Chroma Studio One 100 V User manual

Chroma-Q
®
Studio One 100 V™
User Manual
Version 1.0 September 2015, Software Version 1.
PN: 638-0702

Studio One 100 V User Manual 1 V1.0 Septe ber 2015
www.chroma
-
q.com
Warranty Statement
Chro a-Q warrants to the original purchaser, with proof of purchase, that its delivered products shall be free fro defects in
aterial and work anship under nor al use for a period of 12 onths fro date of ship ent.
Chro a-Q will repair, or at its option, provide an equivalent ite or replace, the defective product during the stated warranty
period. This warranty applies only to the repair or replace ent of the product and only when the product is properly handled,
installed and aintained according to Chro a-Q instructions. This warranty excludes defects resulting fro i proper
handling, storage, installation, acts of God, fire, vandalis or civil disturbances. Purchaser ust notify Chro a-Q in writing
within 14 days of noticing the defect. This warranty excludes field labour or service charges related to the repair or
replace ent of the product.
The warranty contained herein shall not extend to any finished goods or spare parts fro which any serial nu ber has been
re oved or which have been da aged or rendered defective (a) as a result of nor al wear and tear, wilful or accidental
da age, negligence, isuse or abuse; (b) due to water or oisture, lightning, windstor , abnor al voltage, har onic
distortion, dust, dirt, corrosion or other external causes; (c) by operation outside the specifications contained in the user
docu entation; (d) by the use of spare parts not anufactured or sold by Chro a-Q or by the connection or integration of
other equip ent or software not approved by Chro a-Q unless the Custo er provides acceptable proof to Chro a-Q that
the defect or da age was not caused by the above; (e) by odification, repair or service by anyone other than Chro a-Q,
who has not applied for and been approved by Chro a-Q to do such odification, repair or service unless the Custo er
provides acceptable proof to Chro a-Q that the defect or da age was not caused by the above; (f) due to procedures,
deviating fro procedures specified by Chro a-Q or (g) due to failure to store, install, test, co ission, aintain, operate or
use finished goods and spare parts in a safe and reasonable anner and in accordance with Chro a-Q’s instructions (h) by
repair or replace ent of engines without factory training.
The warranty contained herein shall not apply to finished goods or spare parts which are sold “as is”, as “second-hand”, as
used”, as “de o” or under si ilar qualifications or to Consu ables (“Consu ables” is defined as any part(s) of goods or
part(s) for use with goods, which part(s) of goods or part(s) for use with goods are consu ed during the operation of the
goods and which part(s) of goods or part(s) for use with goods require replace ent fro ti e to ti e by a user such as, but
not li ited to, light bulbs).
The warranty contained herein shall not apply, unless the total purchase price for the defective finished goods or spare parts
has been paid by the due date for pay ent.
The warranty contained herein applies only to the original purchaser and are not assignable or transferable to any
subsequent purchaser or end-user.
This warranty is subject to the ship ent of the goods, within the warranty period, to the Chro a-Q warranty returns
depart ent, by the purchaser, at the purchasers’ expense. If no fault is found, Chro a-Q will charge the purchaser for the
subsequent return of the goods.
Chro a-Q reserves the right to change the warranty period without prior notice and without incurring obligation and
expressly disclai s all warranties not stated in this li ited warranty.

Studio One 100 V User Manual 2 V1.0 Septe ber 2015
www.chroma
-
q.com
Disclaimer
The infor ation contained herein is offered in good faith and is believed to be accurate. However, because conditions and
ethods of use of our products are beyond our control, this infor ation should not be used in substitution for custo er's
tests to ensure that Chro a-Q products are safe, effective, and fully satisfactory for the intended end use. Suggestions of
use shall not be taken as induce ents to infringe any patent. Chro a-Q sole warranty is that the product will eet the sales
specifications in effect at the ti e of ship ent. Your exclusive re edy for breach of such warranty is li ited to refund of
purchase price or replace ent of any product shown to be other than as warranted.
Chro a-Q reserves the right to change or ake alteration to devices and their functionality without notice due to our ongoing
research and develop ent.
The Chro a-Q Studio One 100 range has been designed specifically for the lighting industry. Regular aintenance should
be perfor ed to ensure that the products perfor well in the entertain ent environ ent.
If you experience any difficulties with any Chro a-Q products please contact your selling dealer. If your selling dealer is
unable to help please contact support@chro a-q.co . If the selling dealer is unable to satisfy your servicing needs, please
contact the following, for full factory service:
Outside North America: North America:
Tel: [phone] Tel: [phone]
Fax: [phone] Fax: [phone]
support@chro a-q.co support@chro a-q.co
For further infor ation please visit the Chro a-Q website at www.chro a-q.co .
Chro a-Q and Studio One 100 V are trade arks, for ore infor ation on this visit www.chro a-q.co /trade arks.
The rights and ownership of all trade arks are recognised.
Important Notice:
As per the require ents in the Occupational Safety and Health Ad inistration standards for product approval, please refer to
the OSHA web pages http://www.osha.gov/dts/otpca/nrtl/ for infor ation on the list of Nationally Recognized Testing
Laboratories (NRTLs) and the scope of recognition.

