Chauvet Hurricane Haze 1D User manual

User Manual

Page 2 of 16 Hurricane Haze 1D User Manual Rev. 1
Table of Contents
1. Before You Begin ...........................................................................3
What Is Included ...........................................................................................3
Unpacking Instructions..................................................................................3
Claims ...........................................................................................................3
Text Conventions ..........................................................................................3
Icons..............................................................................................................3
Document Information...................................................................................3
Product at a Glance ......................................................................................4
Safety Notes..................................................................................................4
2. Introduction ....................................................................................5
Product Overview..........................................................................................5
Product Dimensions......................................................................................6
3. Setup ...............................................................................................7
AC Power......................................................................................................7
Fuse Replacement.................................................................................................7
Mounting .......................................................................................................8
Orientation .............................................................................................................8
Rigging...................................................................................................................8
4. Operation ........................................................................................9
Control Panel Operation................................................................................9
Fluid Tank Indicator LEDs.............................................................................9
Wired Timer Remote Operation..................................................................10
Menu Map ...................................................................................................11
Configuration (DMX) ...................................................................................11
Starting Address..........................................................................................11
Configuration (Standalone Mode)...............................................................11
Manual Mode .......................................................................................................11
DMX Channel Assignments and Values.....................................................11
1-CH.....................................................................................................................11
5. Technical Information ..................................................................12
Hazer Maintenance.....................................................................................12
Storage........................................................................................................12
General Troubleshooting.............................................................................13
Returns..............................................................................................14
Contact Us..........................................................................................15
6. Technical Specifications..............................................................16

Hurricane Haze 1D User Manual Rev. 1 Page 3 of 16
1.Before You Begin
What Is
Included
•Hurricane Haze 1D
•Power cord
•FC-T remote controller
•Hanging bracket with mounting hardware
•Warranty card
•Quick Reference Guide
Unpacking
Instructions
Immediately upon receiving this product, carefully unpack it and check the container in
which you received it.
Claims
If the container or the material inside the container (the product and included
accessories) appear damaged from shipping, or show signs of mishandling, upon
receipt notify the carrier immediately, not Chauvet. Failure to do so in a timely manner
may invalidate your claim with the carrier. In addition, keep the container and all the
packing material for inspection.
For other issues such as missing components or parts, damage not related to
shipping, or concealed damage, file a claim with Chauvet within seven (7) days of
receiving the merchandise.
Text
Conventions
Convention Meaning
<Menu>
A key to be pressed on the product’s control panel
1–512
A range of values
50/60
A set of values of which only one can be chosen
Settings A menu option not to be modified (for example, showing the
operating mode/current status)
Menu > Settings
A sequence of menu options to be followed
ON
A value to be entered or selected
Icons
Icon Meaning
Critical installation, configuration, or operation information.
Failure to comply with this information may render the
product partially or completely inoperative, cause damage
to the product, or cause harm to the user.
Important installation or configuration information. Failure
to comply with this information may prevent the product
from functioning correctly.
Useful information.
Document
Information
The information and specifications contained in this document are subject to change
without notice. Chauvet
assumes no responsibility or liability for any errors or
omissions that may appear in this manual.
© Copyright 2016 Chauvet. All rights reserved.
Electronically published by Chauvet in the United States of America.

