Christie CineLife+ 4 Series User manual

User Guide
020-103073-11
CineLife+

NOTICES
COPYRIGHT AND TRADEMARKS
Copyright © 2023 Christie Digital Systems USA Inc. All rights reserved.
All brand names and product names are trademarks, registered trademarks or trade names of their respective holders.
GENERAL
Every effort has been made to ensure accuracy, however in some cases changes in the products or availability could occur which may not be reflected in this
document. Christie reserves the right to make changes to specifications at any time without notice. Performance specifications are typical, but may vary
depending on conditions beyond Christie's control such as maintenance of the product in proper working conditions. Performance specifications are based on
information available at the time of printing. Christie makes no warranty of any kind with regard to this material, including, but not limited to, implied
warranties of fitness for a particular purpose. Christie will not be liable for errors contained herein or for incidental or consequential damages in connection
with the performance or use of this material. Our centers of excellence for manufacturing in Kitchener, Ontario, Canada and in Shenzhen, China are ISO
9001:2015 Quality Management System-certified.
Christie is committed to making our documents free from language bias; however, we are not responsible for the language used on any linked or third-party
documentation.
For the most current technical documentation and office contact information, visit http://www.christiedigital.com.
Warranty
Products are warranted under Christie’s standard limited warranty, the details of which are available at https://www.christiedigital.com/help-center/
warranties/ or by contacting your Christie dealer or Christie.
PREVENTATIVE MAINTENANCE
Preventative maintenance is an important part of the continued and proper operation of your product. Failure to perform maintenance as required, and in
accordance with the maintenance schedule specified by Christie, voids the warranty. For preventative maintenance schedules, refer to
www.christiedigital.com.
REGULATORY
The product has been tested and found to comply with the limits for a Class A digital device, pursuant to Part 15 of the FCC Rules. These limits are designed
to provide reasonable protection against harmful interference when the product is operated in a commercial environment. The product generates, uses, and
can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio
communications. Operation of the product in a residential area is likely to cause harmful interference in which case the user will be required to correct the
interference at the user’s own expense. Changes or modifications not expressly approved by the party responsible for compliance could void the user's
authority to operate the equipment
CAN ICES-3 (A) / NMB-3 (A)
이 기기는 업무용(A급)으로 전자파적합등록을 한 기기이오니 판매자 또는 사용자는 이점을 주의하시기 바라며, 가정 외의 지역에서 사용하는 것을 목적으로 합니다.
ENVIRONMENTAL
The product is designed and manufactured with high-quality materials and components that can be recycled and reused. This symbol means electrical and
electronic equipment, at their end-of-life, should be disposed of separately from regular waste. Please dispose of the product appropriately and according to
local regulations. In the European Union, separate collection systems are for used electrical and electronic products.
If printing this document, consider printing only the pages you need and select the double-sided option.
Please help us to conserve the environment we live in!
Notation
Learn the hazard and information symbols used in the product documentation.
Danger messages indicate a hazardous situation which, if not avoided, results in death or serious injury.
Warning messages indicate a hazardous situation which, if not avoided, could result in death or serious injury.
Caution messages indicate a hazardous situation which, if not avoided, could result in minor or moderate injury.
Notice messages indicate a hazardous situation which, if not avoided, may result in equipment or property
damage.
Information messages provide additional information, emphasize or provide a useful tip.

