China Deluxe RT6500 User manual

RT6500
USER MANUAL
Deluxe Multi-functional Massage Chair

Thanks for your purchase of this product, Before using, please read
this User Manual carefully and pay special attention to the safety
precaution to ensure proper operation and use.
Please keep this Users Manual properly for further reference.
CONTENTS
Safety precautions 1
Name and function of each component 3
Exterior structure 3
Interior structure 4
Functions on main remote controller 4
Button area on main remote controller 5
VFD area 8
Functions on auxiliary controller 10
Preparation before using 11
Installation position 11
Surrounding environment 11
Earthing 11
Installation method 14
Back cushion checking 14
Move method 15
Turn on power supply 15
Use method 16
Before sitting down 16
Reclining and stretching system 16
MP3 function 17
After use 17
Product storage and maintenance 18
Trouble shooting 19
Technical specifications 20

1
SAFETY PRECAUTIONS
Safety Precautions
Before using, please read this SAFETY PRECAUTIONS carefully to
ensure proper operation.
The following SAFETY PRECAUTIONS is of great help to your correctly
use of this massage chair.
To clearly indicate the degrees of danger and damage, the classes of
accidents caused by incorrect use are classified into WARNING and
CAUTION , instructions marked as followings should be strictly
followed:
WARNING
Improper operation may cause injury to users.
CAUTION
Improper operation may cause users injury or
product damage.
Forbidden. Specific instruction will be indicated in the diagram
drawings.(e.g, the left drawings means disassembly is not allowed.)
Compulsory Specific instruction will be indicated in the diagram
drawings.(e.g, the left drawings means to disconnect the power plug)
WARNING
COMPULSARY
We recommend that those with any of the following
conditions should consult a doctor before using.
1. Those whoare using electronic
medical instrument imbedded in
the body, such as cardiac
pacemaker etc.
2. Those thatare being treated by
doctors, especially those who feel
uncomfortable.
3. Those whoare malignant tumor
patients, heart disease patients,
acute patients.
4. Women who are pregnant
or menstruating.
5. Those withosteoporosis or
fracture spine.
6. Those withskin disease or
those whose skinsare
injured.
7. Those whosebody
temperature is over 38
degrees (Febrile Phase).
Do not allow the mentally disabled to use the chair alone. (It is
OK under supervision)
Do not allow children play on massage chair.
Do not allow more than one person to use this massage chair at a time.
If the power cord or power plug becomes damaged in any way
you must disconnect from the mains supply immediately and
consult an authorized service engineer for repair orreplacement.
Do not damage, process, excessively bend, pull hard, twist or knot power cord.
Juveniles are not allowed to use this product.
PROHIBITED
Anyone else, except maintenance personnel specified by our company,
should not disassemble, maintain, or remodel this massage chair. If any
problem, please contact local dealer immediately.
NO DISASSEMBLY
TECHNICAL SPECIFICATIONS
Product name: Deluxe Multi-functional Massage Chair
Product Model: RT6500
Rated voltage: 220-240V~
Rated frequency: 50/60Hz
Rated power: 230W
Safety design: Class

