condition................................................................19
Check the Engine..................................................................................19
Operation ................................................................................................19
Starting the Engine ..............................................................................19
Stopping the Engine .............................................................................21
Operation at High Altitude...................................................................21
Operating the Machine...........................................................................21
Control Levers.......................................................................................21
Drive System........................................................................................22
Adjusting the Snow Discharge Direction and Height..........................22
Adjusting the Snow Shoes..................................................................... 23
To Adjust the Shoes ............................................................................. 23
After Use..............................................................................................24
Maintenance..............................................................................24
Servicing ................................................................................................24
Safety Precautions..............................................................................24
Maintenance..........................................................................................25
Regular Service Periods.......................................................................25
Refueling..............................................................................................26
Adding Fuel ..........................................................................................26
Check Engine Oil Level.........................................................................26
Oil Change ............................................................................................ 27
Replacing Shear Pins ...........................................................................28
Adjusting Self-Drive Control Handle Cable.........................................29
Adjusting Auger Control Cable.............................................................29
Replace Auger Drive Belt Without Splitting the
Snowblower Body (Option 1)................................................................30
Replace Auger Drive Belt – Splitting the
Snowblower Body (Option 2)...............................................................34
Repair or Replace Friction Disc ........................................................... 36
Lubrication...........................................................................................38
Long-Term Storage...............................................................................38
Transporting.........................................................................................38
Specifications ...........................................................................39
Specifications .......................................................................................39
Snowblower Specifications.................................................................39
Engine Specifications..........................................................................39
Oil Specifications ................................................................................39
Fuel Specifications..............................................................................39
Parts List Diagram .................................................................................40
Parts List.................................................................................................41
Engine Parts List Diagram......................................................................46
Parts List................................................................................................ 47
Troubleshooting .........................................................................50
Troubleshooting .....................................................................................50
Warranty Information.................................................................51
2-Year Limited Warranty........................................................................51
Additional Limitations.........................................................................52
Notice To Consumer.............................................................................52

SAFETY INFORMATION
model no. 060-3732-6 | contact us 1-844-428-7277
4
GENERAL SAFETY
1. Read the operating and service instruction
manual carefully. Be thoroughly familiar
with the controls and the proper use of the
equipment. Know how to stop the unit and
disengage the controls quickly.
2. Never allow children under 16 years old to
operate the equipment. Never allow adults
to operate the equipment without proper
instruction.
3. Thrown objects can cause serious injury.
Keep the area of operation clear of all
persons, particularly small children,
and pets. Plan your snow discharge pattern
to prevent throwing material toward cars,
structures, roads and people.
4. Exercise caution to avoid slipping or falling,
especially when operating in reverse.
5. Keep in mind that the operator or user
is responsible for accidents or hazards
occurring to other people or their property.
6. Never use the snowblower under the
influence of alcohol or medication, or if you
are tired or ill.
PREPARATION FOR USE
1. Thoroughly inspect the area where the
equipment is to be used and remove all
doormats, sleds, boards, wires, and other
foreign objects.
2. Disengage all clutch handles before starting
the motor.
3. Do not operate the equipment without
wearing adequate winter garments. Wear
footwear which will improve footing on
slippery surfaces.
4. Adjust the auger housing height to clear
gravel or crushed rock surface.
5. Never attempt to make any adjustments
while the engine is running (except where
specifically recommended in the manual).
6. Let engine and machine adjust to outdoor
temperatures before starting to clear snow.
7. The operation of any powered machine
can result in foreign objects being thrown
into the eyes. Always wear safety glasses
or eye shields during operation, or while
performing an adjustment or repair.
8. Inspect the auger and impeller before
starting to ensure that there is no ice build
up.
SAFE HANDLING OF GASOLINE
To avoid severe injury or property damage use
high levels of care while handling gasoline.
Gasoline is an extremely flammable substance
and the vapours are explosive. Serious personal
injury can occur when gasoline is spilled on
yourself or your clothes, which can ignite. If you
come into contact with gasoline, wash affected
areas of skin and change clothing immediately.
1. Use only an approved gasoline container.
2. Extinguish all cigarettes, cigars, pipes and
other sources of ignition prior to working
with or near gasoline.
3. Never refuel machine within closed spaces.
4. Never remove gas cap or add fuel while the
engine is hot or running.
5. Allow engine to cool at least two minutes
before refueling.
6. Do not over fill fuel tank. Keep fuel level at
least ½ in. (1.27 cm) below bottom of filler
neck to provide space for fuel expansion.
7. Replace gasoline cap and tighten securely.

