Chevrolet 2015 TRAX User manual

Table of Contents
Introduction.........................................1
In brief.................................................3
Keys, doors and windows.................17
Seats, restraints................................35
Storage..............................................59
Instruments and controls..................71
Lighting............................................107
Infotainment system........................115
Climate controls..............................185
Driving and operating......................197
Vehicle care....................................229
Service and maintenance...............297
Technical data.................................309
Customer information .....................317

Memo

Introduction 1
Introduction
Introduction
Your vehicle is a designed
combination of advanced
technology, safety, environmental
friendliness and economy.
This Owner’s Manual provides you
with all the necessary information to
enable you to drive your vehicle
safely and efficiently.
Make sure your passengers are
aware of the possible risk of accident
and injury which may result from
improper use of the vehicle.
You must always comply with the
specific laws and regulations of the
country that you are in. These laws
may differ from the information in this
Owner’s Manual.
When this Owner’s Manual refers to
a repairer visit, we recommend your
Chevrolet Service Partner.
All Chevrolet Service Partners
provide first-class service at
reasonable prices. Experienced
mechanics trained by Chevrolet work
according to specific Chevrolet
instructions.
The customer literature pack should
always be kept ready to hand in the
vehicle.
Using this Manual
This manual describes all options
and features available for this
model. Certain descriptions,
including those for display and
menu functions, may not apply to
your vehicle due to model variant,
country specifications, special
equipment or accessories.
The "In brief" section will give you
an initial overview.
The table of contents at the
beginning of this manual and
within each chapter shows where
the information is located.
The index will enable you to
search for specific information.
The Owner’s Manual uses the
factory engine designations. The
correspondingsalesdesignations
can be found in the chapter
"Technical data".
Directional data, e.g. left or right,
or front or back, always relate to
the direction of travel.
The vehicle display screens may
not support your specific
language.

2 Introduction
Danger, Warnings and
Cautions We wish you many hours of
pleasurable driving
Chevrolet
{Danger
Text marked ?Danger provides
information on risk of fatal injury.
Disregarding this information may
endanger life.
{Warning
Text marked ?Warning provides
information on risk of accident or
injury. Disregarding this
information may lead to injury.
Caution
Text marked Caution provides
information on possible damage to
the vehicle. Disregarding this
information may lead to vehicle
damage.

In brief 3
In brief Initial drive information
Unlocking the Vehicle
Radio remote control
TDL050A
Press button K.
Unlocks all doors. Hazard lamps will
flash twice.
See Radio remote control on page
18.
See Central locking system on page
20.
Seat adjustment
Seat positioning
GO3E3014A
To move seat forward or backward,
pull the handle and slide seat to
desired position.
Release the handle and make sure
the seat is locked in place.
See Seat adjustment on page 38.
See Seat position on page 37.

4Inbrief
Seat backrests
GO3E3015A
Pull lever, adjust inclination and
release lever. Allow the seat to
engage audibly.
Do not lean on seat when adjusting.
Seat height
GO3E3016A
Pumping the lever on the outside of
the seat cushion until the seat
cushion is adjusted to the desired
position.
To lower the seat cushion, push the
lever down several times.
To raise the seat cushion, pull the
lever up several times.
Head restraint adjustment
Height adjustment
GO3E1003A
Pull the head restraint upwards.
To move down press the catch (1)
and push the head restraint
downwards.
See Head restraints on page 35.

In brief 5
Horizontal adjustment
GO3E3002A
Pull the head restraint forwards. It is
adjusted to the three positions. To
move back pull the head restraint
forwards. Then it is moved
automatically backwards.
Safety Belt
MD033
Withdraw belt from reel, guide it
untwisted across the body and
engage the latch plate in the buckle.
Tension the lap belt regularly whilst
driving by tugging the shoulder belt.
See Safety belts on page 41.
Mirror Adjustment
Interior mirrors
GO3E2007A
To reduce dazzle, pull the lever on
the underside of the mirror housing.
See Manual rearview mirror on page
28.

6Inbrief
Exterior mirrors
GC3N2006A
Select the relevant exterior mirror by
turning the control knob to left (L) or
right (R). Then swivel the control to
adjust the mirror.
When the position is in "o", mirror is
not selected.
See Remote control mirrors on page
27.
Steering Wheel Adjustment
GC3N5001A
Unlock lever, adjust steering wheel,
then engage lever and ensure it is
fully locked. Do not adjust steering
wheel unless vehicle is stationary.

In brief 7
Instrument Panel Overview
LHD
GC3G1001A

8Inbrief
RHD
GC3G1001R

In brief 9
1. Side air vents
2. Exterior lamp switch
3. Turn signals
4. Cruise control
5. Cluster
6. Horn, Driver’s airbag
7. Steering wheel controls
8. Wiper and washer lever
9. Central air vents
10.Infotainment system
11.Storage
12.Passenger airbag ON-OFF
switch
13.Glove box
14.Passenger airbag ON-OFF light
15.Hazard warning flasher
16.Power outlet
17.Shift lever
18.Safety lock switch/HDC switch
19.Climate control system
20.ESC switch
21.Accelerator pedal
22.Brake pedal
23.Ignition switch
24.Steering wheel adjustment
25.Hood release lever
26.Clutch pedal
Exterior Lighting
GO3E6004A
Turn light switch knob.
O(OFF): To turn off all lamps, turn
the knob to OFF position. All lamps
are off and return knob to its original
AUTO position.
AUTO: Exterior lamps and
instrument panel lamps are
automatically turned on or off
depending on external lighting
conditions.

