Master Forge RT2417S User manual

1
Master Forge & M Design®is a registered
trademark of LF, LLC. All rights reserved.
Lowes.com/masterforge
ATTACH YOUR RECEIPT HERE
Serial Number _________________________ Purchase Date _________________________
Questions, problems, missing parts? Before returning to your retailer, call our
customer service department at 1-800-963-0211, 8 a.m. - 6 p.m., EST,
Monday - Thursday, 8 a.m. - 5 p.m., EST, Friday.
ITEM #0503231
3-BURNER STAINLESS STEEL GRILL
MODEL #RT2417S
Español p. 39
AB13577
WARNING
Improper installation,
adjustment, alteration, service
or maintenance can cause
injury or property damage.
Read this instruction manual
thoroughly before installing or
servicing this equipment.
WARNING
1. Do not store or use gasoline or
other ammable vapors and
liquids in the vicinity of this or
any other appliance.
2. An LP tank not connected for
use should not be stored in the
vicinity of this or any other
appliance.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open ames.
3. Open the lid.
4. If the odor continues, keep
away from the appliance and
immediately call your gas
supplier or re department.
WARNING
For Outdoor Use Only
GAS-FIRED
C US
MH 10297

2Lowes.com/masterforge
TABLE OF CONTENTS
Safety Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Safety Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Package Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Hardware Contents . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7
Preparation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Assembly Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
Natural Gas Conversion Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Cooking with Gas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19
Operating Instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Care and Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 34
Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
Replacement Parts List. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 37

3Lowes.com/masterforge
SAFETY INFORMATION
Please read and understand this entire manual before attempting to assemble, operate
or install the product. If you have any questions regarding the product, please call
customer service at 1-800-963-0211, 8:00 am to 6:00 pm, EST, Monday- Thursday, 8:00
a.m. to 5:00 p.m., EST, Friday.
1. The installation of this appliance must conform with local codes or, in the absence of local
codes, with either the National Fuel Gas Code, ANSI Z223.1/NFPA 54, or Natural Gas
and Propane Installation Code, CSA/CGA-B149.1.
2. This grill is intended for use outdoors and should not be used in a building, garage or any
other enclosed or covered area.
3. This outdoor grill is not intended for installation in or on recreational vehicles and/or boats.
4. A minimum clearance of 36 in. from combustible constructions to the sides of the grill and
36 in. from the back of the grill to combustible constructions must be maintained. This
outdoor cooking gas appliance must not be placed under overhead combustible
construction.
5. The use of an electrical source requires that when installed, the grill must be electrically
grounded in accordance with local codes or, in the absence of local codes, with
ANSI/NFPA 70, or the Canadian Electrical Code, CSA C22.1. Keep electrical supply cords
and the fuel supply hose away from heated surfaces.
6. Inspect the hoses before each use for excessive abrasion or wear, or cuts that may affect
safe operation of the grill. If there is evidence of excessive abrasion or wear, or the hose is
cut, it must be replaced prior to the grill being put into operation. The replacement hose
assembly must be those specied by the manufacturer.
7. Keep your grill in an area clear and free from combustible materials, gasoline and other
ammable vapors and liquids.
8. DO NOT obstruct the ow of combustion and ventilation air to this appliance.
9. Keep the ventilation openings of the tank enclosure free and clear from debris.
10. Check all gas connections for leaks with a soapy water solution and brush. Never use an
open ame to check for leaks.
11. Never use charcoal in the grill.
12. Never use the grill in windy areas.
13. Only a 20 lb. LP-gas cylinder is allowed. The cylinder must be
constructed and marked in accordance with the Specications for
LP Gas Cylinders of the U.S. Department of Transportation (D.O.T.)
or the National Standard of Canada, CAN/CSA-B339, Cylinders,
Spheres and Tubes for Transportation of Dangerous Goods; and
Commission. A 20 lb LP-Gas cylinder’s dimensions are:
14. Never use the grill without the drip tray installed and pushed completely into the back of
the grill. Without the drip tray, hot grease and debris could leak downward and produce a
re hazard.
18 in
13.9 in
8 in
12.2 in

