CERTIFIED 0600581 User manual

Electric 12" (30.5 cm) Snow Shovel
model no. 060-0581-2 I contact us: 1-844-428-7277
IMPORTANT:
This manual contains important safety and operating instructions. Read all
instructions and follow them with use of this product.
IMPORTANT :
Ce manuel contient des consignes de sécurité et d’utilisation importantes.
Lisez et respectez toutes les instructions lorsque vous utilisez ce produit.
English version... Page 3
French version... Page 23
INSTRUCTION
MANUAL
GUIDE
D’UTILISATION
Pelle à neige électrique de 12 po (30,5 cm)

DD
For problems or ques�ons, DO NOT RETURN TO STORE.
Please contact one of our Customer Service Agents who
would be happy to assist you.
For Customer Assistance Please Call:
CANADA: 1-844-428-7277
STOP

3
model no. 060-0581-2 I contact us: 1-844-428-7277
SAVE THESE INSTRUCTIONS
This manual contains important safety and operating instructions. Read all instructions
and follow them with use of this product.
TABLE OF CONTENTS
Technical Specifications 4
Parts List 5
Intended Use 6
Safety Information 7
Assembly 13
Operation 14
Maintenance 17
Warranty 22
TABLE OF CONTENTS

4
TECHNICAL SPECIFICATIONS
TECHNICAL SPECIFICATIONS
Rated voltage
Power
No load speed
Paddle size
Clearing width
Clearing depth
Throw Distance (Max)
Plowing capacity (Max)
LED light
Weight
120 V 60 Hz
10 A
Up to 2500 RPM
6 in (15.24 cm)
12 in (30.5 cm)
6 in (15.24 cm)
Up to 20 ft (6 m)
300 lbs (136 kg)/min
1 W
13 LB 2 OZ (6 KG)

5
model no. 060-0581-2 I contact us: 1-844-428-7277
PARTS LIST
KNOW YOUR SNOW SHOVEL
No. Part
1 Safety lock button
2 Trigger switch
3 Upper handle
4 Extension cord hook
5 Adjustable handle
6 Handle knob
7 Joint-fixing knob and bolt
No. Part
8 Appliance cord
9 Upper tube
10 Lower tube
11 Motor housing
12 1 W LED light
13 2-blade paddle
14 Scraper blade
13
4
2
5
6
7
8
9
10
11
12
13
14

6
INTENDED USE
This electric snow shovel is intended for outdoor, residential use only. Do not use this product
indoors or for commercial or industrial purposes.
INTENDED USE

7
model no. 060-0581-2 I contact us: 1-844-428-7277
SAFETY INFORMATION
..... DANGER! Cutting/
dismemberment hazard -
Keep hands away from the
rotating paddle. Do not
use hands to unclog rotor
housing. Stop motor before
removing debris.
..... Keep the flexible power
supply cord away from the
rotating paddle.
..... Wear safety gloves during
use to protect hands.
..... Wear safety footwear at all
times to provide protection
against objects that may
accidentally fall on feet.
..... Keep bystanders and
children a safe distance (at
least 11 yd/10 m) away from
the work area.
..... CAUTION! Beware of stones
and other foreign objects
that could be thrown from
the product.
..... Always keep the power cable
away from heat sources, oils
or sharp edges. Immediately
remove plug from the mains
if the cable is damaged,
frayed or entangled.
SAFETY INFORMATION
IMPORTANT
Please read these instructions fully before
assembling and operating.
Description of Symbols
Symbols are used in this manual to advice
you of possible risks. The safety symbols and
the explanations which accompany them
must be perfectly understood. The warnings
themselves do not prevent the risks and cannot
be a substitute for proper methods of avoiding
accidents.
Warning Symbols on the product
..... READ THE OPERATOR'S
MANUAL(S) – Read, understand
and follow all instructions
in the user manual(s) before
attempting to assemble and
operate.
..... SAFETY ALERT – Indicates a
precaution, a warning or a
danger.
..... WARNING! Electrical shock
hazard.
..... WARNING! Do not expose the
unit to rain or wet conditions.
Keep dry.
..... DANGER! Cutting/
dismemberment hazard - Keep
feet away from the rotating
paddle.