2
SAFETY PRECAUTIONS
CAUTION
Please do not continuously use themassage chair over20 minutes,
and it is limited to massage a particular part of body in 5 minutes.
Please put the massage chair on flat groundfor use.
When adjusting the legrest or backrest, please do not exert
excessive force on it; in addition, keep children and pets well clear.
When removing power plug, please hold the insulation plug, do
not pull power cord.
Please do not use the power supply that is beyond the specified electric
voltage, as this may cause fire disaster or damage massage chair.
Before using, please uncover the back cushion to check whether backrest
or fabric is damaged; if damaged, please stop using this massage chair
immediately, and contact franchiser for repair immediately.
Please do not operate the controller with damp hands, and donot
put heavy objects on controller.
Only people less than 120kgsare acceptable.
Please do not use other therapeutic equipments together with
this massage chair.
During use, if you feel uncomfortable, please stop use immediately
and consult your doctor.
This massage chair is designed and intended for non commercial
household use only, do not use the massage chair for medical treatment.
The massage chair is equipped with heating function,so people who
are insensitive to heat must use itcarefully.
Always switch offpower and removethe plug from themains socket
immediately after use and before cleaning.
COMPULSARY
PROHIBITED
To avoid causing discomfort, do not use the massage chair immediately after meals.
Do not fall into sleep on massage chair, when the massage chair is working.
Do not use the massage chair when you are drunk or feel bad.
If the upholstery becomes dirty, please use onlyknown good quality
leather cleaner, do not usechemical cleaners, petrol or detergents
etc, and do not spray pesticide on it.
Do not sit on backrest, legrest, or armrest to avoid accidental injury or machine fault.
Please do not smoke while using themassage chair.
REMOVE PLUG
Before maintenance,please pull out power plug. In addition, please
do not insert or unplug the power plug with damp hands, to avoid
electric shock.
When the massage chair is not in use, please switch off power and
remove the plugfrom socket. When power is off, please cut off
power supply immediately and pull out the power plug from socket.
TROUBLE SHOOTING
No. Problem Possible Cause Solution
The sound Xu
Xu,TaTa
is heard.
The machine
can not be
started up.
Some music
can not be
played normally
Alarm sound is
heard when
pressing the
music control
button.
No sound from
the speaker or
earphone
Backrest or
legrest can not
ascend or
descend.
It is a normal sound made
by the working motor or
the sound is produced
when the massage ball is
rubbed against the cloth.
2.1 The power supply
plug is detached.
2.2 The power supply
switch is not turned on.
2.3 The fuse of massage
chair blew out.
Music format is not
correct.
4.1 The U-disk is not
connected well.
4.2 The U-disk is
initializing
4.3 The format of music
files in U-disk is
unmatched.
5.1 The speaker or
earphone is not
connected well.
5.2 The volume is turned
down to lowest.
Over pressure is put on
backrest or legrest.
It is normal and no
need for treatment.
2.1 Insert the power
supply plug into the
socket again.
2.2 Turn on the switch
2.3 Replace a new one
with the same mode
Replace the MP3
music file
4.1 Insert the U-disk
again.
4.2 Wait 5-10 seconds
4.3 Tocheck MP3 music
files with the help of
computer.
5.1 Insert the speaker
or earphone again
5.2 Turn the volume up
Reduce the pressure on
backrest or legrest.
If abnormal phenomenon still remains after above measures have been
taken to the massage chair, please contact local distributor for repair and
maintenance.

PRODUCT STORAGE AND MAINTENANCE
18
NAME AND FUNCTION OF EACH PART
Exterior structure
Main
controller
Auxiliary
controller
Controller
holder
Seat cushion
Legrest
Pillow cushion
Backrest cushion
Airbag massage
unit for arms
Armrest
Caster
Earphone jack
Auxiliary controller Jack
Main controller Jack
U disk USB jack
Power supply socket
Fuse
Power supply switch
Power box
Do not store the product under direct sunlight or in places with high
temperature. This may cause the color of the upholstery to fade.
3. Controller
Using wet cloth to clean the controller may cause failure of it, so it is
advisable to use dry cloth to clean controller.
4. Leather and lining
Please use soft and dry cloth to clean the machine.
Every two or three month, polish the lining with clean cloth that has
been dipped with cleaning agents, and then clean it with dry and soft
cloth after it dried.
1. Cleaning
Before cleaning, make sure that the plug has been pulled out from
the socket.
Use a piece of cloth that has been dipped with cleaning agents to
wipe the main unit of massage chair, and then use a piece of dry and
soft cloth to wipe it.
Caution
Do not use corrosive cleaning agents like benzene or thinner to
clean the massage chair, otherwise, the color of upholstery will
fade or the massage chair will crack or be eroded.
Do not iron the upholstery.
Make sure that the plug has been pulled outfrom the socket.
Sweep off the dust. Keep the massage chair clean and away from
damp places.
If the massage chair is not to be used for a long period of time, please
cover the massage chair with a dustproof cover (self provided).
2. Maintenance
Caution

