CHARCOAL GRILL
Manual applies to the following model number(s)
These numbers are located on the rating label of the unit.
Mfg. Date - Serial NumberYour model number
MB20042119
IMPORTANT, RETAIN FOR FUTURE REFERENCE: READ CAREFULLY
IMPORTANT
FOR OUTDOOR USE ONLY. NOT FOR COMMERCIAL USE.
Manual Code: 9804190097 | 191120-SPS
Master it. Masterbuilt.

2
WARNINGS AND IMPORTANT SAFEGUARDS
• This manual contains important information necessary for the proper assembly and safe use of the
appliance.
• Read and follow all warnings and instructions before assembling and using the appliance.
• Keep this manual for future reference.
• WARNING! Do not use spirit or petrol for lighting or re-lighting! Use only firelighters complying to
EN 1860-3!
WARNING
READ ALL INSTRUCTIONS
• Always use grill in accordance with all applicable local, state, and federal fire codes.
• Before each use check all nuts, screws, and bolts to make sure they are tight and secure.
• Never operate grill under overhead construction such as roof coverings, carports, awnings, or overhangs.
• Grill is for OUTDOOR HOUSEHOLD USE ONLY.
• Never use inside enclosed areas such as patios, garages, buildings, or tents.
• Never use inside or on recreational vehicles or boats.
• Maintain a minimum distance of 3 m from overhead construction, walls, rails or other structures.
• Keep a minimum 3 m clearance of all combustible materials such as wood, dry plants, grass, brush, paper,
or canvas.
• Never use grill for anything other than its intended use. This grill is NOT for commercial use.
• Accessory attachments not supplied by Masterbuilt Manufacturing, LLC are NOT recommended and may
cause injury.
• Use of alcohol, prescription, or non-prescription drugs may impair user’s ability to properly assemble or
safely operate grill.
• Keep a fire extinguisher accessible at all times while operating grill.
• When cooking with oil or grease, have a type BC or ABC fire extinguisher readily available.
• In the event of an oil or grease fire do not attempt to extinguish with water. Immediately call the fire
department. A type BC or ABC fire extinguisher may, in some circumstances, contain the fire.
• Use grill on a level, non-combustible, stable surface such as dirt, concrete, brick, or rock. An asphalt
surface (blacktop) may not be acceptable for this purpose.
• Grill MUST be on the ground. Do not place grill on tables or counters. Do NOT move grill across uneven
surfaces.
• Do not use grill on wooden or flammable surfaces.
MB-CGW-190611
CARBON MONOXIDE HAZARD
• Burning wood chips, wood chunks, wood pellets, charcoal and propane gives off carbon monoxide,
which has no odor and can cause death.
• DO NOT burn wood chips, wood chunks, wood pellets, charcoal or propane inside homes, vehicles,
tents, garages or any enclosed areas.
• USE ONLY OUTDOORS where it is well ventilated.
• Do not use the barbecue in a confined and/or habitable space e.g. houses, tents, caravans, motor
homes, boats. Danger of carbon monoxide poisoning fatality.
Failure to follow these instructions could result in fire, explosion or burn
hazard which could cause property damage, personal injury, or death.
19
Masterbuilt 2-Year Limited Guarantee/Warranty
WHAT IS NOT COVERED: These guarantees are based on normal and reasonable domestic use and good
maintenance of the product. The warranty does not apply to additional or unforeseen damage or breakage, or
for damage caused by: transport; drop; wrong assembly; incorrect support; attempts to support the product
by means other than an approved Masterbuilt accessories or solid, non-flammable surface under the base;
commercial use; amendments; changes; negligence; abuse; improper care / maintenance; hazards on the
road; normal and reasonable wear; or natural disasters.
The warranty does not apply to scratches, dents, shards, hairline cracks, the appearance of small cosmetic
cracks in the outer layer of glaze that do not affect the operation of the product.
Buying a Masterbuilt product or related items through unauthorized dealers, unauthorized retail channels
and unauthorized third parties voids the warranty.
Note: When consumers buy something from an unauthorized source, even if it works as a lawful company
and offers products in unopened boxes with blank warranty cards (but is an unauthorized reseller), they sell
second-hand products according to the legal definition. If someone buys something from an unauthorized
reseller or trader, or from an unauthorized online reseller, it almost always concerns products without a
manufacturer’s warranty, regardless of any statements or claims made by the seller. This is the standard
policy of many brands and companies, not just Masterbuilt.
COVERAGE DATE: Warranty coverage commences when a product purchased from an authorized dealer
by the original purchaser and owner is registered with masterbuilt.com as required by these warranty
conditions. A valid proof of purchase from an authorized dealer is required to file a warranty claim.
COVERAGE ACCORDING TO THE GUARANTEE: Original parts of Masterbuilt which are found to contain material
and construction faults and which are covered by a valid and registered warranty will be replaced or repaired
free of charge at Masterbuilt’s discretion, subject to the terms and conditions of this warranty.
WARRANTY CLAIM PROCEDURE: For warranty support, please contact the authorized dealer from whom you
purchased the item.
For products purchased in countries outside Europe, warranty claims are handled by an authorized dealer
or distributor in the country where they were purchased. Consult the INTERNATIONAL section of the
masterbuilt.com website to find the recognized international Masterbuilt distributor in your specific region.
Warranty claims must be submitted through an authorized dealer or distributor in the country where the item
was originally purchased. Do not submit parts for a warranty claim before contacting an authorized dealer or
distributor, as in some cases there is no need to return the guaranteed part.