Content
Introduction...................................................... 9
Models..........................................................9
Product documentation................................................9
Safety precautions..................................................10
General safety precautions...........................................10
AC power precautions..............................................10
Laser safety precautions............................................11
Lamp safety precautions............................................11
Light intensity hazard distance........................................12
CineMaster cinema calculator tool........................................ 13
Technical support...................................................13
Contact your dealer.................................................13
Operating the projector.............................................14
Projector power modes...............................................14
System operation for CP4440-RGB and CP4450-RGB projectors only...................15
Turning on or off the projector........................................ 15
LED status indicators................................................15
Logging into the projector.............................................16
Logging out of the projector..........................................16
Determining the projector IP address......................................16
Resetting the projector IP address to the default...............................17
Using the Remote user interface (UI)......................................18
Turning on or off the touch panel.........................................19
Understanding the Christie touch panel interface and remote user interface............19
Turning on or off the light source.........................................20
Opening or closing the shutter.......................................... 21
Adding a network time protocol server..................................... 21
Deleting a network time protocol server.................................... 22
Changing the time zone.............................................. 22
Changing the time format............................................. 22
Automatically adjusting the time for Daylight Saving Time.........................22
Changing the orientation of the projected image...............................23
Changing the projector hostname........................................ 23
CineLife+ User Guide 3
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

Changing the temperature display........................................23
Video Input panel................................................. 25
HDMI video source..................................................26
HDMI video formats...............................................26
SDI video source...................................................28
SDI video formats................................................28
DisplayPort video source..............................................34
DisplayPort video formats........................................... 34
Integrated Media Block (IMB) video source...................................35
Series 2 Integrated Media Block (IMB) video formats.......................... 36
Series 4 Integrated Media Block (IMB) video formats.......................... 37
HDMI video source connection from an Integrated Media Block (IMB)................40
SDI video source connection from an Integrated Media Block (IMB).................40
GPIO connector....................................................40
Managing the laser light source......................................43
Creating a new laser file for non-chiller RGB projectors...........................43
Creating a new laser file for external chiller-based projectors....................... 44
Modifying an existing laser file.......................................... 45
Copying existing laser settings to a new file..................................45
Deleting a laser file................................................. 46
LiteLOC™ sensor-to-screen calibration ..................................... 46
LiteLOC™ sensor-to-screen calibration: Workflow.............................46
Creating a new calibration file.........................................47
Recalibrating an existing calibration file...................................48
Editing the existing calibration file parameters.............................. 49
Verifying the sensor-to-screen calibration .................................49
Adding a calibration file to the Channel Setup...............................50
Managing the lamp................................................51
Turning on the lamp.................................................51
Turning off the lamp.................................................51
Adjusting the lamp power............................................. 51
Changing the lamp power percentage......................................51
Enabling lamp overdrive.............................................. 52
Using LampLOC™ to adjust the lamp position................................. 52
Manually adjusting the lamp position...................................... 52
Viewing lamp information............................................. 53
Content
CineLife+ User Guide 4
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

Setting a lamp warranty date alarm.......................................53
Setting a lamp half-life alarm...........................................53
Lamp power ratings and warranty hours.................................... 53
Managing user accounts............................................55
Default user access permissions......................................... 55
Adding a user account............................................... 55
Changing user account permissions.......................................55
Changing a user account password........................................56
Deleting a user account...............................................56
Network settings..................................................57
Connecting the projector to the theater network...............................57
Activating SNMP...................................................57
Downloading MIB information...........................................58
Managing content, playlists, and storage...............................59
Setting up an integrated media block..................................60
Selecting Integrated Media Block (IMB) preferences.............................60
Activating marriage.................................................60
Enabling Integrated Media Block (IMB) Powered in Standby mode.................... 60
Working with channels.............................................62
Using channels to set input signal parameters.................................62
Adding a channel for HDMI input.........................................63
Adding a channel for SDI input..........................................65
Adding a channel for DisplayPort input..................................... 66
Adding a channel for Integrated Media Block (IMB) input..........................67
Selecting the active channel............................................68
Editing an existing channel.............................................69
Copying existing channel settings to a new channel.............................69
Viewing the channel list...............................................69
Moving a channel up or down the channel list.................................69
Deleting a channel..................................................70
Managing color setting files.........................................71
Creating a MCGD file................................................ 71
Editing an existing MCGD file........................................... 71
Copying existing MCGD file settings to a new file...............................72
Content
CineLife+ User Guide 5
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

