Certified Yfg6621 User manual

GAS 21" (53 cm) Snowblower

model no. 060-1310-2 I contact us: 1-844-428-7277

IMPORTANT:

This manual contains important safety and operating instructions. Read all

instructions and follow them with use of this product.

IMPORTANT :

Ce manuel contient des consignes de sécurité et d’utilisation importantes.

Lisez et respectez toutes les instructions lorsque vous utilisez ce produit.

English version... Page 2

French version... Page 34

INSTRUCTION

MANUAL

GUIDE

D’UTILISATION

Souffleuse à neige de 21 po (53 cm)

For problems or ques�ons, DO NOT RETURN TO STORE.

Please contact one of our Customer Service Agents who

would be happy to assist you.

For Customer Assistance Please Call:

CANADA: 1-844-428-7277

STOP

model no. 060-1310-2 I contact us: 1-844-428-7277

SAVE THESE INSTRUCTIONS

This manual contains important safety and operating instructions. Read all instructions

and follow them with use of this product.

TABLE OF CONTENTS

Technical Specifications 3

Parts List 4

Intended Use 6

Safety Information 7

Assembly 14

Operation 19

Storing And Maintenance 24

Troubleshooting

Warranty 3 2

TABLE OF CONTENTS

TECHNICAL SPECIFICATIONS

Engine type

Engine displacement

Engine max. power

Engine speed

Max. torque

Clearing width

Clearing depth

Electric start

Wheel diameter

Ignition

Fuel tank

Oil capacity

Spark plug

LED light

Weight

Single cylinder 4-stroke

212 cc

4.1 kW/ 3600 RPM

3600 RPM

8.84 ft. lbs @ 2500 RPM

21” (53 cm)

12‘’ (30.5 cm)

120V AC

7” (18 cm)

TCI

3.6 L

0.55 L

F6RTC/TORCH

3 W

87 lb (39.5 kg)

model no. 060-1310-2 I contact us: 1-844-428-7277

PARTS LIST

KNOW YOUR SNOW BLOWER

No. Part

1 Upper handle

2 Auger Control Lever

3 Recoil Starter handle

4 Rope guide

Fixing knob with arc head bolt

6 Lower handle

7 Rear wheel

No. Part

8 Deck

9 Auger Paddle

10 LED light

11 Discharge Chute

12 Discharge Chute Deflector

Discharge Chute Rotation Handle

14 Auger Control Cable

PARTS LIST

Carefully remove the machine from its packaging and check that the following parts are included:

A. Snowblower (with lower handle) 1 pc

B. Discharge Chute 1 pc

C. Discharge Chute Rotation Handle 1 pc

D. Manual 1 pc

E. Fixing knob with arc head bolt M8 2 pcs

1. Spark Plug

2. Oil fill Cap

3. Oil Drain Plug

4. Choke Lever

5. Primer

6. Ignition Key

7. Fuel tank cap

8. Throttle lever

9. Electric Start button

10. Fuel valve lever

PARTS LIST

F. Upper handle 1 pc

G. Screw for discharge chute 3 pcs

H. Funnel 1 pc

I. Spanner 1 pc

WARNING!

• If any parts are damaged or missing, do not operate this tool until the missing parts are

replaced. Failure to heed this warning could result in serious personal injury.

WARNING!

• This item requires a two person lift to remove from the packaging. Make sure that you have

sufficient space to put this snowblower down. Keep your feet apart so that you have a stable

position, bend at the knees and keep your back straight.

NOTE:

• Always recycle the packaging in accordance with local recycling schemes.

A D

GAS 21" (53 cm) Snowblower

model no. 060-1310-2 I contact us: 1-844-428-7277

IMPORTANT:

This manual contains important safety and operating instructions. Read all

instructions and follow them with use of this product.

IMPORTANT :

Ce manuel contient des consignes de sécurité et d’utilisation importantes.

Lisez et respectez toutes les instructions lorsque vous utilisez ce produit.

English version... Page 2

French version... Page 32

INSTRUCTION

MANUAL

GUIDE

D’UTILISATION

Souffleuse à neige de 21 po (53 cm)

model no. 060-1310-2 I contact us: 1-844-428-7277

INTENDED USE

This gas snowblower has been designed for removing snow around a single household or residence.