Page 4 of 16 Hurricane Haze 1D User Manual Rev. 1
Product at a
Glance
Use on Dimmer
x
Auto Programs
x
Outdoor Use
x
Auto-ranging Power Supply
x
Sound-Activated
x
Replaceable Fuse
P
DMX
P
User-Serviceable
x
Master/Slave
x
Duty Cycle
x
Safety Notes
Please read the following Safety Notes carefully before working with the
product. The Notes include important safety information about installation,
usage, and maintenance.
•Always connect the product to a grounded circuit to avoid the risk of electrocution.
•Always disconnect this product from the power source before cleaning it or
replacing the fuse.
•Make sure the power cord is not crimped or damaged.
•Never disconnect the power cord by pulling or tugging on the cord.
•Do not touch the output nozzle on this product. It is very hot during operation and
it may remain hot for several hours after turning the unit off.
•If mounting this product overhead, always secure it to a fastening device using a
safety cable.
•Do not mount this product on a flammable surface (e.g., wood, linoleum, carton,
plastic, or carpet).
•Always make sure that the voltage of the outlet to which you are connecting the
product is within the range stated on the decal or rear panel of the product.
•Keep this User Manual for future consultation. If you sell this product to another
user, be sure that they also receive this document.
•This product is for indoor use only! To prevent risk of fire or shock, do not expose
this product to rain or moisture.
•Make sure there are no flammable materials close to the unit while operating.
•Always install this product in a location with adequate ventilation, at least
20 in (50 cm) from adjacent surfaces.
•Be sure that no ventilation slots on the unit’s housing are blocked.
•Make sure to replace the fuse with another of the same type and rating.
•The maximum ambient temperature (Ta) is 104 °F (40 °C). Do not operate this
product at higher temperatures.
•In the event of a serious operating problem, stop using the unit immediately.
•Never try to repair this product. Repairs carried out by unskilled people can lead
to damage or malfunction. Please contact the nearest authorized technical
assistance center.
•Never connect this product to a dimmer pack.
•Make sure there are no flammable materials close to the unit while operating.
•Depending on the amount of fog/haze generated, all fog machines may set off
smoke detectors.
•Do not use for space heating purposes.
•Use only CHAUVET water-based haze fluid.
•Drain the tank before transporting the product.
•To eliminate unnecessary wear and improve its lifespan, during periods of non-
use completely disconnect the product from power via breaker or by unplugging it.
FCQ (Fog Cleaner Quart) was specifically developed by Chauvet to clean your
Hurricane Haze 1D. Make sure you use FCQ regularly, no longer than 90 days
between cleanings, to increase the life of your product.

Hurricane Haze 1D User Manual Rev. 1 Page 5 of 16
2.Introduction
Product Overview
LED Display
DMX In/Out
Remote Control
Receiver Port
Power In
Fuse Holder
On/Off Switch
Wireless Remote
Manual Fog
Button
Fluid Level
Indicator
Fluid Tank

Page 6 of 16 Hurricane Haze 1D User Manual Rev. 1
Product Dimensions
12.80 in
325 mm
12.52 in
318 mm
9.84 in
250 mm
5.95 in
151 mm
7.95 in
202 mm
10.55 in
268 mm

Hurricane Haze 1D User Manual Rev. 1 Page 7 of 16
3.Setup
AC Power
This product can work with an input voltage of either 120 VAC, 60 Hz or 230 VAC, 50 Hz
depending on the model.
To determine the power requirements for a particular product, see the label affixed to the
back plate of the product or refer to the product’s specifications chart. The listed current
rating indicates the product’s average current draw under normal conditions.
Always connect this product to a protected circuit (circuit breaker or fuse), making
sure that it has an appropriate electrical ground to avoid the risk of electrocution or
fire.
Never connect this product to a rheostat (variable resistor) or dimmer circuit, even
if the rheostat or dimmer channel serves only as a 0 to 100% switch.
Fuse Replacement
Disconnect this product from the power outlet before replacing the fuse.
1. Wedge the tip of a flat-head screwdriver into the slot of the fuse holder.
2. Pry the fuse out of the housing.
3. Remove the blown fuse from the holder and replace with a fuse of the exact same
type and rating.
4. Insert the fuse holder back in place and reconnect power.
The product does not ship with a spare fuse; however, the safety cap has room for
a spare.
Spare fuse holder
(inside safety cap)
Installed fuse (held
by plastic clip)
Safety cap

Page 8 of 16 Hurricane Haze 1D User Manual Rev. 1
Mounting
Orientation
The Hurricane Haze 1D may be mounted in any position
provided there is
adequate room for ventilation around it.
Rigging
Be sure that the structure or surface onto which you are mounting this product can
support its weight. Please see the Technical Specifications section of this manual
for weight information.
Make sure to mount the product securely to a rigging point, whether an elevated
platform or a truss.
When rigging this product onto a truss, you should use a mounting clamp of
appropriate weight capacity. The bracket has a 13 mm hole, which is appropriate
for this purpose.
When mounting this product overhead, always use a safety cable.
Before deciding on a location for this product, always make sure that it will be easy
to access the unit for maintenance and programming purposes.
When power linking multiple products, you must always consider the length of the
power linking cable and mount the products close enough for the cable to reach
them.
The bracket knobs allow for directional adjustment when aiming the product to the
desired angle. Only loosen or tighten the bracket knobs using your bare hands.
Using tools could damage the knobs.
Mounting Diagram
Rubber Feet
Safety Cable
Mounting Clamp