8
SAFETY INFORMATION
..... Wear hearing and eye
protection.
..... WARNING! Turn the machine
OFF and disconnect it from
the power supply before
inspecting, cleaning,
changing accessories or
conducting any other
maintenance task.
..... Double Insulation.
..... The rotating part will
continuously run for several
seconds after you turn off
the machine.

9
model no. 060-0581-2 I contact us: 1-844-428-7277
SAFETY INFORMATION
General Safety WARNINGS!
You and any other operator of this snow
shovel must read, understand and follow these
instructions in their entirety, and should re-
read them at the start of each snow season.
Failure to follow these instructions may
result in ELECTRIC SHOCK, FIRE and/or serious
PERSONAL INJURY.
Pay attention the the personal safety alert
symbols used in this manual to inform you of
the WARNING associated with the particular
operating instruction. This means that the
operations requires special, ATTENTION,
CAUTION and AWARENESS.
1. Replacement parts – When servicing
this unit, use only identical replacement
parts. Replace or repair damaged cords
immediately. Do not use on gravel surfaces
unless the snow shovel is adjusted for such
surfaces in accordance with the operator’s
manual.
2. Keep children, bystanders and pets away
– All spectators, including pets, should be
kept a safe distance away from the work
area.
3. Dress properly – Do not wear loose articles
of clothing or jewellery. They can become
caught in moving parts. Wear rubber or
winter boots. The electric snow shovel
should not be operated in the hand-held
position except when the instructions
provided in this manual deem such use
permissible.
4. Extension cords – To prevent
disconnection of the snow showel cord
from the extension cord during operation,
secure the extension cord to the product
as shown on page 15 in Figs. 5 & 6.
WARNING! To prevent electric shock,
use only with an extension cord
suitable for outdoor use.
5. Avoid accidental starting –Do not carry
the electric snow shovel with your finger
on the switch. Make sure the switch is off
before plugging in the unit. If the cord is
damaged in any manner during operation,
pull the extension cord from the wall
receptacle.
6. Do not abuse the cord – Never carry
the electric snow shovel by the cord or
yank the cord to disconnect it from the
receptacle. Keep the cord away from heat,
oil and sharp edges.
7. Moving parts – Keep hands and feet away
from moving parts. Keep guards in place
and in proper working order.
8. Do not force the tool – It will perform
better with less likelihood of personal
injury or mechanical damage if it is used at
the rate for which it was designed.
9. Do not overreach – Keep proper footing
and balance at all times. If the electric
snow shovel strikes a foreign object, follow
these steps:
• Stop the electric snow shovel.
• Inspect for damage.
• Repair any damage before restarting
and operating the snow shovel.
10. Disconnect the tool – Disconnect the
electric snow shovel from the power supply
when it is not in use, before servicing
it, when changing accessories and when
performing any other maintenance task.
11. Store idle tool indoors – When not in use,
the electric snow shovel should be stored
indoors in a dry, locked place out of the
reach of children.
12. Maintain the electric snow shovel with
care – Follow the applicable maintenance
instructions for replacing parts and
changing accessories. Lubrication is not
required.

