chinesport AV3 Series Operating instructions

CHINESPORT SPA
Via Croazia, 2
33100 –Udine –IT
www.chinesport.com
AV3 - User Manual rev.1.2 - EN.docx 1/47
Standing Frames
User and maintenance manual
REV. 1.2 (06/2018)
A
V
3
EN

CHINESPORT Spa –ITALIA
AV3
2/47 AV3 - User Manual rev.1.2 - EN.docx

CHINESPORT Spa –ITALIA
AV3
AV3 - User Manual rev.1.2 - EN.docx 3/47
EN
EN 4
GENERAL INFORMATION 4
1.1 PURPOSE,CONTENT AND RECIPIENTS OF THESE INSTRUCTIONS 4
1.2 MANUFACTURER 4
1.3 INTENDED USE AND EQUIPMENT DESCRIPTION 4
1.4 BIOCOMPATIBILITY 5
1.5 PRODUCT DESCRIPTION 5
1.6 STORAGE AND OPERATING ENVIRONMENT 5
1.7 SYMBOLS 6
SPECIAL WARNINGS AND USE RESTRICTIONS 7
USE INDICATION 8
3.1 INDICATIONS 8
3.2 CONTRAINDICATIONS 8
3.3 PROPER USE 8
3.4 PREDICTABLE IMPROPER USE 8
3.5 UNSAFE USE 9
3.6 EXCLUSION OF RESPONSIBILITY 9
CONFIGURATION ITEM CODE 9
4.1 LATEST IMPROVEMENTS 13
4.2 STANDARD ACCESSORIES 14
4.3 UNPACKING 15
USE OF THE DEVICE 15
5.1 SWITCING ON 15
5.2 SWITCHING OFF 16
5.3 SECURITY LOCKING AND UNLOCKING OF JOYSTICK 18
5.4 INITIAL SETTINGS 19
5.5 NORMAL USE OF THE DEVICE 20
5.6 EMERGENCY LOWERING 28
5.7 ADJUSTMENTS 29
5.8 ACCESSORIES ADJUSTMENTS 34
MAINTENANCE 35
6.1 EXTRAORDINARY MAINTENANCE 36
6.2 SPARE PARTS 36
6.3 NON ROUTINE MAINTENANCE 36
TROUBLESHOOTING 37
TAKING CARE OF PARTS AND CLEANING 38
8.1 CLEANING 39
8.2 DISINFECTION 39
BATTERIES NOTES 40
ELECTROMAGNETIC COMPATIBILITY INFORMATIONS 41
10.1 MANUFACTURER DECLARATION –ELECTROMAGNETIC EMISSIONS 41
10.2 MANUFACTURER DECLARATION –ELECTROMAGNETIC IMMUNITY 41
10.3 RECOMMENDED SEPARATION DISTANCES BETWEEN RF PORTABLE COMMUNICATION DEVICES
AND MOBILES AND AV3 43
WARRANTY 43
DISPOSAL OF ELECTRICAL OR ELECTRONIC EQUIPMENT 44
MAINTENANCE RECORD SHEET 45

