Chess mymesh BLC 200 User manual

Safety
- Installation should be performed only by a qualied electrician.
- Disconnect power at the source before installation, inspection or removal.
- Do not use the BLC200 if it is damaged.
- The electrical installation must be in conformance with the national legislation and relevant
standards.
- The mains connection of the BLC200 must be provided with a fuse or circuit breaker.
- The BLC200 has protection class IP20 and is suitable for use at indoor locations. Mount the
- BLC200 in an IP66 housing for use at outdoor locations.
BLC 200
Mymesh Building Light Control
The Mymesh BLC200 is a product in the Mymesh Building Light Control product suite for
wireless lighting control. The BLC200 is a wireless light controller for DALI and 1..10V drivers. A
relay is available to control the power to the driver and lighting xture.
Application
- Refer to the BLC200 product sheet (see chess-wise.eu/downloads) for the maximum
ratings of the relay and the environmental conditions.
Installation
- Mount the BLC200 with 2x M4 screw/bolt (140mm distance).
- Use maximal 1.5 mm2 wiring for all connections. Push the wires completely into the terminal
- block. Use wire end sleeves when using exible wires.
- De BLC200 can be wired in three congurations: DALI driver, 1..10V driver or a 230V load. See
- wiring diagrams below.
- Use either 1..10V or DALI, not both.
- Do not connect more than one DALI driver to a BLC200.
by Chess

BLC200 + DALI driver
Connect the power input of a DALI driver directly to the 230V mains.
Connect the power input of a 1...10V driver to the switched 230V of the BLC200
BLC200 + 1....10V driver
Connect the 230V load to the switched 230V output of the BLC200
BLC200 + 230V load

 Conguration
When the BLC200 is powered, the connected lamp should go on. Use the iPad Mymesh
commission app for conguration of the BLC200.
Usage
The BLC200 will control the connected driver and lamp.
Compliance
This product complies with the European directives and relevant standards for low voltage,
EMC, RED, REACH and RoHS. The BLC200 contains a radio. The applied radio frequency is
within the ISM band 2400 – 2483.5 MHz (default 2403 MHz) and the maximum transmit
power is +4 dBm. Hereby,
Chess Wise declares that the radio equipment type BLC200 is in compliance with Directive
2014/53/EU. The full text of the EU declaration of conformity is available at chess-wise.eu/
downloads.
Repair
Do not open this product. In case of failure the BLC200 must be replaced.
Recycling
Do not dispose this product as household waste, but bring it to an appropriate collection
point for recycling.
