Chaparral Signature 240 User manual

Signature 240

ID. PAGE NO.
DESCRIPTION
PAGE NO.
10 11
Anchor Lid & Hardware
Anchor Option
Bow Light
Bow Rail
Deck Hatch
Pole Light & Base
Rod Holder Option
Spotlight Option
Windshield & Wiper
12, 14 13, 15
Aft Exterior Grab Rail
Bow Chafe Option
Bow Eye
Cleats
Drain Plug
Dunnage Box & Components
Fuel Fill
Horn
Midget Vent
Portlights
Rubrail & Insert
Shore Power
Stern Eyes
Swim Platform & Components
Thru Hulls
Transom Door
Transom Lights
Transom Shower
Transom Stereo Remote
Transom Tilt Switch Option
Vents & Vent Covers
Water & Waste Deck Fittings / Vents
16 17
Bird Head Logo
Chaparral Lettering & Bird
Deck Tapes
Extended Hull Decal
Hull Flares
Hull Tapes
Model Designator & Chrome Designator
PARTS IDENTIFICATION GUIDE INDEX
2003 MODEL YEAR
SIGNATURE 240
GRAPHICS (includes the following)
HULL & DECK EXTERIOR (includes the following)
DECK - OVERHEAD VIEW (includes the following)
DESCRIPTION

ID. PAGE NO.
DESCRIPTION
PAGE NO.
18 19
Bunk Storage Lids & Rings
Halogen Lights
V-Berth Table & Storage
20 21
Carbon Monoxide Detector
Double Low Profile Light
Faucet & Sink
Fish Anode
Galley Cabinets & Components
Galley Rails
Galvanic Isolator
Microwave
Refrigerator
Stereo/CD Player
Stove
Waste Basket
N/A 23
110v & 220v AC Kits
24 25
Access Door
Double Low Profile Light
Faucet & Sink
Grab Rail
Head Door, Ring & Latch
Head Electrical Panels
Manual Porcelain Head
Mirror
Shower Drain
Shower Head
Tissue Holder
Windshield Wiper Cover
26 27
115v Air Conditioning Kit
220v Air Conditioning Kit
HEAD (includes the following)
DESCRIPTION
ALTERNATING CURRENT ELECTRICAL SYSTEM (includes the following)
GALLEY & AFT CABIN (includes the following)
AIR CONDITIONING (includes the following)
PARTS IDENTIFICATION GUIDE INDEX
SIGNATURE 240
2003 MODEL YEAR
FORWARD CABIN (includes the following)

ID. PAGE NO.
DESCRIPTION
PAGE NO.
28, 30 29, 31
Cabin Door
Compass
Console & Components
Courtesy Light
Cup Holders
Dash Kit & Components
Depth Finder
Engine Components
Fire Extinguisher Light Option
Kill Switch
Ray Nav 320 GPS Option
Sliding Cabin Door Option
Steering Cable
Steering Wheel
Stereo Remote
Storage Tub
Trim Tab Switch
VHF Radio
Windshield Braces
32 33
Aft Cabin Window
Battery Panel & Access Door
Cockpit Galley
Cockpit Grab Rails
Courtesy Lights
Cup Holders
Engine Lids
Helm Seat Base
Ice Maker Option
Igloo Cooler
Inspection Plate
Speakers
Table & Storage
34 35
Battery Switch Panel Conduit
Blower Hoses
Cockpit Galley Drain
Cockpit Speaker/Cup Holder Tub
Engine Well Liner Drains
Helm Motor Well Boot
Helm Seat Liner Drain
Manual Bilge Pump Option
DECK - UNDERSIDE VIEW (includes the following)
DASH / HELM (includes the following)
PARTS IDENTIFICATION GUIDE INDEX
SIGNATURE 240
2003 MODEL YEAR
DESCRIPTION
COCKPIT (includes the following)

