Charmate Corona CM155-028 User manual

1
CHARMATE
CHARMATENZ
@CHARMATENATION
CHARMATE
CHARMATENZ
@CHARMATENATION
CHARMATE
CHARMATENZ
@CHARMATENATION
Corona
Charcoal Kettle BBQ
Model No. CM155-028
Grill, roast, smoke and bake generous amounts of food on the 56cm (22”) diameter chrome plated rack
Durable black vitreous enamel bowl and lid
Lid mounted temperature gauge and twin vent system for heat control
Load fuel or wood chips while cooking using the hinged racks
Two charcoal baskets included for indirect cooking and smoking
Large capacity removable ash catcher
Handy storage rack and wheels for portability
Assembled dimensions (mm): 663 W x 1070 H x 615 D
FOR OUTDOOR USE ONLY
DO NOT OPERATE THIS APPLIANCE BEFORE READING THE INSTRUCTION BOOKLET
DO NOT PLACE ARTICLES ON OR AGAINST THIS APPLIANCE
DO NOT STORE CHEMICALS OR FLAMMABLE MATERIALS OR SPRAY AEROSOLS NEAR THIS APPLIANCE
DO NOT OPERATE THE APPLIANCE INDOORS
DO NOT OPERATE IN AN ENCLOSED AREA. ACCESSIBLE PARTS MAY BE VERY HOT. KEEP YOUNG CHILDREN AWAY.
MINIMUM CLEARANCES FROM COMBUSTIBLE MATERIALS: 3 METRES
is a registered trademark of: Sitro Group Australia Pty Ltd - www.sitro.com.au & Aber, Hamilton, N.Z - www.charmate.co.nz
Important: Retain these instructions for future use.
4771-07/17

32
READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY
BEFORE ASSEMBLING AND OPERATING YOUR KETTLE BARBECUE.
• Only use this barbecue on a hard, level, non-combustible, stable surface (concrete, ground etc.) capable of supporting
the weight of the barbecue. Never use on wooden or other surfaces that could burn.
• DO NOT use barbecue without charcoal ash pan in place. DO NOT attempt to remove charcoal ash pan while barbecue
contains hot coals.
• Proper clearance of 3m between the barbecue and combustible material (bushes, trees, wooden decks, fences,
buildings, etc.) or construction should be maintained at all times when barbecue is in use. Do not place barbecue
under a roof overhang or other enclosed area. Not adhering to these clearances will prevent proper ventilation and
may increase the risk of a re and/or property damage, which could also result in personal injury.
• For outdoor use only. Do not operate barbecue indoors or in an enclosed area.
• For household use only. Do not use this barbecue for other than its intended purpose.
• We recommend the use of a Charcoal Chimney Starter to avoid the dangers associated with charcoal lighting uid.
If you choose to use charcoal lighting uid, only use lighting uid approved for lighting charcoal. Carefully read
manufacturer’s warnings and instructions on the charcoal lighting uid and charcoal prior to the use of their product.
Store charcoal lighting uid safely away from barbecue.
• When using charcoal lighting uid, allow charcoal to burn with barbecue lid open until covered with a light ash
(approximately 20 minutes). This will allow charcoal lighting uid to burn o. Failure to do this could trap fumes from
charcoal lighting uid in barbecue and may result in a ash re or explosion when lid is opened.
• Never use charcoal that has been pre-treated with lighter uid. Use only a high grade plain charcoal or charcoal/wood
mixture.
• Do not use gasoline, kerosene or alcohol for lighting charcoal. Use of any of these or similar products could cause an
explosion possibly leading to severe bodily injury.
• Never add charcoal lighting uid to hot or even warm coals as ashback may occur causing severe burns.
• Place barbecue in an area where children and pets cannot come into contact with unit. Close supervision is necessary
when barbecue is in use.
• Do not leave barbecue unattended when in use.
• Do not store or use barbecue near gasoline or other ammable liquids, gases or where ammable vapors may be
present.
• Barbecue is hot when in use. To avoid burns:
• DO NOT attempt to move the barbecue.
• Wear protective gloves or oven mitts when adjusting vents.
• DO NOT touch any hot barbecue surfaces.
• DO NOT wear loose clothing or allow hair to come in contact with barbecue.
IMPORTANT SAFETY WARNINGS
WARNING

