Chef's Grill IR2818-1 User manual

2-Burner IR-TECTM Infrared
Liquid Propane Gas Grill
MODEL: IR2818-1
WARNING
Improper installation,
adjustment, alteration, service or
maintenance can cause injury or
property damage.
Read this instruction manual
thoroughly before installing or
servicing this equipment.
DANGER
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flames.
3. Open the lid.
4. If the odor continues, keep away
from the appliance and
immediately call your gas supplier
or fire department.
WARNING
For Outdoor Use Only
WARNING
1. Do not store or use gasoline or
other flammable vapors and
liquids in the vicinity of this or
any other appliance,
2. An LP tank not connected for use
should not be stored in the
vicinity of this or any other
appliance.
Questions, problems, missing parts? Before returning to your retailer, call our customer service
department at 1-888-804-7455, 8 a.m. - 6 p.m., EST, Monday - Thursday, 8 a.m. - 5 p.m., EST, Friday.
ATTACH YOUR RECEIPT HERE
SerialNumber PurchaseDate
Français p.31
Español p.61

2
Call Grill Service Center For Help And Parts
If you have questions or need assistance during assembly,
please call 1-888-804-7455. You will be speaking to a
representative of the grill manufacturer.
Product Record
IMPORTANT: Fill out the product record information
below.
Installation Safety Precautions
• Use grill, as purchased, only with LP (propane) gas and the
regulator/valve assembly supplied. A conversion kit must
be purchased for use with natural gas.
• Grill installation must conform with local codes, or in their
absence of local codes, with either the National Fuel Gas
Code, ANSI Z223.1/ NFPA 54, Natural Gas and Propane
Installation Code, CSA B149.1, or Propane Storage and
Handling Code, B149.2, or the Standard for Recreational
Vehicles, ANSI A 119.2/NFPA 1192, and CSA Z240 RV
Series, Recreational Vehicle Code, as applicable.
• All electrical accessories (such as rotisserie) must be
electrically grounded in accordance with local codes, or
National Electrical Code, ANSI / NFPA 70 or Canadian
Electrical Code, CSA C22.1. Keep any electrical cords
and/or fuel supply hoses away from any hot surfaces.
• This grill is safety certified for use in the United States
and/or Canada only. Do not modify for use in any other
location. Modification will result in a safety hazard.
Safety Symbols
The symbols and boxes shown below explain what each
heading means. Read and follow all of the messages found
throughout the manual.
If you smell gas:
1. Shut off gas to the appliance.
2. Extinguish any open flame.
3. Open lid.
4. If odor continues, keep away from the
appliance and immediately call your gas
supplier or your fire department.
1. Do not store or use gasoline or other
flammable liquids or vapors in the vicinity
of this or any other appliance.
2. An LP cylinder not connected for use shall
not be stored in the vicinity of this or any
other appliance.
Model Number
Serial Number
See rating label on grill for serial number.
Date Purchased
For residential use only. Do not use for
commercial cooking.
DANGER: Indicates an imminently hazardous
situation which, if not avoided, will result in death or
serious injury.
WARNING: Indicates an potentially hazardous
situation which, if not avoided, could result in death
or serious injury.
CAUTION: Indicates a potentially hazardous
situation or unsafe practice which, if not avoided,
may result in minor or moderate injury.

3
ForYourSafety.................................2
Grill Service Center..............................2
Product Record Information . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Safety Symbols.................................2
InstallationSafetyPrecautions.......................2
Kenmore Grill Warranty...........................4
UseandCare................................5-12
NaturalGasConversionKit........................13
PartsList.....................................14
Parts Diagram.................................15
Assembly..................................16-25
NaturalGasConversionInstructions............26-28
Troubleshooting................................29
NOTICE: Using a water spray bottle to extinguish flame
flare-ups can cause thermal shock to firebox porcelain
surfaces, and create “feathering” cracks in the porcelain.
Water can seep through the cracks and cause the
underlying metal to rust.
TABLE OF CONTENTS
CALIFORNIAPROPOSITION 65
1. Combustion by-products produced when using
this product contain chemicals known to the
State of California to cause cancer, birth
defects, and other reproductive harm.
2. This product contains chemicals, including lead
and lead compounds, known to the State of
California to cause cancer, birth defects or
other reproductive harm.
Wash your hands after handling this product.
WARNING
GREASE FIRE HAZARD
Putting out grease fires by closing the grill lid is
not possible. Grills are well ventilated for safety
reasons.
Do not use water on a grease fire. Serious
personal injury may result. If a grease fire
develops, wear gloves to protect hands and
turn knobs and LP cylinder off.
Do not leave grill unattended while preheating
or burning off food residue on HI. If grill has not
been regularly cleaned, a grease fire can occur
that may damage the product.
WARNING

