Fact Sheet
Astronaut Series
An audio system for the classroom containing
superior features and better acoustics for learning.
Powerful Audiophile®electronics provide 1,500 ft2(140 m2) of coverage
Simple connections below the ceiling
Easy low-cost installation and removal
Built-in mixer with 3 connections for projectors, computers,
and microphones
Classroom Learning Above©
Find out what school districts are learning all over the country: There is
now an audio system designed to improve learning in the classroom.
“Just hearing speech is not enough! Understanding
speech is the core of learning.”
Anything less slows down the pace of student learning. The Astronaut
improves student ability to understand live and recorded voice in the
classroom. It is a difference we call Classroom Learning Above©.
Technical Design
In addition to solving the word recognition problems inherent in today’s
classrooms, the Astronaut reproduces more speech frequencies than
projector sound systems, in-ceiling, or in-room speakers. Since students
hear and learn differently, improving their ability to understand and
comprehend allows more time to focus on lesson content.
“A technical marvel that works so well it is patented in
over 40 countries!”
Just look at some of these features: custom digital electronics, custom
Audiophile 40 watt transducer, custom omnidirectional horn cabinet
design, custom tuned circular port, and custom designed built-in mixer
that accepts up to three mono- or stereo inputs.
© 2008 Cetacea Sound Corp. Audiophile®Astronaut™ and Lite Energy™ are
trademarks of Cetacea Sound Corp. Covered by multiple international patents.
Cetacea Sound Corporation, 2003 East Center Circle Plymouth, MN 55441
P: 763.559.1019 F: 763.559.1585 www.cetaceasound.com 11/08
An audio paradigm that creates a dramatic
improvement in classroom audio. Sound
you can listen to all day leaving students
and teachers productive and healthy!

1
2
654
3
Dimensions
7.2"w x 3.5"h
175 ounces (.5 kg)
Features
1Tuned port
2Inspired industrial design
3Patented acoustic ceiling
coupling uses less energy
4Built-in 3-channel mixer
5Each mini-jack accepts
mono- or stereo inputs
6External power supply
fitting uses a tuning-fork
design for strength
Ceiling Installation
Our multi-coupling bracket system is an industry first. The Astronaut
mounts to the surface of the ceiling and all connections are inside the
room potentially eliminating wiring above it. Once the bracket is in place
the speaker can be installed or removed without tools, including its security
feature. Installation and removal are greatly simplified.
Save Green with Green
The Astronaut is a thoroughly thought out sound system
for classroom installations. It not only meets the low cost
acquisition needs of the budget conscious user, it also has
the lowest cost of long-term ownership. Our marvelous
patented technology uses 75% less energy than other
sound systems with the same performance without
sacrificing loudness. In addition, the Astronaut meets the
new, and very stringent, California Energy Conservation
standards. Now that is what we call Lite-Energy™!
Optional Features
In addition to its base model, the Astronaut offers the following
optional features:
Microphone input Priority input management
Hi-Low voltage select Daisy chaining
Intuitive remote control Three styles of power supplies
Three styles of brackets Balanced inputs
The Astronaut, respectfully named after our greatest
human achievements.
Specifications
Electrical
Signal Connections
3 input jacks, 3.5 mm, mono-stereo with auto detection and mix-down
Input Impedance
62k ohms per input
Amplifier Power/Requirements
40 watts RMS @ 10% THD
12 VDC, 40 watts
Power Supply/Requirements
Switch mode, low noise, high efficiency wall or desk top style
Voltage input: 100-240 V, 50/60 Hz
Voltage output: 12 VDC, 40 watt
85% efficient
Fuse and over-temp protection (80 degrees centigrade)
Regulation +/- 5%
Ripple and noise less than 1%
Overload and over voltage protection
Short circuit protection with auto-recovery
CEC Level IV compliant
< .5W stand-by power consumption
Approvals: UL, cUL, TUV, PSE, CSA, CCC, BEAB
Acoustics
Patented omni-directional horn with ceiling acoustic coupling
Magnetically shielded custom Audiophile®transducer
Custom circular tuned port, 70 Hz
Performance
Frequency response
70-15kHz @ -3 dB
Signal to Noise Ratio
>90 dB
Loudness
92 dB
Port Tuning
70 Hz
Mechanical
System Dimensions
Diameter – 7.2" Height – 3.5"
System Weight
17.5 ounces (.5 kg)
Power Supply Dimensions
Wall Mount and Desktop – 4.33" x 2.07" x 1.44"
Power Supply Weight
Wall Mount and Desktop – 8 ounces
AC cord (if needed) – 8 ounces
Power Cord
Standard CEC certified wall mount power supply – 9' reach with
tuning fork barrel connector
Optional CEC certified desktop style power supply – 6' AC power
cord and attached 9' output cord with tuning fork barrel connector AC
input style plug IEC-320, C-8.
Mediaphile AV mounting bracket for false or firm ceiling structure
False ceiling mount is a two-piece sandwich style system – requires
2-4 each 1/4-20 x 11/2" aluminum flat head machine screws (included)
Firm ceiling mount is a one-piece system – 4 each 1/2"-11/2" flat head
wood screws (wood screws not included)
Optional ceiling mount lock
Weight of two-piece system – 7 ounces including 4 mounting screws
Warranty
Full two years on all components
