Chauvet DJ Scorpion Dual V2 User manual

User Manual
LASER LIGHT
AVOID DIRECT EYE EXPOSURE
CLASS 3R LASER PRODUCT
CLASSIFIED PER EN/IEC 60825-1:2007
Complies with FDA performance standards for
laser products except for deviations pursuant
to Laser Notice No. 50, dated June 24, 2007.

Page 2 of 64 Scorpion Dual V2 User Manual Rev. 3
TABLE OF CONTENTS
Warranty/Garantía/Garantie.............................................................................................. 5
Limited Warranty ..............................................................................................................................5
Garantía Limitada.............................................................................................................................5
Garantie Limitée ...............................................................................................................................5
1. Before You Begin .......................................................................................................... 6
What is Included...............................................................................................................................6
Unpacking Instructions .....................................................................................................................6
Claims ....................................................................................................................................................... 6
Manual Conventions.........................................................................................................................6
Symbols............................................................................................................................................6
Disclaimer.........................................................................................................................................6
Safety Notes .....................................................................................................................................7
Non-Interlocked Housing Warning............................................................................................................. 8
Laser Safety Notes.................................................................................................................................... 8
Laser Safety Label Reproduction .....................................................................................................9
Laser Exposure Warning ........................................................................................................................... 9
Laser Emission Data ........................................................................................................................9
Laser Compliance Statement .................................................................................................................... 9
2. Introduction ..................................................................................................................10
Overview.........................................................................................................................................10
Dimensions.....................................................................................................................................11
3. Setup.............................................................................................................................12
AC Power .......................................................................................................................................12
Fuse Replacement .................................................................................................................................. 12
Power Linking.......................................................................................................................................... 13
Mounting.........................................................................................................................................14
Orientation............................................................................................................................................... 14
Rigging .................................................................................................................................................... 14
Proper Usage .......................................................................................................................................... 15
4. Operation ......................................................................................................................16
Control Panel Operation.................................................................................................................16
Menu Map.......................................................................................................................................16
Configuration (DMX).......................................................................................................................16
Starting Address...................................................................................................................................... 16
Test Mode................................................................................................................................................ 16
DMX Channel Modes, Assignments, and Values ..........................................................................17
10-Channel.............................................................................................................................................. 17
Patterns ..........................................................................................................................................18
Configuration (Standalone) ............................................................................................................19
Sound-Active Mode ................................................................................................................................. 19
Sound Sensitivity..................................................................................................................................... 19
Auto Mode ............................................................................................................................................... 19
Master/Slave Mode.................................................................................................................................. 19
IR Wireless Control.................................................................................................................................. 19
Remote Control ..............................................................................................................................20
5. Technical Information ..................................................................................................21
Product Maintenance .....................................................................................................................21
6. Technical Specifications..............................................................................................22
Returns .............................................................................................................................23

Scorpion Dual V2 User Manual Rev. 3 Page 3 of 64
Contact Us ........................................................................................................................24
1. Antes de Empezar ........................................................................................................25
Qué va Incluido...............................................................................................................................25
Instrucciones de Desembalaje .......................................................................................................25
Reclamaciones ........................................................................................................................................ 25
Convenciones del Manual ..............................................................................................................25
Símbolos.........................................................................................................................................25
Exención de Responsabilidad ........................................................................................................25
Notas de Seguridad........................................................................................................................26
Advertencia sobre Carcasa no Cerrada .................................................................................................. 27
Notas de Seguridad sobre Láser............................................................................................................. 27
Reproducción de la Etiqueta de Seguridad del Láser....................................................................29
Advertencia Sobre Exposición al Láser................................................................................................... 29
Datos de Emisión Láser .................................................................................................................29
Declaración de Conformidad Láser ......................................................................................................... 29
2. Introducción .................................................................................................................30
Vista General..................................................................................................................................30
Dimensiones...................................................................................................................................31
3. Instalación ....................................................................................................................32
Corriente Alterna ............................................................................................................................32
Sustitución del Fusible............................................................................................................................. 32
Alimentación en Cadena ......................................................................................................................... 33
Montaje...........................................................................................................................................34
Orientación .............................................................................................................................................. 34
Colocación............................................................................................................................................... 34
Uso Adecuado......................................................................................................................................... 35
4. Funcionamiento............................................................................................................36
Manejo del Panel de Control ..........................................................................................................36
Mapa de Menú................................................................................................................................36
Configuración (DMX)......................................................................................................................36
Dirección de Inicio ................................................................................................................................... 36
Modo Prueba........................................................................................................................................... 36
Modos de Canal, Asignaciones y Valores DMX.............................................................................37
10 Canales .............................................................................................................................................. 37
Patrones .........................................................................................................................................38
Configuración (Independiente) .......................................................................................................39
Modo Activo por Sonido .......................................................................................................................... 39
Sensibilidad al Sonido ............................................................................................................................. 39
Modo Automático..................................................................................................................................... 39
Modo Maestro/Esclavo............................................................................................................................ 39
Control Inalámbrico por IR......................................................................................................................... 39
Control Remoto ..............................................................................................................................40
5. Información Técnica ....................................................................................................41
Mantenimiento del Producto...........................................................................................................41
6. Especificaciones Técnicas ..........................................................................................42
Devoluciones ....................................................................................................................43
Contacto.............................................................................................................................44
1. Avant de Commencer ..................................................................................................45
Ce Qui est Compris ........................................................................................................................45
Instructions Relatives au Déballage...............................................................................................45
Réclamations........................................................................................................................................... 45
Conventions de ce Manuel.............................................................................................................45