Deleting a MCGD file................................................ 72
Creating a TCGD file.................................................72
Editing an existing TCGD file............................................73
Copying existing TCGD file settings to a new file...............................73
Deleting a TCGD file.................................................73
Adjusting the image size and position................................. 74
Intelligent Lens System (ILS)...........................................74
Activating the Intelligent Lens System....................................74
Creating a new ILS file.............................................74
Automatically calibrating the ILS.......................................75
Editing ILS file settings.............................................75
Copying existing ILS file settings.......................................75
Deleting an ILS file............................................... 75
Resetting the lens................................................75
Electronically adjusting convergence.......................................76
Creating a source file................................................77
Editing source file settings.............................................77
Copying existing source file settings to a new source file..........................78
Deleting a source file................................................78
Creating a screen file................................................78
Editing screen file settings.............................................79
Copying existing screen file settings to a new screen file..........................79
Deleting a screen file................................................79
Activating a warp file................................................ 79
Adjusting the image............................................... 81
Correcting vignetting................................................ 81
Correcting keystone effect.............................................81
Masking the screen edges.............................................82
Test patterns.....................................................84
Displaying a test pattern..............................................84
Turning off a test pattern..............................................84
Importing a test pattern..............................................85
Deleting a test pattern............................................... 85
Working with the scheduler......................................... 86
Scheduling automation...............................................86
Content
CineLife+ User Guide 6
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

Editing a scheduled event............................................. 87
Copying and pasting an existing scheduled event...............................87
Copying and pasting scheduled events for an entire day.......................... 87
Cutting and pasting a scheduled event..................................... 87
Deleting a scheduled event............................................ 88
Deleting scheduled events for an entire day..................................88
Changing the day of the week the scheduler starts..............................88
Turning off the scheduler..............................................88
Automation......................................................89
Available macro actions...............................................89
Fire alarm macro...................................................90
Christie ACT actions.................................................90
JNIOR actions.....................................................90
Dolby Cinema processor actions......................................... 91
SKA-3D actions....................................................91
Creating a macro...................................................92
Running a macro...................................................92
Adding an action item to an existing macro.................................. 92
Adding a macro to an existing macro...................................... 93
Deleting a macro...................................................93
Adding an automation device to your auditorium...............................93
Modifying automation device settings......................................94
Removing an automation device from your auditorium........................... 94
Creating, editing, and deleting playlist triggers................................94
Creating a new global trigger...........................................95
Editing existing global trigger settings......................................95
Deleting a global trigger.............................................. 95
Importing a device library.............................................95
Viewing a device library...............................................95
Deleting a device library..............................................96
Backing up, restoring, and upgrading files..............................97
Creating a new backup file.............................................97
Exporting a backup file...............................................97
Importing a backup file...............................................97
Sorting backup files by name and date created................................98
Deleting a backup file................................................98
Restoring settings from a backup file...................................... 98
Content
CineLife+ User Guide 7
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

Restoring factory default settings.........................................98
Upgrading the projector software.........................................98
Accessing projector diagnostics.....................................100
Retrieving and downloading system logs................................... 100
Running the projector interrogator.......................................100
Viewing laser diagnostic information......................................101
Downloading a certificate.............................................101
Regulatory......................................................102
Safety.........................................................102
Electro-magnetic compatibility..........................................102
Emissions.................................................... 102
Immunity.....................................................102
Environmental....................................................103
Content
CineLife+ User Guide 8
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

Introduction
This manual is intended for operators of Christie CineLife+ projection systems.
For complete product documentation and technical support, go to www.christiedigital.com.
Models
This guide applies to the following models.
• All Christie Series 4 laser projectors: CP44xx-RGB, CP24xx-RGB
• All Christie Series 4 xenon projectors:
• CP2415-Xe
• CP2420-Xe
• CP4420-Xe
Product documentation
For installation, setup, and user information, see the product documentation available on the Christie
Digital Systems USA Inc. website. Read all instructions before using or servicing this product.
1. Access the documentation from the Christie website:
• Go to this URL: https://bit.ly/3vxrm4Y or
https://www.christiedigital.com/products/cinema/projection/cinelife-plus-series/.
• Scan the QR code using a QR code reader app on a smartphone or tablet.
2. On the product page, select the model and switch to the Downloads tab.
CineLife+ User Guide 9
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