18
Grilling Guide
BEEF SIZE GRILLING TIME INTERNAL TEMP
Steaks 2cm thick 3-4 min./side Med. rare 62°C
4-5 min./side Med. 71°C
Kabobs 2.5cm cubes 3-4 min./side 62°-71°C
Hamburger patties 12mm thick 3-4 min./side Med. 71°C
Roast, rolled rump 1.8-2.7kg 18-22 min./lb. 62°-71°C
Sirloin tip 1.5-1.8kg 20-25 min./lb. 62°-71°C
Ribs, back Cut in 1-rib portions 10 min./side Med. 71°C
Half, 0.9-1.3kg 10-12 min./side Med. rare 62°C
Tenderloin Whole, 1.8-2.7kg 12-15 min./side Med. 71°C
PORK SIZE GRILLING TIME INTERNAL TEMP
Chops, bone-in 2cm thick 3-4 min./side Med. 71°C
Chops, bone-out 4cm thick 7-8 min./side Med. 71°C
Tenderloin 0.2-.06kg 15-20 min. total Med. 62°C
Ribs (indirect heat) 0.9-1.8kg 1½-2 hrs. Med. 71°C
VENISON SIZE GRILLING TIME INTERNAL TEMP
Roast, saddle or leg 2.7-3.1kg 25-30 min./lb. 62°-71°C
Steaks 2cm thick 6-7 min./side Med. 71°C
CHICKEN SIZE GRILLING TIME INTERNAL TEMP
Broiler fryer (indirect heat) 1.3-1.8kg 60-75 min. In thigh 82°C
Cornish hen 510-680g 45-55 min. In thigh 82°C
Breast halves, bone-in 170-226g each 10-15 min./side 77°C
Breast halves, boneless 113g each 6-8 min./side 77°C
Legs or thighs 13-226g 10-15 min./side 82°C
Drumsticks 113g 8-12 min./side 82°C
Wings 56-85g 8-12 min./side 82°C
• When outside temperature is cooler than 18°C and/or altitude is above 1067m, additional cooking time may
be required.
• To ensure that meat is cooked thoroughly use a meat thermometer to test internal temperature.
• Lifting grill lid during cooking process may extend cooking time due to heat loss.
3
WARNINGS AND IMPORTANT SAFEGUARDS
• Keep grill clear and free from combustible materials such as gasoline and other flammable vapors and
liquids.
• Do not leave grill unattended.
• Keep children and pets away from grill at all times. Do NOT allow children to use grill. Close supervision is
necessary when children or pets are in the area where grill is being used. • Do NOT allow anyone to
conduct activities around grill during or following its use until it has cooled.
• Never use glass, plastic, or ceramic cookware in grill. Never place empty cookware in grill while in use.
• Never move grill when in use. Allow grill to cool completely (below 45°C) before moving or storing.
• Do not store grill with hot ashes or charcoal inside grill. Store only when fire is completely out and all
surfaces are cold.
• Never use grill as a heater (READ CARBON MONOXIDE HAZARD).
• The grill is HOT while in use and will remain HOT for a period of time afterwards and during cooling
process. Use CAUTION. Wear protective gloves/mitts.
• Be careful when removing food from grill. All surfaces are HOT and may cause burns. Use protective
gloves/mitts or long, sturdy, cooking tools for protection from hot surfaces or splatter from cooking liquids.
• DO NOT bump or impact the grill to prevent personal harm, damage to grill, or spillage/splashing of hot
cooking liquid.
• Do not touch HOT surfaces
• Grill is hot during use. To avoid burns, keep face and body away from door(s) and vents. Steam and hot air
are expelled during use.
• Air dampers are HOT while the grill is in use and during cooling; wear protective gloves when adjusting.
• Grill has an open flame. Keep hands, hair, and face away from flame and burning charcoal. Do NOT lean over
grill when lighting. Be careful of loose hair and clothing during operation as they could catch fire.
• DO NOT obstruct flow of combustion and ventilation.
• Do not cover cooking racks with metal foil. This will trap heat and may cause damage to the grill.
• Never leave HOT coals or ashes unattended.
• Fuel should be kept red hot for at least 30 minutes prior to use.
• Do not cook before the fuel has a coating of ash.
• Do not remove ash can while ashes and charcoal are HOT.
• Use protective gloves when handling this grill or working with fire. Use protective gloves or long, sturdy
fireplace tools when adding charcoal.
• Use only charcoal as fuel. Do not use any other fuel source.
• Use only charcoal lighting fluid. Never use gasoline, alcohol or other highly volatile fluids to ignite charcoal.
These fluids can explode causing injury or death.
• Never overfill charcoal grate. This can cause serious injury as well as damage to the grill.
• Never add additional lighter fluid once charcoal has ignited. Follow directions on lighter fluid container.
• Dispose of cold ashes by placing them in aluminum foil, soaking with water, and discarding in a non-
combustible container.
SAVE THESE INSTRUCTIONS

