CF MOTO CFORCE 850XC User manual

CFORCE 850XC
CFORCE 1000
CF800ATR-3
CF1000ATR
OWNER’S MANUAL
READ THIS MANUAL CAREFULLY
It contains important safety information
This ATV should not be ridden by anyone under
16 years of age. Passenger under 12 are
prohibited.

TABLE OF CONTENTS
Foreword ...................................................................................................... 5
Welcome .......................................................................................................................5
Signal Words.................................................................................................................6
Introduction................................................................................................. 10
Vehicle Identication Numbers....................................................................................10
Specication................................................................................................................11
Operator Safety .......................................................................................... 16
Age Restrictions ..........................................................................................................16
Know Your Vehicle ......................................................................................................16
Equipment Modications .............................................................................................17
Avoid Burns from Hot Parts.........................................................................................18
Pulling a Trailer ...........................................................................................................18
Safety Training ............................................................................................................19
Hazardous Operation Warnings .................................................................................19
Safe Riding Gear.........................................................................................................43
Safety decals and locations ........................................................................................44
Features & Controls.................................................................................... 48
Left Hand Controls ......................................................................................................48
Right Hand Controls....................................................................................................51

Foot Controls...............................................................................................................57
Vehicle Features .........................................................................................................58
CVT System ................................................................................................................67
How To Avoid CVT Drive Belt and Component Failure ...............................................68
Dashboard Indicators and Operation ..........................................................................70
Operation of Your Vehicle........................................................................... 75
Break-In Period .........................................................................................................75
Pre-Ride Inspection.....................................................................................................77
Starting the Engine......................................................................................................78
Gear Selector Operation .............................................................................................80
Hauling and Towing Cargo ..........................................................................................83
Load Distribution .........................................................................................................85
Driving Safely ..............................................................................................................91
Maintenance............................................................................................. 107
Severe Use Denition ...............................................................................................107
Periodic Maintenance Schedule and Icon Key..........................................................108
Pre-Ride Maintenance Checklist...............................................................................110
Break-In Maintenance Checklist ...............................................................................112
Periodic Maintenance Schedule................................................................................114
Maintenance Procedures ..........................................................................................121

Cleaning and Storage............................................................................... 159
Transporting the Vehicle............................................................................................163
Vehicle Issue Diagnosis............................................................................ 164
Engine doesn’t turn over ........................................................................................164
Engine pings or knocks .............................................................................................164
Engine stops or loses power .....................................................................................165
Engine turns over, Fails to start.................................................................................166
Engine backres........................................................................................................167
Engine runs irregularly, stalls or misres...................................................................167
EFI Malfunction Indicator Light..................................................................................171
EPS Malfunction Indicator Light ...............................................................................172
Declaration ............................................................................................... 175
Declaration of Vibration declaration ..........................................................................175
Declaration of Drivers exposure to noise level .........................................................176
CFMOTO LIMITED WARRANTY ............................................................. 179

FOREWORD
5
Foreword
Welcome
Thank you for purchasing a CFMOTO vehicle, and welcome to our world-wide family of CFMOTO
enthusia󰀬s. Be sure to visit us at www.cfmoto.com for the late󰀬 news, new product introductions,
upcoming events,and more.
CFMOTO, an international company that specializes in the development, manufacture and marketing of
large displacement motorcycles, all terrain vehicles, utility vehicles, and core components (power sports
liquid cooling engines, frames,etc). Founded in 1989, CFMOTO is always devoted to the developing
routine of independent brand cultivation and independent R&D innovation. Now, CFMOTO products
are di󰀬ributed through more than 2000 companions worldwide for more than 100 countries and areas.
CFMOTO is edging into the advanced ranks in the world in the power sports indu󰀬ry, and aims to supply
superior products to dealers and fans globally.
For safe and enjoyable operation of your vehicle, be sure to follow the in󰀬ructions and recommendations
in this owner’s manual. Your manual contains in󰀬ructions for minor maintenance. Information about major
repairs is outlined in the CFMOTO Service Manual.
Your CFMOTO dealer knows your vehicle be󰀬 and is intere󰀬ed in your total satisfaction. Be sure to return
to your dealership for all of your service needs during, and after, the warranty period.
Due to con󰀬ant improvements in the design and quality of production components, some minor
discrepancies may result between the actual vehicle and the information presented in this publication.
Depictions and/or procedures in this publication are intended for reference use only.

