CF MOTO ZFORCE 800EX User manual

This ROV should not be ridden by anyone under 16
years of age. Passenger under 12 are prohibited.
ZFORCE 800EX
ZFORCE 1000
ZFORCE 500TRAIL
ZFORCE 800TRAIL
READ THIS MANUAL CAREFULLY
It contains important safety information
ZFORCE
SERIES
OWNER'S MANUAL

TABLE OF CONTENTS
ForewordForeword .................................................................................................................................................................................................................. 11
WelcomeWelcome .................................................................................................................................................................................................................................................... 11
EVAP System (Evaporative Emission Control System)EVAP System (Evaporative Emission Control System) ...................................................................................................... 22
Catalytic ConverterCatalytic Converter...................................................................................................................................................................................................................... 22
Signal WordsSignal Words........................................................................................................................................................................................................................................ 33
IntroductionIntroduction ............................................................................................................................................................................................................................................ 66
Vehicle Identication NumbersVehicle Identication Numbers.................................................................................................................................................................................. 77
ZFORCE 1000 SpecicationsZFORCE 1000 Specications .................................................................................................................................................................................... 88
ZFORCE 800 EX SpecicationsZFORCE 800 EX Specications ........................................................................................................................................................................ 1515
ZFORCE 800 Trail SpecicationsZFORCE 800 Trail Specications .................................................................................................................................................................... 2222
ZFORCE 500 Trail SpecicationsZFORCE 500 Trail Specications .................................................................................................................................................................... 2929
Operator SafetyOperator Safety .......................................................................................................................................................................................... 3636
General Safety PrecautionsGeneral Safety Precautions ...................................................................................................................................................................................... 3636
Owner ResponsibilitiesOwner Responsibilities...................................................................................................................................................................................................... 3939
Safety Labels, Locations and WarningsSafety Labels, Locations and Warnings.................................................................................................................................................. 4444
Potential Hazard WarningsPotential Hazard Warnings.......................................................................................................................................................................................... 4949
Controls and FeaturesControls and Features...................................................................................................................................................................... 6969
Primary ControlsPrimary Controls ........................................................................................................................................................................................................................ 6969
Secondary ControlsSecondary Controls................................................................................................................................................................................................................ 7272
Vehicle FeaturesVehicle Features ........................................................................................................................................................................................................................ 7878

CVT SystemCVT System ...................................................................................................................................................................................................................................... 8585
Engine Braking System (EBS) - 800cc Engines OnlyEngine Braking System (EBS) - 800cc Engines Only ........................................................................................................ 8686
How To Avoid CVT Drive Belt and Component FailureHow To Avoid CVT Drive Belt and Component Failure .................................................................................................... 8787
Dashboard Indicators and WarningsDashboard Indicators and Warnings ............................................................................................................................................................ 8989
Operating Your VehicleOperating Your Vehicle.................................................................................................................................................................... 9494
Break-In PeriodBreak-In Period ............................................................................................................................................................................................................................ 9494
Pre-Ride InspectionPre-Ride Inspection................................................................................................................................................................................................................ 9696
ThrottleThrottle ...................................................................................................................................................................................................................................................... 9696
Foot BrakeFoot Brake............................................................................................................................................................................................................................................ 9696
Starting the EngineStarting the Engine.................................................................................................................................................................................................................. 9797
Shifting the TransmissionShifting the Transmission .............................................................................................................................................................................................. 9898
Safe Operation - Driving SafelySafe Operation - Driving Safely...................................................................................................................................... 101101
Responsibilities of the OperatorResponsibilities of the Operator ...................................................................................................................................................................... 101101
Practice ExercisesPractice Exercises................................................................................................................................................................................................................ 105105
Operating Your VehicleOperating Your Vehicle.................................................................................................................................................................................................. 108108
Hauling and Towing LoadsHauling and Towing Loads ...................................................................................................................................................................................... 113113
Winch OperationWinch Operation .................................................................................................................................................................................................................... 118118
MaintenanceMaintenance................................................................................................................................................................................................ 128128
Severe Use DenitionSevere Use Denition .................................................................................................................................................................................................... 129129
Periodic Maintenance Schedule and Icon KeyPeriodic Maintenance Schedule and Icon Key.......................................................................................................................... 130130