4Lowes.com/masterforge
SAFETY INFORMATION
15. The pressure regulator for LP-gas grill is set for 11-in. water column (WC). Natural gas
grill provides a hose assembly which includes a quick-disconnect device, but no pressure
regulator. The LP pressure regulator or the natural gas hose assembly must be used.
Replacement pressure regulators and hose assemblies must be those specied in the
parts list.
16. The cylinder used must include a collar to protect the cylinder valve.
17. Do not store a spare LP-gas cylinder under or near this appliance.
18. Never ll the cylinder beyond 80 percent full.
19. If the information in “17” and “18” is not followed exactly, a re
causing death or serious injury may occur.
20. The natural gas grill and its individual shutoff valve must be disconnected from the gas
supply piping system during any pressure testing of that system at test pressures in
excess of 0.5 PSI (3.5 kPa).
21. The outdoor cooking gas appliance must be isolated from the gas supply piping system
by closing its individual manual shutoff valve during any pressure testing of the gas supply
system at test pressures equal to or less than 1/2 PSI (3.5 kPa).
22. CALIFORNIA PROPOSITION 65 WARNING: The burning of gas cooking fuel generates
some byproducts which are on the list of substances known by the state of California to
cause cancer, reproductive harm, or other birth defects. To reduce exposure to these
substances, always operate this unit according to the use and care manual, ensuring you
provide good ventilation when cooking with gas.
IMPORTANT: We urge you to read this manual carefully and follow the recommendations
enclosed. This will ensure you receive the most enjoyable and trouble-free operation of your
new gas grill. We also advise you retain this manual for future reference.
WARNING: Your grill has been designed to operate using only the gas specied by the
manufacturer on the rating plate. Do not attempt to operate your grill with other gases. Failure
to follow this warning could lead to a re hazard and bodily harm and will void your warranty.
WARNING: Make certain your LP (propane) tank is lled by a reputable propane dealer. An
incorrectly lled or an overlled LP tank can be dangerous. The overlled condition combined
with the warming of the LP tank (a hot summer day, tank left in the sun, etc.) can cause LP
gas to be released by the pressure relief valve on the tank since the temperature increase
causes the propane to expand. LP gas released from the tank is ammable and can be
explosive. Refer to your Owner’s Manual for more information concerning lling your LP tank.
This unit contains one or more patents pending:
61/163,753
61/215,319
11/495,104
11/268,051

5Lowes.com/masterforge
SAFETY TIPS
●Never pull your grill. Always push it.
●Never move your grill while it is in operation or still hot.
●Always use a protected hand when cleaning the grid surface after the post-heating period an
when closing the propane tank valve.
●Use a covered hand during the grilling period.
●Wait until the burner box has completely cooled before reaching under to turn off the gas
●Using an uncovered hand to turn off the LP tank valve without allowing the grill to cool down
could result in severe burns.
●Never operate your grill under overhangs, awnings or any covered or enclosed area.
● Never spray liquid on the grid area to control are ups.
● To guard against possible grease res getting out of control, never leave a grill unattended.
● Grease res can be severe and cause grill damage, property damage and bodily harm.
● Always turn off the control knob rst, then the propane gas supply tank.
●Never cover your grill while it is still warm.
●Position your portable grill away from direct wind.
● Do not store or use gasoline or other ammable substances in the vicinity of your gas grill.
●Never store a propane tank (whether full or empty) inside your home or living area.
●Before storing your tank, make sure that it has been turned to the “OFF” position.
●Should you store your grill indoors, be sure to close the tank valve, disconnect the hose from
the tank, remove the tank from the grill and store the tank outdoors.
●Make sure the grill hood is completely open before lighting your grill.
● When connecting or replacing any gas ttings, all joints must be sealed with an approved,
leak-proof sealing compound.
● Never use an open ame to test for gas leaks.
●When your grill is not in use, it is recommended that for child safety, you remove the control
knobs and store them indoors.
●Keep children away from the grill at all times.
● Never drill out any orice or make any eld alterations to your grill without receiving approval
from the manufacturer.
● Do not store ammable materials in any of the cabinets beneath the grill burner box or in the
vicinity of your grill.
●Be careful while handling any parts during assembly. It is strongly recommended that you
protect your hands with a pair of work gloves.
●At high temperatures, some stainless grids may discolor over time. When the grill is cool,
wiping with a towel and vegetable oil may remove and treat some of this effect. Some
discoloration is normal.

6Lowes.com/masterforge
PACKAGE CONTENTS
A
H
G
I J K L
M
N
O
PQ
R
S
T
U
B C D
E
F

7Lowes.com/masterforge
PACKAGE CONTENTS
PART DESCRIPTION QUANTITY
A Burner Box 1
BHeat Tent 3
CMain Grid 2
DWarming Rack 1
ERight Side Shelf
Bracket 2
FRight Side Shelf 1
G Left Side Shelf 1
HLeft Side Shelf
Bracket 2
IDrip Tray Support 1
JSafety Tank Ring 1
K Tank Ring Bracket 1
PART DESCRIPTION QUANTITY
L Rear Panel 1
MIgniter 1
NRight Panel 1
ODrip Tray 1
PBottom Panel 1
QLocking Caster 2
R Caster 2
S Door 1
T Left Panel 1
U Front Beam 1