32
WARNING
• When grilling, grease from meat may drip into the charcoal and cause a grease re. If this should happen close lid and
vents to suocate the ame. Do not use water to extinguish grease res.
• Use caution since ames can are-up when fresh air suddenly comes in contact with re. When opening the lid, keep
hands, face and body a safe distance from hot steam and ame are-ups.
• Use caution when assembling and operating your barbecue to avoid scrapes or cuts from sharp edges of metal parts.
Use caution when reaching into or under barbecue.
• In windy weather, place barbecue in an outdoor area that is protected from the wind.
• Never leave coals and ashes in barbecue unattended. Before barbecue can be left unattended, remaining coals and
ashes must be removed from barbecue. Use caution to protect yourself and property. Carefully place remaining coals
and ashes in a non-combustible metal container and saturate completely with water. Allow coals and water to remain
in metal container 24 hours prior to disposing.
• Extinguished coals and ashes should be placed a safe distance from all structures and combustible materials.
• With a garden hose, completely wet the surface beneath and around barbecue to extinguish any coals or ashes which
may have fallen during the cooking or cleaning process.
• After each use, clean the barbecue thoroughly. Cover the barbecue to protect it from excessive rusting.
• Use caution when lifting or moving barbecue to prevent strains and back injuries.
• We advise that a re extinguisher be on hand. Refer to your local authority to determine proper size and type of re
extinguisher.
• Store the barbecue out of reach of children and in a dry location when not in use.
• Properly dispose of all packaging material.
USE CAUTION AND COMMON SENSE WHEN OPERATING YOUR BARBECUE.
FAILURE TO ADHERE TO SAFETY WARNING AND GUIDELINES IN THIS MANUAL COULD
RESULT IN BODILY INJURY OR PROPERTY DAMAGE.
SAVE THIS MANUAL FOR FUTURE REFERENCE.

54
Assembly Instructions Exploded View
For Easiest Assembly:
• To avoid losing any small components or hardware,
assemble your product on a hard level surface that
does not have cracks or openings. You may wish to lay
down a blanket or similar, to avoid possible damage to
the nish during assembly.
• Clear an area large enough to layout all components
and hardware.
• Great care has been taken during production to remove
sharp edges but you should handle all components
with care to avoid injury.
• Check you have all components before beginning.
• When applicable, tighten all hardware connections by
hand rst. Once the step is completed go back and fully
tighten all hardware.
• Follow all steps in order to properly assemble your
product.
Typical assembly: approximately ½ hour.
Tools Needed:
• 5/16” Open End Wrench
• Slotted Screwdriver
• Pliers
• Phillips Head Screwdriver
No. Description Qty
1 Handle 2
2 Thermometer 1
3 Lid 1
4 Hook for Lid 1
5 Cooking Grid 1
6 Charcoal Grid 1
Parts List
No. Description Qty
7 Charcoal Basket 2
8 Fire Bowl 1
9 Ash Door 1
10 Leg Cap 4
11 Straight Leg 2
12 Ash Receiver 1
No. Description Qty
13 Bottom Tray 1
14 Wheel 2
15 Wheel Leg 2
16 Tool Hook 1
17 Air Vent 1
18 Screw Cap 2
A. M6x12
Qty. x8
B. Φ6x16
Qty. x12
C. M5x12
Qty. x4
D. Φ6x12
Qty. x3
E. M5
Qty. x4
F. M6
Qty. x14
G. M10
Qty. x2
H. Φ6x18
Qty. x4
Hardware

