Channel Vision CHANNEL VISION 6403 User manual

500-264 rev B
w w w . c h a n n e l v i s i o n . c o m
234 Fischer Avenue, Costa Mesa, California 92626 USA
[phone] [phone] [phone] fax
email: [email protected]
Channel Vision Technology will repair or replace any defect in material or workmanship which
occurs during normal use of this product with new or rebuilt parts, free of charge in the USA, for
one year from the date of original purchase. This is a no hassle warranty with no mail in
warranty card needed. This warranty does not cover damages in shipment, failures caused by
other products not supplied by Channel Vision Technology, or failures due to accident, misuse,
abuse, or alteration of the equipment. This warranty is extended only to the original purchaser,
and a purchase receipt, invoice, or other proof of original purchase date will be required before
warranty repairs are provided.
Mail in service can be obtained during the warranty period by calling [phone] toll free.
A Return Authorization number must be obtained in advance and can be marked on the outside
of the shipping carton.
This warranty gives you specific legal rights and you may have other rights (which vary from
state to state). If a problem with this product develops during or after the warranty period,
please contact Channel Vision Technology, your dealer or any factory-authorized service
center.
Channel Vision products are not intended for use in medical, lifesaving, life sustaining or
critical environment applications. Channel Vision customers using or selling Channel Vision
products for use in such applications do so at their own risk and agree to fully indemnify
Channel Vision for any damages resulting from such improper use or sale.
1
* :
Image Sensor:
Picture Elements:
Resolution:
S/N Ratio:
Min Illumination:
Electronic Shutter:
Iris Control:
Gamma Characteristic:
Dimensions:
Operating Temp:
Specifications
1/3” SONY Super HAD CCD
NTSC: 768x494
550 lines
More than 48 dB
0.2 LUX @ F2.0
1/60s - 1/100,000s
Automatic
0.45
1.18” x 1.18” x 0.55” (30 x 30 x 18mm), camera only
-10°C to 50°C (14°F to 122°F)
*Specifications subject to change without notice.
White Balance:
Lens Focal Length:
Sync. System:
Power Requirements:
Power Consumption:
Video Output:
Automatic
5.5mm
Internal
12VDC
65mA
1 Vp-p @ 75 ohms
6403
Mini Pinhole Color Camera
0
1

2
The is a high-resolution mini pinhole camera. Its
extremely small size and cone-shaped lens make it ideal for
hidden and inconspicuous CCTV installations. Typical
applications include door stations, small flush-mount camera
assemblies, and hidden camera installations.
6403
6403 Mini Pinhole Camera Includes
Camera
Small Screws
Camera Cable
Mount Power Supply
Features:
High quality 1/3” SONY Super HAD CCD sensor
550 TV lines of resolution
5.5mm lens for tight viewing angles
Easy to install
h
h
h
h
Dimensions
30
30
31
Red (12VDC)
Black (GND)
Yellow (Video)
18.1
14
2
3
Model 6403
Coax extension
(not included)
Power supply
(included)
To Monitor
or
Video distribution
Power
2-Conductor power
supply extension
(not included)
Crimp-on splice
connectors
(not included)
Video
(BNC Connector)
Installation:
h
h
h
h
Attach the camera mount to a flat surface using the
mounting hole shown above.
Drill a hole in the wall or ceiling for wiring (see diagram).
If necessary, attach the camera’s video output to a coax
extension that is long enough to reach your monitor or
video distribution equipment.
If necessary, cut the connector off of the end of the power
supply and splice in an extension using crimp-on
connectors.