5
SAFETY INFORMATION
8. If gasoline is spilled, wipe it off the engine
and equipment. Move machine to another
area. Wait 5 minutes before starting the
engine.
9. Never store the machine or fuel container
inside where there is an open flame, spark
or pilot light (e.g. furnace, water heater,
space heater, clothes dryer etc.).
10. Allow machine to cool at least 5 minutes
before storing.
11. Never fill containers inside a vehicle or on
a truck or trailer bed with a plastic liner.
Always place containers on the ground
away from your vehicle before filling.
12. If possible, remove gas-powered equipment
from the truck or trailer and refuel it on the
ground. If this is not possible, then refuel
such equipment on a trailer with a portable
container, rather than from a gasoline
dispenser nozzle.
13. Keep the nozzle in contact with the rim of
the fuel tank or container opening at all
times until fueling is complete. Do not use
gas cans with nozzle lock-open devices.
OPERATION
1. Do not put hands or feet near or under
rotating parts. Keep clear of the discharge
opening at all times.
2. Exercise extreme caution when operating
on or crossing gravel drives, walks, or roads.
Stay alert for hidden hazards or traffic.
3. After striking a foreign object, stop the
engine, remove the spark plug, thoroughly
inspect the snowblower for any damage,
and repair the damage before restarting
and operating the snowblower.
4. If the unit should start to vibrate
abnormally, stop the engine and check
immediately for the cause. Vibration is
generally a warning of trouble. Vibration
typically indicates a mechanical problem
has occurred.
5. Stop the engine whenever you leave the
operating position, before unclogging the
auger housing or discharge guide, and when
making any repairs, adjustments,
or inspections.
6. Before cleaning, inspecting or repairing any
parts of the snowblower ensure the auger
has stopped moving. Disconnect the spark
plug wire and keep it away from the plug to
prevent accidental starting.
7. Before leaving the machine unattended,
disengage all control levers, stop the engine
and remove the safety key.
8. Do not run the engine indoors. Exhaust
fumes are dangerous.
9. Do not clear snow across the face of slopes.
Exercise extreme caution when changing
direction on slopes. Do not attempt to clear
steep slopes.
10. Never operate the snowblower without
proper guards, plates or other safety
protective devices in place.
11. Never operate the snowblower near glass
enclosures, automobiles, window wells,
etc., without proper adjustment of the
snow discharge angle. Keep children and
pets away.
12. Do not overload the machine capacity by
attempting to clear snow at too fast a rate.
13. Never operate the machine at high
transport speeds on slippery surfaces.
Use care when reversing.

SAFETY INFORMATION
model no. 060-3732-6 | contact us 1-844-428-7277
6
14. Never direct discharge at bystanders or
allow anyone in front of the unit.
15. Disengage power to the impeller when
snowblower is transported or not in use.
16. Use only attachments and accessories
approved by the manufacturer of
snowblower.
17. Never operate the snowblower without
good visibility or light. Always be sure of
your footing, and keep a firm hold on the
handles. Walk; never run.
18. Take all possible precautions when leaving
the machine unattended. Disconnect the
power take-off and stop the engine.
19. Keep all nuts, bolts and screws tight to
be sure the equipment is in safe working
condition;
20. Replace worn or damaged parts for safety;
Use only genuine replacement parts and
accessories.
21. This snowblower is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision or
instruction concerning use of the appliance
by a person responsible for their safety.
22. Be careful while working on the machine or
clearing a blockage in the auger or impeller
to ensure that fingers and hands do not
become crushed or cut.
23. Do not touch hot engine components like
the muffler, muffler guard or engine block
during operation of the snowblower as they
will cause burns.
24. Should the unit stop discharging snow
for any reason, release the controls to
stop and inspect for any lodged items or
damaged parts in the auger housing.
CLEARING A CLOGGED DISCHARGE CHUTE
Hand contact with the rotating impeller inside
the discharge chute is the most common cause
of injury associated with snowblowers. Never
use your hand to clean out the discharge chute
or auger assembly.
To clear the chute:
1. SHUT THE ENGINE OFF!
2. Wait 10 seconds to be sure the impeller
blades have stopped rotating.
3. Always use a clean-out tool. DO NOT use
your hands.
MAINTENANCE AND STORAGE
1. Check shear bolts, engine mounted bolts,
etc., at frequent intervals for proper
tightness to sure the equipment is in safe,
working condition.
2. Never store the machine with fuel in the
fuel tank inside a building where ignition
sources are present such as hot water
heaters, space heaters, clothes dryers or
any open flame sources. Allow the engine to
cool before storing in any enclosure.
3. Always refer to owner’s guide instructions
for important details if the snowblower is
to be stored for an extended period.
4. Maintain or replace safety and instructions
labels, as necessary.
5. Run the snowblower for one minute to clear
out packed snow and ice to prevent freeze-
up during storage.