Page 4 of 64 Scorpion Dual V2 User Manual Rev. 3
Symboles........................................................................................................................................45
Clause de Non-Responsabilité.......................................................................................................45
Consignes de Sécurité ...................................................................................................................46
Avertissement : Boîtier non Verrouillable................................................................................................. 47
Consignes de Sécurité Relatives au Laser.............................................................................................. 47
Reproductions des Etiquettes en Matière de Sécurité des Appareils Laser..................................49
Avertissement d'Exposition au Laser....................................................................................................... 49
Données d'Emission Laser.............................................................................................................49
Déclaration de Conformité du Laser........................................................................................................ 49
2. Introduction ..................................................................................................................50
Aperçu ............................................................................................................................................50
Dimensions.....................................................................................................................................51
3. Configuration................................................................................................................52
Alimentation CA..............................................................................................................................52
Remplacement du Fusible....................................................................................................................... 52
Branchement d'Alimentation.................................................................................................................... 53
Installation ......................................................................................................................................54
Orientation............................................................................................................................................... 54
Suspension.............................................................................................................................................. 54
Utilisation Adéquate................................................................................................................................. 55
4. Fonctionnement ...........................................................................................................56
Fonctionnement du Panneau de Commande ................................................................................56
Tableau du Menu ...........................................................................................................................56
Configuration (DMX).......................................................................................................................56
Adresse de Départ................................................................................................................................... 56
Mode Test................................................................................................................................................ 56
Modes de Canal DMX, Attributions et Valeurs...............................................................................57
10 Canaux ............................................................................................................................................... 57
Motifs ..............................................................................................................................................58
Configuration (Autonome) ..............................................................................................................59
Mode Son Actif ........................................................................................................................................ 59
Sensibilité Sonore.................................................................................................................................... 59
Mode Auto ............................................................................................................................................... 59
Mode Maître/Esclave............................................................................................................................... 59
Commande sans Fil IR............................................................................................................................ 59
Télécommande...............................................................................................................................60
5. Informations Techniques.............................................................................................61
Entretien de l'Appareil ....................................................................................................................61
6. Spécificités Techniques...............................................................................................62
Renvois.............................................................................................................................63
Nous Contacter..................................................................................................................64