4
Structural Proximity and Safe Usage Recommendations
REMINDER: Maintain a
minimum distance of 10
feet from rear and sides to
walls, rails or other
combustible construction.
This clearance provides
adequate space for proper
combustion, air circulation
and venting.
3 m 3 m 3 m
Packing Contents
IMPORTANT: Remove all packing contents before assembly.
It is important that you remove all paper,
packing foam and cardboard from the grill
before assembly.
Located on the lid/firebox assembly is a
support bar used for shipping purposes only.
This bar must be removed so that you may
successfully assemble your grill. The location
of this bar is shown here. The bar is no longer
needed.
Remove support bar
17
1. Raise the cooking grate, open the charcoal door and open air
dampers.
2. Stack/place up to 1.8kg of charcoal on charcoal tray. Stack charcoal
in a pyramid. Use only charcoal as fuel. Do not use any other fuel
source.
3. Close charcoal door.
4. Add lighter fluid following directions on fluid container. Before
lighting, place lighter fluid at least 7.5m away from grill. Do not lean
into grill when lighting charcoal. Light charcoal. LEAVE GRILL LID
OPEN.
5. In about 15 minutes flames will die out and charcoal will begin to
ash over. Once the charcoal is completely ashed over, spread
charcoal in a single layer.
• If planning to cook for more than 30 to 40 minutes, additional charcoal should be added. Add 10 to 20
briquets to the outer edge of the fire immediately after initial briquets have been spread on tray. Once these
briquets become 80% ashed over, add them to the center of the fire as needed to maintain constant
cooking temperatures. Read all instruction and warnings on charcoal bag.
6. With protective gloves on, lower cooking grate into position.
7. DO NOT cover cooking grate with aluminum foil as this will not allow heat to circulate properly.
8. Place food in the grill, position in the center of the cooking grate.
9. DO NOT overload grill with food. Extra large amounts of food may trap heat, extend cooking time and cause
uneven cooking. Leave space between food on grate and grill sides to ensure proper heat circulation. If
utilizing cooking pans, place pans on center of grate to ensure even cooking.
10. Adjust grill air dampers and charcoal tray height to reach desired cooking temperature.
• Close all air dampers on unit to retain moisture and heat. If cooking foods such as fish or jerky, open air
dampers to release moisture.
• Start with grate in lowest position and raise as needed to reach desired grate temperature.
Tip: The adjustable charcoal tray can be moved to within a few inches of the cooking grate allowing you to
sear your meat and lock in the juices. Searing takes only a few minutes on each side. Don’t allow the meat
or food to burn. After searing, lower the charcoal tray back to the bottom and cook the food to your
personal preference.
11. Extreme cold temperatures may extend cooking times.
12. Once cooking is complete allow grill to cool and then follow CLEANING AND STORAGE. CLEAN AFTER EVERY
USE. This will extend the life of your grill and prevent mold and mildew.
Operating Instructions
LIGHTING YOUR GRILL
Dump charcoal into
charcoal tray as
shown here.
Position charcoal
tray at lowest
adjustment height.
Fig. A
• ALWAYS MAKE SURE UNIT IS COOL TO THE TOUCH BEFORE CLEANING AND STORING.
• Inspect hardware and assembled parts on a regular basis to ensure grill is in safe working condition.
• Always empty ash tray after each use once ashes have completely cooled. This will help prolong the life of
the ash tray.
• Clean grill and cooking grate with mild dish detergent. Wipe outside of grill with a damp rag. DO NOT use
oven cleaner or other cleaning agents. Make sure to dry thoroughly.
• After ashes are cold, clean ash tray and inside of firebox after every use to remove ash build up, residue and
dust.
• Dispose of cold ashes by placing them in aluminum foil, soaking with water and discarding in a non-
combustible container.
• Always cover and store grill in a protected DRY AREA. Store only when fire is out and all surfaces are cold.
• When grill is not in frequent use, even when using a grill cover, remember to check your grill periodically to
avoid possible rust and corrosion due to moisture buildup.
CLEANING AND STORAGE

