Champion TRISYS SSG M3 Owner's manual

Issue Date: 6.8.18
Manual P/N 116088 rev. B
For machines beginning with S/N SG18020035 and above
2674 N. Service Road, Jordan Station
Ontario, Canada L0R 1S0
[phone] Fax: [phone]
Toll-free: 1 [phone]
3765 Champion Boulevard
Winston-Salem, NC 27105
[phone] Fax: [phone]
Toll-free: 1 [phone]
Printed in the USA
INSTALLATION, OPERATION, AND CLEANING
SSG M3
Slow Speed Grinder
and Waterpress
Close-coupled and Remote
Model:
TRISYS

COPYRIGHT © 2018 All rights reserved Printed in the USA
ATTENTION
The model no., serial no., voltage, Hz
and phase are needed to identify your
machine.
The machine data plate
is located on the front
of the control cabinet.
Please have this information ready
if you call for service assistance.
National Service Department
In Canada: In the USA:
Toll-free: [phone] Toll-free: [phone]
Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone]
email: [email protected] email: [email protected]

i
Revision History
Revision History
Revision Revised Serial Number Revision
Date Pages Effectivity Description
4.25.18 All SG18020035 Released First Edition
6.8.18 7-8 SG18050042 Added remote plumbing notes
12-15 SG18050042 Added remote junction boxes
Specifications are subject to change based on continual product improvement. Equipment
owners may request a revised manual, at no charge, by calling 1 [phone] in the USA or
1(800) 263-5798 in Canada.

ii
Revision History........................................................................................................................................... i
Load Warning ............................................................................................................................................ iv
Limited Warranty........................................................................................................................................ v
Table of Contents
Installation ..................................................................................................1
Installation Codes.....................................................................................1
Safety Symbols .........................................................................................1
System Overview......................................................................................2
Site Inspection..........................................................................................2
Table of Contents
System Components ..................................................................................3
Receiving ..................................................................................................3
Placement.................................................................................................3
Standard 9" Trough Adapter (Facotry Supplied) .....................................4
Trough Flush Gusher Head (Factory Supplied) ........................................4
Silver Saver Grabber Mangnet (Factory Supllied)....................................5
Hardware Kit (Factory Supplied) ..............................................................5
Special Tools (Supplied by Others) ..........................................................5
Control Cabinet and Start/Stop Station...................................................5
Plumbing Connections ...............................................................................6
Cold Water Fill..........................................................................................6
Hot Water Flush........................................................................................6
Plumbing Diagrams ..................................................................................7
Electrical Connections................................................................................9
Main Control Cabinet................................................................................9
Conduit Routing ......................................................................................10
Checking Motor Rotation........................................................................10
Control Cabinet Wiring ...........................................................................11
Junction Box Wiring ................................................................................12
SSG Installation Manual

iii
Table of Contents
Operation...................................................................................................14
Pre-Operation System Checks ................................................................ 14
E-STOP Emergency Stop Switch.............................................................15
Normal Operation ...................................................................................16
Initial Fill ..................................................................................................16
Run Mode- Balancing the System ........................................................... 17
Run Mode- Processing Waste .................................................................18
Cleaning .....................................................................................................19
Clean Mode............................................................................................. 19
Waterpress ..............................................................................................20
Feed Trough ............................................................................................21
Extended Shutdown................................................................................ 21
Alarms ........................................................................................................19
Door Open ..............................................................................................22
Motor Overload.......................................................................................23
HMI Troubleshooting Screens .........................................................24
I/O = Inputs Screen .................................................................................24
Outputs Screen .......................................................................................25
Maintenance Mode (Service Only) .......................................................... 26
Manual Control ..............................................26
Rinse Setpoints...............................................29
Keypad ...........................................................30
Clean Setpoints..............................................30
Revision ..........................................................31
Troubleshooting Chart ............................................................................................ 32