10 In brief
;: The tail lamps, number plate
lamps, and instrument panel lamps
are illuminated.
2: The headlamps and all of the
above lamps are illuminated.
Press light switch
#:Front fog lamp
s:Rear fog lamp
See Exterior lamp controls on page
107.
Headlamp high/low-beam
changer
JD13A
To switch from low to high beam,
push lever.
To switch to low beam, push lever
again or pull.
See Headlamp high/low-beam
changer on page 108.
See Flash-to-pass on page 108.
Hazard warning flashers
GC3N6001A
Operated with the |button.
See Hazard warning flashers on
page 109.

In brief 11
Turn and lane-change signals
JD14A
lever up = right indicator
lever down = left indicator
See Turn and lane-change signals
on page 110.
Horn
GC3N5003A
Press Y
Washer and Wiper Systems
Windshield wiper
TDL033A
2: Continuous wipe, fast speed.
1: Continuous wipe, slow speed.
3:Intermittent operation.
O: System off.
3:Misting function.
For a single swipe when the
windshield wipers are off, lightly
move the lever down and release it.

12 In brief
See Windshield wiper/washer on
page 72.
Windshield washer
TDL030A
Pull lever.
See "Windshield washer" under
Windshield wiper/washer on page
72.
See Washer fluid on page 246.
Rear window wiper/washer
Wiper
TEL021A
Press the upward of switch to
operate wiper continue.
Press the downward of switch to
operate wiper interval.
To turn off the wiper set the switch in
neutral.
See Rear window wiper/washer on
page 74.
Washer
TDL031A
Push the lever toward the instrument
panel.
Washer fluid is sprayed onto the rear
window and the wiper swipes for a
few strokes.
See Rear window wiper/washer on
page 74.
See Washer fluid on page 246.

In brief 13
Climate control
Heated rear window, heated
exterior mirrors
GC3N2011A
Operated by pressing the =button.
See Heated mirrors on page 27.
See Heated rear window on page 31.
Demisting and defrosting the
windows
GC3E8003A
Turn the air distribution knob to
DEFROST 5.
See "Defrosting windshield" under
Heating and ventilation system on
page 185.
See"Demisting windshield" underAir
conditioning system on page 189.
Transmission
Manual transmission
GC3N9007A
To engage reverse, with the vehicle
stationary pull up the button on the
selector lever and engage the gear.
If the gear does not engage, set the
lever in neutral, release the clutch
pedal and depress again; then
repeat gear selection.
See Manual transmission on page
211.

14 In brief
Automatic transmission
GC3N9003A
P (PARK): Locks the front wheels.
Select P only when the vehicle is
stationary and the parking brake is
applied.
R (REVERSE): Select R only when
the vehicle is stationary.
N (NEUTRAL): Neutral gear.
D: For all normal driving conditions.
Allows the transmission to shift into
all 6 forward gears.
M: Manual mode position.
TDL148A
MD174
Push the release button to shift.
Arrows indicate shifts that do not
require you to push the release
button.
MD172
Depress the brake pedal and push
release button to shift.
Shifts that require you to push the
release button are indicated by
arrows.

In brief 15
MD173
Shift freely.
Getting Started
Check before starting off
Tyre pressure and condition.
Engine oil level and fluid levels.
All windows, mirrors, exterior
lighting and number plates are
free from dirt, snow and ice and
are operational.
Proper position of seats, safety
belts and mirrors.
Check brake function at low
speed, particularly if the brakes
are wet.
Starting engine with the
ignition switch
MD098
Turn the key to position 1, move
the steering wheel slightly to
release the steering wheel lock
Manual transmission: operate
clutch
Automatic transmission : Move
selector lever to P or N.
Do not accelerate

16 In brief
Diesel engine: turn the key to
position 2 for preheating until K
goes out.
Turn the key to position 3,
depressing the clutch pedal and
footbrake then release when
engine is running
Before restarting or to switch off the
engine, turn key back to 0.
Parking
Do not park the vehicle on an
easily flammable surface. The
high temperature of the exhaust
system could ignite the surface.
Always apply parking brake
without pressing release button.
Apply as firmly as possible on
downhill or uphill slopes. Depress
the footbrake at the same time to
reduce operating force.
Switch off the engine and ignition.
Turn the steering wheel until the
steering wheel lock engages.
If the vehicle is on a level surface
or uphill slope, engage first gear
or "P" position before switching
off the ignition. On an uphill
slope, turn the front wheels away
from the kerb.
If the vehicle is on a downhill
slope, engage reverse gear
before switching off the ignition.
Turn the front wheels towards the
kerb.
Close windows.
Lock the vehicle.

Keys, doors and windows 17
Keys, doors and
windows
Keys and locks ..............................17
Doors.............................................23
Vehicle security .............................25
Exterior mirrors..............................26
Interior mirrors...............................28
Windows........................................29
Roof...............................................32
Keys and locks
Keys
Replacement keys
The key number is specified on a
detachable tag.
The key number must be quoted
when ordering replacement keys as
it is a component of the immobiliser
system.
See "Lock" under Exterior care on
page 289.
Key with foldaway key section
TDL046A
Press button to extend.
To fold the key, press the button and
fold the key manually.

18 Keys, doors and windows
Radio remote control
TDL048A
Used to operate:
Central locking system
Anti-theft alarm system
The radio remote control has an
approximate range of up to 20
metres. This range can be affected
by outside influences.
The hazard warning flashers confirm
operation.
Handle with care, protect from
moisture and high temperatures and
avoid unnecessary operation.
Fault
If the central locking system cannot
be operated with the radio remote
control, it may be due to the
following:
Range exceeded,
Battery voltage too low,
Frequent, repeated operation of
the remote control while not in
range, which will require
resynchronisation,
Overload of the central locking
system by operating at frequent
intervals, the power supply is
interrupted for a short time,
Interference from higher-power
radio waves from other sources.