The machine is to be used only for its described purpose. Any other use is deemed to be misuse.

The user/operator and not the manufacturer will be liable for any damage or injuries of any kind

caused as a result of this.

Do not use this appliance indoors or for commercial or industrial purposes.

SAFETY INFORMATION

..... WARNING: To reduce the risk

of injury, user must read

instruction manual.

..... SAFETY ALERT - Indicates a

precaution, a warning or a

danger.

..... Only use clean-out tool to

clear blockages. NEVER use

your hands.

..... Keep people away from unit

while operating. Keep children

out of work area and under

watchful care of a responsible

adult.

.....

DANGER! Cutting/dismemberment

hazard. Keep feet away from the

auger or impeller.

..... CAUTION! NEVER direct

discharge towards persons or

property that may be injured

or damaged by thrown objects.

..... Stop engine and read manual

before making any repairs or

adjustments.

..... Make sure the engine safety

key is inserted into the key

hole.

..... Remove the engine key.

..... WARNING! Turn the machine

OFF before inspecting,

cleaning, changing

accessories or conducting any

other maintenance task.

.....

Recommended oil is SAE

5W/30. The engine can be

seriously damaged without

oil. Always check the oil

level before using. The

machine must be resting

firmly on level ground when

checking.

..... Use clean, fresh, regular

unleaded gasoline with a

minimum octane rating of 87

and an ethanol content of

less than 10% by volume.

.....

Exhaust gases, muffler and

engine components are

extremely hot and cause burns.

..... Choke opened, when the

engine starts, move the

choke to "RUN" position.

..... Choke closed, to start a cold

engine, move the choke lever

to the "CHOKE" position.

.....

Fuel and its vapours are

extremely flammable and

explosive. Fire can cause

severe burns or death. Do not

add fuel while the product is

operating or still hot.

..... Move the throttle lever to

full speed.

..... Lower the speed of the

engine.

..... Move the fuel valve lever to

the "ON" position.

..... Keep hands and feet away

from rotating parts.

model no. 060-1310-2 I contact us: 1-844-428-7277

SAFETY INFORMATION

..... To start a cold engine, prime

3-5 times.

..... To engage the auger paddle,

hold the auger control lever

against the handle.

..... To disengage the auger

paddle, release the control

bar.

..... Press the electric-start

button to start the engine.

..... WARNING! Do not expose

the unit to rain or wet

conditions. Keep dry.

..... Make sure the engine safety

key is inserted into the key

hole before start the engine.

Remove the engine key to

stop the engine.

..... To disengage the auger

paddle, release the control

bar.

..... To engage the auger paddle,

hold the auger control lever

against the handle.

..... Always wear safety goggles

or safety glasses with side

shields, and as necessary

a full faceshield as well as

full ear protection when

operating this product.

SAFETY INFORMATION

GENERAL SAFETY

Read these safety rules and follow them closely.

Failure to follow these rules could lead to loss

of control of unit, severe personal injury or

death to you or bystanders, or result in damage

to property or the machine.

PRACTICES & LAWS

Practice usual and customary safe working

precautions. Learn applicable rules and laws in

your area. Always follow the practices set forth

in this manual.

EMISSION CONTROL SYSTEM

This equipment and/or its engine may include

exhaust and evaporative emissions control

system components required to meet U.S.

Environmental Protection Agency (EPA) and/

or California Air Resources Board (CARB)

regulations. Tampering with emission controls

and components by unauthorized personnel

may result in severe fines or penalties.

Emission controls and components can only be

adjusted by a qualified dealer or an authorized

engine manufacturer's service centre. Contact

a qualified dealer concerning emission controls

and component questions.

REQUIRED OPERATOR TRAINING

Read and understand the Operator's Manual

and labels on the unit. This information is

for your safety and the proper use of your

equipment. Failure to follow these instructions

and warnings may cause death or serious

injury. Familiarize yourself and any other

operators with all controls and the safe use of

the features of this unit. If you loan, rent or

sell this product to others, provide them with

all manuals. If you have any questions, please

call the customer support line. Do not use

this equipment if, after reading the Operator's

Manual and the on-board labels, you have any

questions about the safe use of this product.