10
SAFETY INFORMATION
This electric snow shovel meets or exceeds
the B71.3 specifications of the American
National Standards Institute in effect at the
time of production.
Read and understand the contents of this
manual before you start the motor.
This is the safety alert symbol. It
is used to alert you to potential
personal injury hazards. Obey all
safety messages that follow this
symbol to avoid possible injury or
death.
Improperly using or maintaining this electric
snow shovel could result in injury or death.
To reduce this potential, comply with the
following safety instructions.
This electric snow shovel can amputate
hands and feet if used incorrectly. It can also
pick up foreign objects, which can become
dangerous projectiles when thrown into the
air. Failure to observe the following safety
instructions could result in serious personal
injury.
Training
Read, understand and follow all instructions
on the machine and in the manual before
operating this unit. Thoroughly familiarize
yourself with the controls and the proper use of
the equipment. Know how to stop the unit and
disengage the controls quickly.
Children should never be allowed access to
the equipment. Adults should never operate
the equipment without carefully reading and
understanding these instructions.
Keep the area of operation clear of all persons,
particularly small children and pets.
Exercise caution to avoid slipping or falling.
Preparation
Thoroughly inspect the area where the
equipment is to be used and remove all
doormats, sleds, boards, wires and other foreign
objects.
Do not operate the equipment without wearing
adequate winter garments. Avoid loose fitting
articles of clothing and accessories that can
become caught in moving parts. Wear footwear
that will improve footing on slippery surfaces.
Do not attempt to clear snow from a gravel or
crushed rock surface. This product is intended
for use only on paved surfaces.
Never attempt to make any adjustments while
the motor is running (except when specifically
recommended by the manufacturer).
Always wear safety glasses or eye shields
during operation or while performing an
adjustment or repair to protect your eyes from
foreign objects that may be thrown from the
machine.
OPERATION
1. Do not put hands or feet near or under
rotating parts. Keep clear of the discharge
opening at all times.
2. Exercise extreme caution when operating
on or crossing gravel drives, walks or roads.
Stay alert for hidden hazards or traffic.
3. After striking a foreign object, stop the
motor. Thoroughly inspect the electric
snow shovel for any damage, and repair the
damage before restarting and operating the
electric snow shovel.
4. If the unit should start to vibrate
abnormally, stop the motor and check the
unit immediately to ascertain the cause.
Vibration is generally a sign of trouble.
5. Stop the motor and disconnect the
electric snow shovel from the power
supply whenever you leave the operating
position, when transporting the unit,

11
model no. 060-0581-2 I contact us: 1-844-428-7277
SAFETY INFORMATION
before unclogging the rotor blade housing
and when making any repairs, adjustments
or inspections to the unit.
6. When cleaning, repairing or inspecting
the electric snow shovel, make sure that
all moving parts have come to a complete
stop before beginning work.
7. Exercise extreme caution when operating
on slopes.
8. Never operate the electric snow shovel
without proper guards and other safety
devices in place and in proper working
order.
9. Never direct the discharge toward people
or areas where property damage can occur.
Keep children, pets and other bystanders
away from the work area.
10. Do not overload the machine capacity by
attempting to clear snow at too fast a rate.
11. Look behind and use care when backing up
with the electric snow shovel.
12. Make sure the 2 W LED light is operational
when using the electric snow shovel at
night or under conditions of poor visibility.
Always check your footing during operation
and keep a firm hold on the handles. Walk,
never run, with the unit.
CLEARING A CLOGGED DISCHARGE CHUTE
Hand contact with the rotating paddle inside
the rotor housing is the most common cause of
injury associated with electric snow shovels.
Never use your hands to clear a clogged rotor
housing.
To clear the rotor housing:
• Shut the motor off and disconnect the
unit from the power supply.
• Wait 10 seconds to be sure the rotating
paddle have come to a complete stop.
• Always use a clean-out tool, not your
hands, to free the rotating paddle.
MAINTENANCE AND STORAGE
• Check all fasteners at frequent intervals
for proper tightness to ensure that the
equipment is in safe working condition.
• Always refer to the operator's manual for
important details, such as how to properly
store your electric snow shovel for an
extended period of time.
• Maintain or replace safety and instruction
labels as needed.
• Run the machine a few minutes after
throwing snow to prevent the paddle from
freezing.
DOUBLE-INSULATED: GROUNDING
NOT REQUIRED. WHEN SERVICING,
USE ONLY IDENTICAL REPLACEMENT
PARTS.
• This electric snow shovel is double-
insulated, eliminating the need for a
separate grounding system. Use only
identical replacement parts. Read the
instructions before servicing double-
insulated products. Use this snow shovel
only as described in this manual.
• Electrical Safety
• Ground fault circuit interrupter (GFCI)
protection should be provided on the
circuit(s) or outlet(s) to be used for this
electric snow shovel. Receptacles are
available having built-in GFCI protection
and may be used for this measure of
safety.
• To prevent electric shock, use only with an
extension cord suitable for outdoor use.
Before use, check that the extension cord is in
good condition. When using an extension cord,
make sure to use one heavy enough to carry
the current your product will draw. For lengths
less than 50 ft (15 m), a No.16 AWG (or greater)
extension cord should be used. An undersized