NAME AND FUNCTION OF EACH PART
Interior structure
Airbag massage
unit for thighs
Airbag massage
unit for calves
Airbag massage
unit for soles
Back massage
mechanism
Instruction on each part of main controller
Manual function area
Memory function area
VFD display area
Semi-auto function area
Full auto function area
USE METHOD
A MP3 music player is installed in the massage chair; either speaker
or headphone is available to enjoy music.
1. Plug the U disk into the USB jack.
2. 5 to 10 seconds later, music can be played with auxiliary controller.
MP3 Function
Turn off power supply and pull power plug out off the power supply
socket after use.
Put the controller back to its bracket.
After use, please turn off power supply switch and pull the plug out
off the power supply socket to avoid any accidental injury to children.
If the massage chair is not to be used for a long time, please store it
appropriately.
After use
Buttock vibration
unit

NAME AND FUNCTION OF EACH PART
Function description on each button of main controller
Power supply and full auto function area
Turn on/off massage chair
When power is on, the VFD display screen is lightened, and
then user can choose the functions which the flashing
function buttons and memory function buttons correspond.
When power is off, the massage chair resets, at this moment, all the
function buttons can not work. When the button is flashing, it
signals the power supply is shut off and the massage chair has gone
to standby mode. After reset, the VFD display screen will also be shut
off.
Full auto function:There are four auto massage modes from RECOVERY,
EXTEND, RELAX to REFRESH for different people at different time.
Semi-auto function area
Upper back auto: Press this button
to turn on UPPER BACK AUTO function.
Lower back auto: Press this button
to turn on LOWER BACK AUTO function.
Press this button to turn on or off
the waist heater.
Press this button to turn on or off
the sole heater.
Airbag auto: Press this button to
turn on or off AIRBAG AUTO function.
Airbag intensity adjusting: Press this button to adjust the air
intensity; there is a 5-step shift mode for your options. When
the air intensity reaches the maximum/minimum point, a
double short reminding sound will be heard.
Press this button to turn on or off seat vibration function.
Vibration intensity adjusting: Press this button to adjust the
vibration intensity; there is a 5-step shift mode for your option.
When the vibration intensity reaches the maximum/minimum
point, a double short reminding sound will be heard.
Reclining backward operation
Backrest ascending
button
Backrest descending
button
Legrest ascending
button
Legrest descending
button
Before sitting down
Before sitting down, make sure all the components are back to their
original positions, if not, please turn on the power supply switch and
reset the components.
Caution
Do not sit on the massage chair when the legrest is raising.
Do not put heavy burden onto the legrest suddenly, otherwise, the
mechanical structure may be damaged.
Reclining and stretching system
Reclining backward/ forward
Keep pressing backrest descending button , the backrest will gradually
go down while the legrest will go up simultaneously with the double
reminding sound Di Di produced by the controller; When the massage chair
reaches to the proper angle, release the backrest descending button , at
this moment, the backrest and legrest will stop simultaneously. During
descending, if the legrest reaches to its highest point firstly, it will stop
ascending, while the backrest will continually descend. The controller will
give out continuous reminding sound when backrest reaches to the highest
point; the controller will give out continuous reminding sound when backrest
reaches to its lowest point while the legrest has not reached to its highest
point, at this moment, if only keep pressing the button, the legrest will
ascend continuously till to its highest point. The angle of legrest can be
adjusted separately by pressing button and button, during legrest
ascending/descending, the backrest keeps still. When legrest reaches to the
highest or lowest point, a continuous reminding sound will be heard.
USE METHOD