4
WARRANTY
CHEF’S GRILL LIMITED WARRANTY
WITH PROOF OF SALE, the following warranty coverage applies when this appliance is correctly installed,
operated and maintained according to all supplied instructions.
ONE YEAR Overall Warranty: From the date of sale this appliance is warranted against defects in material or
workmanship.Adefective appliance will receive free repair or replacement at option of seller.
FIVE YEARS Burner Warranty: From the date of sale, any stainless steel burner that rusts through or burns
through will be replaced free of charge.Anew burner will be supplied at no charge. You are responsible for the
labor cost of burner installation.
All warranty coverage excludes igniter batteries and grill part paint loss, discoloration or surface rusting, which are
either expendable parts that can wear out from normal use within the warranty period, or are conditions that can
be the result of normal use, accident or improper maintenance.
All warranty coverage appliesis void if this appliance is ever used for other than private household purposes.
This warranty covers ONLY defects in material and workmanship, and will NOT pay for:
1. Expendable items that can wear out from normal use within the warranty period, including but not
limited to batteries, screw-in base light bulbs and surface coatings or finishes.
2. Aservice technician to clean or maintain this appliance, or to instruct the user in correct appliance installation,
operation and maintenance.
3. Service calls to correct appliance installation not performed by authorized service agents, or to repair
problems with house fuses, circuit breakers, house wiring, and plumbing or gas supply systems resulting from
such installation.
4. Damage to or failure of this appliance resulting from installation not performed by authorized service agents,
including installation that was not in accord with electrical, gas or plumbing codes.
5. Damage to or failure of this appliance, including discoloration or surface rust, if it is not correctly operated and
maintained according to all supplied instructions.
6. Damage to or failure of this appliance, including discoloration or surface rust, resulting from accident,
alteration, abuse, misuse or use for other than its intended purpose.
7. Damage to or failure of this appliance, including discoloration or surface rust, caused by the use of
detergents, cleaners, chemicals or utensils other than those recommended in all instructions supplied with the
product.
8. Damage to or failure of this appliance resulting from natural or other catastrophe, such as flood, fire or storm.
9. Damage to or failure of parts or systems resulting from unauthorized modifications made to this appliance.
10. Service to an appliance if the model and serial plate is missing, altered, or cannot easily be determined to
have the appropriate certification logo.
Disclaimer of implied warranties; limitation of remedies
Customer’s sole and exclusive remedy under this limited warranty shall be product repair or replacement as
provided herein. Implied warranties, including warranties of merchantability or fitness for a particular purpose, are
limited to one year on the appliance and five years on the burners, or the shortest period allowed by law. Seller
shall not be liable for incidental or consequential damages. Some states and provinces do not allow the exclusion
or limitation of incidental or consequential damages, or limitation on the duration of implied warranties of
merchantability or fitness, so these exclusions or limitations may not apply to you.
This warranty applies only while this appliance is used in the United States.
This warranty gives you specificlegal rights, and you may alsohave other rights which vary from state to state.