FOREWORD
6
Signal Words
A signal word calls attention to a safety message or messages, a property damage message or messages,
and designates a degree or level of hazard seriousness. The standard signal words in this manual are
WARNING, CAUTION and NOTE or NOTICE.
Familiarize yourself with all laws and regulations concerning the operation of this vehicle in your area.
We strongly advise you to strictly follow the recommended maintenance program outlined in your owner’s
manual. This preventive maintenance program is designed to ensure that all critical components on your
vehicle are thoroughly inspected at specic intervals.
The following signal words and symbols appear throughout this manual and on your vehicle. Your safety is
involved when these words and symbols are used. Become familiar with their meanings before reading the
manual.
WARNING
This safety alert and icon indicates a potential hazard that may result in serious injury or death.
CAUTION
This safety alert and icon indicates a potential hazard that may result in minor or moderate personal injury
and/or damage to the vehicle.
CAUTION
This safety alert without an icon indicates a situation that may result in damage to the vehicle.
NOTE or NOTICE
A note or notice will alert you to important information or instructions

FOREWORD
7
WARNING
Improper vehicle use can result in SEVERE INJURY or DEATH
NEVER Operate:
• Without rst viewing owner’ s manual and quick start guide.
•Carrying more passengers than the rated passenger capacity.
• Use ALCOHOL or DRUGS before or while driving this vehicle.
• With Non-CFMOTO approved accessories.
ALWAYS:
•Keep hands and feet inside vehicle.
•Reduce speed and use extra caution when carrying a passenger.
• Operate slowly in reverse-avoid sharp turns or sudden braking.
• Make sure passenger reads and understands all safety labels.
• Watch for branches or other hazards that could enter vehicle.
• Use safety belt during operation.
Locate and Read Owner’s manual, Follow all INSTRUCTIONS and WARNINGS. If Owner’s manual is
missing, contact a CFMOTO dealer for replacement.

INTRODUCTION
8
WARNING FOR TYPE II VEHICLE
(2-person vehicle)
Improper vehicle use can result in SEVERE INJURY or DEATH
ALWAYS
USE AN
APPROVED
HELMET AND
PROTECTIVE
GEAR
NEVER
CARRY MORE
THAN ONE
PASSENGER
NEVER
USE WITH
DRUGS OR
ALCOHOL

FOREWORD
9
READ THE OWNER’S MANUAL
FOLLOW ALL INSTRUCTIONS AND WARNINGS
WARNING
Read, understand, and follow all of the instructions and safety precautions in this manual and on all
product labels. Failure to follow the safety precautions could resullt in serious injury or death.
WARNING
The engine exhaust gas from this product contains CO, which is deadly gas and could cause headache,
giddy, disgusting or lose consciousness, even death.
WARNING
Engine box cover, brake disc and mu󰀪er exhaust pipe will be hot easily after long period usage. Avoid
being burned by those parts.

INTRODUCTION
10
Introduction
Vehicle Identication Numbers
Record your vehicle’s identication numbers in the spaces provided. Remove the spare key and store in a
safe place. Your key can be duplicated only by mating a key blank with one of your existing keys.
So if both keys are lost, the complete lock assembly must be replaced.
1 Vehicle identication number:
2 Vehicle model number:
3 Engine serial number:
1
2
3

INTRODUCTION
11
Specication
Items Specications
CF800ATR-3 CF1000ATR
Overall Length 2395mm
Overall Width 1264mm
Overall Height 1420mm
Wheel Base 1480mm
Minimum ground clearance 285mm
Min. turning radius 3800mm
Basic weight:(With engine oil and full fuel in tank) 479kg 480kg
Engine model and type 2V91W-A
Type V-twin cylinder,4-stroke,liquid-cooled,8 valves,SOHC
Bore×Stroke 91mm×61.5mm 91mm×74mm
Displacement 800mL 962.6mL
Compression ratio 10.3 :1 10.6 :1
Starting type Electric start
Maximum speed 60km/h

