Chevrolet 2013 VOLT Assembly instructions
Congratulations on your new Chevrolet Volt.
It’s an amazing vehicle, and we’re sure you’re eager to get behind the wheel and see what it can do.
For a quick introduction to the Volt, review this guide. It provides the basic information needed to charge
it, start it, and hit the road. Complete details can be found in your Owner Manual.
If you have any questions or would like more information about your Volt, contact a Volt Customer
Advisor at 1-877-4-VOLT-INFO (1-877-486-5846).
www.chevrolet.com/volt
2
Driver
Information
Center Controls
Instrument Panel
Illumination
Control
Turn Signal Lever/
Pedestrian-Friendly
Alert Button/Exterior
Lamps Control
Audio
Steering
Wheel
Controls
Cruise
Control
Fuel Door
Release
INSTRUMENT PANEL CONTROLS
Brake System
Safety Belt Reminder
REAR Seat Safety
Belt Reminder
Airbag Readiness
High Beam Headlamps
Engine Oil Pressure
12V Charging System
Forward Collision Alert
Lane Departure Warning
Engine Coolant
Temperature
Security
Service Electric Parking
Brake
PARK Electric Parking
Brake Set
Cruise Control
Door, Hood or
Hatch Open
Low Fuel
Antilock Brake System
Lights On Reminder
Instrument
Cluster/Driver
Information
Center
Windshield
Wipers
Lever
Power Mirror Controls/
Power Window/Rear
Door Safety Lock
Charge
Port Door
Release
Tilt/
Telescopic
Steering
Wheel Lever
3
Note: Refer to your Owner Manual to learn
about the information being relayed by the
lights, gauges and indicators of the instrument
cluster, as well as what to do to ensure safety
and prevent damage to your vehicle.
See Instruments and Controls in your Owner Manual.
Climate
Control
Screen
Climate/
Fan
Controls
Leaf/Drive
Mode
Power Infotainment
System
Passenger’s
Heated Seat
INSTRUMENT PANEL CONTROLS
Charging
Status
Indicator
Driver’s
Heated
Seat
Hazard
Warning
Flashers
Electric
Parking Brake
Light
Sensor
Power Door
Lock/Unlock
Disc
Eject
Low Tire Pressure
StabiliTrak/Traction Control
Traction Control Off
StabiliTrak Off
Check Engine
READ
Y
Vehicle Ready
4
GETTING STARTED
See More
To get started driving your Volt, review the basic information in this guide along
with your Owner Manual. To view informative online videos about Volt operations,
scan the QR code in this guide with your smartphone. To scan a code:
1. Use the QR Code Reader on your smartphone or download a free reader to
your smartphone from your phone’s app store.
2. Start the reader.
3. Hold the phone over the code and shoot. Some phones will recognize the code
automatically.
Remote Keyless Entry (RKE)
The RKE transmitter performs several remote functions and must be in the vehicle to
operate the Volt.
Keyless Access
With the RKE transmitter within 3 ft. (1 m)
of the door, press the chrome button on
the door handle to unlock the door. Press it
again within 5 seconds to unlock all doors.
Key Release
Press the top button to
extend the key, which
can be used to unlock
the driver’s door.
Unlock
Press to unlock
the driver’s door or
all doors. Press and
hold to open all windows from outside the
vehicle.
Lock
Press to lock all doors.
Charge Port Door
Press to open the charge port door.
Remote Start
Press the Lock button and then press
and hold the button to start the vehicle
and condition the passenger cabin
temperature from outside. The heating
or air conditioning system and rear window
defogger (if needed) will turn on. Depend-
ing on conditions and vehicle personaliza-
tion settings, the engine may start.
After entering the vehicle, press the brake
pedal and then press the POWER
button before driving.
Note:
Remote Start button
again to cancel a remote start.
between ignition cycles.
when the vehicle is plugged in to allow
energy from the wall outlet to assist
in getting the cabin to a comfortable
temperature and to leave more battery
energy for driving.
Panic Alarm
Press and release to locate the vehicle.
Press and hold for three seconds to sound
the panic alarm.
See Keys, Doors and Windows in your Owner Manual.