5
LP Tank Removal, Transport and Storage
• Turn OFF all control knobs and LP tank valve. Turn coupling
nut counterclockwise by hand only - do not use tools to
disconnect. Lift LP tank wire upward off of LP tank collar, then
lift LP tank up and off of support bracket. Install safety cap
onto LP tank valve. Always use cap and strap supplied with
valve.
Failure to use safety cap as directed may result in
serious personal injury and/or property damage.
• A disconnected LP tank in storage or being transported must
have a safety cap installed (as shown). Do not store an LP
tank in enclosed spaces such as a carport, garage, porch,
covered patio or other building. Never leave an LP tank inside
a vehicle which may become overheated by the sun.
• Do not store an LP tank in an area where children play.
LP Cylinder
• The LP cylinder used with your grill must meet the
following requirements:
• Use LP cylinders only with these required measurements: 12"
(30.5cm) (diameter) x 18" (45.7 cm) (tall) with 20 lb. (9 kg.)
capacity maximum.
• LP cylinders must be constructed and marked in accordance
with specifications for LP cylinders of the U.S. Department of
Transportation (DOT) or for Canada, CAN/CSA-B339,
cylinders, spheres and tubes for transportation of dangerous
goods. Transport Canada (TC). See LP cylinder collar for
marking.
• LP cylinder valve must have:
• Type 1 outlet compatible with
regulator or grill.
• Safety relief valve.
• UL listed Overfill Protection
Device (OPD). This OPD safety
feature is identified by a unique triangular hand wheel. Use
only LP cylinders equipped with this type of valve.
• LP cylinder must bearranged for vapor withdrawal and
include collar to protect LP cylinder valve. Always keep LP
cylinders in upright position during use, transit or storage.
LP (Liquefied Petroleum Gas)
• LP gas is nontoxic, odorless and colorless when produced.
For Your Safety, LP gas has been given an odor (similar to
rotten cabbage) so that it can be smelled.
• LP gas is highly flammable and may ignite unexpectedly
when mixed with air.
LP Cylinder Filling
• Use only licensed and experienced dealers.
• LP dealer must purge new cylinder before filling.
• Dealer should NEVER fill LP cylinder more than 80% of LP
cylinder volume. Volume of propane in cylinder will vary by
temperature.
• A frosty regulator indicates gas overfill. Immediately close LP
cylinder valve and call local LP gas dealer for assistance.
• Do not release liquid propane (LP) gas into the atmosphere.
This is a hazardous practice.
• To remove gas from LP cylinder, contact an LP dealer or call
a local fire department for assistance. Check the telephone
directory under “Gas Companies” for nearest certified LP
dealers.
USE AND CARE
OPD Hand Wheel
LP cylinder in upright position for vapor withdrawal
LP Tank Valve
Safety Cap
Retainer Strap
• NEVER store a spare LP cylinder under or near
the grill appliance or in an enclosed area.
• Never fill a cylinder beyond 80% full.
• If the information in the two points above is not
followed exactly, a fire causing death or serious
injury may occur.
• An over filled or improperly stored cylinder is a
hazard due to possible gas release from the
safety relief valve. This could cause an intense
fire with risk of property damage, serious injury
or death.
• If you see, smell or hear gas escaping,
immediately get away from the LP cylinder and
grill appliance and call your fire department.

6
Nipple has to be centered
into the LP tank valve.
LP Tank Exchange
•Many retailers that sell grills offer you the option of replacing
your empty LP tank through an exchange service. Use only
those reputable exchange companies that inspect, precision
fill, test and certify their cylinders. Exchange your tank only
for an OPD safety feature-equipped tank as described in
the "LP Tank" section of this manual.
•Always keep new and exchanged LP tanks in upright position
during use, transit or storage.
•Leak test new and exchanged LP tanks BEFORE
connecting to grill.
LP Tank Leak Test
For your safety
•Leak test must be repeated each time LP tank is exchanged
or refilled.
•Do not smoke during leak test.
•Do not use an open flame to check for gas leaks.
•Grill must be leak tested outdoors in a well-ventilated area,
away from ignition sources such as gas fired or electrical
appliances. During leak test, keep grill away from open
flames or sparks.
•Use a clean paintbrush and a 50/50 mild soap and water
solution. Brush soapy solution onto areas indicated by arrows
in figure below. Leaks are indicated by growing bubbles.
Do not use household cleaning agents. Damage to gas
train components (valve/hose/regulator) can result.
Connecting Regulator To The LP Tank
1. LP tank must be properly secured onto grill. (Refer to
assembly section.)
2. Turn all control knobs to the OFF position.
3. Turn LP tank OFF by turning OPD hand wheel clockwise to
a full stop.
4. Remove the protective cap from LP tank valve. Always use
cap and strap supplied with valve.
5. Hold regulator and insert nipple into LP tank valve.
Hand-tighten the coupling nut, holding regulator in a straight
line with LP tank valve so as not to crossthread the
connection.
If “growing” bubbles appear do not use or move the LP
tank. Contact an LP gas supplier or your fire department!
OPD Hand Wheel
Safety Relief Valve
Strap and Cap
Type 1 outlet with
thread on outside
Do not insert a POL transport plug
(plastic part with external threads)
into the Type 1 tank valve outlet . It
will defeat the Safety Relief Valve
feature.

