CF MOTO ZForce 950EX User manual

1
CFMOTO
SERVICE MANUAL
CF1000US
CF1000US-A
CF1000UTR-B
950EX
950Sport
1000Sport
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

CFMOTO
2
www.cfmoto.com
Edition Number: 20191228
Edition Item: CF1000US CF1000US-A CF1000UTR-B
(5BY#-00WX02-6000) SM-20191228
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

3
CFMOTO
FOREWORD INDEX
This manual outlines CF1000US,
CF1000US-A, CF1000UTR-B maintenance
information, removal & installation
procedures, inspection & adjustment
methods, troubleshooting and technical
specifications in detail. There are
illustrations to guide your operations.
Please read this manual carefully and
maintain the vehicle according to the
intervals indicated, which can effectively
prolong parts service life, improve the
engine performance and the reliability of
the vehicle.
Chapters 1, 2 and 3 outline safety
information, general information and
maintenance information.
Chapters 4 to 12 oultine parts removal,
inspection, repair and installation
procedures of each system, and points for
attention.
Appendix: Start circuit diagram, EFI
schematic diagram and Electrical
schematic diagram.
CFMOTO reserves right to make
improvements and modifications to the
products without prior notice. Overhaul and
maintenance should be done according to
actual condition of vehicle.
This manual can be reproduced only
after obtaining the written consent of the
copyright owner, including extracts or
copies in any form.
This manual is applicable to the following
vehicle(s):
CF1000US/CF1000US-A/CF1000UTR-B
All rights reserved
Zhejiang CFMOTO Power Co., Ltd.
INDEX
Safety Information 1
Specications/Vehicle Data 2
Maintenance 3
CVT System 4
Engine 5
Body and Frame 6
Powertain 7
Brake System 8
Suspension System 9
Steering 10
Cooling and Heating System 11
Electrical 12
Starting Diagram Appendix A
EFI Diagram Appendix B
Electrical Schematic Diagram Appendix C
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

CFMOTO
01-4
1.1 Service Manual ................................................................................... 01-2
1.2 Safety Tips .......................................................................................... 01-2
1.3 Hazardous Level and Symbol............................................................ 01-2
1.4 Operation Notice................................................................................. 01-2
1.5 General Precaution............................................................................. 01-3
1.5.1 Avoid Carbon Monoxide Poisoning ........................................... 01-3
1.5.2 Avoid Corrosion Injury by Electrolyte........................................ 01-3
1.5.3 Avoid Injury .................................................................................. 01-3
1.5.4 Avoid Burns.................................................................................. 01-3
1.5.5 Avoid Toxic Coolant..................................................................... 01-3
1.5.6 Avoid Explosions and Fire .......................................................... 01-3
1.5.7 Operational Safety ....................................................................... 01-3
1.6 Cautions for Removal and Installation............................................. 01-4
1.7 Engine Break-in .................................................................................. 01-5
1.8 Warranty .............................................................................................. 01-5
1.9 Fuel, Engine Oil, Transmission Oil and Coolant.............................. 01-5
1.10 Instructions and Captions ............................................................... 01-6
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

01 Safety Information
01-5
1.1 Service Manual
Before maintenance, please read this service manual carefully. This manual introduces
maintenance information, removal & installation procedures, checking & adjustment
methods, troubleshooting and technical specications with detailed images and diagrams
to guide maintenance technicians. It will help improve the e󰀩ciency of vehicle repair and
maintenance.
1.2 Safety Tips
Follow the safety tips in this service manual.
Safety tips is highlighted in text.
CAUTION: There are labels or warning labels on the visible places of vehicle. Do
not remove any label, or people may not be able to identify the danger, which could
result in injury.
1.3 Hazardous Level and Symbol
Danger/Warning/Caution
Please read the following explanations carefully of “Danger/ Warning/Caution”:
DANGER: The Danger alert and icon indicates a potential hazard that may cause
serious injuries or death.
WARNING: The Warning alert and icon indicates a potential hazard that may
cause light or medium injury.
CAUTION: The Caution alert and icon indicates a potential hazard that requires
you to pay attention.
NOTE or NOTICE: A note or notice alerts to important information or instructions.
Danger, Warning, Caution and Note instructions can not include all the risks during use
or maintenance of the vehicle. Therefore, besides the notices on the vehicle, technicians
should have basic mechanical and safety knowledge, or ask a senior mechanic for help.
1.4 Operation Notice
For some procedures, special tools are required. These tools can be purchased according
to the part number displayed in this service manual.
During installation, certain parts such as seals, o-rings, cotter pins, circlips, etc. cannot
be reused and must be replaced with a new. Follow the instructions when applying
threadlocker to screws.
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