Getting
Started
Basics
Sample
5
GETTING STARTED
POWER Button
The Volt features an electronic push-button start. The POWER
Note: The air conditioning compressor, pumps and fan may run at any time, even when the vehicle is
OFF, to cool or warm the propulsion battery.
Conditions for the Engine Starting
in or completely charged. Conditions that may cause the engine to start include:
Starting the Vehicle/ON
brake pedal and then press the POWER
The vehicle will not shift out of Park and will
display a Charge Cord Connected message
if the vehicle is still plugged in.
active battery or fuel gauge. The engine will start
only if needed.
Stopping the Vehicle/OFF
Shift to Park and then press the POWER
button. A power OFF audio cue will sound.
(depending on
engine-assisted heating options; see Vehicle
Personalization on page 11)
(occur only if the engine has had
very limited operation over a long
period)
See Driving and Operating in your Owner Manual.
Seat and Steering Wheel Adjustment
Before driving, adjust the seat and steering wheel to a comfortable position.
Pull down the lever (A) to unlock the steering
wheel and adjust its position.
Lift the handle (B) under the right-front side of
the seat to slide the seat forward or rearward.
Ratchet the side lever (C) up or down to raise or
lower the seat.
Lift the rear lever (D) to adjust the seatback.
See Seats and Restraints in your Owner Manual.
A
CD
B
6
ELECTRIC AND EXTENDED-RANGE MODES
Volt is an electric vehicle with extended range capability. Plug it in, let it charge overnight,
and it’s ready to run on a pure electric charge — gas- and tailpipe emissions-free. After that,
Volt keeps going, even if you can’t plug it in. Volt uses a range-extending gas engine that
produces enough energy to power it for hundreds of miles on a single tank of gas.
Electric Mode
In Electric Mode, the Volt will not use gasoline or produce tailpipe emissions unless in
extreme cold temperatures. During this primary mode, the Volt is powered by electri-
cal energy stored in its propulsion battery. It can operate in this mode until the battery is
depleted to a predetermined level.
Extended-Range Mode
Once the electric charge is depleted, the range-extending gas engine will start to gener-
ate enough power to continue driving the vehicle. The engine ensures that you will not be
stranded by a depleted battery. The vehicle determines when the engine needs to run.
will not fully charge the propulsion battery. The vehicle must be plugged in to recharge.
Total Vehicle Range The Total Range indicator displays the total
distance that can be driven, based on the
combined electric and extended range,
before recharging or refueling the vehicle.
The displayed electric and fuel ranges
are projections based on past vehicle
performance and charge/fuel level. The dis-
played ranges will change based on current
driving style and climate settings.
See Driving and Operating in your Owner Manual.
PARkING
Electric Parking Brake
To apply the parking brake, pull the PARK Parking Brake switch by the shift lever.
PARK
Parking Brake switch.
Driving and Operating in your Owner Manual.
Low Ground Clearance
The low ground clearance of the Volt aids in the
(bumper) may contact a parking block or curb if
the vehicle is parked too closely. Use care when
parking to avoid damage.
See Vehicle Care in your Owner Manual.
7
INSTRUMENT CLUSTER
of operating information.
The Simple Conguration displays basic information for Electric Mode and Extended-
Range Mode operation.
The Enhanced Conguration
in Mountain or Hold drive modes.)
Driver Information Center
Use the Driver Information Center controls on the left side of the instrument panel to
change the instrument cluster display and access the menus.
CONFIG
Press to select the Simple or Enhanced
SELECT
Turn the knob to scroll through the menus.
Press it to select a highlighted item.
BACK
Press to move back or exit a menu.
See Instruments and Controls in your Owner Manual.
Simple Conguration shown
8
INSTRUMENT CLUSTER
Electric Mode Display The propulsion battery gauge and electric
range estimate are in color and displayed
in the foreground when the vehicle is
operating in Electric Mode. The fuel gauge
is grayed out.
Enhanced Conguration shown
The fuel gauge and fuel range estimate are
in color and displayed in the foreground
when the vehicle is operating in Extended-
Range Mode. The propulsion battery gauge
is grayed out.