16
Assembly
19
K
X2
KK
27
24
Operating Instructions
PRE-SEASONING YOUR GRILL
Pre-seasoning will rid your grill of chemicals and oils left over by the manufacturing process allowing them
to burn off. PRE-SEASON GRILL PRIOR TO FIRST USE.
1. Using a napkin or cloth, rub a light coat of cooking oil on cooking grate, charcoal tray, inside grill lid and
firebox.
2. Raise the cooking grate, open the charcoal door and open air dampers.
3. Stack/place up to 1.8kg of charcoal on charcoal tray. Stack charcoal in a pyramid, close charcoal door
and light charcoal (see LIGHTING YOUR GRILL below). LEAVE GRILL LID OPEN. In about 15 minutes when
the flames die out, spread charcoal into a single layer. Use only charcoal as fuel. Do not use any other fuel
source.
4. With protective gloves on, lower cooking grate into position. CLOSE THE LID.
5. Let the grill burn for about 1 hour. Make sure the temperature reaches 177°C.
6. Allow grill to cool COMPLETELY.
7. Reapply a light coat of cooking oil on cooking grate, charcoal tray, inside grill lid and firebox.
8. Relight the grill and burn for 20 minutes.
Frequent seasoning prevents rusting. If rusting occurs, clean with a steel brush, apply vegetable shortening,
and heat as indicated above.
5
Hardware List
Qty Description Qty Description
A8 M6x52 Hex Phillips/Slotted-Head Screw I1 M6x21 Shoulder Screw
B2 M8 Axle Nut J2 #10 Lock Washer
C2 #8 Flat Washer K39 M6x15 Phillips/Slotted-Head Screw
D2 Door Hinge Pin L3 Cotter Pin
E2 M10 Nut M2 Axle Bushing
F12 M5x10 Flat-Head Screw N1 M5 Self-Locking Nut
G4 M5x8 Shoulder Screw O1 M5x15 Screw
H3 M6 KEPS Nut P2 M6x15 Flathead Screw
DO NOT RETURN TO RETAILER for assembly assistance, missing or damaged parts. Please
contact MASTERBUILT Customer Service at [phone] or service[email protected] in
the U.K and +0031 4 7799920, [phone], or service.eur[email protected] in Europe.
Please have the model number and serial number available. These numbers are located on the
silver rating label on the grill.
STOP
•BEFORE ASSEMBLY READ ALL INSTRUCTIONS CAREFULLY.
• Assemble on a clean flat surface.
• Tools needed: 20.32 cm long Phillips head screwdriver, pliers or adjustable wrench
• Approximate assembly time: 45 minutes
• Actual product may differ from picture shown.
• It is possible that some assembly steps have been completed in the factory.