7
6. Turn the coupling nut clockwise and tighten to a full stop.
The regulator will seal on the back-check feature in the LP
tank valve, resulting in some resistance. An additional
one-half to three-quarters turn is required to complete
the connection. Tighten by hand only – do not use tools.
NOTE:
If you cannot complete the connection, disconnect regulator
and repeat steps 5 and 6. If you are still unable to complete the
connection, do not use this regulator! Call 1-888-804-7455
for assistance.
Leak Testing Valves, Hose and Regulator
1. Turn all grill control knobs to OFF.
2. Be sure regulator is tightly connected to LP tank.
3. Completely open LP tank valve by turning OPD hand wheel
counterclockwise. If you hear a rushing sound, turn gas off
immediately. There is a major leak at the connection.
Correct before proceeding by calling 1-888-804-7455.
4. Brush soapy solution onto areas where bubbles are shown
in picture below:
5. If “growing” bubbles appear, there is a leak. Close LP tank
valve immediately and retighten connections. If leaks
cannot be stopped do not try to repair. Call
1-888-804-7455.
6. Always close LP tank valve after performing leak test by
turning hand wheel clockwise.
Hold coupling nut and regulator
as shown for proper connection
to LP tank valve.
• Outdoor gas appliance is not intended to be installed
in or on a boat.
• Outdoor gas appliance is not intended to be installed
in or on an RV.
• Never attempt to attach this grill to the self-contained
LP gas system of a camper trailer or motor home.
• Do not use grill until leak-tested.
• If a leak is detected at any time, STOP and call the
fire department.
• If you cannot stop a gas leak, immediately close
LPcylinder valve and call LP gas supplier or your fire
department!
• Do not insert any tool or foreign object into the valve
outlet or safety relief valve. You may damage the valve
and cause a leak. Leaking propane may result in
explosion, fire, severe personal injury, or death.
Never remove threaded
orifice at end of valve.

8
Safety Tips
Before opening LP cylinder valve, check the coupling nut
for tightness.
When grill is not in use, turn off all control knobs and LP
cylinder valve.
Never move grill while in operation or still hot.
Use long-handled barbecue utensils and oven mitts to
avoid burns and splatters.
Maximum load for sideburner and side shelf is 10 lbs.
The grease tray must be inserted into grill and emptied
after each use. Do not remove grease tray until grill has
completely cooled.
Clean grill often, preferably after each cookout. If a bristle
brush is used to clean any of the grill cooking surfaces,
ensure no loose bristles remain on cooking surfaces prior
to grilling. It is not recommended to clean cooking surfaces
while grill is hot.
If you notice grease or other hot material dripping from grill
onto valve, hose or regulator, turn off gas supply at once.
Determine the cause, correct it, then clean and inspect
valve, hose and regulator before continuing. Perform a
leak test.
Keep ventilation openings in cylinder enclosure (grill cart)
free and clear of debris.
Do not store objects or materials inside the grill cart
enclosure that would block the flow of combustion air to the
underside of either the control panel or the firebox bowl.
The regulator may make a humming or whistling noise
during operation. This will not affect safety or use of grill.
If you have a grill problem see the "Troubleshooting
Section".
If the regulator frosts, turn off grill and LP cylinder valve
immediately. This indicates a problem with the cylinder and
it should not be used on any product. Return to supplier!
For Safe Use of Your Grill and to Avoid Serious
Injury:
• Do not let children operate or play near grill.
• Keep grill area clear and free from materials that
burn.
• Do not block holes in sides or back of grill.
• Check burner flames regularly.
• Use grill only in well-ventilated space. NEVER use in
enclosed space such as carport, garage, porch,
covered patio, or under an overhead structure of any
kind.
• Do not use charcoal or ceramic briquets in a gas grill.
(Unless briquets are supplied with your grill.)
• Use grill at least 3 ft. from any wall or surface.
Maintain 10 ft. clearance to objects that can catch
fire, or to sources of ignition such as pilot lights on
water heaters, live electrical appliances, etc.
• Apartment Dwellers:
Check with management to learn the requirements
and fire codes for using an LP gas grill in your
apartment complex. If allowed, use outside on the
ground floor with a three (3) foot clearance from walls
or rails. Do not use on or under balconies.
• NEVER attempt to light burner with lid closed. A
buildup of non-ignited gas inside a closed grill is
hazardous.
• Never operate grill with LP cylinder out of correct
position specified in assembly instructions.
• Always close LP cylinder valve and remove
coupling nut before moving LP cylinder from
specified operation position.
• Putting out grease fires by closing the lid is not
possible. Grills are well ventilated for safety reasons.
• Do not use water on a grease fire. Personal injury may
result. If a grease fire develops, turn knobs and LP
cylinder off.
• Do not leave grill unattended while preheating or
burning off food residue on HI. If grill has not been
regularly cleaned, a grease fire can occur that may
damage the product.