CFMOTO
01-6
For those parts that will be reused after removal, clean them up and inspect for damages
or cracks. Replace it if damaged.
Ensure vehicle safety after repair or maintenance.
1.5 General Precaution
1.5.1 Avoid Carbon Monoxide Poisoning
CAUTION: Exhausted gas is poisonous. Do not run the engine in a closed or
poorly ventilated area for a long time.
1.5.2 Avoid Corrosion Injury by Electrolyte
CAUTION:
1. Battery electrolyte (dilute sulfuric acid) is highly caustic and can result in burns.
If you spill electrolyte on skin, flush with water and seek for medical attention
immediately.
2. If you spill electrolyte on clothes, ush with water to avoid burns.
3. Keep battery and electrolyte out of reach of children.
1.5.3 Avoid Injury
CAUTION: Wear suitable work clothes, cap, boots, glasses, dust-proof mask, and
gloves if necessary.
1.5.4 Avoid Burns
CAUTION: Engine and mu󰀪er temperatures are still high when the engine is just
stopped for a very short time. Avoid getting burned. Do not touch the engine before
it completely cools down.
1.5.5 Avoid Toxic Coolant
CAUTION:
1. Coolant is poisonous. Do not drink or spill it on skin, eyes or clothes. If you spill
coolant on skin, wash with soap and water. If you spill coolant on eyes, ush with
water and seek prompt medical attention.
2. If coolant is swallowed, induce vomiting and ask a doctor for medical care.
3. Keep coolant out of reach of children, and keep it away from pets.
1.5.6 Avoid Explosions and Fire
CAUTION:
1. Gasoline is highly flammable. Keep gasoline away from sparks. Vaporized
gasoline is also explosive. Fuel and operate vehicle in a well ventilated area.
2. The battery produces ammable and explosive hydrogen when it is charged. It
has the potential danger of explosion if there is a re or sparks. Charge the battery
in a well-ventilated area.
1.5.7 Operational Safety
CAUTION:
1. Be careful not to get pinched by turning parts such as wheels, axles, and
clutches.
2. When more than two persons are working on the vehicle, remind each other of
operational safety.
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

01 Safety Information
01-7
1.6 Cautions for Removal and Installation
CAUTION:
1. Use only genuine CFMOTO parts, lubricants and service products.
2. Store removed components separately in order for correct installation.
3. Clean the vehicle of mud, dust and debris before servicing.
4. Replace removed seals, o-rings, piston pin retainers, cotter pins with new ones.
5. Elastic retainers might get distorted after disassembly. Do not use loosened
retainers.
6. Clean and blow o󰀨 components after removal. Apply lubricants on the surface of
moving parts before installation.
7. If you do not know the length of screws, install the screws one by one and make
sure they screw in the same depth.
8. Pre-tighten installed bolts, nuts and screws, then torque them to specified
specication. The basic sequence is: from big to small, from inside to outside and
criss-cross.
9.Replace aged rubber parts when assembling. Do not splash gasoline, grease onto
the surface, as this could cause damage.
10. Apply or inject recommended lubricant into the specied lubrication points.
11. Use the correct special tools for removal and installation.
12. When a ball bearing is removed by pressing steel balls, it cannot be reused.
·Replace bearings if the axial or radial free play is too big.
·If the running surface feels uneven, clean with oil and check again. Replace it
if the cleaning does not work.
·When pressing the bearing into the machine or onto the shaft, if the bearing
can not be securely seated, replace it.
13. Install one-side dust-proof bearings in the correct direction. When assembling
open-type or double-side dust-proof bearings, install with the manufacturer’s mark
outward.
14. Install elastic circlips properly. Turn the circlip after assembling to make sure it
has been installed into the slot.
15. After assembling, check that all the tightened parts are properly tightened and
can move smoothly.
16. Brake uid and coolant may damage painting, plastic and rubber parts. Flush
with water if splashed on these parts.
17. Install oil seals with the manufacturer’s mark outward.
·Do not fold or scratch the oil seal lip.
·Apply grease to the oil seal lip before assembling.
18. When installing pipes, insert the pipe until it bottoms in the end of the joint.
Fit the pipe clip, if any, into the groove. Replace pipes or hoses that cannot be
tightened.
19. Do not allow mud or dust into the engine and/or the hydraulic brake system.
20. Clean old gasket and sealant o󰀨 engine casings before assembling with new.
Remove scratches on the joint faces by polishing evenly with a polish stone.
21. Do not twist or bend cables too much. Distorted or damaged cables may cause
poor operation or even damage components.
22. When assembling parts with protection caps, insert the caps to the grooves.
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

CFMOTO
01-8
1.7 Engine Break-in
There are many moving components inside the engine such as the piston, piston rings,
cylinder, crankshaft, gears, etc. During the initial use period, proper run-in for every critical
component is necessary. Break-in helps engine components match to each other and
adjust to working conditions. A new engine with careful treatment will have more e󰀩cient
performance and a longer service life.
Recommended break-in period: 20 hours or 320km (200 miles) whichever comes rst.
Operation guide:
0-10 hours or 0~160km (100 miles): Vary throttle position slowly and smoothly. Do not
operate continuously at more than 50% open throttle position. Cool down the engine for
5~10 minutes after every hour of operation. Avoid prolonged heavy acceleration.
10-20 hours or 160~320km (100 miles): Vary throttle positions slowly and smoothly. Do
not operate continuously at more than 75% open throttle position. Avoid prolonged heavy
acceleration.
CAUTION:
1. Maintain and repair as required during the break-in period.
2. After break-in, check and maintain the vehicle before normal use.
1.8 Warranty
Maintenance procedures specied in the schedule should be carried out in CFMOTO authorized
service stations. Otherwise, warranty and warranty rights may be a󰀨ected.
1.9 Fuel, Engine Oil, Transmission Oil and Coolant
Fuel: Octane US: 89 or higher unleaded gasoline. EU: E10 or 95 (RON)
Engine oil: Use of any oil other than those recommended may cause serious engine
damage. CFMOTO recommends the use of 10W-40 for 4-stroke engines. Changing
engine oil viscosity to 5W-40 due to extreme cold environments or 15W-40 due to hot
environments is acceptable. Reference the chart below for ambient temperature and
viscosity choice.
API: SJ or above engine oil.
Transmission oil: 75W-90-GL5.
Coolant: Any commercialy available 50/50 mix
antifreeze with appropriate anti-corrosion and
rust-proof properties. Freeze temperature must be lower than environment air temperature
(Typically -5 °C or lower).
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

01 Safety Information
01-9
CAUTION: Improper handling of fuel or oil can cause pollution. Fuel or oil is not
allowed to enter into groundwater, soil, or pipe systems.
CAUTION: CFMOTO recommends to use - 35°C mixed, anti-corrosion and high
boiling coolant.
Please only use spare parts and accessories approved or recommended by CFMOTO.
If any loss is caused by using unapproved products, CFMOTO shall not be responsible.
For lastest information about vehicle use, please visit CFMOTO o󰀩cial website:
http://www.cfmoto.com
1.10 Instructions and Captions
Certain instructions and pictures in this service manual require optional special tools. Parts
may have been removed or not shown in certain pictures for better display and illustration.
Depending on the repair required, not all instructions need to be followed, please note the
text.
Numbers in the corner of the pictures in this service manual are only for CFMOTO internal
use.
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

02-10
CFMOTO
2.1 Unit Conversion Table and Symbols ................................................ 02-2
2.2 Identication Number Locations....................................................... 02-3
2.3 Main Specications............................................................................ 02-4
2.4 Specications for Service.................................................................. 02-6
2.5 Fastener Torque Tables ................................................................... 02-11
2.6 Grease and Sealant .......................................................................... 02-15
2.7 Service Products .............................................................................. 02-15
2.8 Service Tools .................................................................................... 02-16
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

02-11
02 Specications/Vehicle Data
2.1 Unit Conversion Table and Symbols
Unit Conversion Table
Item Unit conversion
Pressure
1kgf/cm²=98.0665kPa
1psi= 6.895kPa = 0.06895bar
1mmHg=133.322Pa=0.133322kPa
Torque
1kgf·m=9.80665N•m
1N·m= 8.85(lbf•in)
1N·m= 0.7375621(lbf•ft)
Volume 1mL=1cm3=1cc
1L=1000cm3
Force 1kgf=9.80665N
Length 1in=25.4mm
Symbols
V Voltage
A Electric current
ΩResistance
VAC Alternating current voltage
Vdc Direct current voltage
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