SAFETY RULES

The following safety instructions are based

on the B71.3 specifications of the American

National Standards Institute in effect at the

time of production.

Training

1. Read, understand and follow all instructions

on the machine and in the manual(s) before

operating this unit. Be thoroughly familiar

with the controls and the proper use of the

equipment. Know how to stop the unit and

disengage the controls quickly.

2. Never allow children to operate the

equipment. Never allow adults to operate

the equipment without proper instruction,

including actual operation.

3. Keep the area of operation clear of all

persons, particularly small children.

Keep children under watchful care of a

responsible adult. Be alert and shut off unit

if children enter area.

4. Exercise caution to avoid slipping or falling,

especially when operating the snowblower

in reverse.

5. Always remove key and/or wire from spark

plug before assembly, maintenance or

service. Unintentional engine start up can

cause death or serious injury.

6. Complete a walk-around inspection of the

unit to understand the unit, your work

area, and all safety labels.

WARNING!

AVOID INJURY. This snowblower is

capable of crushing or amputating

body parts. Failure to observe the

safety instructions in the manuals

and on labels could result in serious

injury or death. ALWAYS disengage

auger, stop unit and engine and allow

moving parts to stop before leaving

operator’s position.

model no. 060-1310-2 I contact us: 1-844-428-7277

SAFETY INFORMATION

Preparation

1. Always check overhead and side clearances

carefully before operation.

2. Always be aware of traffic when operating

along streets or curbs.

3. Thoroughly inspect the area where the

equipment is to be used and remove all

pets, doormats, sleds, boards, toys, wires,

debris and other foreign objects.

4. Disengage the auger control lever before

starting the engine.

5. Handle fuel with care; it is highly

flammable.

1) Use an approved fuel container.

2) Never add fuel to a running engine or

hot engine.

3) Fill fuel tank outdoors with extreme

care. Never fill fuel tank indoors.

4) Never fill containers inside a vehicle or

on a truck or trailer bed with a plastic

liner. Always place containers on the

ground, away from your vehicle, before

filling.

5) When practical, remove gas-powered

equipment from the truck or trailer and

refuel it on the ground. If this is not

possible, then refuel such equipment

on a trailer with a portable container,

rather than from a gasoline dispenser

nozzle.

6) Keep the nozzle in contact with the rim

of the fuel tank or container opening

at all times, until refueling is complete.

Do not use a nozzle lock-open device.

7) Replace gasoline cap securely and wipe

up spilled fuel.

8) If fuel is spilled on clothing, change

clothing immediately.

6. Never attempt to make any adjustments

while the engine is running (except

when specifically recommended by

manufacturer).

7. Always allow unit and engine to adjust to

outdoor temperature before clearing snow.

Operation

1. Never leave a running unit unattended.

Always shut off engine before leaving unit.

2. Do not put hands or feet near or under

rotating parts. Keep clear of the discharge

opening at all times.

3. Moving and/or rotating parts can cut

off body parts such as fingers or a hand.

Always keep hands, feet and clothing away

from all rotating parts during operation.

Always keep hands away from all pinch points.

5. Do not touch unit parts which might be hot

from operation. Allow parts to cool before

attempting to maintain, adjust or service.

6. Check for weak spots on docks, ramps or

floors. Avoid uneven work areas and rough

terrain. Stay alert for hidden hazards.

7. Exercise extreme caution when operating

on or crossing gravel drives, walks or roads.

Stay alert for hidden hazards or traffic.

8. After striking a foreign object, stop the

engine, remove the wire from the spark

plug, thoroughly inspect the snowblower for

any damage, and repair the damage before

restarting and operating the snowblower.

9. If the unit should start to vibrate

abnormally, stop the engine and check

immediately for the cause.

10. Stop the engine whenever you leave the

operating position, before unclogging the

auger/impeller housing or discharge chute,

and when making any repairs, adjustments

or inspections.

11.