Scorpion Dual V2 User Manual Rev. 3 Page 5 of 64
WARRANTY/GARANTÍA/GARANTIE
Limited Warranty
FOR WARRANTY REGISTRATION AND COMPLETE
TERMS AND CONDITIONS PLEASE VISIT OUR
WEBSITE.
For Customers in the United States and Mexico: www.chauvetlighting.com/warranty-registration.
For Customers in the United Kingdom, Republic
of Ireland, Belgium, the Netherlands, Luxembourg, France,
and Germany: www.chauvetlighting.eu/warranty-registration.
Chauvet warrants that this product shall be free from defects in material and workmanship under normal use, for the
period specified in, and subject to the exclusions and limitations set forth in the full limited warranty on our website.
This warranty extends only to the original purchaser of the product and is not transferab
le. To exercise rights under
this warranty, you must provide proof of purchase in the form of an original sales receipt from an authorized dealer
that shows the product name and date of purchase. THERE ARE NO OTHER EXPRESS OR IMPLIED
WARRANTIES. This warra
nty gives you specific legal rights. You may also have other rights that vary from state to
state and country to country. This warranty is valid only in the United States, United Kingdom, Republic of Ireland,
Belgium, the Netherlands, Luxembourg, France, G
ermany and Mexico. For warranty terms in other countries,
please consult your local distributor.
Garantía Limitada
PARA VER EL REGISTRO DE GARANTÍA Y LOS TÉRMINOS Y CONDICIONES COMPLETOS, VISITE
NUESTRO SITIO WEB.
Para clientes en los Estados Unidos y México: www.chauvetlighting.com/warranty-registration.
Para clientes en Reino Unido, República de Irlanda, Bélgica, Países Bajos, Luxemburgo, Francia y
Alemania: www.chauvetlighting.eu/warranty-registration.
Chauvet garantiza que este producto estará libre de defectos de material y mano de obra en condiciones de uso
normales, durante el periodo especificado, sujeto siem
pre a las exclusiones y limitaciones establecidas en la
garantía limitada completa de nuestro sitio web. Esta garantía se concede únicamente al comprador original del
producto y no es transferible. Para ejercer los derechos que otorga esta garantía, usted
debe proporcionar una
prueba de compra en forma de un recibo de compra original, expedido por un distribuidor autorizado, donde figure
el nombre del producto y la fecha de compra. NO EXISTEN OTRAS GARANTÍAS EXPRESAS NI IMPLÍCITAS.
Esta garantía le otorga d
erechos legales específicos. Es posible que a usted le asistan otros derechos, que
variarán dependiendo del estado o del país. Esta garantía solamente es válida en los Estados Unidos, Reino
Unido, República de Irlanda, Bélgica, Países Bajos, Luxemburgo, Fr
ancia, Alemania y México. Para conocer los
términos de garantía en otros países, consulte a su distribuidor local.
Garantie Limitée
VEUILLEZ VISITER NOTRE SITE INTERNET POUR CONSULTER LES MODALITÉES D'ENREGISTREMENT
DE LA GARANTIE ET LES CONDITIONS GÉNÉRALES COMPLÈTES.
Pour les clients aux États-Unis et au Mexique: www.chauvetlighting.com/warranty-registration.
Pour les clients du Royaume-Uni, de la République d'Irlande, de la Belgique, des Pays-
Bas, du
Luxembourg, de la France et de l'Allemagne: www.chauvetlighting.eu/warranty-registration.
Chauvet garantit que cet appareil est exempt de défauts de matériaux et de f
abrication dans des conditions
normales d'utilisation, pendant la période spécifiée dans la garantie limitée complète consultable sur notre site
Internet et sous réserve des exclusions et limitations qui y sont énoncées. Cette garantie ne s'applique qu'à
l
'acheteur initial du produit et n'est pas transférable. Pour exercer les droits prévus par cette garantie, vous devez
fournir une preuve d'achat sous la forme d'un reçu de vente original d'un revendeur autorisé qui indique le nom du
produit et la date d'ac
hat. IL N'EXISTE AUCUNE AUTRE GARANTIE EXPRESSE OU IMPLICITE. Cette garantie
vous confère des droits légaux spécifique. Vous pouvez également bénéficier d'autres droits qui varient selon les
états et les pays. Cette garantie n'est valable qu'aux États-Unis, au Royaume-
Uni, en République d'Irlande, en
Belgique, aux Pays-
Bas, au Luxembourg, en France, en Allemagne et au Mexique. Pour connaître les conditions
de garantie dans d'autres pays, veuillez consulter votre revendeur local.