Safety precautions
Learn about the safety precautions related to the Christie CineLife+ projector. This projector is
intended for use in a cinema environment.
General safety precautions
Read all safety and warning guidelines before installing or operating the projector.
Warning! If not avoided, the following could result in death or serious injury.
• TRIP OR FIRE HAZARD! Position all cables where they cannot contact hot surfaces, be pulled, be
tripped over, or damaged by persons walking on or objects rolling over the cables.
• This product must be installed within a restricted access location not accessible by the general
public.
• Only personnel who are trained on the precautions for the restricted access location can be
granted entry to the area.
• Install the product so users and the audience cannot enter the restricted area at eye level.
• ELECTRICAL and BURN HAZARD! Use caution when accessing internal components.
• High leakage current present when connected to IT power systems.
• FIRE AND SHOCK HAZARD! Use only the attachments, accessories, tools, and replacement parts
specified by Christie.
• FIRE HAZARD! Do not use a power cord, harness, or cable that appears damaged.
• Lift equipment must be used to position the product.
• Do not install or operate the projector in any position that does not meet the stated product
specifications for alignment and orientation.
Caution! If not avoided, the following could result in minor or moderate injury.
• Only Christie qualified technicians are permitted to open product enclosures.
AC power precautions
Read all safety and warning guidelines before connecting to AC power.
Warning! If not avoided, the following could result in death or serious injury.
• SHOCK HAZARD! Only use the AC power cord provided with the product or recommended by
Christie.
• FIRE AND SHOCK HAZARD! Do not attempt operation unless the power cord, power socket, and
power plug meet the appropriate local rating standards.
• SHOCK HAZARD! Do not attempt operation if the AC supply is not within the specified voltage
and current, as specified on the license label.
• SHOCK HAZARD! The optional UPS power cord must be inserted into an outlet with grounding.
• SHOCK HAZARD! Disconnect the product from AC before installing, moving, servicing, cleaning,
removing components, or opening any enclosure.
• Install the product near an easily accessible AC receptacle.
Introduction
CineLife+ User Guide 10
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

Caution! If not avoided, the following could result in minor or moderate injury.
• FIRE HAZARD! Do not use a power cord, harness, or cable that appears damaged.
• FIRE OR SHOCK HAZARD! Do not overload power outlets and extension cords.
• SHOCK HAZARD! Power supply uses double pole/neutral fusing.
Laser safety precautions
Read all safety and warning guidelines before operating the projector laser.
Warning! If not avoided, the following could result in death or serious injury.
• Do not operate the cinema projector without all of its covers in place.
• LASER RADIATION HAZARD! This projector has a built-in Class 4 laser module. Never attempt to
disassemble or modify the laser module.
• Do not look directly into the lens when the light source is on. The extremely high brightness can
cause permanent eye damage.
• Possible hazardous optical radiation emitted from this product. (Risk group 3)
Lamp safety precautions
Read all safety and warning guidelines before installing the projector lamp.
Warning! If not avoided, the following could result in death or serious injury.
• This procedure must be performed by Christie qualified technicians.
• EXPLOSION HAZARD! Always wear protective safety clothing (gloves, jacket, face shield)
approved by the manufacturer whenever the lamp door is open or when handling the lamp. Any
local or federal specifications take precedence over Christie's protective clothing
recommendations.
• Do not open the lamp door while the lamp is on.
• EXPLOSION HAZARD! Allow sufficient time for the lamp to cool down before powering down the
product, disconnecting it from AC, and opening the lamp door.
• EXPLOSION HAZARD! Do not stress the glass of a lamp or bare bulb in any way.
• EXPLOSION HAZARD! Lamps and bare bulbs, even when packaged, may explode if dropped or
mishandled.
• EXPLOSION HAZARD! Handle a lamp by the cathode and anode end shafts only. Do not handle
the lamp by the glass.
• EXPLOSION HAZARD! Do not over-tighten the lamp.
• Do not look directly into the lens when the light source is on. The extremely high brightness can
cause permanent eye damage.
• FIRE HAZARD! Keep hands, clothes, and all combustible material away from the concentrated
light beam of the projector.
Caution! If not avoided, the following could result in minor or moderate injury.
• Improper installation of the lamp can damage the projector.
• Incorrect lamp power supply and igniter connections can damage the product.
Introduction
CineLife+ User Guide 11
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