9
Ignitor Lighting the Grill
1. Read instructions before lighting your grill.
2. Open lid during lighting.
3. Open LP cylinder or natural gas valve.
4. Push any burner control knob in and turn the knob to the left
to “HI” position. Keep pressing the knob until the burner is
lit.
5. If ignition does not occur in 5 seconds, turn the burner
control off, wait 5 minutes for gas to clear away, and repeat
the lighting procedure.
6. To light other burners, repeat step 4.
NOTE: If ignitor does not work, follow Match Lighting
instructions.
Main Burner Match Lighting
Do not lean over grill while lighting.
1. Open lid during lighting.
2. Place match into match holder (hanging from side of cart).
Light match, place into the firebox.
3. Push in and turn right knob to HIGH position. Be sure burner
lights and stays lit.
4. Light other burners by pushing knob in and turning to HI
position.
Side Burner Match Lighting
1. Open side burner lid. Turn on gas at LP cylinder.
2. Place match into match holder. Light match. Place lit match
near burner.
3. Turn side burner knob to HI. Be sure burner lights and stays
lit.
Burner Flame Check
•Remove cooking grates and heat diffusers. Light burners,
rotate knobs from HIGH to LOW. You should see a smaller
flame in LOW position than seen on HIGH. Perform burner
flame check on sideburner, also. Always check flame prior to
each use.
Turn off controls and tank or gas supply when not
in use.
Please make sure the drip tray and drip cup are
properly installed before turning burners on.
Drip tray is hot when burner is on and after grilling.
Do not touch the drip tray when it is hot.
If ignition does not occur in 5 seconds, turn the burner
control off, wait 5 minutes, and repeat the lighting
procedure. If the burner does not ignite with
the valve open, gas will continue to flow out of the
burner and could accidently ignite with risk of
injury.

10
Turning Grill Off
•Turn all knobs to position. Turn LP cylinder off by turning
hand-wheel clockwise to a full stop.
Ignitor Check
•Turn gas off at LP cylinder. Push the control knob in and
turn the knob to the left to “HI” position."Click" should be
heard and spark seen each time between collector box or
burner and electrode. See "Troubleshooting" if no click or
spark.
Valve Check
•Important: Make sure gas is off at LP cylinder before
checking valves. Knobs lock in OFF position. To check
valves, first push in knobs and release, knobs should spring
back. If knobs do not spring back, replace valve assembly
before using grill. Turn knobs to LOW position then turn back
to OFF position. Valves should turn smoothly.
Hose Check
•Before each use, check to see if hoses are cut or worn.
Replace damaged hoses before using grill. Use only identical
replacement part valve/hose/regulator as specified in the
Parts List of this Use and Care Guide.
General Grill Cleaning
•Do not mistake brown or black accumulation of grease and
smoke for paint. Interiors of gas grills are not painted at the
factory (and should never be painted). Apply a strong
solution of detergent and water or use a grill cleaner with
scrub brush on insides of grill lid and bottom. Rinse and allow
to completely air dry. Do not apply a caustic grill/oven
cleaner to painted surfaces.
• Plastic parts: Wash with warm soapy water and wipe dry.
Do not use citrisol, abrasive cleaners, degreasers or a
concentrated grill cleaner on plastic parts. Damage to and
failure of parts can result.
•Porcelain surfaces: Because of glass-like composition, most
residue can be wiped away with baking soda/water solution or
specially formulated cleaner. Use nonabrasive scouring
powder for stubborn stains.
•Painted surfaces: Wash with mild detergent or nonabrasive
cleaner and warm soapy water. Wipe dry with a soft
nonabrasive cloth.
•Grease Tray and Cup: Regularly clean the grease drippings
from the Grease Tray and Grease Cup.
When the grill has completely cooled down after use, remove
the cup from the tray and slide the tray out of the grill. Clean
the grease drippings from the cup and tray surfaces by
washing with mild detergent or nonabrasive cleaner and warm
soapy water. Wipe dry with a soft nonabrasive cloth. Slide the
tray back into the grill and replace the cup back into the tray
before using the grill again.
•Stainless steel surfaces: To maintain your grill’s high quality
appearance, wash with mild detergent and warm soapy water
and wipe dry with a soft cloth after each use. Baked-on
grease deposits may require the use of an abrasive plastic
cleaning pad. Use only in direction of brushed finish to avoid
damage. Do not use abrasive pad on areas with graphics.
• Cooking surfaces: If a bristle brush is used to clean any of
the grill cooking surfaces, ensure no loose bristles remain on
cooking surfaces prior to grilling. It is not recommended to
clean cooking surfaces while grill is hot.