iv
LOAD WARNING - AVERTISSEMENT - ADVERTENCIA
English
ATTENTION
This equipment is designed only for food waste reduction, (napkins, paper towels and
cardboard are acceptable).
! LOAD WARNING !
Do not load flatware, service ware, plastics, large bones, raw bones, (shells: clam, oyster,
mussel, shrimp, crab, lobster, scallop, walnut, peanut, pecan, almond, or any other type of
shell not listed), wood, or rags. Do not dump bulk quantities from tubs, garbage cans, or
other large containers directly into the machine or feed troughs.
En Francais
ATTENTION
Cet appareil est uniquement conçu pour la réduction de déchets alimentaires, (serviettes
de papier et cartons sont également acceptables).
! AVERTISSEMENT DE CHARGE !
Ne pas charger de coutellerie, d’ustensiles de service, de plastiques, d’os large ou cru,
(de coquillage: praire, huitre, moule, crevette, crabe, homard, pétoncle, noyer, arachide,
pacane, amande, ou tout autre type de noix ), bois, guenille. Ne pas déverser directement
dans l’appareil ou dans l’auge, de grandes quantitées de déchets, provenant de poubelles,
cuves ou autres récipients en vrac.
En español
ATENCIÓN
Este equipo es diseñado solamente para la reducción de residuous de alimentos,
(servilletas, toallas de papel y cartón son aceptables).
! ADVERTENCIA DE CARGA!
No cargue platos, cubiertos, utensilios de cocina, plásticos, huesos, grandes, huesos
crudos, cáscaras o caracoles de (almeja, ostra, mejillón, camarón, cangrejo, langosta, vieira,
nuez, maní, nuez de pacana, almendra o cualquier otro tipo de cascara o caracol aunque no
aparesca en esta lista), madera o trapos. No use tinas, cestos de basura u otros envases
para descargar grandes cantidades de residuos de alimentos directamente en la máquina,
o en la entradas de canales.

v
Continued on next page.
Champion Industries (herein referred to as the “The Company”), 3765 Champion Blvd., Winston-
Salem, North Carolina 27105, and 2674 N. Service Road, Jordan Station, Ontario, Canada, L0R
1S0, warrants machines, and parts, as set out below.
Warranty of Machines: The Company warrants all new waste processing machines of its
manufacture bearing the name “Champion”, “Trisys”, or “Champion-Trisys” and installed within
the United States and Canada to be free from defects in material and workmanship for a period of
one (1) year after the date of installation or fifteen (15) months after the date of shipment by the
The Company, whichever occurs first. Warranty registration must be submitted to the The Company
within ten (10) days after installation either online at the Champion Industries website (http://www.
championindustries.com/warranty-registration or by fax to [phone] in the USA or (905) 562-
4618 in Canada. The Company will not assume any responsibility for extra costs for installation in
any area where there are jurisdictional problems with local trades or unions.
If a defect in workmanship or material is found to exist within the warranty period, The Company,
at its election, will either repair or replace the defective part or accept return of the machine for
full credit. In the event that The Company elects to repair, the labor and work to be performed in
connection with the warranty shall be done during regular working hours by a Champion authorized
service technician. Defective parts become the property of The Company. Use of replacement parts
not authorized by The Company will relieve The Company of all further liability in connection with
its warranty. In no event will The Company’s warranty obligation exceed The Company’s charge for
the machine.
Approved Waste: Only food, paper napkins, paper towels, and carboard waste are approved
for loading into the machine.
Prohibited Waste: Examples of prohibited waste that must not be loaded into the machine
and not covered by the warranty include, but are not limited to:
a. Flatware, service ware, plastics, large bones, raw bones, (shells: clam, oyster, mussel,
shrimp,crab, lobster, scallop, walnut, peanut, pecan, almond, or any other type of shell not
listed), wood, rags, or nitrile gloves.
b. Loading bulk quantities of waste from tubs, garbage cans, or other large containers directly
into the machine or feed troughs.
c. Metal of any type.
The following are not covered by the warranty:
a. Clogs or damage to any part of the machine due to the loading of prohibited waste.
b. Replacement of fuses or resetting of overload breakers.
c. Opening or closing of utility supply valves or switching of electrical supply current.
d. Cleaning of valves, strainers, screens, nozzles, or spray pipes.
e. Performance of regular maintenance and cleaning.
f. Damages resulting from water conditions, accidents, alterations, improper use, abuse,
tampering, improper installation, or failure to follow maintenance and operation procedures.
Examples of the defects not covered by the warranty include, but are not limited to: (1) Damage
to the exterior or interior finish as a result of the above, (2) Use with utility service other than
that designated on the rating plate, (3) Improper connection to utility service, (4) Inadequate or
excessive water pressure, (5) Corrosion from chemicals dispensed in excess of recommended
concentrations, (6) Failure of electrical components due to connection of chemical dispensing
equipment installed by others,
(7) Leaks or damage resulting from such leaks caused by the installer, including those at machine
trough connections or by connection of chemical dispensing equipment installed by others, (8)
Failure to comply with local building codes, (9) Damage caused by labor dispute.
LIMITED WARRANTY AGREEMENT