02-12
CFMOTO
2.2 Identication Number Locations
1VIN Location
2 EIN - PTO
Model: CF1000US / CF1000US-A / CF1000UTR-B
1. Vehicle identication number (VIN): LCELV1Z1 / LCELV1ZG / LCELV1ZB
2. Engine identication number (EIN): 2V91Y ~
020201
1
020202
2
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

02-13
02 Specications/Vehicle Data
2.3 Main Specications
Vehicle Specication
Model CF1000US CF1000US-A CF1000UTR-B
Size: length×width×height 3020×1650×1850 2990×1565×1820 3135×1820×1820
Wheelbase 2285mm
Min. ground clearance 340mm 310mm 310mm
Dry weight 685kg 680kg 690kg
Passengers 2 person (includes driver)
Rear cargo box maximun load 100kg
Max. vehicle load allowed 290kg
Recommended Towing Capacities:
Towing Hitch Weight
Trailer and Cargo Weight
40kg (bolt type) / 25kg (plug pin type)
400kg (bolt type) / 250kg (plug pin type)
Frame type Steel tube
Engine Specication
Model 2V91Y
Type V-twin, liquid-cooled, 4-stroke,
8 valves, SOHC chain drive
Bore×Stroke 91mm×74mm
Displacement 962.6cc
Compression ratio 10.6:1
Min. no-load stabilized speed (idling) 1300r/min±130r/min
Physical size: Length×Width×Height 679mm×556mm×589mm
Net weight 79kg
Output style Front and rear shaft
Engine output rotating direction Clockwise (rear view)
Electrical
system
Ignition method ECU / Coil
Spark plug DCPR8E (NGK)
Magneto VAC 3-phase
Starting method Electric start
EFI system
ECU Bosch
Injectors Bosch
Idle speed 1300r/min ± 130r/min
Lubrication
system
Lubrication method Pressure + splash
Oil pump Rotor motor
Filter style Full ow cartridge lter
Engine oil
SAE 10W-40 SJ
SAE 5W-40 SJ
SAE 15W-40 SJ
or higher API
Transmission oil SAE 75W/90 GL-5
Cooling
system
Cooling type Closed-circuit coolant radiator
Coolant -35°C Anti-freeze mix
Oil cooling Integrated heat transfer cooler
Throttle Valve diameter 57 mm
Air Filter Paper cartridge lter
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

02-14
CFMOTO
Engine Specication
Transmission
Type CVT+Gearshift Transmission
Gears 2 forward, 1 reverse, 1 parking
Shift/Order Manual/L-H-N-R-P
Clutch type Dry CVT
CVT ratio range 2.88~0.70
Gear ratios
Final 1.333(20/15, Bevel gear)
Secondary 1.952(41/21)
Speed Gears
L gear: 2.529(43/17); H gear: 1.143(32/28)
R gear: 2.231(29/13)
Total ratio: L: 6.585; H: 2.975; R: 5.807
Axle ratios Front axle 33/9
Rear axle 33/9
Fuel System Specication
Fuel type
US: 89 octane or higher unleaded gasoline
EU167: E10/95 or higher unleaded gasoline
EU168: E5/95 or higher unleaded gasoline
Fuel tank capacity 36.5L
Reserve fuel indicator Indicator turns yellow and keeps on when the fuel is below
11.5L. Indicator ashes when the fuel reaches one grid.
Fuel pump 35L per hour at 0.33 Mpa ± 0.02 Mpa
Fuel lter 15-micron, inline type
Steering Specication
Min. turning radius 5500mm
Turn angle Inside 33.3°
Outside 25.2°
Brakes Specication
Front Dual Hydraulic Disc
Rear Dual Hydraulic Disc
Parking Integrated Hand Brake / Rear Discs Only
Suspension Specication
Type
CF1000US CF1000US-A CF1000UTR-B
Front: Dual swing
arm independent
340mm travel
Front: Dual swing
arm independent
280mm travel
Front: Dual swing
arm independent
280mm travel
Rear: Dual swing
arm independent
395mm travel
Rear: Dual swing
arm independent
300mm travel
Rear: Dual swing
arm independent
300mm travel
Shock absorber Front: Oil / Gas - Pre-load Adjustable
Rear: Oil / Gas - Pre-load Adjustable
Standard spring pre-load
setting
Front: 65mm
Rear: 85mm
Front: 45mm
Rear: 60mm
Front: 45mm
Rear: 60mm
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