General Recommended LubricationGeneral Recommended Lubrication ........................................................................................................................................................ 131131
Pre-Ride Maintenance ChecklistPre-Ride Maintenance Checklist.................................................................................................................................................................... 132132
Break-In Maintenance ChecklistBreak-In Maintenance Checklist .................................................................................................................................................................... 134134
Periodic Maintenance SchedulePeriodic Maintenance Schedule...................................................................................................................................................................... 136136
Maintenance ProceduresMaintenance Procedures .......................................................................................................................................................................................... 143143
Cleaning and StorageCleaning and Storage.................................................................................................................................................................... 180180
Transporting the vehicleTransporting the vehicle .............................................................................................................................................................................................. 184184
Vehicle Issue DiagnosisVehicle Issue Diagnosis.............................................................................................................................................................. 185185
Engine starter doesn’t turn onEngine starter doesn’t turn on ...................................................................................................................................................................... 185185
Engine pings or knocksEngine pings or knocks ................................................................................................................................................................................................ 185185
Engine stops or loses powerEngine stops or loses power ................................................................................................................................................................................ 186186
Engine turns over, Fails to startEngine turns over, Fails to start........................................................................................................................................................................ 187187
Engine backresEngine backres...................................................................................................................................................................................................................... 188188
Engine runs irregularly, stalls or misresEngine runs irregularly, stalls or misres............................................................................................................................................ 188188
EFI Malfunction Indicator LightEFI Malfunction Indicator Light.......................................................................................................................................................................... 190190
EPS Malfunction Indicator LightEPS Malfunction Indicator Light ...................................................................................................................................................................... 191191
Electronic Power Steering (EPS) fault diagnosis and solutionElectronic Power Steering (EPS) fault diagnosis and solution.......................................................................... 193193
CFMOTO Limited WarrantyCFMOTO Limited Warranty.................................................................................................................................................. 194194
WARRANTY TERMS & CONDITIONSWARRANTY TERMS & CONDITIONS ................................................................................................................................................ 194194
U.S.A. EPA and CARB Emissions Control Limited WarrantyU.S.A. EPA and CARB Emissions Control Limited Warranty .............................................................................. 202202
Noise Control System and TamperingNoise Control System and Tampering.................................................................................................................................................... 206206
Change of OwnershipChange of Ownership .................................................................................................................................................................................................... 207207

1
FOREWORD
Foreword
Welcome
Thank you for purchasing a CFMOTO vehicle, and welcome to our world-wide family of CFMOTO
enthusia󰀬s. Be sure to visit us online at www.cfmoto.com for the late󰀬 news, new product introductions,
upcoming events, and more.
CFMOTO is an international company that specializes in the development, manufacture, and marketing of
all-terrain vehicles, utility vehicles, large displacement motorcycles, and their core components. Founded
in 1989, CFMOTO is devoted to the development of independent brand cultivation and R&D innovation.
CFMOTO products are currently di󰀬ributed through more than 2000 companions worldwide in more than
100 countries and regions. CFMOTO is edging into the advanced ranks in the world of powersports, and
aims to supply superior products to dealers and fans globally.
For safe and enjoyable operation of your vehicle, be sure to follow the in󰀬ructions and recommendations
in this owner’s manual. Your manual contains in󰀬ructions for minor maintenance. Information about major
repairs is outlined in the CFMOTO Service Manual.
Your CFMOTO dealer knows your vehicle be󰀬 and is intere󰀬ed in your total satisfaction. Be sure to return to
your dealership for all of your service needs during, and after, the warranty period.
Due to con󰀬ant improvements in the design, quality, or conguration of production components, some
minor discrepancies may result between the actual vehicle and the information presented in this publication.
CFMOTO reserves the right to change product features, specications and components without notice or
incurring obligation to the purchaser. Depictions and/or procedures within are intended for reference use
only. The mo󰀬 current version of this manual may be available on the CFMOTO consumer website of the
market you reside in.

