Chevrolet Spin User manual

Introduction .................................... 2
In brief ............................................ 6
Keys, doors and windows ............ 19
Seats, restraints ........................... 32
Storage ........................................ 52
Instruments and controls ............. 57
Lighting ........................................ 78
Infotainment system ..................... 83
Climate control ........................... 129
Driving and operating ................. 139
Vehicle care ............................... 164
Service and maintenance .......... 225
Index .......................................... 231
CCoonntteennttss
Technical data ............................ 212

2 Introduction
Introduction

Introduction 3
Vehicle specific data
Please enter your vehicle’s data on
the previous page to keep it easily
accessible. This information is
available in the sections "Service and
Maintenance" and "Technical data"
as well as on the identification plate.
Introduction
Your vehicle is a designed
combination of advanced technology,
safety, environmental friendliness
and economy.
This Owner's Manual provides you
with all the necessary information to
enable you to drive your vehicle
safely and efficiently.
Whenever the control indicator a
appears in combination with another
control indicator in the instrument
cluster and labels, you should consult
the Owner's Manual.
Make sure your passengers are
aware of the possible risk of accident
and injury which may result from
improper use of the vehicle.
You must always comply with the
specific laws and regulations of the
country that you are in. These laws
may differ from the information in this
Owner’s Manual.
All Chevrolet Dealers provide first
class service, using trained
mechanics to work according to
specific instructions.
The customer literature package
should always be kept readily
available in the vehicle. It can be
found inside the glovebox.
Using this manual
■ This manual describes all options
and features available for this
model. Certain descriptions,
including those for display and
menu functions, may not apply to
your vehicle due to model variant,
country specifications, special
equipment or accessories.
■ The "In brief" section will give you
an initial overview.
■ The table of contents at the
beginning of this manual and within
each chapter shows where the
information is located.
■ The index will enable you to search
for specific information.
■ The Owner's Manual uses the
factory designations, which can be
found in the chapter "Technical
data".
■ Directional data, e.g. left or right, or
front or back, always relate to the
direction of travel.

4 Introduction
■ The vehicle display screens may
not support your specific language.
■ Display messages and interior
labelling are written in bold letters.
Danger, Warnings and
Cautions
9Danger
Text marked 9 Danger provides
information on risk of fatal injury.
Disregarding this information may
endanger life.
9Warning
Text marked 9 Warning provides
information on risk of accident or
injury. Disregarding this
information may lead to injury.
Caution
Text marked Caution provides
information on possible damage to
the vehicle. Disregarding this
information may lead to vehicle
damage.
This symbol indicates a prohibited
procedure which can cause personal
injury or damages to vehicle.
Symbols
Page references are indicated with 3.
3 means "see page".
We wish you many hours of
pleasurable driving.
Chevrolet

Introduction 5

6 In brief
In brief
Initial drive information
Vehicle unlocking
Radio remote control
Press the button c to unlock driver's
door and liftgate. Press the button c
again to unlock other doors. Open the
doors by pulling the handles.
Radio remote control 3 19
Central locking system 3 21
Load compartment 3 24
Seat adjustment
9Danger
In order to permit safe airbag
deployment, do not sit nearer than
25 cm to the steering wheel.
9Warning
Never adjust seats while driving as
they could move uncontrollably.

In brief 7
Seat positioning
Pull the handle, slide the seat, release
the handle.
Make sure that the seat is locked in
place.
Seat adjustment 3 34.
Seat position 3 33.
Seat backrests
Pull the lever, adjust the inclination
and release the lever. Allow the seat
to engage audibly.
Seat adjustment 3 34.
Seat position 3 33.
Seat height
Turn the knob
Clockwise = Higher
Counterclockwise = Lower
Note
Seat height adjustment is only
possible with the driver's seat.
Seats 3 34.
Seat position 3 33.

8 In brief
Head restraint adjustment
Height adjustment
Pull the head restraint upward.
To move down, press the locking
button and push the head restraint
downward.
Removing
Raise the head restraint to full height.
Press the locking button at the same
time.
Pull up the head restraint.
Seat belt
Pull out the seat belt and engage in
the belt buckle. The seat belt must not
be twisted and must fit close against
the body. The backrest must not be
tilted back too far (maximum
approximately 25 °). Tension the lap
belt regularly while driving by tugging
the shoulder belt.
To release the belt, press the red
button on the belt buckle.
Seat belts 3 41.
Seat position 3 33.
Mirror adjustment
Interior mirror
The adjustment is performed by tilting
the mirror to a suitable position.
Some vehicles are equipped with
anti-dazzle feature. Adjust the lever
below the mirror to reduce dazzle.
Interior mirror 3 29.