PREPARATION BEFORE USING
Do not move the chair while people is sitting on the chair.
When move the massage chair, please hold its base and backrest
instead of its armrests (at least 4 people).
Move method
Caution
The equipment can be easily moved with the caster installed at the
bottom of the product.
Ascend the backrest to the highest position.
Turn off the power supply switch and pull out the plug.
Raise the front part of the chair as shown on the picture below, and
move the chair to a desirable place.
Turn on power supply
Before starting up the machine, please make sure the power
supply cord and exposed electric wire have not been damaged.
Before putting the plug into the power supply socket, please
make sure the power supply switch is turned off.
Put the power supply plug into a well
grounding three-core power supply socket.
Turn on the power supply switch located at
the bottom of backrest.
Caution
NAME AND FUNCTION OF EACH PART
Angle adjustment of massage chair and ascending/descending
adjustment of legrest Back massage unitmoving up button:
It is effective in the modes of shoulder
slight adjustment and manual point.
Back massage unit moving down button:
It is effectivein the modes of shoulder
slight adjustment and manual point.
Backrest ascending button
Backrest descending button
Legrest ascending button
Legrest descendingbutton
Memory function area
Four memory function buttons from A, B, C to D can be set repeatedly.
Memory function setting: The massage unit will reset when the
massage program is normally finished (The remaining time is 0
second), and then the memory function is turned on when reset
procedure is finished. At this moment, the MEMORY SETTING icon
is flashing, and user can select any one of the button from A, B, C to D
to store the current massage program combination into its
corresponding button. Meanwhile, the VFD display screen will show
MEMORY OK which signifies memory setting is finished.
Memory function calling: Press the button, then the A/B/C/D four
memory buttons are flashing, press any one of them, then the
memory storing function of this button will be recalled.
Caution:
Body shape and shoulder position sensing data can not be stored.
Manual Function Area

NAME AND FUNCTION OF EACH PART
After pressing this button, this button is lightened; meanwhile,
the functions of other buttons in manual function area are
activated.
Back massage technique selection
Turn on/off kneading massage.
Turn on/off tapping massage.
Turn on/off wavelet massage.
Turn on/off pummel massage.
Turn on/off shiatsu massage.
Turn on/off rhythm massage. (The tapping function will be
synchronized with the high frequency signal of music rhythm;
while the vibration function of seat cushion will be synchronized
with the low frequency signal of music rhythm.)
Back massage locate mode
Select WHOLE locate mode.
Select PARTIAL locate mode.
Select POINT locate mode.
Back massage speedregulation
There is a 5-step shift mode for speed regulation, which is
ineffective under shiatsu massage mode; when the speed
reaches to its maximum or minimum point, a double short
reminding sound will be heard.
Back massage widthregulation
There is a 3-step shift mode for width regulation, which is
ineffective under kneading massage and wavelet massage
modes; when the width reaches to its maximum or minimum
point, a double short reminding sound will be heard.
Airbag massage position selection
Turn on/off all the airbags installed at armrest.
Turn on/off the airbag installed at seat cushion.
Turn on/off the airbags installed at legrest and footrest.
PREPARATION BEFORE USING
Step 6:
Insert the plugs of main/auxiliary controller, U-disk and power supply
cord to their corresponding sockets; Connect and switch on the power
supply.
Check back cushion
Open the pillow to check whether the back cushion is damaged.
Caution
If find that the back cushion is damaged, please stop using the
massage chair immediately, and contact with the local distributor
promptly for repair or replacement.