When cleaning, repairing or inspecting

the snowblower, make certain the auger/

impeller and all moving parts have stopped.

Disconnect the spark plug wire and keep the

wire away from the plug to prevent someone

from accidentally starting the machine.

12.

Do not run the engine indoors. Open the

outside doors; exhaust fumes are dangerous.

SAFETY INFORMATION

13. Never operate the snowblower without

proper guards and other safety protective

devices in place.

14.

Thrown objects can cause injury. Never direct

the discharge toward people or areas where

property damage can occur from thrown

objects. Keep children and others away.

15. Do not overload the machine capacity by

attempting to clear snow at too fast a rate.

Slow down and turn corners slowly.

16. Never operate the machine at high

transport speeds on slippery surfaces. Look

behind and use care when backing.

17. Do not operate in reverse unless absolutely

necessary. Always back up slowly and look

down and behind before and while backing.

18. Do not carry passengers.

19. Disengage attachment drive when traveling

from one work area to another.

20.

Disengage power to the auger/impeller when

snowblower is transported or not in use.

21. Use only attachments and accessories

approved by the manufacturer of the

snowblower (such as wheel weights,

counterweights or cabs).

22.

This product is equipped with an internal

combustion type engine. Do not use the unit

on or near any unimproved, forest-covered or

brush-covered land unless exhaust system

is equipped with a spark arrester meeting

applicable local, provincial or federal laws.

A spark arrester, if it is used, must be

maintained in effective working order by

operator.

23.

Never operate the snowblower without good

visibility or light. Falling snow, fog, etc. can

reduce visibility and cause an accident.

24. Never operate unit after or during the

use of medication, drugs or alcohol.

Safe operation requires complete and

unimpaired attention at all times.

25.

Never allow anyone to operate this unit when

their alertness or coordination is impaired.

26.

Do not throw snow any higher than necessary.

Clearing a Clogged Discharge Chute

1. Hand contact with the rotating auger/

impeller inside the discharge chute is the

most common cause of injury associated

with snowblower. Never use your hand to

clean out the discharge chute.

2. To clear the chute:

1) SHUT THE ENGINE OFF!

2) Wait 10 seconds to be sure the auger/

impeller blades have stopped rotating.

Always use a clean-out tool, not your hands.

Maintenance and Storage

Secure unit so it will not tip over during

maintenance.

Before cleaning, removing clogs or making any

inspections, repairs, etc., disengage auger

control lever, stop unit and engine, and allow

moving parts to stop and hot parts to cool.

3. Make sure the equipment is in safe

working condition. Check hardware at

frequent intervals for proper tightness. If

components are worn or damaged, replace

with manufacturer’s recommended parts.

4. Do not change engine governor settings or

over-speed engine.

5. Adjust and service as required. All motion

of auger/impeller must stop quickly when

auger control lever is released.

6. Always maintain unit in safe operating

condition. Damaged or worn out muffler can

cause fire or explosion.

7. Keep unit free of ice or other debris. Clean

up oil or fuel spills.

Always keep protective structures, guards,

and panels in good repair, in place and

securely fastened. Never modify or remove

safety devices.

9. Never store the machine with fuel in the

fuel tank inside a building where ignition

sources are present such as hot water

heaters, space heaters or clothes dryers.

Allow the engine to cool before storing in

any enclosure or covering the unit.

model no. 060-1310-2 I contact us: 1-844-428-7277

SAFETY INFORMATION

10. Always refer to operator's manual for

important details if the snowblower is to be

stored for an extended period.

11. Maintain or replace safety and instruction

labels as necessary.

12. Run the machine a few minutes after

throwing snow to prevent freeze-up of the

auger/impeller.

Personal Protection

1. Do not operate the equipment without

wearing adequate winter garments. Avoid

loose fitting clothing that can get caught

in moving parts. Wear footwear that will

improve footing on slippery surfaces.

2. Wear adequate safety gear, including safety

glasses with side shields, and protective

gloves.

3. Do not wear loose clothing or jewellery,

and tie back hair that may get caught in

rotating parts.