Light intensity hazard distance
This projector has been classified as Risk Group 3 as per the IEC 62471-5:2015 standard due to
possible hazardous optical and thermal radiation being emitted.
Warning! If not avoided, the following could result in serious injury.
• PERMANENT/TEMPORARY BLINDNESS HAZARD! No direct exposure to the beam must be
permitted.
• PERMANENT/TEMPORARY BLINDNESS HAZARD! Operators must control access to the beam
within the hazard distance or install the product at the height that prevents exposure of
spectators' eyes within the hazard distance. The hazard zone must be no lower than 2.5 meters
(US installations) or 2.0 meters (global installations) above any surface upon which any persons
are permitted to stand and the horizontal clearance to the hazard zone must be a minimum 1.0
meters.
• EXTREME BRIGHTNESS! Do not place reflective objects in the product light path.
The following show the zones for ocular and skin hazard distances.
• A—Hazard zone. The region of space where the projection light from the laser-illuminated
projector is above emission limits for Risk Group 2. The light intensity may cause eye damage
after a momentary or brief exposure (before a person can avert their eyes away from the light
source). The light may cause skin burns to occur.
• B—Hazard distance. Operators must control access to the beam within the hazard distance or
install the product preventing potential exposure of the spectators' eyes from being in the
hazard distance.
• C—No access zone. Horizontal clearance of the no access zone must be a minimum of 1.0
meters (3.3 feet).
• D—Vertical distance to hazard zone. The hazard zone must be no lower than 2.5 meters/8.2
feet (US installations) or 2.0 meters/6.6 feet (global installations) above any surface upon
which any persons are permitted to stand.
If the vertical distance to hazard zone requirement (Zone D) is satisfied, the horizontal
clearance distance (Zone C) is not needed.
• E—Represents the top view of the projector.
Introduction
CineLife+ User Guide 12
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

• F—Represents the side view of the projector.
For information detailing the hazard distance for each lens, refer to the product's Installation and
Setup guide.
For Installations in the United States
The following must be in place for laser-illuminated projector installations in the United States:
• The projection room shall be clearly identified by the posting of laser warning and restricted
access signs, and by restricting entry through physical means. The projection room sign must
display the warning "No direct exposure to beam shall be permitted".
• The Christie Laser Projection System Installation Checklist must be fully completed after the
installation and sent to [email protected]. A copy can remain on-site. This
checklist can be found as a separate document in the accessory box with the manual.
• Certain US states have additional laser regulatory requirements. Contact
[email protected] for additional regulatory requirements.
CineMaster cinema calculator tool
The CineMaster cinema calculator tool helps you calculate and configure the optimal cinema set up.
Use this tool to help determine the right projector, lens, and lamp based on the unique needs of your
installation, as well as your preferred projector type, screen configuration, and brightness
requirements.
https://cinemaster.christiedigital.com/
Technical support
Technical support for Christie Cinema products is available at:
•[email protected]
• [phone]
• Christie Professional Services: [phone] or [email protected]
Contact your dealer
Record the information about your installation and keep this information with your records to assist
with any servicing of your product. If you encounter a problem, contact your dealer.
Purchase record
Dealer:
Dealer or Christie Sales/Service contact phone number:
Serial number:
The serial number can be found on the license label.
Purchase date:
Installation date:
Introduction
CineLife+ User Guide 13
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