NAME AND FUNCTION OF EACH PART
Description on VFD display area
1.Time display area: It displays the remaining time during massage. The
default timeis 20 minutes.
2.Auto mode display area of back massage This icon will be lightened
when the back massage unit works in the following six auto modes:
RECOVERY , EXTEND , RELAX , REFRESH , UPPER BACK AUTO ,
and LOWER BACK AUTO , while this icon will not be lightened under
other modes.
3.Massage program display area: It shows current back massage program.
Whole locate mode: Locating at the whole back.
Partial locate mode: Centering on current massage point; the
massage area is the one third of the whole.
Point locate mode: Staying on current position, and by pressing
UP/DOWN button to change current massage point.
4. Display area of back massage locate mode
5. Display area of massage chair ascending and descending
Legrest ascendingand
descending dynamic indication Backrest ascending and
descending dynamic indication
6. Shoulder position adjustment and back massage unit resetting
6.1 Indicator of back massage unit resetting
6.2 Adjust datum mark: The starting point of back massage unit
when it begins to adjust is the central point, and the
corresponding actual moving distance of every interval is
about 2 cm.
6.3 The position of massage unit with respect to datum mark
during adjustment.
PREPARATION BEFORE USING
Step 4:
Fix the back cushion onto backrest with zipper, fasten the pillow with
Velcro, and insert the plugs of backrest and seat cushion as shown on
the picture below.
Zipper Pillow
Step 5:
Align the mounting holes of controller support with holes of armrest,
and then fix them with screws.

NAME AND FUNCTION OF EACH PART
7. Indicator of soles heating
8. Indicator of back and waist heating
9. Indicator of seat cushion vibration
10. Dynamic indication of air bag massaging position for lower back
11. Indication of massage point, massage unit position and massage
mode for upper back
12. Speed indication of back massage unit:
There is a 5-step shift mode for speed selection.
13. Width indication of back massage unit:
There is a 3-step shift mode for width selection.
14. Air force strength indication: There is a 5-step shift mode for air
force strength selection.
15. Vibration intensity indication: There is a 5-step shift mode for
vibration intensity selection.
16. Memory function
Memory function indication: It will show when the
memory function is started up.
It will show when the memory function is completed.
17. Body shape sensing indication
PREPARATION BEFORE USING
Installation method
Step 1: Take out the components of massage chair
Open the main body carton, and take out the main body and
accessories of the massage chair carefully.
Check whether the components are complete (please check one by
one accordingto the packing list)
Step 2:
Raise up the backrest of massage chair at about 115 then it will be
locked when a sound Ka is heard.
Step 3:
Put the seat cushion onto shelf, connect the airbag tube as shown on
the picture below.
Airbag tube

NAME AND FUNCTION OF EACH PART
NAME AND FUNCTION OF EACH PART
Function description on each button of auxiliary controller
Instruction on Mp3 music player
Play/ pause current music
Stop playing music and back to the first song when replaying
Previous song
Next song
Volume up
Volume down
Note 1: Rhythm massage strength changed as the music cadence.
Note 2: A double short reminding sound will be heard promptly when
pressing the button if there is something wrong in the MP3 system or
the corresponding device has not been well installed. The backrest
and legrest ascending and descending buttons on auxiliary controller
have the same function with the corresponding buttons on main
controller.
PREPARATION BEFORE USING
Installation position
Please place the massage chair in an ample space: The horizontal
interval between the backrest ascending to the highest point and
descending to the lowest point should be 50 cm. The horizontal
interval between the legrest ascending to the highest point and
descending to the lowest point should be 15 cm. To make sure more
than 50 cm horizontal distances are left for the back part of chair, and
more than 15 cm horizontal distances are left for the front part.
Keep the massage chair more than 1 meter away from TV, radio, and
some other audio-visual equipment to avoid signal interference.
The floor may be worn by the massage chair, so it is advised to put
some cushion material (for instance: a carpet) under the massage
chair to protect the floor and reduce noises.
15 cm 50 cm
Surrounding environment
Keep the massage chair away from damp places (for
example: bathroom) to avoid electric leakage.
Keep the massage chair away from high temperature
sources (for example: stove)to avoid fire or damage to
leather material.
Earthing
This massage chair belongs to Level One electrical appliance, so please
use three-core power supply plug and guarantee the ground wire
connected to the power supply socket has obtained good ground
connection to avoid electric leakage, electric shock and some other
negative effect during use.