In brief 9
Exterior mirrors
Manual adjustment
Manually adjust the exterior mirror
using the handle.
Manual adjustment 3 27.
Electric adjustment
Select the left or the right exterior
mirror with the selector switch and
adjust with the four-way switch.
Electric adjustment 3 28.
Steering wheel adjustment
Unlock the lever to adjust the steering
wheel, then engage the lever and
ensure it is fully locked. Do not adjust
the steering wheel unless the vehicle
is stationary and the steering wheel
lock has been released.
Ignition positions 3 151.

1100IInn bbrriieeff
IInnssttrruummeenntt ppaanneell oovveerrvviieeww
23
20 21
22

IInn bbrriieeff1111
11Exterior light switch ............... 78
22Side air vents ...................... 136
33Turn and lane-change
signals ................................... 79
High beam ............................. 78
Headlight flash ...................... 79
Driver information center
switch .................................... 70
44Instrument cluster ................. 62
Driver Information Center ...... 70
55Windscreen wiper,
windscreen washer system ... 58
66Central air vents .................. 136
77Instrument panel storage
compartment ......................... 52
88Infotainment system .............. 83
99Instrument panel storage ...... 52
1100Glovebox ............................... 53
1111Front passenger airbag ......... 45
1122Rear air conditioning
system ................................. 135
1133Hazard warning flashers ....... 79
1144Central locking button ........... 21
1155Ignition switch with
steering wheel lock ............ 151
1166Horn ...................................... 57
Driver airbag ......................... 45
1177Steering wheel adjustment . . 57
1188Panel fuse box .................... 192
1199Bonnet release lever ........... 167
2200Brake pedal ......................... 141
2211Accelerator pedal ................ 141
2222Climate control system ........ 129
2233Automatic Transmission ..... 155
EExxtteerriioorr lliigghhttiinngg
Turn light switch:
= Off
= Sidelights
= Headlights
Press light switch
= Front fog lights
= Rear fog lights
Lighting 78.

12 In brief
Headlight flash, high beam and
low beam
For a headlight flash, pull the turn
signal lever.
To change the headlights from low
beam to high beam, push the turn
signal lever.
The light P in the instrument panel
cluster comes on if the high beam
lamps are turned on while the ignition
is on.
To change the headlights from high
beam to low beam, pull or push the
turn signal lever.
High beam 3 78.
Headlight flash 3 79.
Turn and lane-change signals
Right = Lever down
Left = Lever up
Turn and lane-change signals
3 79.

In brief 13
Hazard warning flashers
Operated with the ¨ button.
On = Press ¨
Off = Press ¨ again.
Hazard warning flashers 3 79.
Horn
Press the j point located in the
centre of the steering wheel.
Washer and wiper systems
Windscreen wipers
§= Off
P= Timed interval wiping (interval
is adjustable in 5 different
times by turning the
thumbwheel)
1= Slow
2= Fast
For a single wipe when the
windscreen wipers are off, press the
lever up and release it.
Windscreen wipers 3 58.

14 In brief
Wiper replacement 3 181.
Windscreen washer system
Pull the lever.
Windscreen washer system 3 58.
Washer fluid 3 179.
Rear window wiper/washer
Press the rocker switch to activate the
rear window wiper:
upper
position
= intermittent
operation
lower
position
= continuous
operation
middle
position
= off
Auto wipe in reverse gear
On/Off
Settings can be changed in the
Infotainment menu. 3 83

IInn bbrriieeff1155
Push the lever. Washer fluid is
sprayed onto the rear window and the
wiper wipes several times.
Do not use if the rear window is
frozen.
Switch off in car washes.
CClliimmaattee ccoonnttrrooll
HHeeaatteedd rreeaarr wwiinnddooww
Operated by pressing the button.
Heating works with the engine
running and is switched off
automatically after some time or by
pressing the button again.

1166IInn bbrriieeff
AAuuttoommaattiicc TTrraannssmmiissssiioonn
PP= Parking position, wheels are
locked, engage only when the
vehicle is stationary and the
parking brake is applied
RR= Reverse gear, engage only
when vehicle is stationary
NN= Neutral
DD= Automatic mode with all gears
MM= Manual mode.
Movement between certain gear
positions requires pressing the
release button on the side of the
selector lever.
Press the brake pedal and push the
release button to release the lever
from PP position.
To shift to PP, MM and RR positions, press
the release button.
To start the engine, the selector lever
should be in either PP or NN position.
Do not accelerate while engaging a
gear. Never press the accelerator
pedal and brake pedal at the same
time.
When a gear is engaged, the vehicle
slowly begins to move when the brake
is released.
CCaauuttiioonn
Do not shift to neutral while the
vehicle is moving. This may cause
damage to your transmission and
personal injury.
Automatic transmission. 155.