CHINESPORT Spa –ITALIA
AV3
4/47 AV3 - User Manual rev.1.2 - EN.docx
EN
GENERAL INFORMATION
Welcome!
Thank you for buying an excellent product for support, sustain, stabilization and
movement. Before use we recommend to read carefully this user manual with
particular reference to the warning to be observes before using the device
(SPECIAL WARNINGS AND USE RESTRICTIONS).
For every additional information, observation or requests for clarification you can
contact the reseller or the company Chinesport S.p.A.
1.1 Purpose, content and recipients of these instructions
This manual is intended to provide the necessary information to permit a proper use
of the equipment and to be able to use it independently and safely. It’ up to the
specialist and to the user to decide to use the equipment in autonomy.
This manual contains information relating to the technical, operation, maintenance,
spare parts and safety. This book is also intended to technicians in charge of
maintenance equipment.
This Instruction booklet must always follows the equipment and must be carefully
preserved in order not to compromise its readability.
In the case of assignment to a third party this manual must be transmitted with the
other documents and communicated to the manufacturer as provided for in the
European Directive 93/42/EEC amended by the Directive 2007/47/EC for the
maintaining of the safety and the traceability of the product.
1.2 Manufacturer
CHINESPORT S.P.A, Via Croazia,2-33100 Udine, Italy
Tel. [phone]–Fax [phone] –website: www.chinesport.com.
The company has a quality system according to the UNI EN ISO 13485:2012.
1.3 Intended use and equipment description
Warning
AV3 Standing Frame is a medical device.
The proper use falls within the medical devices use methodology.
Standing frame allows a person with limited limb and trunk functions to assume and
maintain an upright posture. The equipment is intended for use by people who can
hardly bear their own weight. The choice of which model to use is based on the
user’s remaining motor and coordination skills and is up to a qualified therapist.
Depending on the model, the user can stand up manually, holding on to the large,
side handles and the tray's edges, or by means of a rechargeable battery-powered
electric lift motor, operated by hand control, or servo-assisted by gas spring.
It features large handles to provide support when standing up, as well as a wide
tray to hold objects.

CHINESPORT Spa –ITALIA
AV3
AV3 - User Manual rev.1.2 - EN.docx 5/47
EN
The standing aid is easy to access and can be adapted to the morphological
characteristics of the user through a wide range of adjustments. In particular, the
main body can be adjusted to the user’s height by means of a system servo-assisted
by gas spring or an electric motor.
1.4 Biocompatibility
Every AV3 part and accessory intended for use by the user are developed in order
to be homologated in compliance with the existing biocompatibility directives,
provided that they are used within the prescribed limits.
For every additional information, observation or requests for clarification you can
contact the dealer or the company Chinesport SpA.
For any clarifications, please contact an authorized reseller.
1.5 Product description
The device is composed by 9 elements which are configurable and connected to
the specific functions of support, sustain, stabilization and movement:
1. Base
2. Footplates.
3. Knee supports
4. Height adjustment.
5. Lifting.
6. Back support.
7. Lateral support.
8. Upper part.
9. Service tray.
Different options are provided for all the configurable elements. More than forty
relevant configurations are available in order to fulfil also the most specific needs
of the users. A wide range of accessories can be supplied in order to grow up the
comfort of the user and the and the speciality of the particular function.
1.6 Storage and operating environment
Medical devices covered by this manual are suitable for use for treatment
administered in hospital, rehabilitation centers or in the home user. In any case,
these devices are designed to be used in environments that are not exposed to
atmospheric agents.
Operating temperature
0°C to 40°C / 32°F to 104°F
Storage temperature
-25°C to 70°C / -13°F to 158°F
Humidity
0% to 80% without condensation
Do not charge batteries if they are frozen or have a temperature higher than 45°C
Products insights
Further documentation can be found on our website www.chinesport.com
You can download declaration of conformity and other product documents in their
latest version and in colour format directly from website.
Storage
Besides the environmental conditions, the following conditions must be ensured
when the equipment is to be stored:

CHINESPORT Spa –ITALIA
AV3
6/47 AV3 - User Manual rev.1.2 - EN.docx
1. Switch off the equipment by setting to “O” position the thermomagnetic
switch located on the tray (see “Stop functions” – electric models only).
2. Recharge batteries, if not used at all, at least every six months (see
“Recharging the equipment’s batteries” – electric models only).
3. If the equipment won’t be used for a long time it’s strictly recommended to
disconnect the batteries (please refer to non-routine maintenance)
1.7 Symbols
In this manual and the machine itself, the symbols are used to draw your attention
to important safety notices and useful information.
Observe all warning, attention and danger messages.
Symbol
Significance
Danger
Indicates an immediate danger with a high risk of death or serious
injuries, if it is not avoided.
Warning
Indicates a possible danger with a moderate risk of death or serious
injuries, if it is not avoided.
Attention
Indicates danger with a low risk of light injuries or damages to things,
if it is not avoided.
Class II device
Type B applied parts
Crushing/shearing hazard
xxxx
Compliance to 93/42/EEC and 47/2007/EC directives for medical
devices.
XXXX: Certification body identification number.
Carefully read the instructions in the use and maintenance manual
Warning of dangerous voltage, risk of electric shock
Fragile
Recyclable
Keep dry
Keep upright
Dispose correctly
Manufacturer