INTRODUCTION
12
Items Specications
Engine oil:
Type
Engine oil volume:
Total engine oil volume
Oil change with lter
SAE 10W-40 /SAE 5W-40 /SAE 15W-40
2.6 L
2.5 L
Transmission oil:
Type
Periodic oil change
SAE 75W/90 GL-5
0.6L
Rear gear case oil
Type
Volume
Periodic oil change
SAE 80W/90 GL-5
0.40 L
Front gear case oil:
Type
Volume
Periodic oil change
SAE 80W/90 GL-5
0.23 L
Air lter Sponge and paper lter element

INTRODUCTION
13
Items Specications
Fuel type
Fuel tank capacity
Fuel reverse amount
95(RON) or E10
30 L
4.0 L
Spark plug:
Type
Spark plug gap
DCPR8E (NGK)
0.8mm~0.9mm
Transmission
Clutch type Dry and centrifugal automatic
Transmission (CVT)+ Gear shift
Gear shift/order Manually/L-H-N-R-P
CVT ratio 2.88~0.70
Gear ratio
Final 1.333(20/15)
Secondary 1.952(41/21)
Total L: 43/17 = 2.529 H:32/28 = 1.143 R: 29/13 = 2.231
Chassis
Frame
Caster angle
Kingpin o󰀨set
Steel tube
9°52′
25.5 mm

INTRODUCTION
14
Items Specications
Tire: Type
Size Front tire
Rear tire
Tubeless
26×9-14 / 26×9-12
26×11-14 / 26×11-12
Tubeless
27×9-12/27×9R-14
27×11-12/27×11R-14
Tire pressure:
Front tire
Rear tire
45 kPa
45 kPa
Brake system:
Front brake Type
Operation
Operation Type
Operation
Double disc
Operated by right hand
Double disc
Operated by right foot
Suspension:
Front suspension
Rear suspension
Double A-arm and independent
Double A-arm and independent

INTRODUCTION
15
Items Specications
Shock absorber:
Front shock absorber
Rear shock absorber
Coil spring/Oil damper or Coil spring + Gas/Oil damper
Coil spring/Oil damper or Coil spring + Gas/Oil
Wheel travel:
Front wheel travel
Rear wheel travel
180 mm
190 mm
Electric system
Ignition
Flywheel
ECU
A.C magneto
Headlight type
Head light LED 12V 3W ×2
Front position light LED 12V 1.2W
Tail light/Brake light 12V30Ah
Turn light LED 12V 7W×2
Battery capacity LED 12V/3W× 2 12V/18W× 2

OPERATOR SAFETY
16
Operator Safety
WARNING
Failure to heed the warnings contained in this manual can result in serious injury or death. An Vehicle
is not a toy and can be hazardous to operate. This vehicle handles di󰀨erently from other vehicles, such
as motorcycles and cars. A collision or rollover can occur quickly , even during routine maneuvers, like
turning, or over obstacles, if you fail to take proper precautions.
Read this owner’s manual. Understand all safety warnings, precautions and operating procedures before
operating an Vehicle.
Age Restrictions
This vehicle is an ADULT Vehicle ONLY. Operation is prohibited for anyone under the age of 16.
Know Your Vehicle
As the operator of the vehicle, you are responsible for your personal safety, the safety of others, and
the protection of our environment. Read and understand your owner’s manual, which includes valuable
information about all aspects of your vehicle, including safe operating procedures.

OPERATOR SAFETY
17
Equipment Modications
We are concerned with the safety of our customers and for the general public. Therefore,we strongly
recommend that consumers do not install on an Vehicle any equipment that may increase the speed or
power of the vehicle, or make any other modications to the vehicle for these purposes. Any modications
to the original equipment of the vehicle create a substantial safety hazard and increase the risk of body
injury. The warranty on your Vehicle is terminated if any equipment has been added to the vehicle, or if
any modications have been made to the vehicle, that increase its speed or power.
NOTE
The addition of certain accessories, including (but not limited to) mowers, blades, tires, sprayers, or
large racks, may change the handling characteristics of the vehicle. Use only approved accessories, and
familiarize yourself with their function and e󰀨ect on the vehicle.