8Lowes.com/masterforge
HARDWARE CONTENTS
AA BB CC
3/16-24 x 1/2 in.
Screw
qty. 49
1/4-20 x 5/8 in.
Screw
qty. 2
AA Battery
qty. 1
PREPARATION
Before beginning assembly of product, make sure all parts are present. Compare parts
with package contents list and hardware contents list. If any part is missing or damaged,
do not attempt to assemble the product.
Estimated Assembly Time: 30 minutes by 2 people
Tools Required for Assembly: Phillips screwdriver (sold separately)

9Lowes.com/masterforge
ASSEMBLY INSTRUCTIONS
WARNING: The grill should be assembled and placed on a at, level suface.
Compare the parts and hardware with the list and diagrams. Do not attempt assembly if
any part is missing or damaged.
1. Attach the locking casters (Q) and the
casters (R) to the bottom panel (P)
using 12 screws (AA). When this process
is completed, turn the bottom panel over.
The two locking casters (Q) should be
at the back of the grill.
2. Align the holes in the rear panel (L)
with the holes in the bottom panel (P)
and insert screws (AA) into the aligned
holes.
Note: Do not tighten the screws
completely. Leave at least one full turn
on each. After all the screws have been
installed, go back and tighten them fully.
Hardware Used
Hardware Used
AA 3/16-24 x 1/2 in.
Screw x 12
AA
AA
3/16-24 x 1/2 in.
Screw x 3
1
AA
Q
P
R
2
P
L

10 Lowes.com/masterforge
ASSEMBLY INSTRUCTIONS
3. Attach the left panel (T) and right panel (N) to
the bottom panel (P). For both the left and
right panels, there are three screws for the
rear panel (L) and four for the bottom panel.
Insert the four bottom panel screws rst.
Hardware Used
AA 3/16-24 x 1/2 in.
Screw x 14
4. Attach the front beam (U) to the left panel (T)
and the right panel (N) with 2 screws (AA)
on each side as shown.
Hardware Used
AA 3/16-24 x 1/2 in.
Screw x 4
3
AA
L
N
P
T
AA
U
4

11 Lowes.com/masterforge
ASSEMBLY INSTRUCTIONS
5. Slide the tank ring bracket (K) onto the end
of the safety tank ring (J) as shown. Attach
the tank ring bracket to the rear panel (L)
with 2 screws (BB) as shown.
6. Attach the drip tray support (I) to the front
beam (U) and rear panel (L) with 4 screws
(AA) as shown.
7. Remove the cap and the nut from the igniter
(M). Secure the igniter to the right panel (N)
with the nut. Then, reassemble the cap to
the igniter.
Hardware Used
AA 3/16-24 x 1/2 in.
Screw x 4
Hardware Used
1/4 - 20x 5/8 in.
Screw x 2
5
BB
BB
K
J
6AA
UI
7
Nut Cap
M

12 Lowes.com/masterforge
ASSEMBLY INSTRUCTIONS
8. For the door (S), insert bottom hinge pin into
hole on bottom panel (P). Push top hinge
pin in the corner of the door to insert into
hole in top corner of the right panel (N).
Then, put the drip tray (O) onto the drip tray
support (I).
9. Take the pressure regulator out from under
the burner box (A). Lift the burner box (A)
onto the cabinet, making sure that the gas
pressure regulator is in the cabinet, then
position burner box on the cabinet by
aligning the four tabs on top of the cabinet
with the holes in the burner box. Fasten the
burner box to the cabinet with 4 screws (AA).
Hardware Used
AA 3/16-24 x 1/2 in.
Screw x 4
8
9
S
N
IO
AA
Tab
Pressure
regulator
A

13 Lowes.com/masterforge
ASSEMBLY INSTRUCTIONS
10. Attach the left side shelf bracket (H) to the
left of the burner box (A) and the right side
shelf bracket (E) to the right of the burner
box with 2 screws (AA) on each bracket.
Hardware Used
AA
AA
3/16-24 x 1/2 in.
Screw x 8
Complete Steps 11 - 13 to complete assembly
of the left side shelf (G) and right side shelf (F).
11. Move the side shelves from front to back,
making sure the screw on the side shelf
brackets t inside the holes on the side
shelves.
10 H
H
E
E
11
G
F
Side shelf
bracket Side shelf