Page 6 of 64 Scorpion Dual V2 User Manual Rev. 3
1. BEFORE YOU BEGIN
What is
Included
•Scorpion Dual V2
•Power Cord
•Hanging Bracket
•IR Remote
•User Manual
Unpacking
Instructions
Carefully unpack the product immediately and check the box to make sure all the parts
are in the package and are in good condition.
Claims
If the box or the contents (the product and
included accessories) appear damaged from
shipping or show signs of mishandling, notify the carrier immediately, not Chauvet.
Failure to do so in a timely manner may invalidate your claim with the carrier. In addition,
keep the container and all the packing material for inspection.
For other issues, such as
missing components or parts, damage not related to shipping,
or concealed damage, file a claim with Chauvet within 7 days of delivery.
Manual
Conventions
Convention
Meaning
1–512
A range of values
50/60
A set of values of which only one can be chosen
Settings
A menu option not to be modified
Menu > Settings
A sequence of menu options to be followed
<ENTER>
A key to be pressed on the product’s control panel
ON
A value to be entered or selected
Symbols
Symbol
Meaning
Critical installation, configuration, or operation information.
Ignoring this information can cause the product to not work,
damage it, or cause harm to the operator.
Important installation or configuration information. The product
may not function correctly if this information is not used.
Useful information.
Disclaimer
Chauvet believes that the information contained in this manual is accurate in all
respects. However, Chauvet assumes no responsibility and specifically disclaims any
and all liability to any party for any loss, damage or disruption caused by any errors or
omissions in this document, whether such errors or omissions result from negligence,
accident or any other cause. Chauvet reserves the right to revise the content of this
document without any obligation to notify any person or company of such revision,
how
ever, Chauvet has no obligation to make, and does not commit to make, any such
revisions. Download the latest version from www.chauvetdj.com.
The works of authorship contained in this manual, including, but not limited to, all design,
text and images are owned by Chauvet.
© Copyright 2018 Chauvet & Sons, LLC. All rights reserved.
Electronically published by Chauvet in the United States of America.
CHAUVET, the Chauvet logo, and Scorpion Dual V2 are registered tradem
arks or
trademarks of Chauvet & Sons LLC (d/b/a Chauvet and Chauvet Lighting) in the United
States and other countries. Other company and product names and logos referred to
herein may be trademarks of their respective companies.

Scorpion Dual V2 User Manual Rev. 3 Page 7 of 64
Safety Notes
The Safety Notes include
important laser system safety information. Read and
understand all instructions before powering on the laser for the first time
.
Knowing these safety instructions is crucial to avoiding
laser eye injury and
breaking the law. Keep this User Manual in a safe place for future reference.
STOP AND READ ALL LASER SAFETY DATA
•Lasers can be hazardous and have unique safety considerations. Permanent
eye injury and blindness is possible if lasers are used incorrectly. Pay close
attention to each safety REMARK and WARNING statement in this User
Manual. Read all instructions carefully BEFORE operating this device.
•Always connect the product to a grounded circuit to avoid the risk of electrocution.
•Always disconnect the product from the power source before cleaning or replacing
the fuse.
•Avoid direct eye exposure to the light source while the product is on.
•Make sure the power cord is not crimped or damaged.
•Never disconnect the product from power by pulling or tugging on the cord.
•If mounting the product overhead, always secure to a fastening device using a safety
cable.
•Make sure there are no flammable materials close to the product when operating.
•
Do not touch the product’s housing when operating because it may be very hot.
•
This product is not intended for permanent installation.
•Always make sure that the voltage of the outlet to which you are connecting the
product is within the range stated on the decal or rear panel of the product.
•The product is for indoor use only! (IP20) To prevent risk of fire or shock, do not
expose the product to rain or moisture.
•Always install the product in a location with adequate ventilation, at least
20 in (50 cm) from adjacent surfaces.
•Be sure that no ventilation slots on the product’s housing are blocked.
•Never connect the product to a dimmer.
•Make sure to replace the fuse with another of the same type and rating.
•Always use the mounting bracket to carry the product.
•Do not switch the product on/off in short intervals. This will reduce the laser diode life.
•Do not shake this product. Avoid brute force when mounting or operating this product.
•ALWAYS use a safety cable when mounting the product overhead.
•The ambient operating temperature for the laser is 59 °F to 95 °F (15 °C to 35 °C).
Do not operate this product outside this range.
•In the event of a serious operating problem, stop using the product immediately.
•Never try to repair the product. Repairs carried out by unskilled people can lead to
damage or malfunction. Contact the nearest authorized technical assistance center.
•To eliminate wear and improve its lifespan, during periods of non-use completely
disconnect from power via breaker or by unplugging it.
•Avoid direct eye contact with laser light. Never intentionally expose your eyes or
others to direct laser light.
•This laser product can potentially cause instant eye injury or blindness if laser light
directly strikes the eyes.
•It is illegal and dangerous to shine this laser into audience areas, where the
audience or other personnel could get direct laser beams or bright reflections into
their eyes.
•It is a U.S. federal offense to shine any laser at aircraft.
•Use of controls, adjustments, or procedures other than those specified in this User
Manual may result in hazardous radiation exposure.
•DO NOT attempt any repairs. Repairs and servicing must be carried out by a
certified technician. Unauthorized modifications are forbidden for safety
reasons!
Keep this User Manual for future consultation. If transferring ownership of the product,
be sure this document is kept with the laser.