ID. PAGE NO.
DESCRIPTION
PAGE NO.
36 37
Battery Charger
Battery Trays
Bilge Pump & Float Switch
Blower & Blower Hose
Cabin Step Hinge
Depth Finder Thru Hull Transducer
Fire Extinguisher Option
Fuel Shut Off Option
Fuel Tank
Shower Sump
Trim Tab Pump Stand & Interrupter Relay
Waste Holding Tank
Water Tank
38 39
Hot Water Heater
Water Hoses, Fittings, Pump & Filter
40 41
Macerator Option
Waste & Sink Hoses & Fittings
Waste Holding Tank & Components
42 43
Sump Box & Float Switch
Sink Hoses & Fittings to Waste Tank
N/A 45
Canvas Bimini Top Kits
Canvas Camper Aft Curtains
Canvas Camper Side Curtains
Canvas Camper Tops
Canvas Cockpit Covers
Canvas Side Curtains
Canvas Storage Bags
Canvas Travel Covers
Canvas Windscreens
DESCRIPTION
ENGINE WELL / HULL INTERIOR (includes the following)
WASTE SYSTEM (includes the following)
GRAY WATER SYSTEM(includes the following)
FRESH WATER (includes the following)
PARTS IDENTIFICATION GUIDE INDEX
SIGNATURE 240
2003 MODEL YEAR
CANVAS (includes the following)

ID. PAGE NO.
DESCRIPTION
PAGE NO.
46 47
Cockpit Carpet
Helm Seat Assembly, Cushions & Skins
Port Seating Assembly, Cushions & Skins
Stern Seating Cushions & Skins
Sunbrella Floor Runner Option
48 49
Aft Bunk Cushion & Skin
Bow Seating Assemblies, Cushions & Skins
Bow Wraps, Pads & Skins
50 51
Aft Storage Board & Skin
Bow Step Assembly & Skin
Cabin Table Storage Box & Skin
Curtain & Shower Curtain
Forward Bow Cover Board & Skin
Forward Bow Mirror Bulkhead Assembly & Skin
Mirror
Speakers
52 53
Aft Entrance Door w/Light & Skin
Aft Trim Boards & Skins
Optional AC Starboard Aft Trim & Skin
54 55
Hatch Shim & Skin
Optional AC Board & Skin
OVERHEAD VIEW (includes the following)
SIGNATURE 240
PARTS IDENTIFICATION GUIDE INDEX
2003 MODEL YEAR
TRIM BOARDS (includes the following)
BOW INTERIOR CONT'D (includes the following)
BOW INTERIOR / BUNK CUSHION(includes the following)
TRIM BOARDS (includes the following)
DESCRIPTION

Signature 240

PARTS IDENTIFICATION GUIDE
SIGNATURE 240
2003 MODEL YEA
R
Deck-Overhead View
4
6
2
5
7
10
3
13
12
14
1
9
11 8
15