4. Protect eyes, face and head from objects

that may be thrown from unit. Wear

appropriate hearing protection.

Slope Operation

1. Operate the snowblower on level surfaces.

Stay off slopes and slippery surfaces.

2. Do not clear snow across the face of slopes;

go up and down. Exercise extreme caution

when operating on slopes. Do not attempt

to clear steep slopes.

3. Use a slow speed to avoid stops or shifts

on slopes. Avoid starting or stopping on a

slope. Do not park unit on a slope unless

absolutely necessary. When parking on a

slope always block the wheels.

4. Do not operate near drop-offs, ditches, or

embankments. Unit can suddenly turn over

if a wheel is over the edge of a cliff or ditch,

or if an edge caves in.

Fuel

Do not run engine in an enclosed area.

Always provide good ventilation. Fumes

from engine exhaust can cause injury or

death.

2. Fuel is highly flammable and its vapours

are explosive. Handle with care. Use only

an approved gasoline container with an

appropriately sized dispensing spout.

3. Do not smoke or allow flame or sparks in the

area where the engine is being refueled or

where gas is stored. Always allow engine to

cool before servicing.

4. Never fill fuel tank when engine is running

or hot from operation.

5. Never fill or drain fuel tank indoors.

6. Replace fuel cap securely and clean up

spilled fuel.

7. Properly remove fuel before tipping unit up

onto housing, so no spills will occur.

Towing/Transporting

1. Always shut off engine and close

fuel shutoff valve or drain fuel when

transporting unit on a truck or trailer.

2, Use extra care when loading or unloading

unit onto trailer or truck. Secure unit

chassis to transport vehicle. Never

secure from rods or linkages that could be

damaged. Do not transport machine while

engine is running.

Accessories

1. Use only attachments recommended by

authorized dealers that are appropriate to your

use and can be used safely in your application.

SIGNAL WORDS

VENDOR - please shown 'safety alert symbol

above and signal words below are used on labels

and in this manual. Read and understand all

safety messages.

SAFETY INFORMATION

1. Danger

Indicates an IMMINENTLY HAZARDOUS

SITUATION! If not avoided, WILL RESULT in death

or serious injury.

2. Warning

Indicates a POTENTIALLY HAZARDOUS SITUATION!

If not avoided, COULD RESULT in death or

serious injury.

3. Caution

Indicates a POTENTIALLY HAZARDOUS

SITUATION! If not avoided, MAY RESULT in minor

or moderate injury. It may also be used to alert

against unsafe practices.

4. Notice

Indicates information or procedures that are

considered important but not hazard related. If

not followed, property damage could result.

5. Important

Indicates general reference information that

requires special attention.

SAFETY LABELS

The safety labels on your machine are visual

reminders of the important safety information

in this manual. All messages on your unit must

be fully understood and carefully followed.

Safety labels on the machine are explained

below. Always replace missing or damaged

safety labels.

model no. 060-1310-2 I contact us: 1-844-428-7277

ASSEMBLY

CAUTION! Read INSTRUCTION MANUAL completely before operating this machine.

IMPORTANT! THIS SNOWBLOWER IS SHIPPED WITHOUT OIL OR GASOLINE IN THE ENGINE.

Your new snowblower has been assembled at the factory with the exception of those parts left

disassembled for shipping purposes. All parts such as nuts, washers, bolts, etc., necessary to

complete the assembly have been placed in the parts bag. To ensure safe and proper operation of

your snowblower, all parts and hardware you assemble must be tightened securely. Use the correct

tools as necessary to ensure proper tightness.

To remove snowblower from carton

1. Remove loose parts included with snowblower.

2. Cut down two end corners of carton and lay end panel down flat.

3. Remove all packing materials except padding between upper and lower handle and padding

holding operator presence control bar to upper handle.

4. Roll snowblower out of carton and check carton thoroughly for additional loose parts.

Assembling the upper handle

1. Position the ends of the upper handle on

the inside of the lower handle and align the

holes.

2. Insert the arc head bolt into the aligned

holes, with the bolt heads on the inside of

the handle.

3. Install the handle knobs on the bolts (Fig. 1)

and tighten the knobs securely.