14 Lowes.com/masterforge
ASSEMBLY INSTRUCTIONS
12. Hang the side shelves on the brackets
and slowly rotate the side shelves.
13. Adjust the side shelves until they are
aligned with the control box.
14. Plug the main burner igniter wires into
the sockets in the igniter.
12
13
14
G
G
F
F
Control box
Igniter wires

15 Lowes.com/masterforge
ASSEMBLY INSTRUCTIONS
15. Place the heat tents (B), main grids
(C) and warming rack (D) into the
burner box (A). Remove the battery
cap on the igniter (M) and insert a AA
battery (CC) with the positive end
facing outward. Replace the cap.
B
C
D
Insert
AA battery
15

16 Lowes.com/masterforge
ASSEMBLY INSTRUCTIONS
IMPORTANT
CHECK SPARKS
After you complete your grill assembly, test your ignition system with the GAS OFF.
Check for continuous sparks when pushing in the knob ignition system.
For the side burner, sparks can be seen directly. For main burners, the ignition system
is positioned next to each burner inside the burner box. A reection of sparks or sparks
can be seen at the front of the inside of the burner box, or you can place a mirror on the
left of each main burner and see the sparks and hear the click of the igniters. Be sure the
GAS IS OFF when you push in the control knobs. This will help assure a trouble-free
ignition when you turn on the gas.
ASSEMBLED GRILL DIMENSION (INCHES):
46 (HEIGHT) x 51.2 (WIDTH) x 22.3 (DEPTH) (SIDE SHELF FOLDED OUT)
46 (HEIGHT) x 32 (WIDTH) x 22.3 (DEPTH) (SIDE SHELF FOLDED DOWN)
WARMING RACK AREA (SQUARE INCHES): 142
THE UL LABEL IS ON THE BACK OF THE DOOR, SHOWN AS PICTURED BELOW.
31EV
MH10297
31EV
MH10297
(a) Do not store a spare LP-Gas cylinder under or near this appliance.
(b) Never fill the cylinder beyond 80 percent full.
(c) If the information in “(a)” and “(b)” is not followed exactly, a fire causing death or serious injury may occur.
MADE IN CHINA
CON CERTIFICACIÓN ANS Z21.58a-CSA 1.6a-
2008. ELECTRODOMÉSTICOS DE COCINA A
GAS PARA EXTERIORES.
PARA USO EN EXTERIORES SOLAMENTE. SI
GUARDA LA UNIDAD EN EL INTERIOR,
RETIRE EL TANQUE Y DÉJELO EN EL
EXTERIOR.
L G Sourcing Inc.
P.O.Box 1535 North Wilkesboro,
NC, 28659 USA
Modelo No. RT2417S
Tipo de gas: propano (Convertible a
Gas Natural)
Entrada: Quemador principal:
3x12,000 BTU/h
Debe haber un espacio de separación mínimo de 91,44 cm desde los lados
y la parte posterior de la unidad hasta construcciones de material
combustible.
No use este electrodoméstico debajo de superficies combustibles.
Este electrodoméstico de cocina a gas para exteriores no está diseñado
para instalarse en vehículos recreativos ni en botes.
(a) No almacene un tanque de gas propano de reserva debajo o cerca de este aparato.
(b) Nunca llene el tanque a más del 80% de su capacidad.
(c) Si no sigue con precisión la información en “(a)” y “(b)”, puede provocar un incendio que produzca lesiones
graves o la muerte. HECHO EN CHINA
Date de fabrication : XX N° de série : RT000001
L G Sourcing Inc.
P.O.Box 1535 North Wilkesboro,
NC, 28659 USA
Model No.: RT2417S
Type of Gas:Propane(Convertable to
Natural Gas)
Input: Main Burner: 3x12,000 BTU/Hr
Minimum clearance from sides and back of unit to combustible construction,
36 inches from sides and 36 inches from back.
Do not use this appliance under overhead combustible surfaces.
This outdoor cooking gas appliance is not intended to be installed in or on
recreational vehicles and / or boats.
Manufacturing Date: XX Serial No.: RT000001
CERTIFIED UNDER ANS Z21.58a-CSA 1.6a-
2008. OUTDOOR COOKING GAS APPLIANCES.
FOR OUTDOOR USE ONLY. IF STORED
INDOORS, DETACH AND LEAVE CYLINDER
OUTDOORS.
GAS-FIRED
C US
GAS-FIRED
C US