Item No. Part Number Description Qty. U.O.M.
1 35086 S240 BOW RAIL 1 PR
2 35094 S240 FWD. SECTION W/NAV 1 EA
2a IST34121 240 STD BOW SPOTLIGHT PAD 1 EA
3 3-0117 S240/260 ANCHOR LOCKERLID 1 EA
3a 6722 STAINLESS RUB STRIKE 1 EA
3b 66009-1 6 INCH CLEAT-HOLLOW BASE 1 EA
3c URM-2C BOW ROLLER W/O HOLE(25) 1 EA
3d IST14124 S240 ANCHOR CHAIN GUARD 1 EA
3e IST14114B 240 BOW ANCHOR GUARD 1 EA
4 M1-62-8 LATCH/FLUSH SS (5000 MIN) 1 EA
5 H20-0200 2 INCH BUTT HINGE 2 EA
6 588-1020011 20X20 HATCH 1 EA
6a SFSS-20/20-R42 20X20 SURFACE SKYSCREEN 1 EA
7 0100084 SIG. 240/260 STBD. FRONT 1 EA
8 0100087 SIG. 240/260 STBD. WING 1 EA
9 0100086 245SSI/SIG. 240 DOOR 1 EA
10 0100085 SIG. 240/260 PORT FRONT 1 EA
11 0100088 SIG. 240/260 PORT WING 1 EA
11a 0100089 SIG. 240/260 HARDWARE 1 EA
12 INT-STR8S 8 INCH STRAP W/SNAP 1 EA
13 33110 14-20IN. HEAVYDUTY ARM SS 1 EA
13a 33105 14 INCH CURVED BLADE 1 EA
13b 38000A WIPER MOTOR 1 EA
14 1045-SPL-009-P ROUND LIGHT BASE W/PACKAR 1 EA
14a 6646 66 INCH POLE LIGHT 1 EA
15 66318-1 COMBINATION SIDELIGHT 1 EA
Parts Not Pictured which are Associated with Deck Overhead:
Not Pictured SL0057406/F 14LB. DELTA ANCHOR (Option: Anchor) 1 EA
Not Pictured 62026-4705 SPOTLIGHT W/ CONTROL (Option: Spotlight) 1 EA
Not Pictured 67492-0800 SPOTLIGHT CABLE (Option: Spotlight) 20 FT
Not Pictured 35093 S240 FWD.SECTION W/SPOTLI (Option: Spotlight) 1 EA
Not Pictured IST34120 240 OPT BOW SPOTLIGHT PAD (Option: Spotlight) 1 EA
Not Pictured 66362-1 ROD HOLDER (Option: Rod Holders) 2 EA
Not Pictured 200-2000 2IN SOFTWALL EXHAUST HOSE (Option: Rod Holders) 1 FT
Not Pictured 6732-5 #32 HOSE CLAMP (Option: Rod Holders) 1 EA
Not Pictured 1943-1B BLK CAP LG. .045 X .465 (Option: Rod Holders) 2 EA
NOTE: Numbers with letter designations represent parts included with
primary numbered part for which there is no photo representation.
PARTS IDENTIFICATION GUIDE
SIGNATURE 240
2003 MODEL YEA
R
Deck-Overhead View

PARTS IDENTIFICATION GUIDE
SIGNATURE 240
2003 MODEL YEA
R
Hull / Deck Exterior
6
7
8
55
1011
12
2
16 515
17
18 19 18 209
2
2
14 13
15
3
2
3
3
3
9
11
1
1
1
114

Item No. Part Number Description Qty. U.O.M.
1 66010-1 8 INCH CLEAT W 6 EA
2 01348RB9629-01Z WHITE RUBRAIL 20FT 3 EA
3 STA2416H12 SS INSERT 3/4 X 12 4 EA
4 STA75I114.75 SS INSERT 3/4 X 114 3/4IN 1 EA
5 81814-S S240 OPENING PORTLIGHT 4 EA
6 069A PORT VENT 1 EA
6a VHF-4WS 4 IN. SAND FLANGE 2 EA
7 069B STBD VENT 1 EA
7a VHF-4WS 4 IN. SAND FLANGE 2 EA
8 520-WOO-CHR CHROME WATER FILL(25) 1 EA
9 954 FLUSH FUEL VENT 2 EA
10 72006 1 1/2 SS SHORT THRU HULL (CE Packages) 1 EA
11 72002 3/4 SS SHORT THRU HULL (Cockpit Galley/Sump Pump) 2 EA
12 72006 1 1/2 SS SHORT THRU HULL (Galley Sink) 1 EA
13 240SIGBC 240SIG BOW CHAFE (Option: Bow Chafe) 1 EA
13a STESW1003 1/2 X 3 7/16 STERN EYE (Standard Bow Eye) 1 EA
14 2340-840 MIDGET VENT 1 1/2 X 1 3/4 1 EA
15 IST14114B 240 BOW ANCHOR GUARD 1 EA
16 540-SPL-004 GAS FILL/VENT(25) 1 EA
17 507-CHR CHROME WASTE FITTING(25) 1 EA
18 72004 1 1/8 SS SHORT THRU HULL (Bilge/Helm Liner) 2 EA
19 72003 1 SS SHORT THRU HULL (Option: Macerator) 1 EA
20 72005 1 1/4 SS SHORT THRU HULL (Head Sink) 1 EA
Parts Not Pictured which are Associated with Hull / Deck Exterior:
Not Pictured 11079 DROP IN HORN 1 EA
Not Pictured 11124 SS HORN GRILL 1 EA
Not Pictured 11190 WHITE SCREW MOUNT GRILL 1 EA
NOTE: Numbers with letter designations represent parts included with
primary numbered part for which there is no photo representation.
PARTS IDENTIFICATION GUIDE
SIGNATURE 240
2003 MODEL YEA
R
Hull / Deck Exterior