vi
I acknowledge and agree that a I have read and understand this Limited Warranty Agreement.
I agree that the restrictions contained in this Limited Warranty Agreement are reasonable,
proper and necessitated by The Company’s legitimate interests and the legitimate interests
of its subsidiaries and affiliated entities. I acknowledge and agree that I am entering into this
Limited Warranty Agreement freely and with the intent to be bound by this Limited Warranty
Agreement.
Warranty of Parts: The Company warrants all new machine parts produced or authorized by
The Company to be free from defects in material and workmanship for a period of 90 days
from date of invoice. If any defect in material and workmanship is found to exist within the
warranty period The Company will replace the defective part without charge.
DISCLAIMER OF WARRANTIES AND LIMITATIONS OF LIABILITY. THE COMPANY’S
WARRANTYISONLYTOTHEEXTENTREFLECTEDABOVE.THECOMPANYMAKESNOOTHER
WARRANTIES, EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED, TO ANY WARRANTY
OF MERCHANTABILITY, OR FITNESS OF PURPOSE. THE COMPANY SHALL NOT BE LIABLE
FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES. THE REMEDIES SET OUT ABOVE ARE
THEEXCLUSIVEREMEDIESFORANYDEFECTSFOUNDTOEXISTINTHECOMPANY’S WASTE
PROCESSING MACHINES AND THE COMPANY’S PARTS, AND ALL OTHER REMEDIES ARE
EXCLUDED,INCLUDINGANYLIABILITYFORINCIDENTALSORCONSEQUENTIALDAMAGES.
The Company does not authorize any other person, including persons who deal in Champion
dishwashing machines to change this warranty or create any other obligation in connection
with Champion, Trisys and Champion-Trisys machines.
LIMITED WARRANTY AGREEMENT (continued)
AGREEMENT SIGNATURE
ACCEPTED AND AGREED:
____________________________________
(Signature)
____________________________________________
(Printed Name and Title)
Dated:______________________________
BUYER

1
Installation
Installation Codes
The installation of the SSG must comply with all local electrical, plumbing, health and safety
codes or in the absence of local codes, installed in accordance with the applicable require-
ments in the National Electrical Code, NFPA 70, Canadian Electrical Code (CEC), Part 1, CSA
C22.1.
NOTE:
Only qualified personnel familiar with the installation of food service equipment should
attempt the installation of this machine. Damage or problems associated with improper
installation will not be covered by the dishwasher limited warranty.
Safety Symbols
WARNING:
Warning statements indicate a condition or practice that can result in personal
injury or possible death.
CAUTION:
Caution statements indicate a condition or practice that can result in damage
to the machine or associated equipment.
NOTE:
Note statements highlight important information necessary for the operation
of the machine.
The following symbols are used throughout this manual to alert the reader to important
information.
DANGER
DO NOT OPERATE
WITHOUT GUARDS
IN PLACE
P/N 116135
DANGER:
THE GRINDER CONTAINS ROTATING CUTTERS.
DO NOT OPERATE WITHOUT GUARDS IN PLACE.

2
Installation
Site Inspection
The SSG food waste processing system consists of a slow speed grinder to macerate a
combination of 70% food and 30% paper. The waste is mixed with water to produce a slurry.
The slurry is pumped to a waterpress that separates the water producing a semi-dry pulp. The
water is recirculated to a feed trough system as the pulp is discharged into the customer's
waste containers.
SSG close-coupled (SSG-C): The grinder, slurry tank, recirculation tank, pumps, waterpress
form a single unit. The main control cabinet is wall-mounted with an umounted start/stop
station.
SSG Remote (SSG-R): The grinder and slurry tank form one unit and the recirculation tank,
recirc pump, and waterpress form the second unit. The main control cabinet is wall-mounted
with an umounted start/stop station.
System Overview
Fig. 1 - The P&E drawing must be present at the installation site.
SAMPLE ONLY
SAMPLE ONLY
CAUTION:
An approved copy of the plumbing and electrical, P&E, drawing must be
present at the installation site. Improper installation is not covered by the
limited warranty. Check the site electrical and plumbing to ensure they match
those on the P&E.