2
FOREWORD
WARNING
The engine exhau󰀬 from this product contains chemicals known to the State of California to cause
cancer, birth defects or other reproductive harm.
EVAP Sy󰀬em (Evaporative Emission Control Sy󰀬em)
(If equipped)
When required by environmental emissions regulations, this vehicle is manufactured with a fuel evaporation
sy󰀬em (EVAP) to prevent fuel vapors entering the atmosphere from the fuel tank and fuel sy󰀬em.
During routine maintenance, visually inspect all hose connections for leaks or blockage. Ensure the hoses
are not clogged or kinked, which could damage the fuel pump or di󰀬ort the fuel tank. No other maintenance
is necessary.
Contact your dealer if repair is required. Do not modify the EVAP sy󰀬em. Modifying any part of this sy󰀬em
will violate environmental emissions regulations.
Catalytic Converter
CAUTION: Please pay attention to the following to protect your catalytic converter:
• Use only unleaded gasoline. Even gasoline that contains a little lead could damage the reactive
metals contained in the catalytic converter and disable it.
• Never add ru󰀬 preventive oil or engine oil into the mu󰀪er. Doing so could damage the catalytic
converter.
NOTE
Some features described within this manual may not apply to models sold in North America.
All descriptions and directions given are from the operator’s perspective when properly seated.

3
FOREWORD
Signal Words
A signal word calls attention to a safety message or messages, a property damage message or messages,
and designates a degree or level of hazard seriousness. The standard signal words in this manual are
WARNING, CAUTION and NOTE or NOTICE.
The following signal words and symbols appear throughout this manual and on your vehicle. Your safety is
involved when these words and symbols are used. Become familiar with their meanings before reading the
manual:
WARNING
This safety alert and icon indicates a potential hazard that may result in serious injury or death.
CAUTION
This safety alert and icon indicates a potential hazard that may result in minor or moderate personal injury
and/or damage to the vehicle.
CAUTION
This safety alert without an icon indicates a situation that may result in damage to the vehicle.
NOTE or NOTICE
A note or notice will alert you to important information or instructions

4
FOREWORD
NEVER:
Operate without proper training or instruction.
Operate on public roads. A collision can occur with another vehicle.
Operate on paved roads. Pavement may seriously a󰀨ect handling and control.
Operate at speeds too fast for your skill, conditions, or the terrain.
Carry multiple passengers, SSVs are designed for a single passenger only.
Use ALCOHOL or DRUGS before or while driving this vehicle.
ALWAYS:
Avoid paved surfaces, which may adversely a󰀨ect the handling and control.
Use proper driving techniques to avoid vehicle overturn on hills, rough terrain, and when turning.
Wear eye protection, helmet and protective clothing.

5
FOREWORD
READ THE OWNER’S MANUAL
FOLLOW ALL INSTRUCTIONS AND WARNINGS
WARNING
Read, under󰀬and, and follow all of the in󰀬ructions and safety precautions in this manual and on all
product labels. Failure to follow the safety precautions could result in serious injury or death.
WARNING
The engine exhau󰀬 gas from this product contains CO, which is deadly gas and could cause
headaches, giddy, or lose consciousness, even death.