CHINESPORT Spa –ITALIA
AV3
AV3 - User Manual rev.1.2 - EN.docx 7/47
EN
Expected product life
10 years
Protection degree
IP21.
The IP Code classifies and rates the degree of protection provided against intrusion
(body parts such as hands and fingers), dust, accidental contact, and water by
mechanical casings and electrical enclosures.
IP
2
Fingers or similar objects >12.5 mm
1
Dripping water (vertically falling drops) shall
have no harmful effect.
SPECIAL WARNINGS AND USE RESTRICTIONS
warning
This equipment must not be used:
-Without the necessary adjustments and user-specific setup (see “Set-up
and adjustment”);
-with people weighing over 140 Kg;
-on unstable and/or uneven surfaces (e.g.: stairway, steps, etc.);
-if the original product has been modified or tampered with;
-in an explosive and/or corrosive atmosphere or exposed weather
conditions
-when the environments temperature is over 40°C
warning
Side effects:
-It can cause involuntary muscular contractions.
-It is not recommended for users with limited trunk and upper extremity
control.
-It is not recommended for users with limited range of motion in the knees
and/or the coxofemoral and/or tibiotarsal joints.
-It is not recommended for users with structural impairments of the lower
extremities.
warning
-The user must be declared physically and psychologically fit to use the
equipment by a specialist.
-Never spill liquid of any kind on the equipment.
-Do not use the lifting system in continuous mode, observe the duty cycle
specified in chapter TECHNICAL SHEET.
-Always unplug the battery charger during use and/or to move the
equipment
-Disconnect batteries before carrying out any service on the equipment
circuits.
-Do not connect to an electric system that does not comply with the
current safety regulations.
-Pull out the plug (not the cable) to disconnect the battery charger, the
hand control and the motor.
-Turn off the equipment when not in use to save battery life

CHINESPORT Spa –ITALIA
AV3
8/47 AV3 - User Manual rev.1.2 - EN.docx
USE INDICATION
3.1 Indications
AV3 standing frame is suitable for people with disabilities or spinal cord injuries,
paraplegia, multiple sclerosis, Parkinson's disease or muscular pathologies, muscular
dystrophies and those who are in difficulty in actions that require lifting, for example
elderly people.
Minimum requirements for supervised training
The user can sit in upright position.
Minimum requirements for autonomous training
The user can fully handle AV3 alone and knows all the functions.
User
1. Person who, after proper instruction by the specialized staff or after a careful
reading of this manual, is able to use and train with AV3
2. The user is totally responsible of the safe and proper use with the AV3
intended use
Specialised personnel
1. People who, for their knowledge, obtained from specialized training in the
field of medicine, etc., possess medical-technical specialization (e.g.
doctors, therapists, specialized resellers).
2. People who, for their professional experience and education / training by
the manufacturer, have knowledge about security and are able to
recognize any dangers during use (e.g. specialist assistants).
For the safe use of AV3, specialized personnel must regularly attend refresher
courses.
3.2 Contraindications
- Contraindicated to users with trunk and upper limb control deficiency
- Contraindicated to users with joint limitation of the knees and / or coxo-femoris
and / or ankle.
- Contraindicated to users with structural deficiencies in the lower limbs.
3.3 Proper use
For this purpose, the user moves to the device from a safe and stable wheelchair or
from a simple chair (without wheels) or sofa with a sufficient stability on the floor.
The user must assume an upright sitting position and the chair or wheelchair must
not be able to tip over when the user move on the AV3 seat.
AV3 must be moved on a flat and solid surface, only INDOOR.
Warning
The use of AV3 is to be considered safe only if the safety measures and
warnings described in this manual are observed and the contraindications
described herein or established by a therapist / physician does not occur.
Adjustments and modifications can be safely done only when the device is
turned off and the patient is not seated on the device.
3.4 Predictable improper use
AV3 is not suitable for:

CHINESPORT Spa –ITALIA
AV3
AV3 - User Manual rev.1.2 - EN.docx 9/47
EN
Diagnosis
Monitoring
Measurement
Sport training
Outdoor moving
3.5 Unsafe use
Do not use AV3 (electrical versions)
In combination with other devices that emits ionizing radiation (e.g.
radiotherapy, nuclear medicine, etc.)
In environments where:
-Explosive materials are present
-Enriched oxygen is present
In combination with
-Flammable anaesthetics
-Volatile solvents
3.6 Exclusion of responsibility
The manufacturer and its distributor do not assume any responsibility as a result of:
-Improper, incorrect or not intended use
-Non-observance of this instruction manual
-Intention or gross negligence
-Too intensive training, eg. agonistic activity
-Outdoor training or movements
-Use of inappropriate wheelchairs, chairs, tables or beds that aren’t stable
-Use of the device, although forbidden by the doctor or therapist
-Installation of unauthorized accessories
-Performing repairs or other interventions on AV3 by people not authorized by
the manufacturer
CONFIGURATION ITEM CODE
AV3 standing frame is extremely configurable. See the picture at the end of the
table to have a graphic resume of the possible configurations.
BASE
Pos. 04
Wide base with wheels, assisted
pushing movement, easy to
access.
A
V
3
1
_
_
_
_
_
_
_
Narrow base with traction wheels,
independently moving around,
easy to drive
A
V
3
2
_
_
_
_
_
_
_
_
Wide base with traction wheels,
independently moving around,
easy to drive and to access
A
V
3
3
_
_
_
_
_
_
_
_
FOOTPLATE
Pos. 05
Without footplates, suitable for
special customizations.
A
V
3
_
0
_
_
_
_
_
_
_
Wooden footplates, adjustable in
depth with tools.
A
V
3
_
1
_
_
_
_
_
_
_
Metal footplates adjustable in
depth without tools.
A
V
3
_
2
_
_
_
_
_
_
_

CHINESPORT Spa –ITALIA
AV3
10/47 AV3 - User Manual rev.1.2 - EN.docx
KNEE
SUPPORT
Pos. 06
Without knee support. Indicated
for special customizations.
A
V
3
_
_
0
_
_
_
_
_
_
Adjustable in depth and width.
A
V
3
_
_
1
_
_
_
_
_
_
Adjustable in depth, soft padding
A
V
3
_
_
2
_
_
_
_
_
_
Not adjustable, soft padding
A
V
3
_
_
3
_
_
_
_
_
HEIGHT
REGULATION
Pos. 07
Adjustable by gas spring
A
V
3
_
_
_
A
_
_
_
_
_
Adjustable with electric actuator
A
V
3
_
_
_
B
_
_
_
_
_
LIFTING
Pos. 08
Independent
A
V
3
_
_
_
_
0
_
_
_
_
Gas spring with handle
A
V
3
_
_
_
_
2
_
_
_
_
Electric actuator with hand switch
A
V
3
_
_
_
_
3
_
_
_
_
BACK
SUPPORT
Pos. 09
No support for lifting
A
V
3
_
_
_
_
_
1
_
_
_
Long seat, not adjustable in
depth.
A
V
3
_
_
_
_
_
2
_
_
_
Short seat, adjustable in depth,
removable
A
V
3
_
_
_
_
_
3
_
_
_
Long seat, removable.
A
V
3
_
_
_
_
_
4
_
_
_
Harness support
A
V
3
_
_
_
_
_
5
_
_
_
LATERAL
SUPPORT
Pos. 10
Fixed, not adjustable
A
V
3
_
_
_
_
_
_
1
_
_
Short handles, adjustable by
rotation.
A
V
3
_
_
_
_
_
_
2
_
_
Long handles, adjustable by
rotation.
A
V
3
_
_
_
_
_
_
3
_
_
Short handles, adjustable by
shifting.
A
V
3
_
_
_
_
_
_
4
_
_
Long handles, adjustable by
shifting.
A
V
3
_
_
_
_
_
_
5
_
_
UPPER PART
Pos. 11
Dynamic structure, with
adjustable handles.
A
V
3
_
_
_
_
_
_
_
2
_
Fixed structure, with fixed handles.
A
V
3
_
_
_
_
_
_
_
3
_
Fixed structure, with adjustable
handles.
A
V
3
_
_
_
_
_
_
_
4
_
SERVICE TRAY
Pos. 12
Without service tray.
A
V
3
_
_
_
_
_
_
_
_
N
Wooden service tray –medium
size.
A
V
3
_
_
_
_
_
_
_
_
A
Polyethylene service tray –
medium size.
A
V
3
_
_
_
_
_
_
_
_
B
Plexiglass service tray - medium
size.
A
V
3
_
_
_
_
_
_
_
_
C
Wooden service tray –large size.
A
V
3
_
_
_
_
_
_
_
_
D