Page 8 of 64 Scorpion Dual V2 User Manual Rev. 3
Non-Interlocked
Housing Warning
•This unit contains high power laser devices internally.
•Do not open the laser housing, due to potential exposure to unsafe levels of laser
radiation.
•The laser power levels, accessible if the unit is opened, can cause instant blindness,
skin burns, and fires.
Laser Safety
Notes
STOP AND READ ALL THE LASER SAFETY NOTES BELOW
Laser l
ight is different from any other light sources. The light from this product can
potentially cause eye injury if the product is not set up and used
properly. Laser light is
thousands of times more concentrated than light from any other kind of light source. This
concentration of light can cause instant eye injuries, primarily b
y burning the retina (the
light-sensitive portion at the back of the eye).
Even if you cannot feel “heat” from a laser
beam, it can still potentially injure or blind you or your audience. Even very small
amounts of laser light are potentially hazardous—
even at long distances. Laser eye
injuries can happen faster than you can blink.
DO NOT assume
that because laser entertainment products split the laser into hundreds
of beams and
that the laser beam is scanned out in high speed, that an individual laser
beam is safe for eye exposure. This laser product uses dozens of milliwatts of
laser
power (Class 3B levels internally) before it splits into multiple beams (Class 3R levels).
Many of the individual beams are potentially hazardous to the eyes.
DO NOT assume that because the laser light is moving, it is safe. Laser light is never
without
risk, nor do the
laser beams always move. Since eye injuries can occur instantly, it is critical
to prevent the possibility of ANY direct eye exposure. According to laser safety regulations
, it
is not legal to aim Class 3R lasers into areas where p
eople can get exposed. This is true
even if the laser is aimed below people’s faces, such as on a dance floor.
•Do not operate the laser without first reading and understanding all safety and
technical data in this manual.
•ALWAYS set up and install all laser effects so that all laser light is at least 3 meters
(9.8 feet) above the floor on which people can stand. See the Proper Usage section
of this manual.
•After setup, and prior to public use, test laser to ensure proper function. Do not use if
any defect is detected.
•DO NOT use laser if the laser appears to be emitting only one or two beams, rather
than dozens/hundreds, as this could indicate damage to the diffraction grating optic,
and could allow emission of laser levels higher than Class 3R.
•DO NOT point lasers at people or animals.
•Never look into the laser aperture or laser beams.
•DO NOT point lasers into areas in which people can potentially get exposed, such as
uncontrolled balconies, etc.
•DO NOT point lasers at highly reflective surfaces such as windows, mirrors, and
shiny metal. Even laser reflections can be hazardous.
•Never point a laser at aircraft; this is a U.S. federal offense.
•Never point un-terminated laser beams into the sky.
•Do not expose the output optic (aperture) to harsh cleaning chemicals.
•Do not use the laser if the housing is damaged, open, or if the optics appear
damaged in any way.
•Never open the laser housing. The high laser power levels inside of the protective
housing can start fires or burn skin, and will cause instant eye injury.
•Never leave this product running unattended.
•The operation of a Class 3R laser show is only allowed if the show is controlled by a
skilled and well-trained operator, familiar with the data included in this manual.
•The legal requirements for using laser entertainment products vary from country to
country. The user is responsible for the legal requirements in the location/country of
use.
CAUTION! DO NOT operate this device in ways not specified in this User Manual. Failure to follow
the instructions will void the warranty, may damage the product, or injure the user or the audience.
CAUTION! This product cannot be discarded with household waste. Contact your local waste
management service for electronic disposal regulations in your area.