6
INTRODUCTION
Introduction
Thank you for purchasing a CFMOTO vehicle, and welcome to our world-wide family of CFMOTO
enthusiasts.
For safe and enjoyable operation of your vehicle, be sure to follow the instructions and recommendations
in this owner’s manual. Information about major repairs are outlined in the CFMOTO Service Manual, and
should only be performed by a CFMOTO service dealer and technician. Be sure to return to your dealership
for all of your service needs during, and after, the warranty period.
If you have questions or concerns about your vehicle
All questions or concerns related to your vehicle should be directed to your local CFMOTO dealer rst. Your
dealer knows your vehicle best and is interested in your total satisfaction. In the event your local dealer is
unable to resolve a product issue or concern, you can reach a CFMOTO customer service representative
depending on the market you reside in:
For USA: Please contact CFMOTO POWERSPORTS, INC. TEL: [phone], by e-mail: info@cfmotousa.
com, or online: https://cfmotousa.com/customer-care/customer-care-contact. Please note that customer
service does not have authority to approve or deny warranty, and cannot provide technical repair data,
diagnosis, or instructions.
For CANADA: Please contact CANADA MOTOR IMPORT INC. TEL: [phone], or online: https://www.
cfmoto.ca/en/customer-care/.
For a safety concern related to your Canadian vehicle, you may report your concern to Transport Canada
Defect Investigation and Recalls Division by mail, telephone, or online using the contact information below:
Mailing address: Transport Canada - ASFAD, 330 Sparks Street, Ottawa, ON, K1A 0N5
TEL: [phone] (Ottawa-Gatineau area or international) or toll-free: 1-800-333-0510 (In Canada)
Online: http://www.tc.gc.ca/recalls

7
INTRODUCTION
Vehicle Identication Numbers
Record your vehicle’s identication numbers in the spaces provided.
RH Frame RH Engine
1Vehicle Identication Number:
2Engine Serial Number:
Ignition Keys
Remove the spare ignition key and store in a safe place. Your key can be duplicated only by mating a
CFMOTO key blank with one of your existing keys. If both keys are lost, the complete lock assembly must be
replaced.
1
2

8
SPECIFICATIONS
ZFORCE 1000 Specications
Item ZFORCE 1000 Specication
CF1000US-2
Overall Length 112.9 in. (2870 mm)
Overall Width 59.4 in (1510 mm)
Overall Height 72.6 in. (1845 mm)
Wheel Base 80.3 in. (2040 mm)
Minimum ground clearance 12.2 in. (310 mm)
Min. turning radius 187 in. (4750 mm)
Basic weight 1344 lb. (610 kg)
Rear cargo box weight capacity 220.3 lb. (100 kg)
Maximum vehicle load allowed 694 lb.(315 kg)
Recommended towing capacities:
Tongue weight
Trailer and Cargo weight
110 lb. (50 kg)
550 lb. (250 kg)
Engine model and type 2V91Y
Type V-twin, Liquid-cooled/4-stroke, 8 valves, SOHC

9
SPECIFICATIONS
Item ZFORCE 1000 Specication
CF1000US-2
Bore × Stroke 3.5 x 2.42 in (91 x 74 mm) x 2
Displacement 962.6 cc
Compression ratio 10.6:1
Starting type Electric start
Lubrication type Splash /pressure feed
Engine coolant:
Type
Capacity
Mix Ratio
Commercially available – Safe for aluminum engines
3.1 qt. (3.0 L)
50% coolant / 50% distilled water
Engine oil:
Type
Engine oil volume:
Capacity change / oil lter
SAE 10W-40 / SAE 5W-40 / SAE 15W-40
(See page 95 for oil viscosity chart)
3.06 qt. (2.5L)
Transmission oil:
Type
Periodic oil change
SAE75W/90 GL-5
(0.6L)

10
SPECIFICATIONS
Item ZFORCE 1000 Specication
CF1000US-2
Rear di󰀨erential oil:
Type
Volume
SAE 80W-90 GL-5
13.5 oz.(400mL)
Front di󰀨erential oil:
Type
Volume
SAE 80W-90 GL-5
11.2 oz. (330mL)
Air lter Paper lter element with foam pre-lter
Fuel type
Fuel tank capacity
Fuel reserve amount at fuel gauge
‘ash’(approximate)
89 Octane minimum unleaded gasoline
7.1 gallons (27 L)
0.9 gallons. (3.5 L)
Throttle Body type: 0JY0-173000