02-15
02 Specications/Vehicle Data
Wheel/Tire Specication
CF1000US CF1000US-A CF1000UTR-B
Front tire 29×9.00 R14 27×9.00 R14 27×9.00 R14
Rear tire 29×11.00 R14 27×11.00 R14 27×11.00 R14
Wheel bolt pattern M12×1.25-6h M12×1.25-6h M12×1.25-6h
Wheel nut pattern M12×1.25-6H M12×1.25-6H M12×1.25-6H
2.4 Specications for Service
Lubrication
Item Standard
Engine oil
capacity
Replace oil and oil lter 2500mL (2.64 qt.)
Total capacity 2600mL (2.74 qt.)
Recommended
engine oil
SAE:Use of any oil other than
those recommended may cause
serious engine damage. CFMOTO
recommends the use of 10W-40 for
4-stroke engines. Changing engine
oil viscosity to 5W-40 due to extreme
cold environments or 15W-40 due
to hot environments is acceptable.
Reference the chart below for
ambient temperature and viscosity
choice.
API level: SJ or higher.
Oil pressure
Engine RPM 1300r/min and oil temperature 90°C:
Oil pressure should be between 100kPa to 400kPa. Typical is 200kPa.
Engine RPM 6000r/min and oil temperature 90°C:
Oil pressure should be between 350kPa to 700kPa. Typical is 580kPa.
Transmission oil Total capacity 600mL
Recommended oil SAE 75W/90 GL-5
Front gearcase
oil
Total capacity 330 mL
Recommended oil SAE 80W-90 GL-5
Rear gearcase
oil
Total capacity 400 mL
Recommended oil SAE 80W-90 GL-5
Cooling System
Item Standard
Thermostat
Open temperature 65°C ± 2°C
Full open temperature 85°C
Full open clearance Equal to or greater than 5mm at 85°C
Radiator cap opening pressure 108 kPa (1.1kgf/cm2)
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

02-16
CFMOTO
Coolant
temperature sensor
temperature vs
resistance
Coolant temperature
(°C)
Resistance B terminal-Earth
(Ω)
Resistance A-C terminals
(kΩ)
-20 -- 28.528±0.004
25 -- 2.795±0.0025
50 216~264 0.98±0.00227
80 74.6~90.6 0.334±0.00204
110 32~36 0.133±0.00252
Coolant capacity System Approximately 4.5L (4.8 qt.)
Reservoir 410mL (upper line)
Coolant type Commercially available, -35°C anti-freezing,
anti-corrosive and high boiling point
Mix ratio 50% coolant / 50% distilled water
Wheel (Front and Rear)
Item Standard Service limit
Wheel jump Axial 1.0mm 2.0mm
Radial 1.0mm 2.0mm
Tire
Groove depth -- 3.0mm
Front tire pressure 110kPa --
Rear tire pressure 120kPa --
Brakes
Item Standard Service limit
Brake Fluid DOT 4 --
Brake pad wear value -- ≥ 2 mm
Brake disc thickness - Front 5.0mm 4.0mm
Brake disc wear value - Front 1.0mm
Brake pedal free play 60mm~70mm --
Brake disc thickness - Rear 5.0mm 4.0mm
Brake disc wear value - Rear 1.0mm
Battery / Charging
Item Standard
Battery
Type AGM
Capacity 12V 30Ah
Voltage Fully charged 14.4V
Discharged ≤11.8V
Recharging current/time Standard 2.7A/5h~10h
Quick 12A/1h
A/C magneto
Magneto Type Magneto 3-phase A/C generator
Output 3-phase A/C
Resistance of coils (20°C) 0.2Ω~0.3Ω
Max. output power 600W at 5000r/min
Charging voltage 13.5V~15.0V at 5000r/min
Regulator type 3-phase supply / 12Vdc power output
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