4. Install and adjusting the control cable (see

Adjusting the Control Cable on pg. 14).

Important: Ensure that the cable is routed

on the innerside of the handle.

Installing the Recoil Starter Handle

Install the recoil starter handle in the rope

guide as shown in Fig. 2.

ASSEMBLY

Fig.1

Fig.2

ASSEMBLY

Installing the Discharge Chute

Install the discharge chute assembly as shown

in Fig. 3.

Make sure the discharge chute rotation

handle and discharge chute is in the correct

position, tighten 3 screws with the spanner

cross-head end.

Adjusting the Control Cable

Checking the Control Cable

Before each use, check the control cable and

adjust it if necessary.

CAUTION: You must check and may need to adjust the control cable before you

operate the machine for the first time.

Adjusting the Control Cable Fig. 4 to 5

1. Stop engine and wait for all moving parts to

stop and for hot parts to cool.

2. Move plastic sleeve up to auger control

lever.

3. Remove cable end from adjustment bracket.

4. Insert Z-hook into highest adjustment

bracket hole reachable.

5. Wrap cable end around adjustment bracket.

IMPORTANT: When auger control lever is

disengaged, there should be slight slack in

the cable and no tension.

6. Start engine and engage auger control lever

to ensure proper operation.

7. Release auger control lever and ensure

paddle rotation stops.

IMPORTANT: Cable tension should not be

excessive.

8. Reposition sleeve over adjustment bracket.

Fig.3

Fig.4

1. Plastic Sleeve

2. Z-hook

3. Adjustment Bracket

Fig.5

model no. 060-1310-2 I contact us: 1-844-428-7277

Checking and filling engine oil

As shown in Figs. 6 to 11.

CAUTION! The following procedures and

adjustments must be performed before

the engine is started. Do not attempt

to make any of these adjustments

while the engine is running.

CAUTION! To prevent engine damage,

the engine is shipped without oil or gas.

The engine must be filled with the

correct grade of oil and gas before

starting the engine. See pg 7.

NOTE! Running the engine with a low oil level will cause engine damage. It is recommend

that high detergent, premium quality 4-stroke engine oil is used. Using non-detergent oil

can shorten the engine’s service life, and using 2-stroke oil will damage the engine.

CAUTION! Always use high quality detergent oil classified SAE 5W-30 oil or equivalent.

Never use additives with recommended oil. To prolong the life of the engine, it is important

that the oil is changed after the first 5 hours of use.

NOTE: To check the engine oil level, stop engine and place the snowblower on a level

surface.

1. Remove the oil filler dipstick and wipe oil

from it with a clean cloth (see Fig. 6).

2. Insert the dipstick into the oil filler neck,

twist to close (see Fig. 7).

Fig.6

Fig.7

ASSEMBLY

3. Remove the dipstick again and check the

oil level: the oil level must be between the

lower limit mark and upper limit mark on the

dipstick. The recommended oil (SAE 5W-30

or equivalent). Do not overfill. Wipe away

any spilled oil (see Fig. 8).

Fig.8

lower limit mark

upper limit mark

ASSEMBLY

model no. 060-1310-2 I contact us: 1-844-428-7277

Filling with engine fuel

As shown in fig.9.

CAUTION! To avoid engine problems, the fuel system should be treated with fuel preserver

or emptied of fuel before storage over 30 days. Never mix oil with gas.

CAUTION! Do not fill fuel into the base of neck. Leave space to allow for fuel expansion. Do

not overfill the fuel tank.

CAUTION! WARNING! Gas is highly flammable and extreme caution must be taken when

handling or working with it. Keep out of reach of children.

CAUTION! To prevent engine damage, the engine is shipped without oil or gas. The engine

must be filled with the correct grade of oil and gas before starting the engine.

WARNING! Refuel in a well-ventilated area with the engine stopped. Do not smoke or

allow flame or sparks in the area where the engine is refueled or where gas is stored. Avoid

repeated or prolonged contact with skin or inhalation of vapor.

WARNING! Gasoline with up to 10% ethanol (gasohol) is acceptable. Do not use

unapproved gasoline, such as E15 and E85.