11
SPECIFICATIONS
Item ZFORCE 1000 Specication
CF1000US-2
Spark plug: type
Spark plug gap
DCPR8E (NGK)
0.035 in. ~ 0.045 in. (0.8 mm~0.9 mm)
Transmission
Transmission CVT + Gear shift
Gear shift/order Manual / L-H-N-R-P
CVT ratio 0.70~2.88
Gear
ratio
Low Gear 43/17=2.529
High Gear 32/28=1.143
Reverse 29/13=2.231
Chassis Frame Steel tube
Tires:
Type
Front
Rear
Wheel Bolt Pattern
Tubeless
AT 27×9.0-14 60L or AT 27×9.0-14 61L
AT 27×11.0-14 66L or AT 27×11.0-14 70L
4x110mm

12
SPECIFICATIONS
Item ZFORCE 1000 Specication
CF1000US-2
Tire pressure:
Front
Rear
10.1 psi (70 kPa)
14.5 psi (100 kPa)
Brake system:
Foot brake Type / Operation
Parking brake Type / Operation
Front axles: Double-disc / Rear axles: Double-disc
Foot Operated
Four wheel disc
Operated by hand
Rear discs only
Brake Fluid Type DOT 4
Suspension:
Front suspension
Rear suspension
Double A-arm independent
Double A-arm independent

13
SPECIFICATIONS
Item ZFORCE 1000 Specication
CF1000US-2
Shock absorber:
Front shock absorber
Rear shock absorber
Coil spring/Gas and Oil dampened
Coil spring/Gas and Oil dampened
Wheel travel:
Front wheel travel
Rear wheel travel
6.3 in. (160 mm)
7.8 in. (200 mm)
Electrical system:
Ignition
Charging
Battery
Electronic
Rectied A/C 460 Watt @ 5000 rpm
12Vdc / 30 Amp Hr

14
SPECIFICATIONS
Item ZFORCE 1000 Specication
CF1000US-2
Light system:
Head lamp, low beam
Head lamp, high beam
Front position light
Tail light/Brake light
License plate light
H3 12V 55W×2
H7 12V 55W×2
LED
LED
Incandescent - 5Wx1
Dashboard LED and LCD -- Non-serviceable
Fuses Main – 30 Amp x 1
EPS – 40 Amp x 1
Auxiliary - 10 Amp x 2
Auxiliary – 15 Amp x 3
ECU – 5 Amp x 1

15
SPECIFICATIONS
ZFORCE 800 EX Specications
Item ZFORCE 800 EX Specication
CF800
Overall Length 112.9 in. (2870 mm)
Overall Width 59.4 in (1510 mm)
Overall Height 72.0 in. (1830 mm)
Wheel Base 80.3 in. (2040 mm)
Minimum ground clearance 12.2 in. (310 mm)
Min. turning radius 187 in. (4750 mm)
Basic weight 1267 lb. (575 kg)
Rear cargo box weight capacity 330 lb. (150 kg)
Maximum vehicle load allowed 694 lb.(315 kg)
Recommended towing capacities:
Tongue weight
Trailer and Cargo weight
110 lb. (50 kg)
550 lb. (250 kg)
Engine model and type 2V91W
Type V-twin, Liquid-cooled/4-stroke, 8 valves, SOHC

16
INTRODUCTION
Item ZFORCE 800 EX Specication
CF800
Bore × Stroke 3.5 x 2.42 in (91 x 61.5 mm) x 2
Displacement 800 cc
Compression ratio 10.3:1
Starting type Electric start
Lubrication type Splash /pressure feed
Engine coolant:
Type
Capacity
Mix Ratio
Commercially available – Safe for aluminum engines
3.1 qt. (3.0 L)
50% coolant / 50% distilled water
Engine oil:
Type
Engine oil volume:
Capacity change / oil lter
SAE 10W-40 / SAE 5W-40 / SAE 15W-40
Engine oil should be JASO-certed
(See page 95 for oil viscosity chart)
3.59 qt. (3.4L)