PARTS IDENTIFICATION GUIDE
SIGNATURE 240
2003 MODEL YEA
R
Hull / Deck Exterior
1
15
77
16 15
9
5
3
4
12
13
18
14 17
20
21
210
19
14
14
11
6
8
PORT SIDE OF TRUNK STORAGE
7
25
24
22
23
5
FUSE ASSEMBLY FOR
PLUG INLE
T

Item No. Part Number Description Qty. U.O.M.
1 IST34272 2002-S240 TRANSOM DOOR 1 EA
1a IST34123 240 TRANSOM DOOR STOP 1 EA
2 947-2 BARREL BOLT(25) 1 EA
3 CB12515-06SS 1.25 X 15.00 .06SS 4 #8 (Hinge) 1 EA
4 303SB7481 BONE TRANSOM SHOWER 1 EA
5 JBLREM10/20W JBL WHITE REMOTE 1 EA
5a 220-02721-C Y-REMOTE HARNESS 1 EA
6 3-1142 S240 DUNNAGE BOX LID 2002 1 EA
7 2340-1209 HINGE 3.187 IN X 1.5 IN 2 EA
8 66448-1 2.5 INCH FLUSH SKI TOW 1 EA
9 2264 2 1/2 SS LIFT HANDLE LOCK 1 EA
10 H-128 16IN. GRABRAIL(100) 1 EA
11 3-1062 S240 SWIM PLATFORM 1 EA
12 01348RB9629-03Z WHITE RUBRAIL 22 FT. 0.5 EA
13 STA75I128 SS INSERT 3/4 X 128 INCH 1 EA
13a 800R107200ES SMALL SW. PLATFORM ENDCAP 1 PR
14 PS-9 21 3/4 PLATFORM BRACE(50) 3 EA
15 CHA129PNC 12 X 9 TRIM TAB W/ZINC 1 EA
16 714-1-PLB DRAIN PLUG(50) 1 EA
16a 220-01444-H TRANSOM DRAIN WIRE 1 EA
17 PS-13 19 3/4 PLATFORM BRACE(50) 1 EA
18 TDL-3XDA 3 STEP DROP LADDER(25) 1 EA
19 1640 HINGE FLUSH MOUNT 2 EA
20 3-1109 SPLATTER SWIMPLATFORM LID 1 EA
21 M1-62-8 LATCH/FLUSH SS (5000 MIN) 1 EA
22 HBL303NM INLET PLUG (LOT 3) 1 EA
22a HBL61CM08W 50FT. CABLE 125V (LOT 3) 1 EA
23 R-1241 3/8 SS CABLE HOLDER (100) 1 EA
24 SL34-10-1 10LB GAS SHOCK 1 EA
25 SL50BP3-1 90 DEGREE BRACKET-BLACK 2 EA
Parts Not Pictured which are Associated with Hull / Deck Exterior:
Not Pictured TH-1292 THRU HULL 1 1/8-1 1/4 CON (Aft Liner Drains in Top of Bell) 2 EA
Not Pictured STESW1005 1/2 X 2 STERN EYE 2 EA
Not Pictured 221-03478-P SE TRANSOM TRIM PANEL (Option: Transom Tilt Switch) 1 EA
Not Pictured 350 BUSHING SKI STORAGE (Inside Dunnage Box) 1 EA
NOTE: Numbers with letter designations represent parts included with
primary numbered part for which there is no photo representation.
PARTS IDENTIFICATION GUIDE
SIGNATURE 240
2003 MODEL YEA
R
Hull / Deck Exterior