3
Water Press
Installation
• The SSG may have shipped on multiple pallets. Remove the unit(s) from the pallet(s) and
move to their permanent location.
• Place the grinder and waterpress no less that 2 feet apart.
• Adjust the height and level of the machines using the adjustable legs. Level the
components from side-to-side and front-to-back.
Receiving
Inspect the machine for damage. If damaged, save the packing material and immediately
report damage to a supervisor. The system may have shipped on more than one pallet. Check
the shipping container for parts and accessories that shipped with the machine.
Placement
Fig. 2 -
Close-coupled system shown.
LEVEL ADJUSTMENT
CAUTION:
Use care when moving the machine components to
prevent damage. Damage due to improper moving
is not covered by the limited warranty.
Components
Grinder

4
Installation
Trough Flush Gusher Head (Factory Supplied)
A gusher head and 1-1/2" shut-off valve supplies recirculated water from the SSG to the
trough. The gusher head may ship with the SSG or sent to the trough fabricator.
Gusher Head
Feed Trough (by others)
Gusher Head
Gusher
Throttle
Valve
1-1/2" from
Waterpress
Recirc Pump
Fig. 4
Standard 9" Trough Adapter (Factory Supplied)
The grinder unit is equipped with a 9" opening trough adapter to connect a feed trough,
(supplied by others), to the inlet of the grinder. The adapter is shipped with a rubber gasket,
P/N 111873, and fasteners.
Fig. 3
Components
CL
(9)7/32"Ø
71
4"51
2"
23
4"
27
16 "
47
8"
93
4"
10 1
2"
9"
OPENING
3
4"FLANGE
53
4"
OPENING

5
Installation
Installation
Special Tools (Supplied by Others)
The following special tools are needed for the installation.
(1) 3/8" electric drill, (1) 1-3/8" hole saw for 1" conduit, (1) 7/8" hole saw for 1/2" conduit.
Silver Saver Grabber Magnet (Factory Supplied)
Permanent magnets are standard equipment to prevent silverware and other ferrous metals
from entering the grinder unit. The magnets are usually shipped to the trough fabricator for
installation.
Hardware Kit (Factory Supplied)
The trough adapter gasket, fasteners, and conduit fittings are packaged and placed inside
the trough adapter.
Control Cabinet and Start/Stop Station
The main control cabinet is wall-mounted and installed by others. The cabinet is
equipped with a 20 feet whip from the control cabinet to the grinder junction box and
a 12 foot whip from the grinder junction box to the start/stop station. Longer whips
and wire connections are supplied by others.
Fig. 6
HMI
Emergency Stop
Push Button Switch
Start/Stop Station
Fig. 5

6
Plumbing Connections
Connections must comply with local safety, sanitary, and plumbing codes.
Cold Water Fill:
Connect a 3/4" FNPT cold water supply to the waterpress tank fill line.
The minimum incoming temperature is 36ºF/2ºC
Install a shut-off valve as close to the connection as possible for servicing.
Hot Water Flush:
Connect a 1/2" FNPT hot water supply to the waterpress flushing supply line.
The incoming min/max water temperature is 110ºF/33ºC - 140ºF/60ºC. Install a shut-off valve
as close to the connection as possible for servicing.
3/4" NPT
Cold Water
Fill
1/2" NPT
Hot Water
Fill
2" NPT
to Drain
1/2" NPT
to Drain
Installation
CAUTION: The installing plumber must thoroughly flush debris from the water
supply line before connecting it to the machine.
Fig. 7

77
Installation
Plumbing Diagrams
Fig. 8
Drain
Trough
Slurry Pump
Slurry Tank
Recirc
Tank
Recirc Pump
A
B
B
C C
A
D
D
1-1/2" Recirculation Line
1-1/2" Slurry Line
2" Drain Line
1/4" Pressure Switch Tubing
• Interconnecting plumbing was disconnected at the factory and shipped with the machine.
• Refer to the diagram below and the illustrations on the next page to reassemble the plumbing.
• Additional plumbing required to reach building drains are supplied by others.
STOP!
ALWAYS REFER TO ANY PLUMBING DIAGRAMS SUPPLIED
WITH THE MACHINE BEFORE INSTALLING AND MAKING
CONNECTIONS.
PLUMBING CONNECTIONS MAY BE LABELED TO ASSIST
THE PLUMBING REASSEMBLY.