Studio One 100 V User Manual 3 V1.0 Septe ber 2015
www.chroma
-
q.com
Table of Contents
1.
1.1.
1. Product overview
Product overviewProduct overview
Product overview ................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
.................................
..
. 4
44
4
2.
2.2.
2. Operation
OperationOperation
Operation ................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
...........................................
......................
........... 5
55
5
2.1 Unpacking the Units ....................................................................................................................................... 5
2.2 Cabling ......................................................................................................................................................... 5
2.3 Mounting ...................................................................................................................................................... 5
2.4 Optics ........................................................................................................................................................... 5
2.5 Control ......................................................................................................................................................... 6
2.6 DMX Protocol .............................................................................................................................................. 13
2.7 Ther al Perfor ance .................................................................................................................................. 13
3.
3.3.
3. Troubleshooting
TroubleshootingTroubleshooting
Troubleshooting ................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................ 13
1313
13
4.
4.4.
4. Specification
SpecificationSpecification
Specification ................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
.....................................
..........
..... 14
1414
14
4.1 Technical Specifications ............................................................................................................................... 14
4.2 Drawings – Di ensions ............................................................................................................................... 15
5.
5.5.
5. Ma
MaMa
Maintenance
intenanceintenance
intenance ................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
................................................................
.....................................
..........
..... 15
1515
15

Studio One 100 V User Manual 4 V1.0 Septe ber 2015
www.chroma
-
q.com
1. Product overview
The new Chro a
Chro aChro a
Chro a-
--
-Q® Studio One 100™
Q® Studio One 100™Q® Studio One 100™
Q® Studio One 100™ LED Par is designed to deliver the highest quality of white light fro an LED
based fixture, for the ost de anding applications.
Utilising core LED technology fro the Chro a-Q pre iu perfor ance lighting range, the ulti-purpose fixture is ideal for
a wide range of environ ents and provides a powerful, creative lighting tool.
The Studio One's custo optical design and fully ho ogenised output provides a s ooth, unifor and defined 18° bea .
Theatrical grade di ing e ulates the extre ely s ooth di ing curve of tungsten fixtures.
The Studio One 100 offers adjustable di ing frequencies to ensure flicker-free operation on ca eras.
With the advanced feature set also including convection cooling for silent operation and a versatile ounting yoke, the Studio
One 100 is suitable for nu erous TV, fil , studio, exhibition & entertain ent lighting applications - co ple enting the
popular Chro a-Q Studio Force™ and Studio Force Phosphor™ LED fixtures ranges.
With a si ple to use Infra-Red re ote control included with each fixture, you can be up and running within inutes without
the require ent of a lighting console - saving ti e and labour with instant access to pre-set colour te peratures, on/off,
di ing and effects.
To enable axi u flexibility with users' existing production inventory, the Studio One accepts industry-standard 6.25"
accessories such as egg crates, barndoors and top hats.
Note: HANDHELD COLOUR METERS
•Handheld Colour Meters provide a li ited easuring range for LED fixtures, which results in inconsistent and unreliable
data.
•All photo etric values listed in this docu ent are based on testing and easure ents conducted by certified
independent laboratories with reference to the IES standards.

Studio One 100 V User Manual 5 V1.0 Septe ber 2015
www.chroma
-
q.com
2. Operation
2.1 Unpacking the Units
The Studio One 100 V package includes 1 unit fixture, power cord, power connector, colour fra e, a Quick Start Guide and
an IR Re ote.
We reco end that you keep the original packaging in case the ite needs to be returned.
2.2 Cabling
The Studio One 100 V is built with chassis ount powerCon connectors for power input and through; chassis ount XLR 5-
pin connectors for DMX control data input and through.
The enclosure is ground bonded.
XLR 5-pin Cable:
Power Cable:
Important Notice: The use of an opto-splitter for DMX signal distribution is highly reco ended when several fixtures are
not plugged into the sa e power source.
2.3 Mounting
The Studio One 100 V is built with a split yoke syste for floor ounting and overhead hanging applications. Secure the
fixture with a safety bond when hung. A provision for a fixing hold is built into the fixture.
2.4 Optics
The Studio One 100 V is built with an optical lens that provides a fully ho ogenised bea angle of approxi ately ~ 18°.
Pin# Function
1 Ground (Screen)
2 Data Minus
3 Data Plus
4 Spare Data Minus
5 Spare Data Plus
International
Colour Code
North American
Colour Code
Connections
Green and Yellow Green Earth (E) Ground (Green)
Blue White Neutral (N) Neutral (Silver)
Brown Black Live (L) Hot (Gold)