PARTS IDENTIFICATION GUIDE
SIGNATURE 240
2003 MODEL YEA
R
Graphics
4
8
28
9
10
21
9 10
4
5
3
6
1
3
3
3
56
7

Item No. Part Number Description Qty. U.O.M.
1 U13675-02 SIGNATURE NAME 2 EA
2 U15543-01 240SIG DESIGNATOR 2 EA
3 QMI-215203 LARGE CHROME DESIGNATOR 4 EA
4 U15542-02 BIRD HEAD LOGO (BLUE) 2 EA
5 QMI-215204 CHAPARRAL CHROME BIRD 2 EA
6 QMI-215201 CHAPARRAL CHROME LETTERS 2 EA
7 U13656-01 EXTENDED V-HULL DECAL 1 EA
WHITE BOATS WITH BLUE INTERIOR
8 U16781-01 SIGN. DECK STRIP BLUE/ 50 FT
9 U16782-01 SIGN. HULL GRAPHIC PEWTER 1 SET
10 U16780-01 SIGN HULL STRIPE BLUE 52 FT
WHITE BOATS WITH BLACK INTERIOR
8 U16781-02 SIGN DECK STRIPE BLACK 50 FT
9 U16782-01 SIGN. HULL GRAPHIC PEWTER 1 SET
10 U16780-02 SIGN. HULL STRIPE BLACK 52 FT
WHITE BOATS WITH MOCHA INTERIOR
8 U16781-03 SIGN DECK STRIPE GOLD 50 FT
9 U16782-02 SIGN. HULL GRAPHIC GOLD 1 SET
10 U16780-03 SIGN. HULL STRIPE GOLD 57 FT
PARTS IDENTIFICATION GUIDE
SIGNATURE 240
2003 MODEL YEA
R
Graphics

PARTS IDENTIFICATION GUIDE
SIGNATURE 240
2003 MODEL YEA
R
Forward Cabin
4
321
STARBOARD SIDE CABIN BULKHEAD FACING
AFT/STARBOARD
9
678
15
2
CENTER V-BERTH STORAGE
11
10
4

Item No. Part Number Description Qty. U.O.M.
1 4-202-240 S240 V-BERTH TABLE 1 EA
2 02148RB0855-100 TABLE EDGE - KHAKI (Part of Table Assembly) 8 FT
3 75359-83 27 1/2 LEGS 1 EA
4 75375-40 FLOOR BASE 1 EA
5 75354 TABLE BASE 1 EA
6 66105-1 PAD EYE 2 EA
7 FPH-2 SMALL HOOKS 2 EA
8 BCORD-14BW 1/4IN SHOCK CORD 1.83 FT
9 8268-14-B.AM HALOGEN LIGHT 1 EA
10 4692 BOW BUNK RING 3 EA
11 IFB12083 BUNK STORAGE LID 3PC 3 EA
NOTE: Numbers with letter designations represent parts included with
primary numbered part for which there is no photo representation.
PARTS IDENTIFICATION GUIDE
SIGNATURE 240
2003 MODEL YEA
R
Forward Cabin

PARTS IDENTIFICATION GUIDE
SIGNATURE 240
2003 MODEL YEA
R
Galley & Aft Cabin
SEE ALTERNATING CURRENT ELECTRICAL
SYSTEM SECTION FOR AC COMPONENTS
15
2
2
3
4
7
6
8
9
11
5
10
13 12 1
14