17 Lowes.com/masterforge
NATURAL GAS CONVERSION INSTRUCTIONS
Should you decide to convert your gas grill
from liquid propane gas to natural gas,
use NG Conversion Kit Item #0050772.
The #0050772 kit contains orices for various grill
models. Please select the orices as listed and
discard the rest. Follow the conversion instruction
provided with the kit.
Main Burner Conversion
16. Pull off the R-pins and take the main
burners out. Adjust main burners’ air shutters
by loosening the air shutter screws.
17. The settings are:
1/4 in. open for LP gas.
1/16 in. - 1/8 in. open for NG gas.
You need to adjust the openings before you
put the burners back in the burner box.
Model Item number Main burner
Φ1.37
RT2417S 0503231 3
R-pin Main burner
16
17
Air shutter

18 Lowes.com/masterforge
18. Remove the LP orices rst with the orice
removal tool, then install the NG orice. Make
sure you are using the correct orice, marked
“1.37”.
When this step completed, install the main
burners back to the rebox and secure to the
bracket with the R-pins.
Make sure the orices are aligned with the
burners and the ignition pins are installed
in their original positions. Check the sparks
before operating the grill.
Change to 10 ft. NG hose
19. Take the regulator off from the manifold and
replace it with 10-ft. natural gas hose. Please
make sure the hose is securely fastened.
Adjust valve control screw
20. Pull all the knobs off from valve stems. Adjust
the screw in the valve hole using the athead
screwdriver. Turn screws two complete turns
counterclockwise.
21. To complete conversion, re-install all knobs,
return heat diffusers to rebox, followed by the
grates and warming rack.
NATURAL GAS CONVERSION INSTRUCTIONS
18
1.37
19
20
Valve hole

19 Lowes.com/masterforge
COOKING WITH GAS
For Portable LP-Gas Connection
The cabinet has an opening in the bottom panel that allows a 20 lb. gas tank bottom ange to
drop into place (tank sold separately). This will help to lock the tank in place. Before installing
your gas tank, lift up the safety tank ring (as shown in Fig. 21a). After positioning the tank in
the opening, lower the safety tank ring to lock the tank in place. Use only a 20 lb. gas tank
(see LP Gas Safety Requirements for Additional Information). As shown in Fig. 21b, it is
unsafe to operate the grill if the gas tank is not vertical.
LP Tank
Fig. 21a Fig. 21b
WARNING: The Type I connective coupling (see Fig. 22) supplied with your grill must
not be replaced with a different type of grill/tank connection system. Removal will
result in loss of warranty, gas leakage, re and severe bodily harm.
HAND WHEEL
TYPE I VALVE
EXTERNAL
THREAD
THERMALLY
SENSITIVE NUT
PROPANE
REGULATOR
The propane tank valve connection supplied with this grill incorporates four important safe guards:
Hand Assembly, Hand Disassembly, Excess Flow Control and Temperature-Activated Shut-Off.
Fig. 22

20 Lowes.com/masterforge
COOKING WITH GAS
a. Hand Assembly:
1. Make certain the tank valve and all the appliance valves are in the “OFF” position.
2. When connecting the regulator/burner valve assembly to the tank valve, turn the large plastic
nut clockwise until it stops.
3. Gas will not ow unless the plastic nut is completely connected.
4. HAND TIGHTEN ONLY.
b. Hand Disassembly:
1. Make certain the tank valve and all the appliance valves are in the “OFF” position.
2. Turn the large plastic nut counterclockwise until it is disassembled.
3. HAND LOOSEN ONLY.
c. Excess Flow Control and Low Heat:
The propane regulator assembly incorporates an excess ow device designed to supply the
grill with sufcient gas ow under normal conditions yet control excess gas ow.
Rapid changes in pressure can trigger the excess ow device providing a low ame and low
temperature. If the tank valve is turned open to allow gas ow while a burner valve is open,
the surge of pressure will cause the device to activate. The device will remain closed until the
pressure is equalized. This should occur within 5 seconds.
To ensure this does not cause difculty in lighting the grill, follow these instructions:
1. Make sure all burner valves are “OFF”.
2. Open the tank valve and wait 5 seconds.
3. Light the burners one at a time following the lighting instructions.
d. Temperature-Activated Shut-Off:
The large plastic nut on the regulator assembly is designed in coordination with a check valve
in the tank valve to shut off the ow of gas when exposed to temperatures between
240-300° F.
In the event of a re or hose break, one of the safeguards will function to control or stop the
ow of gas from the propane tank. Never attempt to use damaged equipment.
Important: Before the use of a fresh tank of gas, please check leakage around the
connections according to section ‘Checking Gas Leaks’ and make sure there is no
leakage or vapor accumulation in the cabinet. Make sure all openings around side
walls are not blocked.
Important: Place dust cap on cylinder valve outlet whenever the cylinder is not in use.
Only install the type of dust cap on the cylinder valve outlet that is provided with the
cylinder valve. Other types of caps or plugs may result in leakage of propane.
