Chard GRAIN MILL Guide

- 1 -
Features:
- High quality, durable tin-coated cast iron
- Large capacity hopper, grinds 1 lb. per minute, coarse to ne
- Removable poly handle allows for continuous operation
- Adjustable table clamp, easy to set-up, use and clean
- Create authentic breads and baked goods - made from scratch
For your safety and continued enjoyment of this product,
always read the instruction book carefully before using.

- 2 -
LIST OF COMPONENTS
4
3
2
1
5
Parts List
1. Grinding Plate Pressure Screw
2. Wing Nut
3. Shield
4. Rotating Thumbscrew w/ Bolt
5. Auger
6. Adjustable Grinding Plate
7. Retainer Cap
6
7
8
9
10
12
11
13
14
8. Rubber Protector Pad
9. Grinder Body
10. Hopper
11. Handle
12. Thumbscrew w/ Washer
13. Clamping Thumbscrew
14. Grinder Body Foot
IF MISSING PARTS, PLEASE CALL CUSTOMER SERVICE AT 1-800-288-4545.
DO NOT RETURN ITEM TO STORE.

- 3 -
HOW TO USE
Read and follow instructions and warnings prior to using this product.
1. Read all of the instructions below before using the Chard Grain Mill.
2. Keep the Grain Mill out of reach of children.
3. Never put your ngers or hands into the Grain Mill, as this may cause serious injury.
4. Eye protection should be worn while operating the Grain Mill.
Cleaning
1. Before using for the rst time, disassemble and thoroughly clean all parts with hot soapy water. Rinse
with hot water and towel dry thoroughly, do not allow any parts to air dry as this can lead to corrosion.
2. The Chard Grain Mill is not dishwasher safe, placing the product in the dishwasher will cause damage.
Assembly
1. Clamp the Grain Mill body (#9) to a sturdy bench or table with the rubber protective pad (#8) placed
between the body and bench or the table top.
2. Insert the auger (#5) and adjustable grinding plate (#6) into Grain Mill body (#9).
3. Install the shield (#3) with grinding plate pressure screw (#1) onto Grain Mill body (#9).
4. Align the rotating thumbscrews (#4) into the slots in the Grain Mill body (#9) and tighten securely.
5. Set adjustable grinding plate pressure screw (#1) and then tighten the locking wing nut (#2) against
the shield (#3).
6. Place the handle (#11) on end of auger post (#5) and secure using the thumbscrew (#12).
7. Install hopper (#10) on top of Grain Mill body (#9) and twist slightly to lock into place.
Milling Instructions
1. Fill hopper (#10) with product to be ground or milled.
2. Position a bowl under grinding plates to catch millings as it they are being ground.
3. Slowly turn the handle (#11) clockwise.
Adjusting the Coarseness of the grind: Loosen the wing nut (#2) and turn pressure screw (#1)
counter clockwise to produce a more course grind or clockwise to produce a ner grind. When the right
setting is adjusted, tighten the locking wing nut (#2) to securely set position.
TIP: Whatever is being milled or ground should be dry to prevent caking and ensure a consistent grind.
If the mill jams, turn the handle (#11) counter-clockwise to clear jam and then resume (do not use hands
to clear jam). For best results turn handle at a constant speed.
WARNING
Indicates a potentially hazardous situation which, if not avoided, could result in death or serious injury.

- 4 -
Chard GM-150 / Grain Mill
C/O MW
P.O. Box 237
Two Rivers, WI 54241
chardproducts.com
©2018 Metal Ware Corp, P.O. Box 237, Two Rivers, Wi 54241 1-800-288-4545
LIMITED WARRANTY
Your product is warrantied for one year from date of purchase against all defects in material and
workmanship. Should your product prove defective within one year from date of purchase or receipt,
return the unit, freight prepaid, along with an explanation of the claim. Please package your product
carefully in its original box and packing material to avoid damage in transit. We are not responsible for
any damage caused to the product in return shipment.
Under this limited warranty, we undertake to repair or replace any parts found to be defective at our
sole discretion. This limited warranty is only valid if the product is used solely for household purposes in
accordance with the instructions. This limited warranty is void if the unit is connected to an unsuitable
electrical supply, or dismantled or interfered with in any way or damaged through misuse.
LIMITATION OF REMEDIES AND DAMAGES: Except for the limited warranty and
remedies expressly stated above, the Metal Ware Corp shall not be liable to you, or to anyone claiming
by or through you, for any obligations or liabilities, including, but not limited to, obligations or liabilities
arising out of breach of contract, breach of warranty, statutory claims, negligence or other tort or
any theory of strict liability, with respect to the product or the Metal Ware Corp’s acts or omissions
or otherwise. Buyer agrees that in no event shall the Metal Ware Corp be liable for incidental,
compensatory, punitive, consequential, indirect, special or other damages. Warranty does not cover
consequential or incidental damages such as property damage and does not cover incidental costs and
expenses resulting from any breach of this warranty, even if foreseeable. Some states or provinces do
not allow the exclusion or limitations of incidental or consequential damages, so the above limitation or
exclusion may not apply to you depending on the State or Province of purchase.
We ask that you kindly ll in the details on your warranty card and return it within one week from date of
purchase.
Send warranty card to:
