CHICAGO IG Charcoal BBQ User manual

IG Charcoal BBQ Instruction Manual

Important: Read these instructions carefully before starting
installation or use.
Important: Remove all packing materials and discard
prior to use.
This grill is designed for outdoor use only.
This product should be installed in non-combustible
enclosures only.
Table of Contents
Box Contents 1
Instructions 2-5
Cleaning and Care 6-8
Safety 9-10
Cooking/Grilling Tips 11
Warnings 12
Questions of Concerns 13

1
BOX CONTENTS
1) 1 Grill Body
2) 4 Slide-In Legs
3) 1 Ash Collector Tray
4) 1 Bottom Storage Rack
5) 2 Collapsible Side Trays
6) 2 Removable Grill Grates
7) 2 Pop-In Screw Wheels (Castors)
8) 1 Turning Mechanism/Charcoal Tray Handle
 9) 9TurnbyHandButteryScrews

2
STEP 1
Open carton and remove the protective padding. Take out the grill
grates, legs, side trays, wheels, and storage rack.
STEP 2
Put the grill body upside down. Unwrap the legs. Insert them into
the grill body. No tools necessary.

3
STEP 3
Install the two wheels on the (Casters) legs with screw-hole
placements. Screw in the wheels as shown in picture.
No tools necessary
STEP 4
Stand up the grill body. Install the raising mechanism handle by
tighteningthebutteryscrewasshowninpicture.
No tools necessary.

4
STEP 5
Insert the bottom shelf horizontally and put it into position.
No tools necessary.
STEP 6
Line up the side trays with the bottom holes attached to the side of
thegrill.Attachthebutteryscrewstothesidetraysandthegrill.
Place1(one)butteryscrewonbothsidestheexteriorofthebracket
facing outward. Repeat steps for installing the other side tray.
No tools necessary.

5
STEP 7
Place grill grates in position on top of cooking surface body.
No tools necessary.
You have now completed installation.

6
CLEANING THE GRILL
Cleaning your cooking grates can be done very easily before you
begin grilling.
Before cooking, preheat the grill and keep the grill at a high
temperature for 10-15 minutes.
Then use a stainless steel bristle brush to remove any excess debris
left on the grates.
This is important because any residue left on the grate could cause
food to stick during future grilling.
Clean out your ash collector tray.

7
CARE AND CLEANING
Appliance must be completely cool when cleaning.
Do not spray any cleaner or liquids on the appliance when hot.
Empty the charcoal pan of all ash and drippings after each use.
Clean the grill with a water and mild soap solution.
Protecting your appliance from the weather.
A cover will protect your appliance when not in use.

8
CLEANING TIPS
Stainless steel surfaces will change color when exposed to
temperatures produced by grilling. The stainless steel will change
color from silver to brown and blue.
This can be removed by using Fire Magic Stainless Steel Cleaner.
CleanyourappliancebyrstusingFireMagicBarbecueandGrill
Cleaner to remove grease and dirt. Always wipe with the grain to
maintain a scratch-free shine. Next, use the Fire Magic Stainless
Steel Cleaner to restore the stainless steel color. Finish by wiping
your appliance down using Fire Magic Polish Wipes.
Clean your appliance at least once a month. If your appliance is
installed in a seaside or poolside location, it will be more susceptible
to corrosion and must be maintained/cleaned more frequently.
Do not store chemicals such as chlorine or fertilizer near your
stainless steel appliance. Due to the nature of stainless steel,
surface iron oxide deposits may appear.
Do not be alarmed. These deposits are removable with stainless
steel cleaner through prompt and periodic maintenance. If not
attended to promptly, permanent pitting may occur. By following
these recommendations, you will enjoy the beauty and convenience
of your appliance for many years to come.