Scorpion Dual V2 User Manual Rev. 3 Page 9 of 64
Laser Safety Label Reproduction
Laser
Exposure
Warning
LASER LIGHT AVOID DIRECT EYE EXPOSURE
Further guidelines and safety programs for safe use of lasers can be found in the ANSI
Z136.1 Standard “For Safe Use of Lasers”, available from the Laser Institute of America:
www.laserinstitute.org. Many local governments, corporations, agencies, military, and
others, require all lasers to be used under the guidelines of ANSI Z136.1. Laser Display
guidance can be obtained via the International Laser Display Association:
www.laserist.org.
Laser Emission Data
Laser Classification Class 3R
Green Laser LD / 520 nm / 50 mW
Beam Diameter <5 mm at aperture
Pulse Data All pulses < 4 Hz (>0.25 sec)
Divergence (each beam) <2 mrad
Divergence (total light) <160 degrees
Laser Power of Each Beam
from Aperture* <5 mW
*As measured under IEC measurement conditions for classification.
Laser Compliance Statement
Complies with FDA performance standards for laser products except for deviations
pursuant to Laser Notice No. 50, dated June 24, 2007. No maintenance is required to
keep this product in compliance with laser performance standards.

Page 10 of 64 Scorpion Dual V2 User Manual Rev. 3
2. INTRODUCTION
Overview
Power Indicator LED
Power In
Display and
Control Buttons
DMX In
DMX Out
Microphone
Power Out
Fuse Holder
Safety
Loop
Sound Indicator LED
Laser Output
IR Sensor
Cooling Fan
Surface
Supports (x4)

Scorpion Dual V2 User Manual Rev. 3 Page 11 of 64
Dimensions
7.1 in
(179.5 mm)
6.3 in
(161 mm)
8.5 in
(216 mm)

Page 12 of 64 Scorpion Dual V2 User Manual Rev. 3
3. SETUP
AC Power
The Scorpion Dual V2 has an external auto-
ranging power supply and it can work with
an input voltage range of 100 to 240 VAC, 50/60 Hz.
To determine the product’s power requirements (
circuit breaker, power outlet, and
wiring), use the current value listed on the label affixed to the product’
s back panel, or
refer to the Technical Specifications. The listed current rating indicates the product’s
average current draw under normal conditions.
•Always connect the product to a protected circuit (circuit breaker or fuse).
Make sure the product has
an appropriate electrical ground to avoid the risk
of electrocution or fire.
•To eliminate wear and improve its lifespan, during periods of non-use
completely disconnect from power via breaker or by unplugging it.
Never connect the product to
a rheostat (variable resistor) or dimmer circuit, even
if the rheostat or dimmer channel serves only as a 0 to 100% switch.
Fuse Replacement
Disconnect the product from power before replacing the fuse.
1. Disconnect the product from power.
2. Wedge the tip of a flat-head screwdriver into the slot of the fuse holder.
3. Pry the fuse holder out of the housing.
4. Remove the blown fuse from the holder.
5. Replace with a fuse of the exact same type and rating.
6. Insert the fuse holder back in place and reconnect power.
A spare fuse is not included; however, the safety cap has room for a spare.
Always replace a blown fuse with one of the same type and rating.
Installed fuse
(held by plastic clip)
Spare fuse holder
(inside safety cap)
Safety cap

Scorpion Dual V2 User Manual Rev. 3 Page 13 of 64
Power Linking
The product provides power linking via the Edison/IEC outlet located in the back
of the
unit.
P
ower Linking
Diagram
You can power link up to 44 Scorpion Dual V2 units on 120 V or up to 93 units
on 230 V.
The power linking diagram shown above corresponds to the North American
version of the product ONLY! If
using the product in other markets, you must
consult with the local Chauvet
distributor as power linking connectors and
requirements may differ in your country or region.
1st Product
2nd Product
3rd Product
Additional Products

Page 14 of 64 Scorpion Dual V2 User Manual Rev. 3
Mounting
Before mounting the product
, read and follow the safety recommendations indicated in
the Safety Notes.
Orientation
The Scorpion Dual V2 must be mounted in a position
that includes planning for safe
laser usage. In addition, make sure adequate ventilation is provided around the product.
Rigging
•Before deciding on a location for the product, always make sure there is easy access
to the product for maintenance and programming.
•Make sure that the structure or surface onto which you are mounting the product can
support the product’s weight (see the Technical Specifications).
•When mounting the product overhead, always use a safety cable. Mount the product
securely to a rigging point, such as an elevated platform or a truss.
•When rigging the
product onto a truss, you should use a mounting clamp of
appropriate weight capacity. The bracketed has a 13-mm hole, which is appropriate
for this purpose.
•The bracket adjustment
knobs allow for directional adjustment when aiming the
product to the desired angle. Only loosen or tighten the bracket knobs manually.
Using tools could damage the knobs.
Mounting Clamp
Safety Cable
Mounting Bracket
Bracket
Adjustment
Knob x2