11
Storing Your Grill
•Clean cooking grates.
•Store in dry location.
•When LP cylinder is connected to grill, store outdoors in a
wellventilated space and out of reach of children.
•Cover grill if stored outdoors. Choose from a variety of grill
covers offered by manufacturer.
•Store grill indoors ONLY if LP cylinder is turned off and
disconnected, removed from grill and stored outdoors.
•When removing grill from storage, follow “Cleaning the Burner
Assembly” instructions before starting grill.
Food Safety
Food safety is a very important part of enjoying the outdoor
cooking experience. To keep food safe from harmful bacteria,
follow these four basic steps:
Clean: Wash hands, utensils, and surfaces with hot soapy
water before and after handling raw meat and poultry.
Separate: Separate raw meats and poultry from ready-to-eat
foods to avoid cross contamination. Use a clean platter and
utensils when removing cooked foods.
Cook: Cook meat and poultry thoroughly to kill bacteria. Use a
thermometer to ensure proper internal food temperatures.
Chill: Refrigerate prepared foods and leftovers promptly.
How To Tell If Meat Is Grilled Thoroughly
• Meat and poultry cooked on a grill often browns very fast on
the outside. Use a meat thermometer to be sure food has
reached a safe internal temperature, and cut into food to
check for visual signs of doneness.
• Whole poultry should reach 180° F; breasts, 170° F. Juices
should run clear and flesh should not be pink.
• Hamburgers made of any ground meat or poultry should
reach 160° F, and be brown in the middle with no pink juices.
Beef, veal and lamb steaks, roasts and chops can be cooked
to 145°F. All cuts of pork should reach 160° F.
• NEVER partially grill meat or poultry and finish cooking later.
Cook food completely to destroy harmful bacteria.
• When reheating takeout foods or fully cooked meats like hot
dogs, grill to 165° F, or until steaming hot.
WARNING: To ensure that it is safe to eat, food must be
cooked to the minimum internal temperatures listed in the table
below.
USDA* Recommended Safe Minimum Internal Temperatures
Beef, Veal, Lamb and Pork – Whole Cuts** 145° F
Fish 145° F
Beef, Veal, Lamb and Pork – Ground 160° F
Egg Dishes 160° F
Turkey, Chicken & Duck – Whole, Pieces & Ground 165° F
* United States Department of Agriculture
**Allow meat to rest three minutes before carving or consuming.

12
Gas Requirements
LP Gas
If your grill is for LP Gas, the regulator supplied is set for
an 11-in. water column (WC) and is for use with LPgas
only. The factory-supplied regulator and hose must be
used with a 20-lb. LP gas tank.
Excess Flow Control and Low Heat
The propane regulator assembly incorporates an excess
flow device designed to supply the grill with sufficient gas
flow under normal conditions yet control excess gas flow.
Rapid changes in pressure can trigger the excess flow
device providing a low flame and low temperature. If the
tank valve is turned open to allow gas flow while a burner
valve is open, the surge of pressure will cause the device
to activate. The device will remain closed until the
pressure is equalized. This should occur within 5
seconds.
To ensure this does not cause difficulty in lighting the grill,
follow these instructions:
1. Make sure all burner valves are “OFF”.
2. Open the tank valve and wait 5 seconds.
3. Light the burners one at a time following the lighting
instructions.
Helpful Care and Maintenance Hints
Before grilling, pre-heat grill for 15 minutes on "HI" with
hood down. To avoid uncontrolled flare-ups or grease
fires, grill meats with hood open. Close hood if meats are
thick or weather is cold, or if you are using a rotisserie or
indirect cooking.
Always protect your hand with a pot holder or cooking
glove when coming into contact with a hot surface.
Hood up when grilling meats, especially chicken. Hood
down when indirect or rotisserie cooking.
NEVER leave your grill unattended while cooking.
After use, close hood, turn burners to HI for 15 min. for
self-cleaning, grease burn off.
Care and Maintenance Time Table Chart
Grill Item Frequency Based
on Normal Use Cleaning Method
Painted surface Twice yearly Car wax
Stainless surface
Twice yearly Stainless cleaner
All grates After each use Burn off and wipe
Stainless grates 15 days Wire brush/
Dishwasher safe
Porcelain grates 15 days Scrub pad soapy water
/Dishwasher safe
Burner heat tents
30 days Wire brush
Burners 90 days Wire brush
Burner box
interior 120 days Interior grill cleaning
products (available at
Sears)