12
SAFETY INFORMATION
cord will cause a drop in line voltage resulting in
loss of power and overheating.
Electric shock may cause SEVERE INJURY or
DEATH. Heed these warnings:
• Do not allow any part of the electric snow
shovel to make contact with water while it
is in operation. If the product becomes wet
while turned off, wipe dry before starting.
• Use only a UL-, CSA- or ETL-rated extension
cord for outdoor, all-weather use.
• Do not use an extension cord over 100 ft
(30 m).
• Do not touch the product or its plug with
wet hands or while standing in water.
Wearing rubber or winter boots offers some
protection.
EXTENSION CORD CHART
Extension Cord
Length
Up to 50 ft
(15 m)
50–100 ft
(15–30 m)
Wire Gauge
(AWG): 16 14
• To reduce the risk of electric shock, this
product has a polarized plug (i.e. one blade
is wider than the other). Use this appliance
only with a polarized UL-, CSA-, or ETL-
listed extension cord recommended for
outdoor, all-weather use. The plug will fit
into a polarized extension cord only one
way. If the plug does not fit fully into the
extension cord, reverse the plug. If the plug
still does not fit, obtain a correct polarized
extension cord. A polarized extension cord
will require the use of a polarized wall
outlet. The extension cord plug will fit into
the polarized wall outlet only one way. If
the plug does not fit fully into the wall
outlet, reverse the plug. If the plug still
does not fit, contact a qualified electrician
to install the proper wall outlet. Do not
modify the plug, extension cord receptacle,
or extension cord plug in any way.
To prevent the Snow shovel cord from
disconnecting from the extension cord
during operation, make a knot with the two
cords as shown below.
Method of Securing Extension Cord
Do not modify the cord. Never pull the snow
shovel by the cord or yank the cord to
disconnect it from the receptacle. Keep the
cord away from heat, oil, and sharp edges.
Snow shovel
Extension cord
(A) Tie cord as shown
(B) Connect plug and receptacle

13
model no. 060-0581-2 I contact us: 1-844-428-7277
ASSEMBLY
CAUTION! Read complete INSTRUCTION MANUAL before operating this machine.
Unpacking
Carton contents
• Electric snow shovel X1
• Joint-fixing knob and bolt X1
• Adjustable handle and knob X1
• Manual X1
1. Carefully remove the electric snow shovel and check to see that all of the above items are
supplied.
2. Inspect the product carefully to make sure no breakage or damage occurred during shipping.
NOTE: Do not discard the shipping carton and packaging material until you are ready to use your new
electric snow shovel. The packaging is made of recyclable materials.
Properly dispose of these materials in accordance with local regulations.
IMPORTANT! The equipment and packaging material are not toys. Do not let children play with plastic
bags, foils or small parts. These items can be swallowed and pose a suffocation risk!
Assembly
Connecting the Upper and Lower Tubes
1. Fit the upper and lower tubes together and
tighten the joint-fixing knob (Fig. 1).
2. Assemble the adjustable handle and tight the
handle knob (fig 2 ).
NOTE: the tip on the lower clip shall be
inserted to the solt on the upper tube.
ASSEMBLY
Fig. 1
Fig.3Fig.2
Upper tube
Lower tube