Scorpion Dual V2 User Manual Rev. 3 Page 15 of 64
Proper Usage
This product is for overhead mounting only. For safety purposes, Chauvet recommends
mounting lighting effect products on steady elevated platforms or sturdy overhead
supports using suitable hanging clamps. In all cases, use safety cables. Obtain
appropriate mounting hardware from your lighting vendor.
International laser safety regulations require that laser products must be operated
in the fashion illustrated below, with a minimum of 3 meters (9.8 ft) of vertical
separatio
n between the floor and the lowest laser light. Additionally,
3 meters of horizontal separation is required between laser light and audience or
other public spaces.
CAUTION! USE OF CONTROLS, ADJUSTMENTS, OR PROCEDURES
OTHER THAN THOSE SPECIFIED IN THIS USER MANUAL
MAY RESULT
IN HAZARDOUS RADIATION EXPOSURE.

Page 16 of 64 Scorpion Dual V2 User Manual Rev. 3
4. OPERATION
This product is not designed for continual use. Make sure there are regular breaks during operation to maximize the
life of your laser. Always disconnect the Scorpion Dual V2 from power when not in use.
Control Panel
Operation
To access the control panel functions, use the four buttons located underneath the
display. When the product is on, the LED monitor on the rear panel will show the current
operating mode (standalone or DMX). The product will retain the last saved settings when
powered off.
Button Function
<MENU> Selects an operation mode or backs out of the current menu option
<UP> Scrolls up the list of options or selects a higher value
<DOWN>
Scrolls down the list of options or selects a lower value
<ENT>
Activates a menu option or a selected value
Menu Map
Mode
Programming Steps
Description
DMX Mode
001–503
Selects DMX starting address
Slave Mode
SLA
Slave mode
Remote Control
rEN
Wireless remote control
Test Mode
tSt
Test pattern
Sound-Active/Auto
Modes
Sou
Sound-Active mode
Aut
Auto mode
Sensitivity
S0–9
Sound sensitivity control
Configuration
(DMX)
Set the product in DMX mode to control with a DMX controller.
1. Connect the product to a suitable power outlet.
2. Turn the product on.
3. Connect a DMX cable from the DMX output of the DMX controller to the DMX input
socket on the product.
Starting Address
When selecting a DMX starting address, always consider the number of DMX channels
the selected DMX mode uses. If you choose a starting address that is too high, you could
restrict the access to some of the product’s channels.
The Scorpion Dual V2 uses up to 10 DMX channels in
DMX mode, which defines the
highest configurable address to 503.
If you are not familiar with the DMX protocol, download the DMX Primer from
www.chauvetlighting.com.
To select the starting address, do the following:
1. Press <MENU> repeatedly until 001–503 blinks on the display.
2. Use <UP> or <DOWN> to select the starting address.
3. Press <ENTER>.
Test Mode
Activate the laser test pattern as follows.
1. Press <MENU> repeatedly until tSt blinks on the display.
2. Press <ENTER>.

Scorpion Dual V2 User Manual Rev. 3 Page 17 of 64
DMX Channel Modes, Assignments, and Values
10-Channel
Channel Function Value Setting
1 Control Functions
000 085
086 170
171 255
DMX mode (other channels activated)
Auto program
Sound-Active
2 Strobe
000 009
010 249
250 255
No function
Slow to fast
On
3
Pattern Selection
000 255
Patterns as shown in Patterns table.
4 Zoom
000 127
128 169
170 209
210 255
100%–5%
Zoom in
Zoom out
Zoom in and out
5 Y-Axis Rolling
000 127
128 191
192 255
Fixed position on y-axis (0 to 359°)
Clockwise rolling, slow to fast
Counter-clockwise rolling, slow to fast
6 X-Axis Rolling
000 127
128 191
192 255
Fixed position on x-axis (0 to 359°)
Clockwise rolling, slow to fast
Counter-clockwise rolling, slow to fast
7 Z-Axis Rolling
000 127
128 191
192 255
Fixed position on z-axis (0 to 359°)
Clockwise rolling, slow to fast
Counter-clockwise rolling, slow to fast
8 Pan
000 127
128 191
192 255
Fixed position (128 horizontal points)
Clockwise movement, slow to fast
Counter-clockwise movement, slow to fast
9 Tilt
000 127
128 191
192 255
Fixed position (128 vertical points)
Clockwise movement, slow to fast
Counter-clockwise movement, slow to fast
10 Scan Speed
000 127
128 169
170 209
210 255
Fast to slow (manual)
Slow to fast (automatic)
Fast to slow (automatic)
Fast to slow, then slow to fast (automatic repeat)
•For manual operation of lasers using DMX control, be sure
Channel 1 is set to
DMX mode (000—085).
•
For automatic operation of lasers using DMX control, be sure Channel 1 is set to
Auto program (086–170).
•Channel 2 must be set to 010–255 for Channel 1 to be operational.