54
Step 1
Attach the lid handle (1) using two washers (H). Attach the lid
hanger (4) to the lid (3), using two washers (B) and wing nuts (F).
Step 2
Attach the air vent (17) in the air hole of the lid (3) using nut
(E), washer (D) and screw (C).
Assembly Instructions
Step 3
Attach the body handle (I) to the re bowl (8) using two
washers (B) & (H) and wing nuts (F). Ensure larger washers
(H) are on the outside.
Step 4
Attach the ash door (E) to the bottom of the re bowl (8)
using three screws (C) and nuts (E).
Step 5
Insert leg caps (10) on the wheel legs (15) and straight legs (11),
and attach them to the re bowl (8) bottom one by one, using
two screws (A), washers (B) and wing nuts (F) for each leg.
Step 6
Locate the wire rack (13) inside the legs, ensuring the wider
prongs are located through the holes in the short legs, then
insert the wheels (14) and secure with washers (G) and screw
caps (18) on both sides.
Step 7
Locate the other end of the wire rack through the holes in
the long legs and secure with a washer (D) and wing nut (F)
each side.
Step 8
Tighten all the screws and nuts.
Step 9
Place the charcoal grate (6) into the re bowl, and place the
cooking grill (5). Locate the tool hooks (16) on the side of the
re bowl. Add the charcoal baskets (7) if required.

76
Operating Instructions
This appliance is designed for use only with quality
charcoal briquettes or lump charcoal.
First Use
1. Make sure all labels, packaging and protective lms
have been removed from the barbecue.
2. Remove manufacturing oils before cooking on this
barbecue for the rst time, by operating the barbecue
for at least 15 minutes with the lid closed. This will
“heat clean” the internal parts a nd dissipate odours.
CAUTION: Instant light charcoal can burn at very high
temperatures during initial start up. Make sure lid is open
until charcoal turns to hot coals.
Lighting
1. Open lid and vent.
2. Make sure ash tray is empty and secure.
3. Remove cooking grid.
4. Arrange and light fuel per instructions on fuel package.
5. Allow fuel time to become glowing coals before cooking.
Cooking
Cooking directly over hot coals, ideal for searing in juices
and grilling food requiring less than 25 minutes of grilling
time, such as steaks, hamburgers, hot dogs, chicken parts,
vegetables and fruit.
1. Follow lighting instructions above.
2. While wearing protective gloves, carefully spread hot
coals evenly across charcoal grid with a long handle tool.
3. While wearing protective gloves replace cooking grid,
close lid and allow barbecue to preheat.
4. While wearing protective gloves open lid and place
food onto cooking grid above the hot coals with long
handle tongs.
5. With lid open or closed, cook until desired internal food
temperatures are achieved.
Note: If additional briquettes are needed, remove food
from cooking grid and while wearing protective gloves
remove the cooking grid and place additional briquettes
without disturbing the hot coals. Carefully replace
cooking grid and food.
7. Allow charcoal to burn out by closing lid and all vents.
Except in the case of an emergency, do NOT pour water
on hot coals.
Tips for Better Cooking and
Longer Barbecue Life
1. To reduce are-up keep barbecue clean, use lean cuts
of meat (or trim fat) and avoid cooking on very high
temperatures.
2. Place delicate foods like sh and vegetables in
aluminium foil pouches.
3. To avoid losing natural juices, use long handled tongs
or spatulas instead of forks and turn foods over just
once during cooking.
4. Enhance food avours by using wood chips in smoker
boxes or aluminium foil pouches. Follow the wood
manufacturer’s instructions.
5. Clean cooking rack after every use with a quality grill
brush designed for your rack material. Wear protective
gloves and gently remove the build-up while rack is hot.
6. After every use, allow barbecue to cool. Then protect
clean cooking rack with a light coat of cooking oil,
clean out all ashes, wipe outside surfaces with a
suitable kitchen cleaner and protect sur faces with a
quality cover that properly ts your barbecue.
Cleaning and Care
CAUTION: All cleaning and maintenance should be done
when barbecue is cool and with the fuel supply removed.
Note:
Abrasive cleaners will damage this product Never use
oven cleaner to clean any part of barbecue.
Cleaning Surfaces
1. Wipe surfaces clean with mild dishwashing detergent
or baking soda.
2. For stubborn surfaces use a citrus based degreaser and
a nylon scrubbing brush.
3. Rinse clean with water.

76
