Channel Vision 5005 User manual

CHANNEL VISION
Limited Warranty
Channel Vision Technology will repair or replace any defect in material or
workmanship which occurs during normal use of this product with new or rebuilt
parts, free of charge in the USA, for two years from the date of original purchase. This
is a no hassle warranty with no mail in warranty card needed. This warranty does not
cover damages in shipment, failures caused by other products not supplied by
Channel Vision Technology, or failures due to accident, misuse, abuse, or alteration of
the equipment. This warranty is extended only to the original purchaser, and a
purchase receipt, invoice, or other proof of original purchase date will be required
before warranty repairs are provided.
Mail in service can be obtained during the warranty period by calling [phone]
toll free. A Return Authorization number must be obtained in advance and can be
marked on the outside of the shipping carton.
This warranty gives you specific legal rights and you may have other rights (which
vary from state to state). If a problem with this product develops during or after the
warranty period, please contact Channel Vision Technology, your dealer or any
factory-authorized service center.
500-168 revA
Specifications:
Image Sensor:
Picture Elements:
Resolution:
S/N Ratio:
Min Illumination:
Back Light Compensation:
Electronic Shutter:
Gain Control:
Operating Temp:
Humidity:
Weight:
Output Terminals:
1/3” Black & White CCD
NTSC: 510x492
420 TV lines
More than 50 dB
0.01 LUX @ F2.0
Automatic
Automatic
Automatic
-10°C to 50°C (14°F to 122°F)
Less Than 90%RH
7 oz.
2’ cable w/ female BNC and male DC connector
Specifications subject to change without notice.
Auto White Balance:
Smear Effect:
MTBF:
Camera Lens:
Sync. System:
Scanning System:
Power Requirements:
Video Output:
Color Temperature: 2100K-9100K
0.005%
80,000 Hours
3.6mm
Internal, Negative sync.
2:1 Interlaced
12VDC @ 130mA
1 Vp-p @ 75 ohms
5005
Weatherproof B&W Camera
By
6

2
Features:
h
h
h
h
h
h
High quality 1/3” CCD sensor
Universal swivel mount
Weatherproof
3.6mm lens
Great low light performance
Easy to install
The is a weatherproof black & white bullet camera. It is
available in white (5005-W) or black (5005-B). The low light
performance characteristics of the 5005 make it an excellent
choice for applications in dark locations.
5005
Bullet Camera and
Sun Shield
Power Supply Swivel Mount
Screws and
Wall Anchors
3
Model 5
00
5
1. Connect wiring
2. Mount the camera
Installation:
Drill a hole in the wall or ceiling for wiring (see diagram).
If necessary, attach the camera’s video output to a coax
extension that is long enough to reach your monitor or
video distribution equipment.
If necessary, cut the connector off of the end of the power
supply and splice in an extension using crimp-on
connectors.
Attach the swivel mount with the provided screws.
Move the camera to adjust the view.
Tighten the swivel mount to secure the camera
placement.
h
h
h
h
h
h
2-Conductor power
supply extension
(not included)
Crimp-on splice
connectors
(not included)
To Monitor
or
Video distribution
Power supply
(included)
Coax extension
(not included)
BNC connector
Dimensions
BNC Connector
DC Connector
19mm
(0.75”)
57mm
(2.25”)
