CESCO GlucCell Reference guide

1
GlucCellTM Glucose Monitoring System
Quick Reference Card
Intended Use
The GlucCellTM Glucose Monitoring System is intended for use by laboratory
researchers or bioreactor professionals to obtain a quantitative measurement of
glucose in cell culture medium from 30 to 500 mg/dL. The glucose strips are
pre-calibrated, and for single use only.
Please read the following check list before usage
Check the glucose test strip condition and expiry date.
Check if the glucose meter has been coded. Note: Remember to code the
meter before using a new lot of test strips.
Use each test strip immediately after removing it from the vial. Recap the
vial immediately after taking out the strip.
Do not refrigerate the test strips and avoid sun exposure.
Dispose of the used strips carefully according to local regulations.
Sample temperature should > 10 ℃, best at room temperature or 37 ℃.
Perform A Test
I. Coding Your Meter (required only for new lot of purchasing test strips)
Insert the test strip into the strip slot, the
meter will activate. The last code number will
appear on the screen.
Compare the code number shown on the
meter display against the code number on
the test strip vial. If the two numbers match,
you may begin testing by referring section II,
step 3. Otherwise continue to the next step.
Press S button until you hear the sound of
buzzer and the code value flashes, press S
or M button to obtain the code number
indicated on the new test strip vial.
Upon obtaining the right code number, wait
the new setting to flash 3 times to validate
the change. The new code number is
displayed on the screen.
After screen shows the proper code and a
blinking drop symbol shows up, your meter is
ready to perform a test by referring section II,
step 3.
II. Performing a Glucose Test
Insert test strip into strip slot as illustrated.
The meter turns on automatically. The last
code number will appear on the screen.
Check that the code number in the meter
matches the code on the vial. If the two
numbers match you may begin testing.
Otherwise refer to above section to code
your meter first.
When the drop symbol flashes, you are
ready to perform a test.
Use a pipette tip to withdraw around 1.5 ul
test sample.
Carefully depress to form a 1.5 ul droplet on
the pipette tip. Bring the droplet underneath
the right or left aperture of the testing strip
and touch gently to the strip, allowing the
entire droplet to be wicked into the strip.
Please allow the sample to be absorbed
naturally to fill up the confirmation window.
Make sure that the sample has saturated
the test confirmation window. Never push
test sample over the aperture and cause
overloading of the sample.
When sample is applied to the strip, a line
moves on the screen until measurement is
completed.

2
Test result will show up in 15 seconds as a
unit of mg/dL.
After test complete, remove the strip from
meter, and discard the used strip safely.
The accurate testing range of the meter is
from 30 to 500 mg/dL. If HI is displayed,
your cell culture glucose result may be
higher than 600 mg/dL. If LO is displayed,
your cell culture glucose result may be lower
than 20 mg/dL. When the measurement is
higher than 500 mg/dL, please dilute the
sample to a proper measurement range. If
the measurement between 20~30mg/dL,
the deviation may larger than ±15%.
Specifications of GlucCellTM Glucose Meter
1. Assay Method
Electrochemical biosensor
2. Test Sample
Cell Culture Medium or equivalent
solution
3. Test Result
glucose concentration (mg/dL)
4. Sample Size
1.5 μL (0.0015 cc)
5. Measuring Range
20~600 mg/dL
6. Accurate Measuring Range
30~500 mg/dL
7. Measuring Time
Less than 15 seconds
8. Memory Capacity
Last 180 test results
9. Battery Type
CR2032 3V-Lithium battery
10. Battery Life
Approximately 1000 tests
11. Operating Temperature Range
10
℃
~40
℃
(50
℉
~104
℉
)
12. Operating Relative Humidity
20%~80%RH
13. Dimensions of the meter
96 mm
×
60 mm
×
18.5 mm
14. Weight of the meter
70 g including battery
15. Auto Shut-off
In 3 minutes
Content of GlucCellTM Glucose Monitoring System
Item
Description
1. GlucCellTM Glucose Meter
1 set
2. GlucCellTM Glucose Test Strip
1 box, 2 bts/box, 25 strips/bt
3. Check Key
1 pc
4. Quick Reference Card
1 copy
5. Case
1 ea
To download the GlucCellTM user manual and quick reference
card, please visit our website or scan the QR code:
Contact Information
GC001000, September 2017, Ver. 2.5
No. 36., 20th Rd., Taichung Industrial Park,Taichung,
Taiwan 40850, R.O.C.
Tel: [phone]
Fax: [phone]
E-mail: [e-mail]
Website: www.cescobio.com.tw