CHINESPORT Spa –ITALIA
AV3
AV3 - User Manual rev.1.2 - EN.docx 11/47
EN
Polyethylene service tray –large
size.
A
V
3
_
_
_
_
_
_
_
_
E
Plexiglass service tray - large size.
A
V
3
_
_
_
_
_
_
_
_
G

CHINESPORT Spa –ITALIA
AV3
12/47 AV3 - User Manual rev.1.2 - EN.docx

CHINESPORT Spa –ITALIA
AV3
AV3 - User Manual rev.1.2 - EN.docx 13/47
EN
4.1 Latest Improvements
Chinesport constantly improves his product trying to implement all the changes
dictated by the market and by user feedback as well as constant post marketing
surveillance in order to keep safety and conformity to the most recent medical
devices regulations, testing and deploying the most recent available technology.
Latest product upgrades involves various aspects of the production phases and
improvements of electronic and electric components, as well as improvements on
usability and comfort. Main big changes that affect better performances and
better battery durations are already available from June 2018. These are:
Improved Battery Technology
We adopted a better battery technology based on patented “ATB - Advanced
Technology Battery” from Soneil which greatly improves battery life (more than
doubled), expanded environment conditions, increased shelf life and discharge
cycles, reduced gas emissions. Furthermore, we have increased the battery
duration with a single charge more than 10%. Here a comparison table with other
battery technology:
Improved Movement Control Technology
We have migrated all the movement control technology to the latest available
solutions on the market, aiming to solve some performance problems and to
improve durability and usability. The new low profile joystick, in conjunction with the
new power module, give a better, smooth control of the device traction.
Improved Joystick support
We changed radically the joystick support to meet user requests to have more
flexible solution and wider position management of the Joystick.

CHINESPORT Spa –ITALIA
AV3
14/47 AV3 - User Manual rev.1.2 - EN.docx
If you have a less recent version of the AV3 device, you can contact your local
distributor or manufacturer (Chinesport) to have more information on the possibility
to upgrade your product.
4.2 Standard accessories
Here the list for the standard accessories available for the AV3 device.
FOOTPLATES
Foot straps
A
C
0
0
4
7
Fixed heel rests
A
C
0
6
8
5
Adjustable heel rests
A
C
0
6
8
6
KNEE
SUPPORT
Leg straps
A
C
0
0
1
4
Coloured paddings
A
C
0
6
8
9
.
W
BACK
SUPPORT
Long seat padding
A
C
0
5
4
4
Short seat padding
A
C
0
5
4
3
Adjustable long seat
A
C
0
6
9
0
Adjustable short seat
A
C
0
6
9
1
Shaped pocket
A
C
0
0
4
8
LATERAL
SUPPORT
Back strap
A
C
0
7
8
3
Long handles
A
C
0
7
8
2
Lateral and back supports
A
C
0
0
5
0
Lateral supports
A
C
0
0
4
9
Adjustable lateral supports
A
C
0
7
0
2
Axillary support
A
C
0
0
7
2
Back support
A
C
0
0
7
4
Head support
A
C
0
0
7
6
Locking devices
A
C
0
0
7
5
Adjustable lateral-back supports
A
C
0
7
0
3
UPPER PART
Anti-crushing safety system
A
C
0
6
9
2
Front support
A
C
0
6
9
3
Anti-crushing front support
A
C
0
6
9
4