13
Plug
Socket Sleeve
Your grill can be converted to natural gas. The
conversion must be performed by a qualified gas
technician. The following listed Natural Gas Conversion
Kit (sold separately) are required for the conversion.
Natural gas conversion kit
Model # NGKIT-01
(Manufacturer Part No.: IR2818-1-KIT)
Natural Gas Connection Preparation:
1. Turn off gas supply, and then remove cap on gas
supply side.
2. Recommended: Install a shut-off valve on
gas supply side before installing the socket.
3. Socket should be installed by an authorized
technician in accordance with the national fuel gas
code (NFPA54/ANSI223.1).
Before inserting plug, turn on gas supply and leak test all
connections including the stem of the shut-off valve and
the opening of the socket. For best results, use an
ammonia-free soap & water solution.
Operating Instructions:
1. To connect, push back socket sleeve.
2. Insert plug and release sleeve.
3. Push plug until sleeve snaps forward. (Gas will flow
automatically. Failure to connect plug properly to
socket will inhibit gas flow to the appliance.)
To disconnect
1. Pull Sleeve back. Pull plug out of socket. (Gas is
automatically shut off.)
2. Close shut-off valve or turn off gas supply, and replace
dust caps on socket and plug.
Natural Gas
Now that your grill is converted to Natural Gas use, it is
set for 7-inch water column (WC) pressure, and cannot
be used with Propane Gas. Gas pressure is affected by
gas line size and the length of gas line run from the
house. Follow the recommendations in the chart below.
From House to Grill
Distance Tubing Size
Up to 25 ft. 3/8 in. diameter
26-50 ft. 1/2 in. diameter
51-100 ft. 2/3 of the run: 3/4 in. diameter
1/3 of the run :1/2 in. diameter
Over 101 ft. 3/4 in. diameter
Natural Gas Conversion Kit
Sleeve
Socket

14
Key Qty Description Manufacturer
Part #
1 1 HOOD HANDLE IR2818-00-4300
2 2 RUBBER PLUG 3219B-8083
3 1 HOOD IR2818-00-4000
4 1 TEMPERATURE GAUGE 2518-4C-8012
5 1 TEMPERATURE GAUGE BEZEL 3218LTN-00-4001
6 1 TEMPERATURE GAUGE SLEEVE E3518-00-4009
7 2 MAIN GRID RB2818ST-00-2001
8 1 WARMING RACK 2818-2T-2002
9 5 HEAT TENT IR2818-00-2004
10 1 REFLECTOR IR2818-00-2041
11 1 BURNER BOX IR2818-00-2000
12 2 NUT 5/16-18 UNC
13 2 HOOD SLEEVE E3518-00-0001
14 2 SCREW 5/16-18 UNC x 1”
15 2 MAIN BURNER IR2818-00-2050
16 1 IGNITION PIN ( MAIN BURNER ) IR2818-00-8002
17 1 COVER HANDLE 3218LT-00-2804
18 1 SIDE BURNER COVER E3518-00-6001
19 1 SIDE BURNER GRID IR2818-00-6002
20 1 ELECTRICAL IGNITOR RT2417S-00-8004
21 1 SIDE BURNER SHELF IR2818-00-6100
22 1 IGNITION PIN ( SIDE BURNER ) L3018SN-00-8007
23 1 SIDE BURNER IR2818-00-8300
24 1 LPG REGULATOR IR2818-00-8007
25 3 BEZEL L3018SN-00-3302
26 3 KNOB L3018SN-00-3301
27 1 IGNITION PIN ( MAIN BURNER ) IR2818-00-8001
28 1 MAIN BURNER HOSE(BACK) IR2818-00-8003
29 1 MANIFOLD IR2818-00-3200
30 1 MAIN BURNER HOSE(FRONT) 2518SL-8005
31 1 DRIP TRAY RB2818TN-00-2600
32 1 SIDE SHELF IR2818-00-5000
33 1 LEFT PANEL IR2818-00-1700
34 1 SIDE PANEL BRACKET (LEFT) 2818-2T-1600
35 1 DRIP CUP SUPPORT 2818-2T-1500
36 1 DRIP CUP P3018-00-1002
37 1 TANK RING P3018-00-1203
38 1 TANK RING BRACKET E3518-00-1202
39 1 REAR PANEL IR2818-00-1200
40 1 RIGHT PANEL IR2818-00-1800
41 1 SIDE PANEL BRACKET (RIGHT) 2818-2T-1700
42 1 BOTTOM PANEL IR2818-00-1100
43 2 LOCKING CASTER RT2417S-00-8005
44 2 CASTER RT2417S-00-8006
45 2 MAGNET L3018S-00-1310
46 1 RIGHT DOOR IR2818-00-1600
Key
Qty Description Manufacturer
Part #
47 1 LEFT DOOR IR2818-00-1400
48 2 DOOR HANDLE RT2417S-00-1610
49 1 BEAM IR2818-00-1500
50 2 REFLECTOR SUPPORT IR2818-00-2143
51 2 HEAT TENT SUPPORT IR2818-00-2102
1 HARDWARE PACK IR2818-1
HARDWARE
1 PRODUCT MANUAL IR2818-1 - MANUAL
PARTS LIST
To order replacement parts after using grill, call
1-888-804-7455
If you are missing hardware or have damaged parts after
unpacking grill, call 1-888-804-7455 for replacement.
NOTE: Some grill parts shown in the assembly steps may differ slightly in appearance from
those on your particular grill model. However, the method of assembly remains the same.