7
SAFETY INFORMATION
SAFETY DEFINITIONS
FDANGER
DANGER indicates a hazardous situation
which, if not avoided, will result in death or
serious injury.
FWARNING
WARNING indicates a hazardous situation
which, if not avoided, could result in death or
serious injury.
FCAUTION
CAUTION indicates a hazardous situation
which, if not avoided, could result in minor or
moderate injury.
NOTICE
NOTICE is used to address practices not
related to physical injury.
SAFETY SYMBOLS
Some of the following symbols may be used on
this product. Please study them and learn their
meaning. Proper interpretation of these symbols
will allow you to safely operate the product.
Symbol Name Designation/Explanation
Read the
Instruction
Manual
To reduce the risk of
injury, user must read and
understand the instruction
manual before using this
product.
Eye and Ear
Protection
Always wear safety goggles
or safety glasses with side
shields, and as necessary
a full face-shield as well as
full ear protection when
operating this product.
Always wear eye protection
with side shields marked to
comply with ANSI Z87.1.
Symbol Name Designation/Explanation
Safety Alert
This machine was built
to be operated according
to the safe operation
practices in this manual.
As with any type of power
equipment, carelessness
or error on the part of
the operator can result in
serious injury. This machine
is capable of amputating
fingers, hands, toes and
feet and throwing foreign
objects. Failure to observe
the safety instructions
could result in serious
injury or death.
Electric
Shock
Failure to use the starter
in dry conditions and to
observe safe practices can
result in electric shock.
Risk of Fire
Fuel and its vapours are
extremely flammable and
explosive. Fire can cause
severe burns or death.
Do not add fuel while the
product is operating or
still hot.
Toxic Fumes
The engine exhaust from
this product contains
chemicals known to cause
cancer, birth defects and
other reproductive harm.
Risk of
Asphyxiation
This engine emits carbon
monoxide, an odourless,
colourless poison gas.
Breathing carbon monoxide
can cause nausea, fainting
or death. Use only in a well-
ventilated area.
Thrown
Objects
This machine may pick up
and throw objects which
can cause serious personal
injury.
Always Use
Chute Tool
Never use your hands
to clear a clogged chute
assembly. Shut OFF engine
and remain behind handles
until all moving parts have
stopped before unclogging.

SAFETY INFORMATION
model no. 060-3732-6 | contact us 1-844-428-7277
8
Symbol Name Designation/Explanation
Hot Surface
Exhaust gases, muffler and
engine components are
extremely HOT and cause
burns.
Risk of Fire
Fuel and its vapours are
extremely flammable and
explosive. Fire can cause
severe burns or death.
Do not add fuel while the
product is operating or
still hot.
Rotating
Auger
DANGER: Avoid injury from
rotating auger - keep feet
away.
Rotating
Blades
Never put your hand
in the chute. Contact
with rotating parts can
amputate fingers and
hands.
OPERATION SYMBOLS
Some of the following symbols may be used on
this product. Please study them and learn their
meaning. Proper interpretation of these symbols
will allow you to safely operate the product.
Symbol Name Designation/Explanation
Engine Start Follow steps to start
engine.
0W-30 Check Oil
Level
Recommended oil is
0W-30. The engine can be
seriously damaged without
oil. Always check the oil
level before using. The
machine must be resting
firmly on level ground when
checking.
Check Fuel
Level
Use clean, fresh, regular
unleaded gasoline with a
minimum octane rating of
85 and an ethanol content
of less than 10% by
volume.
Minimum
Octane
Use clean, fresh, regular
unleaded gasoline with a
minimum octane rating of
85 and an ethanol content
of less than 10% by
volume.
Fuel Valve:
ON
Move the fuel valve lever to
the on position.
Choke: ON
To start a cold engine,
move the choke lever to
the choke position.
Throttle: Full
Speed
Move the throttle lever
to full speed to start the
engine.
Throttle: Low
Speed
Lowers the speed of the
engine.

9
SAFETY INFORMATION
Symbol Name Designation/Explanation
Insert Engine
Key
Make sure the engine
safety key is inserted into
the key hole.
3-5x
Cold Prime To start a cold engine,
prime 3-5 times.
Warm Prime To start a warm engine,
DO NOT prime.
Recoil Start Pull the recoil starter grip
to start manually.
Choke: OFF
When the engine starts,
move the choke to run
position.
Stop Follow steps to stop.
Fuel Valve:
OFF
Move the fuel valve lever to
the OFF position.
Remove
Engine Key Remove the engine key.

FEATURES
model no. 060-3732-6 | contact us 1-844-428-7277
10
KNOW YOUR SNOWBLOWER
• Self-Drive Control Handle
• Upper Handles
• Speed Control Connecting Lever
• Handle Locking Knobs
• Lower Handle
• Wheels
• Auger Housing
• Adjustable Skid Shoes
• Auger
• Impeller
• Clean Out Tool
• Discharge Chute
• Discharge Deflector
• Discharge Chute Rotation Lever
• Discharge Chute Lever Guide
• Auger Control Handle
• Speed Adjusting Handle
• Shear Pin and Clip Storage
ENGINE
• Key (safety lock out)
• Primer Bulb
• Throttle Lever
• Choke Lever
• Fuel Valve (On/Off)
• Oil Drain Plug
• Recoil Starter Grip
• Electric Start Button
• Fuel Cap
• Oil Fill and Level Check Cap
11
22
33
44
55
66
77
88
99
10 10
11
12
13
14
15
16
17
18