CHINESPORT Spa –ITALIA
AV3
AV3 - User Manual rev.1.2 - EN.docx 15/47
EN
SERVICE TRAY
Hand grip
0
1
6
0
8
Hand-wrist grip
0
1
6
0
9
Coloured padding for medium
service tray
A
C
0
7
6
6
.
W
Coloured padding for large service
tray.
A
C
0
7
6
7
.
W
Large ABS service tray
A
C
0
7
6
4
Medium ABS tray
A
C
0
7
6
5
The W option on some accessories refers to the possibility of having a different color
compared to the standard black color. The options are:
4.3 Unpacking
The device is shipped already fully assembled for the options and accessory
requested in the order. Simply remove the device from the package.
The version for independent mobility has the new Joystick support that is fixed to the
handles only for shipment purposes. Before use find the best position for the Joystick,
please see 5.4.1 Joystick placement.
USE OF THE DEVICE
5.1 Switcing on
Some configurations of the AV3 Device contain electric motors for:
Movement, for independent mobility
Verticalization
Structure height adjustment
Those devices have a main switch that turn-on the whole system and allow the use
of the electric motors. The main switch also activate the battery charging when the
suitable charger is connected to the device.
TURN ON MAIN
SWITCH
Switch to “1” the main
switch placed under the
service tray.
A
V
3
_
_
_
B
3
_
_
_
_
AFFECTED MODELS

CHINESPORT Spa –ITALIA
AV3
16/47 AV3 - User Manual rev.1.2 - EN.docx
TURN ON
INDEPENDENT
MOBILITY
Switch to “1” the main
switch placed under the
service tray
AFFECTED MODELS
A
V
3
2
_
_
_
_
_
_
_
_
3
Push the power button
to turn ON the green
light (JA)
5.2 Switching off
All electric function, on selected models that contain electronics, are ceased when
the device is turned off. The device will stay still if no action is explicitly required by
pushing the respective button, so the main switch can be safely left turned on.
However is always better to turn off the device when not in use or when not in
charging, to preserve the battery charge.
When in use, to terminate the movement actions is sufficient to arrest that action by
stopping to push the button that triggered that action.
TURN OFF MAIN
SWITCH
Switch to “0” the circuit
breaker placed under the
service tray.
A
V
3
2
_
_
B
3
_
_
_
_
3
AFFECTED MODELS
STOP HEIGHT
REGULATION
By stopping to press the
grey buttons PC and/or PD
on the hand switch
A
V
3
_
_
_
B
_
_
_
_
_
AFFECTED MODELS
JA
JA

CHINESPORT Spa –ITALIA
AV3
AV3 - User Manual rev.1.2 - EN.docx 17/47
EN
STOP
VERTICALIZATION
By stopping to press the
blue button PA and/or PB
on the hand switch.
A
V
3
_
_
_
_
3
_
_
_
_
AFFECTED MODELS
VERTICALIZATION
EMERGENCY STOP
A safety sensor (SA, yellow
button) could be provided
in order to attend the lifting
operation as accessory.
This device allows the
operator to stop the lifting
at any time he wants. When
the button is pushed, the
lifting of the back support is
disabled, and only the
descend of the back
support s allowed. Once the
yellow button has been
released, the lifting will be
enabled again.
A
C
0
6
9
2
A
C
0
6
9
4