Hurricane Haze 1D User Manual Rev. 1 Page 9 of 16
4.Operation
Control
Panel
Operation
To access the control panel functions, use the 4
buttons located underneath the
display.
Button
Function
<MENU>
Exits from the current menu or function
<UP>
Navigates upwards through the menu list and increases the numeric value
when in a function
<DOWN>
Navigates downwards through the menu list and decreases the numeric
value when in a function
<ENTER>
Enters into a menu or sets the currently displayed value
Important note regarding the priority level for the three types of methods used
to control the operation of your Hurricane Haze 1D.
A DMX controller will take priority control over the digital display and Remote Control.
The priority control levels are:
1. DMX
2. Remote controller
3. Digital display
Fluid Tank
Indicator
LEDs
Indicator LEDs show the status of the fill tank, as follows:
•Red - the heater is currently warming up
•Blue - the hazer is ready
•Flashing Blue - the fluid tank requires refilling
Note: The Hurricane Haze 1D may be operational while the heater is warming up and
may emit bursts of fog while resetting itself or while the fluid tank is heating. This is
normal operation.
See the General Troubleshooting section to identify possible sources of trouble
and find solutions.

Page 10 of 16 Hurricane Haze 1D User Manual Rev. 1
Wired Timer
Remote
Operation
Important: Using the Control Board, set the Haze (HAZe) output to 0. You can then
connect and operate the included wired remote with the Hurricane Haze 1D.
The wired timer controller allows you to automatically trigger fog output by setting interval and duration
times. LED indicator lights display the machine and controller’s current state. Rotary knobs set interval
and duration times, while manual and continuous buttons allow overriding control.
1. Plug in the fog machine to power and turn the power switch to the product on.
2. Plug in the timer controller to the Manual Controller socket on the back of the fog machine.
3. Press the <TIMER ON/OFF> latching button on the timer controller. The Timer LED Indicator
above the button will light up. The <TIMER ON/OFF> latching button will remain on until it is
pressed again.
4. Set the INTERVAL, DURATION, and OUTPUT adjustment knobs to the desired positions.
•INTERVAL knob sets the amount of time in between bursts of fog
•DURATION knob sets the length of time that the fog machine will run during the burst
•OUTPUT knob adjusts the fog output
5. Press the <CONTINUOUS> latching button and the fog machine outputs fog until the button is
pressed again. The Manual/Power LED Indicator above the button will light up during
continuous operation.
Note: The duration of continuous fog output is based on the capability of the fog
machine.
6. Press the <MANUAL> button to momentarily output fog. The fog machine will output fog for
as long as you hold down the button. During manual operation the Manual Momentary LED
Indicator above the button will light up.
Note: The duration of manual fog output is based on the capability of the fog machine.
Interval
Adjustment
Timer LED
Indicator
Manual
Momentary
LED
Manual/Power
LED
Manual Control
Momentary Button
Continuous
Latching Button
Timer On/Off
Latching Button
Duration
Adjustment
Output
Adjustment
OUTPUT

Hurricane Haze 1D User Manual Rev. 1 Page 11 of 16
Menu Map
Mode
Programming Steps
Description
HAZe
h 0~h 3
Output Low~High
Ht
H _ _ _
Shows current temperature
Addr
d 1~512
Selects the DMX starting address
Configuration
(DMX)
Set this product in DMX mode to control it with a DMX controller.
•Connect this product to a suitable power outlet.
•Turn this product on.
•Connect a DMX cable from the DMX output of the DMX controller to the
DMX input socket of this product.
Starting
Address The Hurricane Haze 1D has one DMX personality, a 1-
channel mode for basic
control.
The Hurricane Haze 1D uses 1 channel in DMX mode, which defines the highest
configurable address to 512.
When selecting a starting DMX address, always consider
the number of DMX
channels the selected DMX mode uses. If you choose a starting address that is too
high, you could restrict the access to some of the product’s channels.
If you are not familiar with the DMX protocol, download the DMX Primerfrom
www.chauvetlighting.com.
To select the starting address, do the following:
1. Press <MENU>repeatedly until d*** shows on the display.
2. Use <UP> or <DOWN> to select the starting address.
Configuration
(Standalone
Mode)
Set this product in one of the standalone modes to control it without a DMX controller.
1. Connect this product to a suitable power outlet.
2. Turn this product on.
Manual Mode
Never connect a product that is operating in any standalone mode, whether
Static, Automatic, or Sound to a DMX string connected to a DMX controller.
Products in standalone mode may transmit DMX signals that could interfere
with the DMX signals from the controller.
To enable the Automatic Mode, follow the instructions below:
1. Press <MENU>repeatedly until h*** shows on the display.
2. Use <UP> or <DOWN> to adjust the haze volume.
DMX Channel Assignments and Values
1-CH
Channel Function Value Setting
1
Output
000 ó255
Low~High