02-17
02 Specications/Vehicle Data
CVT / Transmission
Item Standard - mm Limit Remark
Drive belt width 33.7(Fiber level) 32.2
Sliding sleeve diameter, driven pulley 38.10~38.14 38.30
Clearance between shifting fork and
groove 0.20~0.40 0.50
Shifting fork moving thickness 5.80~5.90 5.70
H/L sliding fork groove width 6.10~6.20 6.30
Output main gear sliding groove width 6.10~6.20 6.30
Shifting drum groove width 8.02~8.12
Shifting fork pin diameter 7.90~7.95 7.83
Shifting gear hole diameter 29.000~29.021 29.025
Reverse dual gear hole diameter 29.007~29.028 29.032
Shifting main shaft diameter φ30 28.980~29.993 29.970
φ17 16.983~16.994 16.978
Driven shaft diameter φ24 23.980~23.993 23.974
φ17 16.983~16.994 16.978
Drive bevel gear shaft diameter φ17 16.983~16.994 16.978
Reverse dual gear shaft diameter φ25 24.980~24.993 24.974
Ignition / EFI / Electrical
Item Standard
Ignition controller Bosch ECU
Spark plug
Type Resistance control
Model DCPR8E(NGK)
Spark clearance 0.8mm~0.9mm
Spark specication >8mm,1 kPa
Ignition coil resistance Primary 740Ω~780mΩ
Secondary 10.1kΩ~11.1 kΩ
Peak voltage Ignition primary ≥1.5V, 200r/min
Pulse starter ≥25kV
Start relay coil resistance 3Ω~5Ω
Start auxiliary coil resistance 90Ω~100Ω
Peak voltage of trigger coil ≥1.5V, 200r/min
Resistance of trigger coil 250Ω~300Ω
Fuses / Lights
Item Standard
Fuses Main 40A
Secondary 5A×1 10A×2 15A×4 40A×1
Lights
Headlight 30W (High-beam) 14.2W (Low-beam)
3.5W (position light) 23W (turn light)
Brake light 4.5W
Indicators LCD+LED
Rear license light H2 W5W bulb
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

02-18
CFMOTO
Valve / Camshaft / Rocker Arm / Cylinder Head
Item Standard - mm Limit Remark
Valve diameter IN 33 --
EX 29 --
Valve thickness IN & EX 1 0.5
Valve clearance (Cold engine) IN 0.06~0.14 --
EX 0.11~0.19 --
Valve guide diameter IN & EX 5.000~5.012 5.045
Valve stem outer diameter IN 4.965~4.980 4.93
EX 4.955~4.970 4.93
Valve guide and stem clearance IN 0.020~0.047 --
EX 0.030~0.057 --
Valve stem roundness (run out) IN & EX 0.01 0.05
Valve stem end run out IN & EX 0.02 0.05
Valve length IN 90.1 --
EX 88.7 --
Valve bevel side run out IN & EX 0.03 0.05
Valve sealing line width IN 1.2±0.1 1.7
EX 1.3±0.1 1.8
Valve spring free length IN & EX 40 38.2
Valve spring force IN & EX
Compress to 33mm:
200.5 N~235.5 N
Compress to 23mm:
531 N~587 N
--
Cam lobe height - Cylinder 1 IN 32.931~33.051 32.831
EX 32.945~33.065 32.845
Cam lobe height - Cylinder 2 IN 33.019~33.139 32.919
EX 32.853~32.973 32.753
Camshaft journal diameter φ35 34.959~34.975 34.95
φ22 21.959~21.980 21.95
Camshaft bearing diameter φ35 35.007~35.025 35.04
φ22 22.012~22.025 22.04
Camshaft bearing t clearance φ35 0.032~0.066 0.09
φ22 0.032~0.066 0.09
Camshaft axial clearance 0.12~0.28 --
Camshaft run out 0.10
Rocker arm inner hole diameter IN & EX 12.000~12.018 12.03
Rocker arm shaft diameter IN & EX 11.973~11.984 11.96
Rocker arm shaft t clearance IN & EX 0.016~0.045 0.07
Rocker arm shaft axial clearance IN & EX 0.06~0.34 --
Cylinder head atness 0.03 0.05
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