Operating the projector
Learn how to operate the projector and adjust projector settings.
Projector power modes
The CineLife+ projectors track laser operation hours for the laser optical subsystems (LOS) and the
lamp operation hours for xenon lamps.
The projector operates with the following power modes:
Mode Description
Standby • CineLife+ electronics remain on standby with the light engine off.
•Fans, laser optical sub-systems (LOS) or xenon lamp, and thermo-electric cooler
(TEC) devices are off.
• Integrated Media Block (IMB) is off—IMB automation does not function.
• Fire alarm does not function.
Standby (IMB On) • CineLife+ electronics and the IMB are powered on with the light engine off.
• Power is available to the optional touch panel and laser optical sub-systems
(LOS).
• Power is available to the thermo-electric cooler (TEC) devices; however, the
drivers are disabled.
• Some fans are low speed (depending on projector type).
• Pumps are off.
• Chiller is off (if applicable).
This mode is set from Service Setup > Preferences > IMB.
Projector on • CineLife+ electronics and light engine are on.
• LOS and TEC devices are off.
• Chiller is on (CP4440-RGB and CP4450-RGB projectors only).
• IMB is on.
Light source on • CineLife+ electronics and light engine are on.
• LOS and TEC devices are on.
• Fans run at full speed.
• Chiller is on (CP4440-RGB and CP4450-RGB projectors only).
• IMB is on.
CineLife+ User Guide 14
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

System operation for CP4440-RGB and CP4450-
RGB projectors only
Understand the correct sequence for powering up and operating CP4440-RGB and CP4450-RGB
systems.
The connected chiller must always be turned on first and turned off only after the projector is turned
off. Once the chiller is connected to AC and the chiller communication cable is connected to the
projector, the projector controls the chiller automatically to maintain the required coolant temperature.
The system is ready to operate when the following steps are completed:
1. The connected chiller unit is powered on.
2. The projector's main power switches are on.
3. Communication between the projector and the connected chiller is confirmed and coolant
temperatures are correctly maintained.
If a thermal shutdown occurs in a dual projector installation, verify the chiller communication
cables are connected correctly between each projector-chiller pair. This makes sure no cross-
connection exists relative to the coolant lines.
Turning on or off the projector
Turn on the projector to display content or turn off the projector to conserve energy or service the
projector.
In the right toolbar, select and hold Power.
LED status indicators
Red, yellow, and green LEDs on the top and rear corners of the projector indicate the status of the
projector.
This following table provides the status indicator LED action and its meaning. The LEDs can be solidly
lit, flash frequently, or flash intermittently.
LED action Projector state Description
Solid green Power on Power is on, light source is on.
Flashing green one time per second Standby mode Power is off, light source is off.
Power saving mode.
Flashing green three times per
second
Warming up mode Projector is warming up.
Flashing green and yellow Cool-down mode Power is on, light source is off.
The light source can be turned on
when in this mode.
Flashing yellow Warning Warning exists but has not been
acknowledged by the operator.
Operating the projector
CineLife+ User Guide 15
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

LED action Projector state Description
Flashing red New critical alarm or warning New critical alarm or warning has
not been acknowledged by the
operator.
Solid red Existing critical alarm or warning Critical alarm or warning exists, but
has been acknowledged by the
operator.
Logging into the projector
Log into the projector to access projector menus.
1. Select Login.
2. In the User list, select a username.
3. Enter your password.
4. Select Login.
Logging out of the projector
Log out of the projector to restrict access to projector menus or to change access permissions.
• Select Logout.
Determining the projector IP address
Before accessing the projector user interface remotely, determine the IP address of the projector. Use
the following method to determine the projector IP address when no touch panel is installed.
1. Connect the projector to the theater network using an Ethernet cable.
2. Make sure the projector is not in Standby mode by selecting the recessed button between the
USB-C port and the USB port on the Video Input panel.
Pressing the recessed button transitions the projector from Standby to powered on.
Operating the projector
CineLife+ User Guide 16
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