1. Clean the area around the gas filler cap

before removing the cap. Remove the

warning tag, and check the fuel level (see

fig.9).

2. Refill the tank if the fuel level is low.

3. Refuel carefully to avoid overfilling or

spilling fuel.There should be no fuel in the

filler neck.

4. Clean up any overflow or splashes of gas

before starting the engine.

5. Tighten the filler cap after filling: finger

tight only (see fig.10).

Fig. 9

Fig. 10

ASSEMBLY

OPERATION

Start and Stop the engine

NOTE: Do not operate the machine in enclosed or poorly-ventilated areas as the exhaust

gas contains toxic substances. Keep hands, feet, hair and clothing away from the moving

parts of the machine. The exhaust and other parts of the machine will become hot during

use. Make sure that the blade is securely fastened before starting the engine.

NOTE: to start the engine, make sure that the spark plug cover is located on the plug and

the machine is filled with sufficient oil and gas.

Operation at high altitude

The density of air at high altitude is lower than at sea level. Engine power is reduced as the air

mass and air-fuel ratio decrease. Engine power will be reduced for every 3000' (914 m) of elevation

above sea level. This is a natural trend and cannot be changed by adjusting the engine. At high

altitudes increased exhaust emissions can also result due to the increased enrichment of the

air-fuel ratio. Other high altitude issues can include hard starting, increased fuel consumption

and spark plug fouling. To alleviate high altitude issues other than the natural power loss, we can

provide a high altitude carburetor main jet at an additional cost.

To start the engine

As shown in fig.11 to 12.

1. Push the ignition key fully inward (Fig. 11).

2. Move the fuel valve lever to the "ON"

position (Fig. 12）.

a. To start a cold engine, move the choke

lever to the choke closed position (fig. 13).

3. Move choke lever depending "ON" unit's

temperature:

a. To start a cold engine, move the choke

lever to the choke closed position (fig. 12).

b. To start a warm engine, leave the choke

lever to the opened position (fig. 13).

4. Move the throttle lever to full speed to

start the engine (fig. 13).

5. Use primer control depending on unit’s

temperature (fig. 13):

To start a cold engine, prime 3-5 times

(Fig. 13).

b. To start a warm engine, do not prime

Fig. 11

ignition key

Fig. 12

throttle lever

choke lever

fuel valve lever

This manual suits for next models

Table of contents

Languages:

Other CERTIFIED Snow Blower manuals

CERTIFIED

CERTIFIED 060-3732-6 User manual

CERTIFIED

CERTIFIED 0600581 User manual

CERTIFIED

CERTIFIED 060-3742-2 User manual

CERTIFIED

CERTIFIED 060-3732-6 User manual

CERTIFIED

CERTIFIED 060-0582-0 User manual

CERTIFIED

CERTIFIED 060-3938-8 User manual

Popular Snow Blower manuals by other brands

Craftsman

Craftsman 247.88705 Operator's manual

Ariens

Ariens Sno-Thro Compact Classic 24 Track Operator's manual

Simplicity

Simplicity 9GT Initial setup

MTD

MTD H660G Operator's manual

SNOWJOE

SNOWJOE SJ622E Operator's manual

MTD

MTD Yard Machines E602E Operator's manual

Poulan Pro

Poulan Pro XT XT824ES Illustrated parts list

Poulan Pro

Poulan Pro 435548 owner's manual

Troy-Bilt

Troy-Bilt 7524 Operator's manual

Toro

Toro Powerlite 38273 Operator's manual

Toro

Toro Toro Snow Blower 38515 Operator's manual

Poulan Pro

Poulan Pro 192044 owner's manual

GreenWorks Tools

GreenWorks Tools 26027 manual

Husqvarna

Husqvarna ST 327T Repair parts manual

Craftsman

Craftsman 247.88690 Operator's manual

Snapper

Snapper ESS50220E (7800083), SS50220E parts manual

Craftsman

Craftsman 536.886261 Operator's manual

Murray

Murray 624808x4NA Instruction book

CERTIFIED YFG6621 User manual

Popular Snow Blower manuals by other brands