8
Plumbing Diagrams
Fig. 9 -
Sample close-coupled assembly shown
Installation
STOP!
ALWAYS REFER TO ANY PLUMBING DIAGRAMS SUPPLIED
WITH THE MACHINE BEFORE INSTALLING AND MAKING
CONNECTIONS.
PLUMBING CONNECTIONS MAY BE LABELED TO ASSIST
THE PLUMBING REASSEMBLY.

9
Installation
Electrical Connections
Main Control Cabinet
WARNING:
Electrocution may occur when working on energized circuits. Disconnect
power at the main breaker or service disconnect switch, then lock out and
tag it to indicate that work is being performed on the circuit.
• Install the wall-mounted control cabinet 48"/1219 mm above the finished floor. Junction boxes
are located on the grinder and the waterpress as well. Remote systems have an additional Emergency
Stop on the waterpress.
• Factory conduit/wire assemblies are located in the marked areas.
• Additional holes and wiring not supplied at the factory must be supplied by others and installed
in the same * areas.
• Electrical schematics are located inside the wall-mounted control cabinet.
Fig. 10
16 716
"
10 14"
25 916
"26 78"
716 "
11"
48"
FFL
C
B
A
• Ensure the UL508A Data Plate electrical requirements match the installation site.
• Connect incoming power to the control cabinet input terminal block.
• If required, connect the control wires at the terminals to the left of the PLC.
• If required, onnect the motors at the bottom of the control cabinet.
B
C
D
*
*
*
*
*
L1 L2 L3
Fig. 11
Champion Industries, Inc.
Winston-Salem, N.C.
Model: SSG
Maximum Voltage:
Phase:
VAC
Total FLA:
Largest Motor FLA:
Hertz:
Field Wiring Diagram:
SCCR:
Cabinet Type:
Amps
Amps
3 PH
60 Hz
703054
5000 Amps
NEMA 4X
UL508A
Electrical Connection
Data Plate
A
40 43 46 4941 44 47 5042 45 48 51
Grinder
Mtr.
Slurry
Mtr.
Water Pres
Mtr.
Recirc
Mtr.
D

10
G-1
S-1
G-1 S-1
20’Whip
12’Whip
(Supplied by others)
REMOTE
Electrical Connections (continued)
Conduit Routing
Note the illustrations to the right for close-coupled and remote systems.
Close-coupled systems:
• Contains: main control cabinet, grinder and waterpress junction boxes,
start/stop station.
• Whips: 20' waterpress/control cabinet, 20' grinder/control cabinet,
12' grinder to start/stop station.
• Whips and junction boxes labeled for easy identification.
Checking Motor Rotation
• All the motors are wired to rotate in the same direction at the factory.
Proper motor rotation is clockwise when viewed from the rear.
• To reverse motor rotation: DISCONNECT MAIN POWER. Reverse
L1 and L2 wires at the input terminal block located at the top of the
main control cabinet. Reconnect power and bump the motors to verify
the motor rotation is correct.
Installation

11
Fig. 13a
Control Cabinet Wiring- Close-coupled System
Terminal Block
Wiring
L1 L2 L3
40 43 46 4941 44 47 5042 45 48 51
Grinder
Motor
Slurry
Pump
Motor
Water
Press
Motor
Water Press
Recirc
Motor
WARNING:
ALWAYS CONSULT THE WIRING SCHEMATICS INCLUDED WITH THE
MACHINE BEFORE CONNECTING OR ALTERING ANY WIRING.
19A19A
19 21 21 21 21
21
23 23 25 27 29 30 34 36
15 16 1712103A3A2
2
1100
Installation

12
Fig. 13b
Control Cabinet Wiring- Remote System
Terminal Block
Wiring
L1 L2 L3
40 43 46 4941 44 47 5042 45 48 51
Grinder
Motor
Slurry
Pump
Motor
Water
Press
Motor
Water Press
Recirc
Motor
WARNING:
ALWAYS CONSULT THE WIRING SCHEMATICS INCLUDED WITH THE
MACHINE BEFORE CONNECTING OR ALTERING ANY WIRING.
23A
1A
21 21 21 21 23 23 25 27 29 30 34 36 60 62
1512103A2
2
1100
Installation
19A