OPERATOR SAFETY
18
Avoid Burns from Hot Parts
Certain components become hot during operation. Avoid contact with those parts during and shortly after
operation to avoid burns.
Pulling a Trailer
Check the maximum axle loads of the vehicle identification plate (statutory plate). CFMOTO vehicle
can tow a trailer on the road. Check the trailer,the maximum loads on the identification plate. Check
the national packages limits the use of a vehicle-trailer on the road. Connect the trailer lights and
set the slow moving vehicle triangle behind the trailer.
NOTE
A CFMOTO approved rear hitch must be properly installed on the vehicle for hauling trailers. Riding this
vehicle with a trailer substantially increases the risk of toppling, especially on inclined slopes. If a trailer is
used behind the vehicle make sure that its hitch is compatible with the one on the vehicle. Make sure the
trailer is horizontal with the vehicle.(In some instances a special extension may have to be installed on the
vehicle hitch).Use security chains or cables to secure the trailer with the vehicle.
Reduce your speed when pulling a trailer and turn gradually. Avoid hills and rough terrain. Never attempt
steep hills. Allow more distance for braking, especially on inclined surfaces and when a passenger is on
board. Be careful not to skid or slide.

OPERATOR SAFETY
19
Safety Training
When you purchased your vehicle, your dealer offered a hands-on safety training course that covers
all aspects of vehicle safety. You were also provided with printed materials that explain safe operating
procedures. You should review this information on a regular basis. If you purchased a used Vehicle from a
party other than a dealer, you can request safety training from any authorized dealer. Familiarize yourself
with all laws and regulations concerning the operation of Vehicles in your area. CFMOTO strongly advises
you to strictly follow the recommended maintenance program outlined in your owner’s manual. This
preventive maintenance program is designed to ensure that all critical components on your vehicle are
thoroughly inspected and serviced at specic intervals for safety.
Hazardous Operation Warnings
Serious injury or death can result if you do not follow the following instructions and procedures outlined in
further detail within your owner’s manual:
WARNING
●Never operate a vehicle without proper instruction.
●Never allow anyone under 16 years of age to operate this vehicle.
●Never permit a guest to operate the vehicle unless the guest has read this manual and all product labels
and has completed a certied safety training course.
●Never operate an vehicle without wearing an approved helmet that fits properly. Always wear eye
protection (goggles or face shield),gloves,boots,a long-sleeved shirt or jacket,and long pants.
●Never consume alcohol or drugs before or while operating a vehicle.

OPERATOR SAFETY
20
●Never operate at excessive speeds. Travel at speeds appropriate for the terrain, visibility and operating
conditions, and your experience.
●Never attempt wheelies,jumps or other stunts.
●Always inspect your vehicle before each use to make sure it’s in safe operating condition.
●Always follow the inspection schedules and maintenance outlined in your owner’s manual.
●Always keep both hands on the handlebars and both feet on the foot-rests of the Vehicle during
operation.
●Always travel slowly and use extra caution when operating on unfamiliar terrain. Be alert to changing
terrain conditions.
●Never operate on excessively rough,slippery,or loose terrain.
●Always follow proper turning procedures as described in this manual. Practice turning at low speeds
before attempting to turn at faster speeds. Do not turn at excessive speeds.
●Always have the vehicle inspected by an authorized dealer if it’s been involved in an accident.
●Never operate on hills too steep for the vehicle or for your abilities. Practice on smaller hills before
attempting larger hills.
●Always follow proper procedures for climbing hills:
▪ Check the terrain carefully before ascending a hill.
▪ Never climb hills with excessively slippery or loose surfaces.
▪Shift your weight forward.
▪ Never open the throttle suddenly or make sudden gear changes.
▪ Never go over the top of a hill at high speed.