CHINESPORT Spa –ITALIA
AV3
18/47 AV3 - User Manual rev.1.2 - EN.docx
STOP MOVING
AROUND
By releasing the joystick
knob (JM)
By pushing the off button to
turn the green light off (JA)
AFFECTED MODELS
A
V
3
2
_
_
_
_
_
_
_
_
3
5.3 Security locking and unlocking of Joystick
Sometimes is useful to lock the joystick functions for security reasons (e.g. children in
the house). In this way only trained people can unlock the joystick and start the
movement.
INSERT
SECURITY LOCK
Locking of Joystick
A
V
3
2
_
_
_
_
_
_
_
_
_
3
AFFECTED MODELS
When the device is on,
push more than 4
seconds the ON button
(JA)
The LEDs (JE) in the odd
positions (1, 3, 5) will start
blinking for a short time
The control box is now
locked. If the JA button
will be pushed again,
the LEDs (JE) in the odd
positions (1, 3, 5) will blink
shortly but the use of the
device will not be
possible. After 10
seconds the control box
will turn off.
REMOVE
SECURITY LOCK
Unlocking of Joystick
A
V
3
2
_
_
_
_
_
_
_
_
3
AFFECTED MODELS
JM
JA
JA
JE

CHINESPORT Spa –ITALIA
AV3
AV3 - User Manual rev.1.2 - EN.docx 19/47
EN
1) Push the on button (JA).
The LEDs (JE) in the odd
positions (1, 3, 5) will blink
shortly and the use of the
device will not be
possible
2) Push twice the horn
button (JB) within 10
seconds. The control box
LEDs now will turn on
permanently and the
use of the device will be
enabled again.
5.4 Initial settings
Before the first use of the device is recommended to adjust the settings in relation
with the pathological and physical features of the patient. The set up could be
performed by using all the regulation provided for each option. Please contact your
therapist in order to provide you all the support for the most comfortable setting up
of the device and supervise the first use of the device to check if the latter is used
safely. Please see 5.7 Adjustments and 5.8 Accessories adjustments for all the
adjustments that best fit your model.
Warning
-A BAD SETUP COULD LIMIT OR PREVENT THE CORRECT USE OF THE DEVICE
-ADJUST THE KNEE SUPPORTS TO HAVE THE MAXIMUM CONFORT AN THE
MINIMUM STRESS TO THE JOINTS DURING THE VERTICALIZATION PROCESS
-ADJUST THE HEIGHT OF THE STRUCTURE TO HAVE THE MAXIMUM CONFORT
AND THE BEST POSITION OF THE BODY AND OF THE LIMBS
-THE REGULATION IN DEPTH OF THE SEAT MUST BE PERFORMED BEFORE
STARTING THE TRANSFER FROM THE WHEELCHAIR
-BEFORE USE PLEASE CHECK THAT ALL THE REGULATION ITEMS ARE PROPERLY
LOCKED
5.4.1 Joystick placement
AV3 Models that have independent mobility are equipped with a Joystick to control
the device movements inside your locations. The joystick support mainly consist of
two adjustment that allows two degrees of freedom for the positioning and
orientation of the Joystick. The first adjustment is used to reach the required position
on the table or on the handles. The second adjustment is used for the joystick
ergonomically positioning.
JA
JE
JB

CHINESPORT Spa –ITALIA
AV3
20/47 AV3 - User Manual rev.1.2 - EN.docx
Item “A” allows to open and close the clamp in order to move the Joystick support
and reach the required position on the table or on the handle. Once the positioning
has been reached clamp the support with the knob “A”. The support must be firmly
clamped in order to guarantee a good stability of the joystick.
Item “B” is used to give the required positioning and orientation of the Joystick
making use of the two spheres of the support:
Once the position has been reached the joystick can be horizontally and vertically
orientated. Clamp firmly the “B” knob if a rigid position is required. Otherwise the
“B” knob can be gentle clamped to obtain an adaptive regulation of the joystick.
Here some joystick positioning examples on the AV3 Table:
Warning
THE JOYSTICK SUPPORT IS NOT INTENDED TO SUPPORT THE PATIENT LOAD. WE
RECOMMEND TO MAINTAIN THE JOYSTICK ALWAYS IN CONTACT WITH THE
TABLE IN ORDER TO GUARANTEE A GOOD STABILITY. DON’T APPLY ALL THE
LOAD ON THE JOYSTICK OR ON THE SUPPORT.
5.5 Normal use of the device