9
SAFETY
When using charcoal briquettes or wood chunks, form a pyramid
anddousewithlighteruid.Waituntiluidhassoakedinbefore
lighting.
Caplighteruidimmediatelyandkeepasafedistancefromgrill.
Neveraddlighteruidtocoalsthatarealreadyhotorwarm.
Neverusegasoline,kerosene,orotherhighlyvolatileuidsasa
starter. They can explode.
Donotaddmoreinstantlightbriquettesoncetherehasbeenlit.
Add only regular charcoal briquettes if more are needed.
Once the grill is lit, do not touch briquettes or wood chunks to see
if they are hot. Keep grill uncovered until ready to cook.
Keep vents open while cooking. Charcoal briquettes and wood
chunks need oxygen to burn.
Allow coals to burn out completely and let ashes cool at least 48
hours before disposing remaining debris.
Dispose of cold ashes by wrapping in heavy-duty aluminum foil
and placing in non-combustible container. Be sure no other com-
bustible materials are nearby.
If you must dispose of ashes before completely cooled, place them
in heavy duty foil and soak with water completely before disposing
in non-combustible container

10
SAFETY TIPS FOR USING THE GRILL
Trimexcessfatfrommeattoreduceareupsfromdrippings.
Always wait until the charcoal has completely burned down and
the grill is completely cool before removing and emptying the ash
collector tray.
Do not move grill during cooking or while the grill is hot.
To avoid burns and splatters while cooking and the grill is hot, use
long-handled utensils and oven mitts.
Do not use tongs or other utensils with metal handles or with
plastic handles that might melt from the heat.
Use heat-resistant oven mitts when working near hot coals and
when adjusting the charcoal tray handle, emptying the ash collector
tray or placing condiments and utensils on the side trays.
Once the grill has cooled, clean promptly. Do not leave the grill
unattendedwhilepreheatingorburningofoodresidue.Ifthe
grillhasnotbeenregularlycleanedasinstructed,agreaserecan
occur.Neverusewateronagreasere.

11
COOKING/GRILLING TIPS
The best oils to use when grilling meats are high temperature oils
(i.e.,peanut,canola,saower,andcottonseedoils).
Coat your food, not the grates, with oil.
Keep grates clean. A clean grate is less likely to be sticky and will
last longer.
Before you start grilling, organize the food by cooking technique,
required cooking time, and grilling area required.
Saucescontainingsugarsandfatscancauseare-upsandburnyour
food. Apply these sauces only in the last 10 minutes of cooking.
Marinadesandrubsenhancetheavoroffood.Adryruborliquid
marinade can be used prior to cooking.
Charcoal lighting and cooking results will vary, depending on the
number of briquettes and the brand and type of charcoal used.
Ageneralruleforcookingwithcharcoal:Aftertheamesdie
out, allow a light gray ash to form on the outside of the briquettes
before beginning to cook.
Youcancontroltheamountofheatandairowbyraisingand
lowering the charcoal bed with the turning mechanism/charcoal
tray handle.

12
Warning
Donotstoreorusegasolineorotherammablevaporsandliquids,
including propane cylinders, in the vicinity of this or any other ap-
pliance.
Warning
Improper installation adjustment, alteration, service, or mainte-
nance can cause injury or property damage. Refer to this manual.
Forassistanceoradditionalinformation,consultaqualiedprofes-
sional installer, or service agency.
Warning
All surfaces of the charcoal unit become hot during use. Exercise
caution when using this unit, especially when adding charcoal or
cranking the turning mechanism/charcoal tray handle up or down.
Donotusethisunitunderunprotectedammablesurfaces.Donot
use this appliance inside a building, garage, or any other enclosed
area. It must not be used in or on recreational vehicles or boats.
Warning
When adding charcoal, spread it across the charcoal bed evenly
and do not exceed a height of 1” above the charcoal bed.
Excessive amounts of charcoal may cause overheating and damage
to your grill.

13
California Proposition 65
WARNING: Combustion by-products produced when using this
product may contain chemicals known to the State of California to
cause cancer, birth defects, or other reproductive harm. To reduce the
risk of exposure to these substances, always use the grill in a well-
ventilated area. is product contains chemicals, including lead and
lead compounds, known to the State of California to cause cancer,
birth defects, or other reproductive harm. Wash hands aer handling.
To minimize exposure to these substances, always operate this unit
according to the Operator’s Manual, ensuring you provide adequate
ventilation when cooking with charcoal.
For question and concerns please contact us at
WWW.IGBBQ.COM