Page 12 of 16 Hurricane Haze 1D User Manual Rev. 1
5.Technical Information
Hazer Maintenance
Do not allow the hazer
to become clogged. After every 40 hours of continuous
operation, use CHAUVET Fog Cleaner Quart (FCQ) through the system to prevent
the accumulation of particulate matter in the heating element.
The recommended cleaning procedure is as follows.
1. Unplug the product from power.
2. Empty all fog fluid from the machine.
3. Add cleaning solution to the tank.
4. Connect the product to power and allow it to warm up.
5. Run the unit in a well-ventilated area until the tank is almost empty. Do not
allow the pump to run dry.
6. Refill with hazer fluid to continue using the hazer. Run the machine briefly to
clear any remaining cleaning solution from the pump and heater.
Do not operate the machine without fluid at any time.
Fog Cleaner Quart (FCQ) was specifically developed by Chauvet to clean your
Hurricane Haze 1D. Make sure you use FCQ regularly, no longer than 90 days
between cleanings, to increase the life of your product.
Storage
Before storing the hazer, run FCQ through the system as described in the cleaning
procedure above; however, only follow steps 1 through 5. Do not refill the tank with
fog fluid if storing the hazer. Cleaning the system prior to storage will help prevent
any particles from condensing inside the pump or heater while not in use.
Test-run your Hurricane Haze 1D
on a monthly basis to achieve the best
performance.

Hurricane Haze 1D User Manual Rev. 1 Page 13 of 16
General Troubleshooting
Symptom Indicator Status Possible Cause Possible Action
No output or short output
Red Heater warming up
Allow the product to warm up completely. This should take less than 10
minutes.
Red flashing Air bubble in fluid line
Allow the product to warm up completely.
Turn fog machine 45° to flatten out the bubble and allow the fog fluid to
flow properly
Turn off the product for 5 seconds, and then turn it back on. Repeat as
necessary.
Note: After more than 10 attempts, contact Customer Service.
Blue
Incorrect fluid
Clean thoroughly with CHAUVET FCQ. For full instructions, see Hazer
Maintenance. Refill with CHAUVET water-based haze fluid.
Blocked pipes
Contact Customer Service
Failing part
Contact Customer Service
Spitting fluid
Blue blinking
Incorrect fluid
Clean thoroughly with CHAUVET FCQ. For full instructions, see Hazer
Maintenance. Refill with CHAUVET water-based haze fluid.
Blocked pipes Contact Customer Service
Failing part
Contact Customer Service
Blue
Incorrect fluid Clean thoroughly with CHAUVET FCQ. For full instructions, see Hazer
Maintenance. Refill with CHAUVET water-based haze fluid.
Blocked pipes
Contact Customer Service
Failing part
Contact Customer Service
Normal
Blue
Normal
Normal function
Circuit breaker or fuse
keeps blowing
N/A
Excessive load on the
circuit
Make sure that the total load does not exceed 80% of the breaker or fuse
nominal current
Short circuit along the
power lines Check the power lines and power cords
Product does not power
up
No energy on power outlet Check power outlet
Change to another outlet
Loose or damaged power
cord Check the power cord
Blown fuse
Replace blown fuse with a good one of the same type and rating
Internal problem
Send product for repair
Product does not respond
to DMX
Blue
Wrong starting address on
the product Set the correct starting address on the product
Use the right fader(s) on the controller
Wrong DMX personality on
the product
Set the correct DMX product’s personality
Assign the faders accordingly
Wrong polarity setting on
the DMX controller
Change the signal polarity on the controller
Loose or damaged DMX
cable Check the DMX cable before the faulty unit
Internal problem
Send product for repair
Intermittent DMX
Problems
Signal cables are not DMX
compatible Replace non DMX cables with true DMX cables
Interference with AC or
radio signals
Keep DMX cables away from AC wires or radio equipment
DMX cable too long Install an optically coupled DMX amplifier right before the product with
intermittent problems
Too many products
connected
Install an optically coupled DMX amplifier after unit #32
Terminator not connected
Install a terminator, as indicated in the “DMX Primer” section.
If you still experience problems after trying the solutions presented here, contact Chauvet
Technical Support.