14
OPERATION
Operation
Connecting to a Power Source
To reduce the risk of electric shock, this
appliance has a polarized plug (i.e. one blade is
wider than the other; see Fig. 4).
Use this appliance only with a polarized UL-,
CSA- or ETL- listed extension cord recommended
for outdoor, all-weather use.
The appliance plug will fit into a polarized extension cord only one way. If the appliance plug does
not fit fully into the extension cord, reverse the plug. If the plug still does not
fit, obtain a correct polarized extension cord. A polarized extension cord will require the use of a
polarized wall outlet. The extension cord plug will fit into the polarized wall outlet only one way. If
the plug does not fit fully into the wall outlet, reverse the plug. If the plug still does not fit, contact
a qualified electrician to install the proper wall outlet. Do not modify the appliance plug, extension
cord receptacle or extension cord plug in any way.
IMPORTANT: Check the extension cord frequently during use for holes or cracks in the
insulation. Do not use a damaged cord. Do not run the cord through standing water or wet
grass.
Use only an extension cord recommended for outdoor use.
Securing the Extension Cord
1. Make a loop with the extension cord (Fig. 5).
Fig.4
Fig.5
Fig. 4
Polarized plug

15
model no. 060-0581-2 I contact us: 1-844-428-7277
OPERATION
2. Insert the loop through the opening in the
back of the upper handle and secure the
loop onto the extension cord hook (Fig. 6).
3. Connect the extension cord to the snow shovel cord.
NOTE: Securing the extension cord in this way helps to prevent you from accidentally disconnecting
the extension cord from the snow shovel during operation.
4. Plug the extension cord into a wall outlet.
5. Keep the area to be cleared free of stones, toys or other foreign objects that the rrotating
paddles might pick up and throw. Such items could be covered by snow and are easy to
overlook, so be sure to conduct a thorough inspection of the area before operating the snow
shovel.
Starting and Stopping
1. To start the electric snow shovel, push
and hold the safety lock button on the top
of the handle grip with your thumb and
then squeeze the trigger switch with your
fingers. Once the machine powers on, you
can release the safety lock button and
proceed with operation (Fig. 7).
2. To stop the electric snow shovel, release the
trigger switch (Fig. 7).
Operating Tips
• Start the electric snow shovel and tilt it forward until the scraper blade at the base of the unit
contacts the ground. Push the shovel forward at a comfortable rate, yet slow enough to clear
the path completely. The clearing width of the snow shovel and the depth of snowfall should
dictate your forward speed.
• Direct the snow discharge to the right or to the left by holding the electric snow shovel at a
slight angle.
Fig.6
Fig.7
Upper handle
Extension cord hook
Extension cord
Snow shovel cord
Safety lock button
Trigger switch

16
OPERATION
• To remove snow most efficiently, throw the snow downwind and slightly overlap each swath.
• If you need to clear snow from a crushed rock or gravel surface, push down on the handle to
clear the scraper of any loose material that the rotating paddles could throw.
• This electric snow shovel cuts a path 12 in. (30.5 cm) wide and up to 6 in. (15.24 cm) deep in one
pass.
• When clearing deeper drifts, hold the electric snow shovel by the upper and lower handles and
use a swinging or sweeping motion. Remove up to 6 in. (15.24 cm) of snow with each pass and
repeat as many times as needed.
• Keep the cord clear of obstructions, sharp objects and the rotating paddles. Do not pull sharply
on the cord or abuse it in any manner. Frequently inspect the cord for signs of damage. If
damage is found, replace the cord immediately.
• This electric snow shovel is equipped with
a 1 W LED light to faciliate clearing at night
and under conditions of poor visibility
(Fig. 8). When you start the machine, the
LED light will automatically power on and
illuminate the path in front of you. When
you stop the machine, the LED light will
automatically power off.
• Disconnect the extension cord after using the electric snow shovel. Hang the extension cord
with the shovel so it will not be misplaced or damaged.
Fig.8
LED light