Page 18 of 64 Scorpion Dual V2 User Manual Rev. 3
Patterns

Scorpion Dual V2 User Manual Rev. 3 Page 19 of 64
Configuration
(Standalone)
Set the product in one of the standalone modes to control without a DMX controller.
1. Connect the product to a suitable power outlet.
2. Turn the product on.
Never connect a product that is operating in any standalone mode (Auto or
Sound-Active) to a DMX
string connected to a DMX controller. Products in
standalone mode may transmit DMX signals that could interfere with the DMX
signals from the controller.
Sound-Active
Mode
To enable the Sound-Active program, do the following:
1. Press <MENu> repeatedly until Sou (Sound-Active) or Aut (Auto) blinks on the
display.
2. Use <UP> or <DOWN> to select Sou.
3. Press <ENTER>.
Sound Sensitivity
To set the sound sensitivity, follow the instructions below:
1. Press <MENU>repeatedly until S0–9 blinks on the display.
2. Use <UP> or <DOWN> to select the desired sound sensitivity.
3. Press <ENTER>.
The product will only respond to low frequencies of music (bass and drums).
The laser will blackout when in Sound-Active mode after 3 seconds of silence or
noise below the sensitivity setting.
Auto Mode To enable the auto mode, follow the instructions below:
1. Press <MENU>repeatedly until Sou (Sound-Active) or Aut (Auto) blinks on the
display.
2. Use <UP> or <DOWN> to select Aut.
3. Press <ENTER>.
Master/Slave
Mode
The Master/Slave mode allows a single Scorpion Dual V2 product (the master) to control
the actions of one or more Scorpion Dual V2
products (the slaves) without the need of a
DMX controller. The master will be set to operate in either Auto mode or Sound-Active
mode, while the slaves will be set to operate in Slave mode. Once set and connected,
the slaves will operate in unison with the master.
Configure the products as indicated below.
Slaves:
1. Press <MODE>repeatedly until SLA shows on the display.
2. Press <ENTER>.
3. Connect the DMX input of the first slave to the DMX output of the master.
4. Connect the DMX input of the subsequent slaves to the DMX output of the previous
slave.
5. Finish setting and connecting all the slaves.
Master unit:
1. Set the master to operate in either Auto mode or Sound-Active mode.
2. Make the master the first unit in the DMX daisy chain.
•
Configure all the slave units before connecting the master unit to the DMX
daisy chain.
•Never connect a DMX controller to a DMX
string configured for Master/Slave
operation because the controller may interfere with the signals from the
master unit.
•Do not connect more than 31 slave units to the master unit.
IR Wireless
Control
To enable IR wireless control, follow the instructions below:
1. Press <MENU> repeatedly until rEN shows on the display.
2. Press <ENTER>.

Page 20 of 64 Scorpion Dual V2 User Manual Rev. 3
Remote Control
Button Function Description
ON/OFF Turn laser on/off.
Auto Mode Laser runs on built-in auto program
Sound-Active
Mode
Sound-Active mode. LED Indicator flashes when sound is detected
Sound Sensitivity In Sound-Active mode, press <MUSIC> + <B> + <1> (least sensitive)
to <9> (most sensitive) to adjust sensitivity setting
Patterns Show and change patterns
Fixed Pattern Choose favorite PATTERN from 1 to 32
Pattern Repeat Last PATTERN and current PATTERN cycle repeats
•
Any control or setting on the IR remote will be saved until the system is rebooted. The
system will revert to Auto Mode after reboot.
•The buttons on the IR remote not listed above are reserved for future use with the Scorpion
Dual V2.
Laser On/Off
Pattern Repeat
Pattern Changing
Effect Pause
Auto Mode
Sound-Active Mode
Patterns
Sound Sensitivity