Page 14 of 16 Hurricane Haze 1D User Manual Rev. 1
R
ETURNS
To return a product or request support:
•In the U.S., contact Chauvet World Headquarters (see Contact Us).
•In the UK or Ireland, contact Chauvet Europe Ltd. (see Contact Us).
•In Mexico, contact Chauvet Mexico (see Contact Us).
•In any other country, DO NOT contact Chauvet. Contact your distributor. See www.chauvetlighting.com for
distributors outside the U.S., United Kingdom, Ireland, or Mexico.
If you live outside the U.S., United Kingdom, Ireland, or Mexico, contact your distributor
of record and follow their instructions on how to return Chauvet
products to them.
Visit our website for contact details.
Call the corresponding Chauvet Technical Support office and request a Return Merchandise Authorization (RMA)
number before shipping the product. Be prepared to provide the model number, serial number, and a brief description of
the cause for the return.
You must send the merchandise prepaid, in its original box, and with its original packing and accessories. Chauvet will
not issue call tags.
Clearly label the package with the RMA number. Chauvet will refuse any product returned without an RMA number.
Write the RMA number on a properly affixed
label. DO NOT write the RMA number
directly on the box.
Before sending the product, clearly write the following information on a piece of paper and place it inside the box:
•Your name
•Your address
•Your phone number
•RMA number
•A brief description of the problem
Be sure to pack the product properly. Any shipping damage resulting from inadequate packaging will be your
responsibility. FedEx packing or double-boxing is recommended.
Chauvet reserves the right to use its own discretion to repair or replace returned
product(s).

Hurricane Haze 1D User Manual Rev. 1 Page 15 of 16
C
ONTACT
US
USA WORLD HEADQUARTERS
General Information – Chauvet
Address: 5200 NW 108th Avenue
Sunrise, FL 33351
Voice: [phone]
Fax: [phone]
Toll free: [phone]
Technical Support
Voice: [phone] (Press 4)
Fax: [phone]
Email: [e-mail]
World Wide Web
www.chauvetlighting.com
EUROPE
General Information - Chauvet Europe BVBA
Address: Stokstraat 18
9770 Kruishoutem
Belgium
Voice: [phone]
Technical Support
Email: [e-mail]
World Wide Web
www.chauvetlighting.eu
General Information - Chauvet Europe Ltd.
Address: Unit 1C
Brookhill Road Industrial Estate
Pinxton, Nottingham, UK
NG16 6NT
Voice: [phone]
Fax: [phone]
Technical Support
Email:
[e-mail]
World Wide Web
www.chauvetlighting.co.uk
MEXICO
General Information - Chauvet Mexico
Address: Av. Santa Ana 30
Parque Industrial Lerma
Lerma, Mexico C.P. 52000
Voice: [phone]
Technical Support
Email: [e-mail]
World Wide Web
www.chauvet.com.mx
Outside the U.S., United Kingdom, Ireland, Mexico, or Benelux contact the dealer of
record. Follow their instructions to request support or to return a product. Visit our
website for contact details.

Page 16 of 16 Hurricane Haze 1D User Manual Rev. 1
6.Technical Specifications
Dimensions and
Weight
Length
Width
Height
Weight
12.5 in (318 mm)
10.5 in (268 mm)
9.8 in (250 mm)
8.4 lb (3.7 kg)
Note: Dimensions in inches rounded to the nearest decimal digit.
Power
Power Supply Type
Range
Voltage Selection
Model-specific
120 V, 60 Hz
or
230 V, 50 Hz
Fixed voltage
Parameter
120 V, 60 Hz
230 V, 50 Hz
Consumption
840 W (6.8 A)
840 W (3.7 A)
Fuse size
F 10 A, 250 V
F 10 A, 250 V
Power I/O
Input
Connectors
IEC
Cord plug
Edison
Operation
Heat-up Time
Tank Capacity
Fluid Consumption
1 min
1.5 l
10 ml/min
Fog output
CFM
700
Approved Fluids
Chauvet Haze Fluid (Gallon)
HFG
Thermal
Maximum External Temp.
Cooling System
104 °F (40 °C)
Convection
DMX
I/O Connectors
Connector Type
Channel Range
3-pin XLR
Sockets
2
Ordering
Product Name
Item Code
UPC Number
Hurricane Haze 1D
09071158 (120 V)
09071159 (230 V)
781462215064
781462215071
UL 499
CSA C22.2 No. 64