17
model no. 060-0581-2 I contact us: 1-844-428-7277
WARNING! Disconnect the extension cord before performing any maintenance task.
If the extension cord is plugged into the snow shovel, someone could accidentally turn on the unit
while you are performing maintenance on it, which could result in serious personal injury.
Replacing the Paddle
WARNING! Disconnect the power supply to the electric snow shovel before beginning work.
1. Use a wrench to remove the bolt and the
washer on the right side of the housing
(Fig. 9).
2. Using a cross-head screwdriver,
disassemble the left side cover by
removing the seven (7) screws (Fig. 10).
3. Remove the tensioner. Unscrew the three
(3) screws securing the big pulley plate,
then remove the plate and pulley assembly
(Fig. 11).
MAINTENANCE
Fig.9
Fig.10
Fig.11
Wrench
Bolt
Tensioner
Big pulley plate

18
4. Remove the old paddle from the housing
(Fig. 12).
5. To install the new paddle, place the washer
(A) back onto the bolt (removed in step
1) and insert the bolt so that it protrudes
slightly into the housing of the unit. Thread
the nut and then the other washer (B) onto
the bolt. Fit the new paddles onto the end
of bolt and tighten the bolt (Fig. 13).
6. Reinstall the big pulley plate and align it
with the other end of the paddles. After
fitting the paddles into position, secure the
big pulley plate with the three (3) screws
(Fig. 14).
NOTE: The housing will flex to allow for
installation of the new paddle.
Fig. 14
MAINTENANCE
Fig. 12
Fig. 13
Bolt
Nut
Washer (A)
Washer (B)

19
model no. 060-0581-2 I contact us: 1-844-428-7277
7. Place the tensioner back into position.
Rotate the paddles to ensure that the belt
and paddles move freely, then reinstall
the cover by securing it with the seven (7)
screws (Figs. 15 & 16).
WARNING! Do not power the unit until the
cover guard is securely in place to prevent
damage or injury.
Replacing the Belt
WARNING! Disconnect the power from the electric snow shovel before performing these tasks.
1. Disassemble the left side cover by
removing the seven (7) screws (Fig. 10).
2. Remove the tensioner (Fig. 17).
3. Unscrew the three (3) screws from the big
pulley plate and the four (4) screws from
the small pulley plate (Fig.17).
4. Replace the worn belt with a new belt.
5. Screw the big and small pulley plates back
into position, then reinstall the tensioner.
6. Place the left side cover back into position
and refasten the seven (7) screws.
MAINTENANCE
Fig. 15
Fig. 16
Fig. 17
Tensioner
Big pulley plate
Small pulley plate
Big pulley plate
Belt
Tensioner

20
Replacing the Scraper Blade
WARNING! Disconnect the power from the electric snow shovel before performing this task.
1. Position the paddles so that you can gain
access to the three (3) screws that secure
the scraper blade to the base of the unit.
2. Using a long cross-head screwdriver, remove
the three (3) screws and the old scraper
blade (Fig. 18).
3. Install the new scraper blade and fasten it
securely to the snow shovel with the three
(3) screws.
Lubricating the Electric Snow Shovel
This electric snow shovel does NOT need lubrication. All bearings are lubricated at the factory for
the life of the product.
Storage
1. Examine the electric snow shovel thoroughly for worn, loose or damaged parts. Should you need
to repair or replace a part.
2. Examine the extension cord thoroughly for signs of excess wear or damage. If it is worn or
damaged, replace it immediately.
3. Disconnect the extension cord from the electric snow shovel before storing.
4. Store the cord with the electric snow shovel indoors in a clean, dry and locked location out of
the reach of children and animals.
NOTE: Devices for storing extension cords are commercially available, should you wish to purchase
one.
MAINTENANCE
Fig. 18
3 screws
Scraper
blade
Use a long
cross-head
screwdriver