Enhanced Conguration shown
Extended-Range Mode Display
To view a tutorial about the unique
features of the instrument cluster, with
the vehicle in Park, turn the SELECT
knob until Tutorial Mode is high-
lighted. Press the knob to select it.
See Instruments and Controls in your Owner Manual.
Enhanced Conguration shown
Cluster Tutorial
Congurable
Cluster
Display
Driver
Information
Center
9
EFFICIENCY
Driving Style
Press the CONFIG button to select
instrument cluster to display the
While driving, try to keep the spinning ball
center of the gauge. The ball will turn yel-
acceleration or aggressive braking. The
ball stops spinning when the vehicle stops.
Efciency Gauge
Driver-Selected Operating Modes Normal (Default)
Use when possible in normal driving
each time the vehicle is started.
Sport
Use when more responsive acceleration is
Mountain
Use when planning to drive in mountain-
ous terrain (long grades of 5% or higher);
reserves battery power to maintain higher
speeds on steep grades.
Hold
Use when wanting to preserve electric
range for later use. Range-extending
operation will engage.
Climate Settings
Use the heated seats (if equipped) to reduce the demand on the cabin heating system.
Heating the seats uses less energy than heating the vehicle interior.
See Driving and Operating in your Owner Manual.
Press the DRIVE MODE button on the
center stack to scroll through a menu of
operating modes when more performance
is needed. After three seconds, the high-
lighted mode will become active. At the
next start, the vehicle will default to
10
EFFICIENCY
Center Stack Information Displays
The center stack touch screen displays Power Flow, Charging and Energy Information.
Press the Leaf button on the center
stack and then touch the desired tab at
the top of the screen to display the
desired information.
Power Flow
The Power Flow screens show the power
-
tric drive unit and engine. Each component
is highlighted when it is active.
Charging
The Charging screens show the charge
mode status. The vehicle has three
programmable charge modes:
departure time
Charge Complete times are estimates and
most accurate at moderate temperatures.
The charging level can be programmed
using the Change Charge Level screen
button (see Charging on page 13).
Energy Information
The Energy Info screens show the energy
use (Electric Mode and Extended-Range
Mode) since the last time the vehicle was
improve energy use.
See Instruments and Controls in your Owner Manual.
Power Flow screen
Charging screen
Energy Info screens
Leaf Button
11
SETTINGS, SIGHTS AND SOUNDS
Infotainment/Vehicle Personalization Displays
The touch screen in the center stack also can be used to display and adjust Infotainment,
Vehicle Personalization and Climate Control settings.
Use the controls on the center stack and
the touch screen to access the various
menus and settings.
The center stack controls only need a
light touch to operate and work best with
time. The controls work with most gloves
but may take longer to respond. Remove
gloves if necessary for proper operation.
In the screen menus, an arrow on
the right side indicates a submenu is
available. A check mark next to an item
indicates it is selected/on.
Infotainment
The infotainment system features radio, CD and MP3 player, auxiliary device input, voice
recognition and Bluetooth®phone functions, and available navigation.
Connect an auxiliary device to the input jack or USB port, located in the center console.
the pairing instructions.
See Bluetooth Phone/Devices in your Infotainment Manual.
Vehicle Personalization
Some features can be customized to your preference. Press the CONFIG button on the
center stack to display the available personalization menus; use the TUNE/MENU knob
and BACK button or touch screen buttons to enter and select menu options.
An audible tone sounds each time a button is pressed on the center stack. To turn the
tone on/off, select Vehicle > Comfort and Convenience > Button Chime.
To set the clock, press the TP (Time Program) control on the center stack. Use the
screen buttons on the display to adjust the time.
To change climate settings such as Auto Defog and engine-assisted heating options,
select Vehicle > Climate and Air Quality.
Audio
System Chevrolet
MyLink
See Instruments and Controls in your Owner Manual.
12
SETTINGS, SIGHTS AND SOUNDS
Climate Controls
Press the CLIMATE button on the
center stack to view the Climate Control
touch screen.
Press the AUTO button on the center
stack to have the system operate
automatically.
The Climate Power gauge on the screen
displays the impact of the climate settings
on energy consumption. A lower percent-
age indicates less energy is being used.
See Climate Settings
on page 9.
Note: Under certain conditions, the engine will
start to ensure full heat and defrost capability.