02-19
02 Specications/Vehicle Data
Cylinder / Piston / Piston Ring / Connecting Rod / Crankshaft
Item Standard - mm Limit Remark
Cylinder compression pressure 1000kPa --
Cylinder taper 0.038 0.090
Cylinder roundness 0.015 0.020
Cylinder hole clearance 90.99~91.01 --
Piston diameter 90.94~90.96 90.85 Above 8mm from
piston bottom
Piston and cylinder clearance 0.04~0.06 0.10
Cylinder upside and bottom atness 0.03 0.05
Piston ring gap clearance
1st 0.15~0.30 1.35
2nd 0.15~0.30 1.35
Oil 0.2~0.7 1.5
Piston ring thickness
1st 1.17~1.19 --
2nd 1.47~1.49 --
Oil 2.37~2.47 --
Piston ring groove depth
1st 1.21~1.23 --
2nd 1.51~1.53 --
Oil 2.50~2.52 --
Piston ring/groove thickness
1st 0.02~0.06 0.15
2nd 0.02~0.06 0.15
Oil 0.03~0.15 0.25
Piston pin hole inner diameter 22.004~22.010 --
Connecting rod small end inner diameter 22.01~22.02 22.06
Piston pin hole inner diameter 21.995~22.000 21.980
Piston pin hole/piston pin clearance 0.004~0.015 0.08
Connecting rod small end hole/piston
pin clearance 0.010~0.025 0.08
Connecting rod big end axial clearance 0.3~0.56 0.8
Connecting rod journal diameter 43.930~43.950 43.915
Connecting rod big end bearing diameter 43.970~44.000 44.03
Connecting rod big end radial clearance 0.028~0.049 0.09
Crankshaft main journal diameter 41.960~41.970 41.935
Crankcase main bearing hole diameter 41.980~42.020 42.10
Crankshaft main journal radial clearance 0.02~0.05 0.09
Crankshaft axial clearance 0.26~0.54 0.64
Oil Pump
Oil pump rotor
Clearance between inner and outer
rotor 0.06mm~0.14mm
Clearance between outer rotor and
bore 0.09mm~0.15mm
Rotor end clearance 0.023mm~0.109mm
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.

02-20
CFMOTO
2.5 Fastener Torque Tables
Torque Table - Vehicle Components
Fasteners excluded in below table should also be torqued to specication.
NOTE: Threads and contact area should be coated with oil.
No. Item Type Qty Torque(N•m)
1 Front mounting shaft, engine 7030-000401 1 60~70
2Rear LH mounting bolt, engine GB5789 M10×1.25×100 1 55~65
3Rear RH mounting bolt, engine GB5789 M10×1.25×130 1 55~65
4 Nut, exhaust pipe joint 8010-020001 M8 4 25~35
5Upper mounting bolt, muffler
body GB5789 M10×1.25×70 1 40~50
6Lower mounting bolt, muffler
body GB5789 M8×65 1 30~40
7
Mounting shaft, front lower
swing arm 5BY0-050203 2 90~100
Mounting shaft, front upper
swing arm 5BY0-050103 2 90~100
8 Bolt, front shock absorber GB5789 M10×1.25×50 2 45~55
GB5789 M10×1.25×55 2 45~55
9Slotted nut, upper&lower swing
arm ball pin GB9459 M12×1.25 4 50~60
10 Bolt, rear shock absorber GB5789 M10×1.25×55 4 45~55
11 Mounting shaft, rear bearing
carrier GB5789 M10×1.25×80 4 45~55
12 Mounting shaft, rear swing arm GB5789 M10×1.25×65 2 45~55
13 Bolt, rear swing arm tie-rod GB5789 M12×1.25×70 2 90~100
14 Bolt, rear swing arm tie-rod GB5789 M12×1.25×60 6 90~100
15 Rear tie rod Shaft 5BY0-060703 4 90~100
16 Mounting nut, rim 5HY0-070203(Aluminum) 16 110~120
17 Hex slotted nut 5HY0-110001 4 220~250
18 Mounting nut, front gear case GB6187 M10×1.25 1 50~60
19 Mounting bolt, front gear case GB5789M10×1.25×25 1 50~60
20 Mounting bolt, front gear case GB5789M10×1.25×35 1 50~60
21 Mounting bolt, rear gear case GB5789 M10×1.25×75 2 50~60
22 Mounting nut,rear gear case GB6187 M10×1.25 2 60~70
23 Screw, front drive shaft GB/T70.1 M10×1.25×25 8 40~50
24 Screw, rear drive shaft GB/T70.1 M10×1.25×25 4 40~50
25 Bolt, front brake caliper GB5789 M10×1.25×25 4 40~50
26 Bolt, rear brake caliper GB5789 M10×1.25×35 4 40~50
27 Bolt, front brake disc A000-080001 16 25~30
28
Lock nut, steering tie-rod&knuckle
GB/T 9459 M12×1.25 2 50~60
© CFMOTO Powersports, Inc. This manual is subject to all applicable copyright laws.
Reproduction or duplication in any form, whole or in part, is strictly prohbited.