15
PARTS DIAGRAM
○
3
○
5
○
6
○
7
○
8
○
20
○
21
○
28
○
31
○
1
○
30
○
9
○
10
○
22
○
23
○
29
○
2
○
4
○
69
○
13
○
12
○
24
○
37
○
25
○
26
○
27
○
15
○
16 ○
19
○
32
○
11
○
14
○
38 ○
39
○
40
○
35
○
44 ○
43
○
41
○
49
○
17 ○
18
○
33
○
34
○
36
○
42
○
45
○
46
○
47
○
48
○
50
○
51

16
Magnet
UNPACKING
After removing all parts and hardware pack from the top of the shipping box, and when the only part showing is the grill
head, use a box cutting knife to slice down the sides of the box. Be careful of staples along shipping box edges.
Remove the corner supports from the box and the styrofoam side pieces from the grill head. With the aid of an assistant,
rest grill head on one of the styrofoam side pieces to protect grease tray.Allow grill head to rest on cardboard until
placing grill head on cart in Step 10.
Open grill lid and remove all packaged parts and packing material.
WARNING: Assemble and place the grill on a flat level surface. Compare the parts and hardware with the list
and diagrams. Do not attempt assembly if any part is missing or damaged.
Attach the casters and locking casters to the bottom panel with 12 screws; note that the locking casters are
at the back of the grill. Then, turn the bottom panel over.
Attach the magnet to the bottom panel with two 5/32-32 x 3/8″screws.
3/16-24 x 1/2″Screw
Qty. 12
5/32-32 x 3/8″Screw
Qt
y
. 2
Bottom Panel Locking Caster
Caster

17
Attach the left panel and rear panel to the bottom panel.There are 3 screws for the rear panel, 5 screws for
the bottom panel.
Attach the right panel to the bottom panel and rear panel with 5 screws.
There are 2 screws for bottom panel and 3 screws for rear panel.
3/16-24 x 1/2″Screw
Qty. 8
3/16-24 x 1/2″Screw
Qty. 5
Left Panel Rear Panel
4
Right Panel

18
Slide the tank ring bracket onto the end of the tank ring.Attach the bracket to the rear panel with 2 screws.
Loosen the two screws in the right and left side panel brackets 3 to 4 turns.
Insert the screws through the 2 holes at the base of each side panel and slide the bracket down until it
stops. Attach each bracket to the bottom panel with one 3/16-24 x 1/2 in. screw. Retighten the 4 loosened
screws.
Tank Ring Bracket
Tank Ring
1/4-20 x 5/8″Screw
Qty. 2
3/16-24 x 1/2″Screw
Qty. 2
Side Panel Bracket
5
6

19
Attach the beam to the side panels with 4 screws.
Attach the drip cup support to the rear panel and beam with 4 screws, 2 screws for the rear panel and 2
screws for the beam.
Beam
3/16-24 x 1/2″Screw
Qty. 4
3/16-24 x 1/2″Screw
Qty. 4
7
8
Drip Cup Support

20
Put the drip cup on the drip cup support.
Cut tie wraps holding regulator underneath grill head control panel. Be careful not to cut igniter wires or the
tie wraps holding the igniter wires in place.
With the aid of an assistant, lift and place grill head onto cart. Grill head sides go over attachment tabs on
cart. Make sure that regulator and igniter wires hangs inside the cart.Attach head to cart with 4 screws as
shown.
Drip Cup
Burner Box
Cabinet
3/16-24 x 1/2″Screw
Qty. 4
9
10
