CHIBATTERYSYSTEMS GLADIATOR Series User manual

THE GLADIATOR
SERIES
MAX
72
FOR THE SUR RON AND SEGWAY
INSTRUCTIONAL GUIDE

SPECS
For technical and support
questions please reach out to
[email protected]
51AhAH
3672WH
CONT. AMPS 420
PEAK AMPS 540
CONT. POWER 30KW
CHARGED VOLT 84V
VOLT CUT OFF 58V
CELL MOLICEL 21700
@chibatterysystems
FOLLOW US

X2
LATCH SCREW
WHAT’S IN YOUR
HARDWARE KIT
X1
X1
SHIM
X2
HINGE SCREW
X2
HINGE NUT
X2
HINGE COWLING
X1
RUBBER BLOCK
X1
TOUCH UP PEN
X1
BASE PLATE
X4
WASHER
CLICK HERE
FOR
INSTALL
VIDEO.

To connect to the app for the first time, you will want
to make sure your Gladiator is plugged in and
charging. Once this is achieved, you should be able
to find your device in the app. To select the correct
view, you will want to choose "single cell" when first
entering the app.
The only things you will need to use within the app
are the voltage, temperature, and cell levels. Other
aspects of the app will give incorrect readings, so
don’t be alarmed if your app looks like it's giving
strange readings, such as the amount of cycles.
SMART
BMS
Click iOS or Android
to Download
iOS
Download
READING YOUR SMART BMS CELL LEVELS
You will find your individual cell levels under the
name Battery Strings. Every once in a while you
will want to make sure everything is balanced
and within tolerance. Cell levels should stay even,
but as your battery is used there will be some
variation. If you have any questions about cell
level differences please reach out to our support
team!
Android
Download

BATTERY
HEALTH
Low voltage cutoff: If you are using an
aftermarket controller, make sure to properly
set the low voltage cutoff to protect your
battery from draining to the point of no return.
60V Gladiators: The lowest we recommend is 46.4V, which
is 2.9V per cell group.
66V Gladiators: The lowest we recommend is 52.2V, which
is 2.9V per cell group.
72V Gladiators: The lowest we recommend is 58V, which is
2.9V per cell group.
Storing your battery: Batteries should be prepared for storage
based on voltage, not percentage. They should be stored near
nominal voltage and periodically checked and charged to
ensure they remain within the following ranges:
60V Gladiators: between 54.4V-57.6V
66V Gladiators: between 61.2V-64.8V
72V Gladiators: between 68V-72V
Keep your battery in a dry, temperature controlled environment
during periods of storage. Storing your battery near 0% or 100%
can result in permanent degradation and damage.
Balance charging: Balance charging can be a preventative
measure - it keeps the voltage difference between cell
groups to a minimum and helps counter major imbalances
before they can occur. We recommend performing a 48 hour
balance charge every few months.