6
Parts List
Actual product may differ
from picture shown.
Item # Qty Description
1 1 Cooking Grate Rear Frame
2 2 Cooking Grate
31
Cooking Grate Front Frame with Handle
4 1 Smoke Stack Cap
5 1 Smoke Stack
6 1 Temperature Gauge
7 2 Lid Handle Stand-Off
8 1 Lid Handle
9 2 Side Shelf
10 1 Slotted Adjustment Panel
11 1 Charcoal Tray Linkage Assembly
12 1 Charcoal Tray Linkage Knob
13 1 Lid and Firebox Assembly
14 1 Left Rear Leg #3
15 1 Left Front Leg #4
16 1 Right Rear Leg #1
17 1 Right Front Leg #2
18 2 Wheel Cap
3
2
1
2
8
6
5
7
4
7
9
10 9
12
11
15
20
14
18
17
19
13
16
24
23
21
22
27
26
30
29
25
28
32
36
31
35
33
34
31
32
33
36
Item # Qty Description
19 1 Wheel Axle
20 2 Wheel
21 1
Cart Bottom Shelf
22 1 Cart Front Panel
23 1 Cart Rear Panel
24 1 Ash Tray
25 1 Firebox Right Lower Panel
26 2 Air Damper
27 1 Ash Tray Handle
28 1 Firebox Left Lower Panel
29 2 Charcoal Door Hinge
30 1 Charcoal Door
31 2 Charcoal Door Handle
32 2 Charcoal Door Handle Washer
33 2 Charcoal Door Locking Latch
34 1 Charcoal Tray Lift Assembly
35 1 Charcoal Tray
36 2 Cooking Grate Side Frame
15
F
F
F
F
1
36
36
3
2
Assembly
18
F
X4
17
E
X2
J
X2
E
J
E
J
31
31
32
32
33
33
Slanted edge up
Flat side up
36
3
2
3
2
2
O
N
N
X1
O
X1

14
Assembly
15
16
K
X4
D
X2
K
K
K
K
35
To avoid personal injury and damage to
grill, have someone help you position the
charcoal door into the hinges and hold it
steady until hinge and cotter are installed.
L
X2
30
D
L
L
30
7
Assembly
1
2
P
K
K
P
K
P
X2
X2
14 16
15 17
28 25
K
K
X4
21
K
K
K
Note: Do not fully tighten screws until step 11 is complete.

8
Assembly
3
4
K
X4
K
X4
K
K
K
K
K
K
K
K
23
22
Note: Do not fully tighten
screws until step 11 is complete.
Note: Do not fully tighten
screws until step 11 is complete.
13
Assembly
14
I
X1
13
K
X2
Left Front Leg
K
K
15
11
10
L
X1
I
L
11
34
12
11
10

12
Assembly
11
12
A
X8
K
X4
A
A
A
A
A
A
A
A
9
9
Note: After completing step 11, fully tighten screws from steps 1, 3, 4 and 8.
K
K
K
K
34
34
34
9
Assembly
5
6
M
X2
G
X4
C
X2
B
X2
C
B
CB
M
M
19 20
20
18
18
G
G
G
G
26
26

10
Assembly
7
8
F
X8
K
X6
F
F
F
F
F
F
F
F
29
K
K
K
KK
K
To avoid personal injury and damage to grill,
have someone help you lift the lid/firebox
assembly and place onto the cart. Your
helper should hold the lid/firebox assembly
steady until all screws are installed.
13
Note: Do not fully tighten
screws until step 11 is complete.
11
Assembly
9
10
K
X4
K
X3
7
7
86
K
K
K
K
Wing Nut
5
5
4
H
X3
HH
H
KK
K
Washer