See Climate Controls in your Owner Manual.
Pedestrian-Friendly Alert
The pedestrian alert feature can help alert people who may not hear your vehicle
approaching when driving at low speeds, such as in a parking lot (not available in Park).
Press the button on the end of the turn signal lever. A soft-note alert will sound. Press
the button again for additional activations.
See Lighting in your Owner Manual
.
Climate
System
FUELING
1. Press the Fuel door release button,
located on the driver’s door, for one second.
The Wait to Refuel message will display on
the instrument cluster.
2. When the Ready to Refuel message
displays, the fuel door on the passenger’s
side of the vehicle will unlock. It will not
open automatically.
3. Press the rear edge of the fuel door; it will
pop open slightly. Open the door to refuel
the vehicle.
Fuel
Use premium fuel with an octane rating of 91
or higher.
See Driving and Operating in your Owner Manual.
Filling the Fuel Tank
13
CHARGING
Battery
The Volt is powered by a lithium-ion high voltage battery pack, which holds its charge
recharging). Keep the vehicle plugged in, even when fully charged, to keep the battery
temperature ready for the next drive.
Start Charging
Charging
Basics
The provided 120-volt portable charge cord is
located in the storage compartment under the
1. Plug the charge cord into an electrical outlet.
CORD. Charge cord indicators should be
green. Where possible, secure the charge
cord to the wall.
2. Press the Charge port door release
button, located on the driver’s door or RKE
transmitter, for one second.
3.
Review Charging screen on the center stack
for selected Charge Mode. Select the Change
Charge Level screen button if an increased
charging level is desired. Use the reduced
your electrical circuit capacity, or if the electri-
cal circuit or socket capacity is not known.
Note: The Charge Level selection returns to the
reduced level each time the vehicle is driven.
4. Plug the charge cord into the vehicle’s charge
port located just in front of the driver’s door.
5. The charging indicator on top of the instru-
ment panel will illuminate green and the horn
will chirp when properly connected.
If the vehicle is locked with the RKE transmitter,
the charge cord theft alert is armed automatically
after 30 seconds.
Note: When the theft alert is armed, the alarm
will sound when the plug is disconnected from
the locked vehicle. To change charge cord theft
alert options, press the CONFIG button on the center
stack. Use the TUNE/MENU knob to select Vehicle >
Comfort and Convenience > Charge Cord Theft Alert.
To temporarily override a delayed charge
event, unplug the cord from the charge port
It will begin charging immediately.
Note: DO NOT USE AN EXTENSION
CORD WHEN CHARGING THE VEHICLE.
See Driving and Operating in your Owner Manual.
14
CHARGING
Charging Status
The charging status indicator is located on the instrument panel near the windshield.
Note: Immediately after plugging in, the
charging status indicator may be amber for
up to ve seconds before turning green.
The charging system may run fans and
pumps when the vehicle is turned off.
Solid green with single horn chirp
Vehicle is plugged in; battery is charging
Slow (long pulse) ashing green with
double horn chirp
battery charging is delayed
Fast (short pulse) ashing green
Vehicle is plugged in; battery is fully charged
Solid yellow
not charging
No light
there is an issue with the charger or outlet
Repetitive horn chirps and no light
Electricity was interrupted before charging
was completed
Charging Time
Using a 120-volt standard outlet will take approximately 10 hours to charge your Volt at the
12 amp setting, or 16 hours at the 8 amp default setting. Using a 240-volt charging station
will take approximately 4 hours. Charge times will vary with outside temperature.
Charging Mode
Press the Leaf button and then touch the Charging tab on the center stack touch
screen or press the Charge port door release button to view the current charge
mode status.
Programmable Charging
The Volt can be programmed for three charging modes: Immediate, Delayed Departure
Time, Delayed Rate and Departure Time.
On the Charging screen, touch the Change Charge Mode screen button to select a
charge mode.
End Charging 1. Unlock the vehicle with the RKE transmitter
to disarm the charge cord theft alert.
2. Unplug the charge cord from the vehicle by
squeezing the plug button.
3. Unplug the charge cord from the electrical
outlet.
4 Stow the charge cord.
See Driving and Operating in your Owner Manual.
