Chesterton Connect User manual

QUICK START GUIDE
Equipment monitoring sensor—vibration,
temperature, and pressure

1Install Sensor
Apply thread sealant tape on the 1/4" NPT
threads. Install the process sensor NPT plug.
2Attach Connector
Attach the M12 pin connector to the unit.
Green = Ready for Connection
Blue = Connected
Red = Alert

4Download App
Download the mobile app: Chesterton Connect™
20m
Attach Unit
Attach the vibration and surface temperature
measuring unit.
3

A.W. Chesterton Company, 860 Salem Street, Groveland, MA 01834 USA
Telephone: [phone], Fax: [phone], chesterton.com
Form No. EN350553 Chesterton Connect Quick Start Guide 01/20
Chesterton Connect™ is a trademark of A.W. Chesterton Company. The Bluetooth® word mark and logos are registered trademarks owned
by Bluetooth SIG, Inc. and any use of such marks by A.W. Chesterton is under license. Apple, theApple logois a trademark ofAppleInc.,
registered in the U.S. and other countries. App Store is a service mark of Apple inc. Google Play, the “Android” name, the Android logo, the
“Google play” brand, and other Google trademarks, are property of Google LLC .
To view Chesterton’s privacy policy please visit: chesterton.com/en-US/Pages/Privacy.aspx
©2020 A.W. Chesterton Company.
®Registered trademark owned by A.W. Chesterton Company in USA and other countries, unless otherwise noted.
Warnings and Cautions
• Chesterton Connect™ contains a replaceable lithium thionyl chloride battery
and a neodymium magnet. Follow local laws for proper treatment and disposal
of this product or its components.
• To reduce the risk of re or burns, do not crush, puncture, expose to
temperatures above 85°C (185°F) or dispose of in re.
• Chesterton Connect™ contains a very strong neodymium magnet. Use caution
when handling unit to avoid injuries.
• Disable the product if it is damaged or operates incorrectly.
• Do not stick anything into the pressure/temperature 1/4" NPT port.
• Handle the unit using the supplied ESD protective caps until ready to install.
• Make sure product is used as specied and within its advertised
operating limits.
• Do not bend cable beyond its bend radius.
• Do not allow the pressure/temperature sensor to come in contact with
the magnet.
• Do not drop magnet against hard surfaces, including the pump.
• Do not drop the Chesterton Connect™ product. Dropping the product may
aect its ability to function properly.
• Follow all nearby PPE and equipment safety requirements when installing,
troubleshooting or removing the sensor and its components.
• If using the Pressure/Temperature (P/T) sensor, ensure the process uid is
compatible with the stainless-steel P/T sensor.
You must read the Chesterton Connect User Guide before
installation. Go to: awc-connect.co/f4r
For support visit: [e-mail]
Inside USA: 833-677-7343
International: [phone]
