PROFESSIONAL AUDIO MIXERS SPECIFICATION SHEET
CVM-1624FXUSB CVM-1224FXUSB CVM-1022
Mixing is making music.
Built into every CVM Series product is over 50 years of Cerwin-Vega! experience in excellent audio design.
•Premium grade components and signal paths deliver precision audio from all channels.
• Tough, all-metal housing satisfies the demands of a reliable and durable product necessary for portability.
•Easy to identify markings and color-coordinated knobs allow for intuitive operation.
•Inserts and AUX/EFX sends opens the mixers to the most unique requirements.
•Complete access to 100 VFX presets that digitally energize vocals and sounds.*
•Digital audio USB input/output support for laptop playback and recording.*
*12 and 16 channel models only
Specifications and design subject to change without notice
Cerwin-Vega has developed a new class of products to complement its highly-reputable loudspeaker and amplifier product lines, a
complete line of small-format audio mixers featuring a wide selection of 10-, 12- and 16-channel models. Coupled with Cerwin-Vega’s
reputation of delivering performance and value for the money, the Cerwin-Vega professional audio mixer line supports a wide range of
sound reinforcement applications from a church choir to a rock band performance. Take control of your sound system with a CV-Mixer.

CV Mixers
PROFESSIONAL AUDIO MIXERS SPECIFICATION SHEET
GENERAL SPECIFICATIONS
CVM-1022
10-Channel
CVM-1224FX USB
12-Channel
CVM-1624FX USB
16-Channel
Mic/Line Inputs
Line Inputs 2 mono + 4 stereo 4 mono + 4 stereo 8 mono + 4 stereo
10 12 16
4 6 10
Mixer Input Channels
AUX & EFX ALT3/4, AUX, EFX ALT3/4, AUX, EFXGroup Busses
Stereo Stereo StereoMAIN Busses
22 dBm 24 dBm 24 dBmMaximum Output Level
20 Hz – 20 kHz 20 Hz – 20 kHz 20 Hz – 20 kHzFrequency Response (-1 dB)
< 0.01% < 0.01% < 0.01%T.H.D.
> 70 dB > 70 dB > 70 dBCrosstalk
Hum & Noise
> 127 dB > 127 dB > 127 dBEIN
> 100 dB > 100 dB > 100 dBResidual
> 80dB > 80dB > 80dBMain, AUX Output
Equalization
12 kHz ±15 dB 12 kHz ±15 dB 12 kHz ±15 dBHigh
2.5 kHz ±12 dB 2.5 kHz ±12 dB 2.5 kHz ±12 dBMid
80 Hz ±15 dB 80 Hz ±15 dB 80 Hz ±15 dBLow
NA USB B Type,
Audio 44.1/48 kHz
USB B Type,
Audio 44.1/48 kHz
Digital Input / Output
NA 24-Bit Resolution,
100 Program Selection
24-Bit Resolution,
100 Program Selection
Vega Effects (VFX)
NA Included,
with mounting hardware
Included,
with mounting hardware
Rack Ears
100-120VAC
or 220-240VAC, 50/60Hz
100-120VAC
or 220-240VAC, 50/60Hz
100-120VAC
or 220-240VAC, 50/60Hz
Power Source
2.4 kg (6.2 lbs) 3.4 kg (7.5 lbs) 5.6 kg (12.3 lbs)Weight
247 x 65 x 290 mm
(9.7 x 2.5 x 11.4 in)
328 x 65 x 420 mm
(12.9 x 2.5 x 16.5 in)
436 x 65 x 420 mm
(17.2 x 2.5 x 16.5 in)
Dimensions (W x H x D)