Model may vary.
15
MYCHEVROLET AND ONSTAR® MOBILE APPS
CHARGING
myChevrolet
The myChevrolet mobile app provides owners with a variety of vehicle informa-
tion and services, such as a searchable Owner Manual, Roadside Assistance and
more. Download the myChevrolet mobile app from your iPhone®or Android™
device’s app store. Once downloaded, follow the steps on your mobile device to
OnStar RemoteLink
The OnStar RemoteLink mobile app takes connectivity a step further, enabling
users to perform Remote Keyless Entry transmitter commands, including locking
and unlocking the doors, as well as checking current battery charge level
and initiating charging of your Volt. An active OnStar account is required.
Visit OnStar.com for more information.
To download and begin using OnStar RemoteLink:
MyVolt.com (see page 16).
®or Android™
device’s app store.
MyVolt.com.
Note: For security purposes, you will need to log in to the OnStar RemoteLink app with your
username and password on each visit.
Charging equipment with a rating of at least
240Volt/20Amp will provide the fastest charging
time to recharge the propulsion battery.
Contact your dealer or a Volt Customer Advisor,
or go to www.homecharging.spx.com/volt, for
more information about an available 240V home
charging station.
Home Charging Station
16
MyVolt.com OWNER SITE
MyVolt.com is a complimentary resource for Volt owners powered by OnStar. Owners
can communicate with their vehicle online to check pertinent vehicle information and per-
form a number of remote commands. Also available are online service reminders, vehicle
maintenance tips, an online owner manual and more.
To create your OnStar username and password:
MyVolt.com.
OnStar RemoteLink mobile app are available.
!22779091!
Certain restrictions, precautions and safety procedures apply to your vehicle. Please read your Owner Manual
for complete instructions. All information contained herein is based on the latest information available at the
Always demand genuine GM Parts
ROADSIDE ASSISTANCE
1-800-CHEV-USA TTY Users: 1-888-889-2438
(1-800-243-8872)
As the owner of a new Chevrolet, you are automatically enrolled in the Chevrolet Roadside
Assistance program, which provides roadside service for 5 years/100,000 miles at no
expense to you. This value-added service is intended to provide you with peace of mind
as you drive across town or travel the open road.
Chevrolet’s Roadside Assistance toll-free number is staffed by a team of trained advisors
who are available 24 hours a day, 365 days a year, to contact a service provider for light
your vehicle to the nearest Volt Authorized Chevrolet dealer.
Roadside Assistance and OnStar®
If you require roadside service and have a current OnStar subscription, press the OnStar
speak to you, assess your problem, contact Roadside Assistance and relay your exact
location so you will get the help you need.
To learn more about OnStar services, press the OnStar button, refer to your Owner
OnStar.com.
Other manuals for 2013 VOLT
4
Table of contents
Other Chevrolet Automobile manuals
Chevrolet
Chevrolet 2011 Cruze User manual
Chevrolet
Chevrolet 1998 C/K Full-Size Pickup User manual
Chevrolet
Chevrolet 2005 SSR Pickup Assembly instructions
Chevrolet
Chevrolet AVEO - S User manual
Chevrolet
Chevrolet 1999 Express Van User manual
Chevrolet
Chevrolet 2011 Traverse User manual
Chevrolet
Chevrolet Traverse 2014 Assembly instructions
Chevrolet
Chevrolet 2012 Malibu User manual
Chevrolet
Chevrolet 2006 Epica User manual
Chevrolet
Chevrolet 2002 tracker User manual
Chevrolet
Chevrolet 2008 Equinox Specification sheet
Chevrolet
Chevrolet 1998 Corvette User manual
Chevrolet
Chevrolet 1996 S10 Pickup User manual
Chevrolet
Chevrolet Colorado 2024 User manual
Chevrolet
Chevrolet 2008 HHR Assembly instructions
Chevrolet
Chevrolet 2009 Corvette User manual
Chevrolet
Chevrolet chevelle 1973 User manual
Chevrolet
Chevrolet 2013 Cruze User manual
Chevrolet
Chevrolet 2009 Avalanche User manual
Chevrolet
Chevrolet 2003 Avalanche User manual