3. Make sure the path in front of the lens is clear and ready for the IP address to be projected as
continuing to step 4 turns on the light source and projects the IP address on the screen.
4. Once the unit is powered on, select and hold the Marriage button on the projector for 5 to 25
seconds.
The projector turns on the light source and displays a test pattern with the projector's IP
address and any currently active alarms.
The light source remains on.
5. To turn the light source off, select and hold the Marriage button for 5 to 25 seconds.
Resetting the projector IP address to the default
Use the following method to reset the projector IP address to the default value (192.168.206.110) and
the subnet is 255.255.255.0when no touch panel is installed.
1. Connect the projector to the theater network using an Ethernet cable.
2. Make sure the projector is not in Standby mode by selecting the recessed button between the
USB-C port and the USB port on the Video Input panel.
Pressing the recessed button transitions the projector from Standby to powered on.
Operating the projector
CineLife+ User Guide 17
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

Before resetting the IP address to factory default, the light source turns on and remains on.
The IP address is shown as described in Determining the projector IP address (on page 16).
3. Once the unit is powered on, select and hold the Marriage button on the projector for 30
seconds.
The IP address of the projector is reset to the default.
4. Once you have reset the IP address, turn off the light source by selecting and holding the
Marriage button for 5 to 25 seconds.
Using the Remote user interface (UI)
Use the remote user interface (UI) to access projector functionality.
1. Log into the Remote UI.
The default IP address is 192.168.206.110.
2. From the Remote UI default page, to access the main projector user interface, select the
Projector Control tab.
3. To upload and download files from the projector, use the File Menu.
Examples of items that can be uploaded include:
• Projector upgrade packages
• Backup packages to restore from
• Rental files to license the projector for Rental mode
• Test patterns (PNG files only)
• Gamma files
Examples of items that can be downloaded include:
• Projector backup files
• Projector certificates (required for content decryption)
Operating the projector
CineLife+ User Guide 18
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

• Interrogator files (for support and troubleshooting)
4. If the projector has a GDC IMB SR-1000 installed and configured, access the GDC IMB Web UI
by using the Media Block tab.
Turning on or off the touch panel
Turn on the touch panel to view projector menus, or turn off the touch panel to conserve energy.
• To turn on or off the touch panel, select the Power button (A) on the top of the touch
panel.
Understanding the Christie touch panel interface and remote
user interface
Use the touch panel to control the projector and perform functions such as turning on or off the light,
selecting channels, and viewing status information.
If no touch panel is installed, use the Remote UI feature. See Using the Remote user interface (UI) (on
page 18).
Operating the projector
CineLife+ User Guide 19
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.

H
G
F
A
EDB C
L
K
J
I
A Left navigation menu.
Access permissions determine the
available options.
G Turns the light on or off.
B Current access permissions. H Opens and closes the shutter.
C Projector name and IP address. I Turns test patterns on or off.
D Current date and time. J Displays channels.
E System status.
To display all alarms, select the colored
icon.
K Displays macros.
F Turns the projector on or off.
Turning on or off the light source
Turn on the light source to display content or view test patterns. Turn off the light to extend the life of
the light source.
• To turn on or off the light source, in the right toolbar, select and hold Light.
If turning on the light source when the projector power is off, power is turned on automatically.
Operating the projector
CineLife+ User Guide 20
020-103073-11 Rev. 1 (05-2023)
Copyright © 2023 Christie Digital Systems USA, Inc. All rights reserved.
If printed, please recycle this document after use.