IInn bbrriieeff1177
SSttaarrttiinngg ooffff
CChheecckk bbeeffoorree ssttaarrttiinngg ooffff
■ Tyre pressure and condition 197,
224.
■ Engine oil level and fluid levels
171.
■ If all windows, mirrors, exterior
lighting and number plates are free
from dirt, snow and ice and
operational.
■ The position of seats, seat belts
and mirrors
Proper position of seats 28.
Mirrors 33.
Seat belts 42.
■ Check brake function at low speed,
particularly if the brakes are wet.
SSttaarrttiinngg eennggiinnee wwiitthh tthhee iiggnniittiioonn
sswwiittcchh
■ Turn the key to position 11.
■ Move the steering wheel slightly to
release the steering wheel lock.
■ Automatic transmission: press and
hold brake pedal and move
selector lever to P or N.
■ Do not accelerate.
■ Turn the key to position 33.
Before restarting or to switch off the
engine, turn the key back to 11.
PPaarrkkiinngg
■ Always apply the parking brake
without pressing the release button.
Apply as firmly as possible on a
downhill slope or uphill slope.
Operate the foot brake at the same
time to reduce operating force.
■ Switch off the engine and ignition.
Turn the ignition key to 00, remove it
and turn the steering wheel until the
steering wheel lock is felt to
engage.
■ If the vehicle is on a level surface or
uphill slope, engage the first gear
before switching off the ignition. On
an uphill slope, turn the front
wheels away from the kerb.
If the vehicle is on a downhill slope,
engage the reverse gear before
switching off the ignition. Turn the
front wheels towards the kerb.
■ Close the windows.
■ Lock the vehicle.
■ Activate the anti-theft alarm system
25.

1188IInn bbrriieeff
■ Do not park the vehicle on an easily
flammable surface. The high
temperature of the exhaust system
could ignite the surface.
■ The engine cooling fans may run
after the engine has been switched
off 167.
Keys, locks 19.

Keys, doors and windows 19
Keys, doors and
windows
Keys, locks ................................... 19
Doors ........................................... 24
Vehicle security ............................ 25
Exterior mirrors ............................ 27
Interior mirrors ............................. 29
Windows ...................................... 29
Keys, locks
Keys
Replacement keys
The key number must be quoted
when ordering replacement keys as it
is a component of the immobiliser
system.
The replacement key is not foldable.
Key with foldable profile
Press the button to extend. To fold the
key back, first press the button, then
turn the key to the original position.
Radio remote control
Used to operate:
■ Central locking system.
■ Anti-theft alarm system.
■ Liftgate.
The radio remote control has a range
of approximately 20 metres. This
range can be affected by outside
influences.
The hazard warning flashers confirm
the operation.
Handle with care, protect it from
moisture and high temperatures and
avoid unnecessary operation.

20 Keys, doors and windows
The radio remote control will not work
when inserted in the ignition as a
precaution to avoid unwilling
activation of the remote control.
Fault
If the central locking system cannot
be operated with the radio remote
control, it may be due to the following:
■ Range exceeded.
■ Battery voltage too low.
■ Frequent, repeated operation of the
remote control while not in range,
which will require
resynchronisation.
■ Overloading the central locking by
operating at frequent intervals, the
power supply is interrupted for a
short time.
■ Interference from higher-power
radio waves from other sources.
Opening the vehicle 3 21.
Radio remote control battery
replacement
Replace the battery as soon as the
range reduces.
Batteries must be disposed of at an
appropriate recycling collection point.
Battery replacement of the remote
control
1. Open the transmitter cover.
2. Remove the used battery. Avoid
touching the circuit board to other
components.
3. Install the new battery. Be sure
the negative side (-) faces down
towards the base.
4. Close the transmitter cover.
5. Check the operation of the
transmitter with your vehicle.
Caution
Avoid touching the flat surfaces of
the battery with your bare fingers
as it will shorten battery life.
Note
Use CR2032 (or equivalent)
replacement battery.
Note
Used lithium batteries can harm the
environment.
Follow local recycling laws for
disposal.
Do not discard with household
refuse.