Studio One 100 V User Manual 6 V1.0 Septe ber 2015
www.chroma
-
q.com
2.5 Control
The Studio One 100 V is controlled re otely via ANSI E1.11 USITT DMX512-A protocol or can operate as a standalone unit
with the wireless IR Re ote. The control functions can be accessed through the LCD display at the rear of the fixture with 4
push buttons.
Back Arrow (Enter) Stores the enu choice
Up Arrow Increases (+) the ode level or value
Down Arrow Decreases (-) the ode level or value
Exit Back to the previous enu
Power-Up Display:
On power-up, the display shows the Brand, Model Na e and Software Version for 5 seconds then goes on to show the Main
Menu. The Main Menu shows:
•
Model Na e
•
DMX Status
•
DMX Address
•
Set Control Personality (Mode)
•
Nu ber of Assigned Channels
Display ode:
The LCD is backlit when you access the enus. This will switch off when left undisturbed for 10 seconds.
Personality:
The Studio One 100 V features a single War and Cold White LED engine which can be controlled through four Personality
odes:

Studio One 100 V User Manual 7 V1.0 Septe ber 2015
www.chroma
-
q.com
Display Ch Description
1-CTI 2 1 channel controls Color Te perature adjust ent for all LEDs and 1 channel for Intensity control of all
LEDs.
2-WW CW 2 1 channel controls all War White LEDs and 1 channel controls all Cold White LEDs.
3-Master The unit is set as the Master unit. All settings of the Master unit will be repeated on all Slave units.
4-Slave The unit is set as the Slave unit. All settings of the Slave units follow the Master unit.
Wireless IR Remote:
The Studio One 100 V can be controlled via wireless IR Re ote in standalone operation. The fixture is set in IR Re ote
control by selecting IR Re ote in the enu No DMX Present. Point the IR Re ote towards the fixture.
The IR Remote features buttons for the following control options:
•On and Off
•Fade In and Out
•White
Color and Effects Buttons applicable to the Color One 100 units:
•15 Colors
•4 Effects: Full Color Scroll (Flash), War Color Scroll (Strobe),
•Fade In/Fade Out, and Cold Color Scroll (S ooth)

Studio One 100 V User Manual 8 V1.0 Septe ber 2015
www.chroma
-
q.com
Control enu
•
Use the Up
UpUp
Up and Down
DownDown
Down arrows to navigate the control enu options
•
Press Enter
EnterEnter
Enter to select a control enu option
•
Press Enter
EnterEnter
Enter to save the setting, display shows Done and returns to the previous enu
•
Press Exit
ExitExit
Exit to return to the previous enu without saving
•
The display goes back to the Main Menu

Studio One 100 V User Manual 9 V1.0 Septe ber 2015
www.chroma
-
q.com
Main Menu
The Main Menu displays the following:
•Model na e
•DMX status
•DMX start address
•Personality (Control Mode)
•Nu ber of assigned channels
To set the DMX start address,
1. Fro the Main Menu, press Enter
EnterEnter
Enter.
..
.
2. Press Up
UpUp
Up or Down
DownDown
Down to adjust the DMX start address.
3. Press Enter
EnterEnter
Enter to save.
Display shows Done and returns to the Main Menu.
1-Personality
The Studio One 100 V can be set to operate in DMX controlled and standalone odes. Refer to the list below for
details.
To set the Personality,
1. Fro the Main Menu, press Up
UpUp
Up or Down
DownDown
Down to access 1-Personality.
2. Press Enter
Enter Enter
Enter and then Up
UpUp
Up or Down
DownDown
Down to select the ode.
3. Press Enter
EnterEnter
Enter to save.
The display shows Done, returns to 1-Personality and then the Main Menu.
Personality – Software Version 1.6
Display Ch Description
1-CTI 2 Color Te perature + Intensity
2-WW CW 2 War White + Cold White
3-Master 0 Set as aster unit in standalone
4-Slave 0 Set as slave unit in standalone

Studio One 100 V User Manual 10 V1.0 Septe ber 2015
www.chroma
-
q.com
2-No DMX Present
If DMX control signal fro an external source is not detected, various standalone output options can be
selected:
1-OFF Fixture has no light output
2-Hold Last Fixture holds the last valid DMX state
3-IR Re ote Fixture is controlled via re ote infrared control unit
4-Look 1 Fixture snaps to saved Look
5-Look 2 Fixture snaps to saved Look
6-Look 3 Fixture snaps to saved Look
7-Look 4 Fixture snaps to saved Look
8-Look 5 Fixture snaps to saved Look
To set the option when there is No DMX Present,
1. Fro the Main Menu, press Up
UpUp
Up or Down
DownDown
Down to access 2-No DMX Present.
2. Press Enter
EnterEnter
Enter, then press Up
Up Up
Up or Down
DownDown
Down to select the option.
3. Press Enter
EnterEnter
Enter to save.
The display shows Done, returns to 2-No DMX Present and then the Main Menu.

Studio One 100 V User Manual 11 V1.0 Septe ber 2015
www.chroma
-
q.com
3-Look Store
In this ode,
•
5 internal preset Looks are available for stand-alone operation (see No DMX Present).
•
Looks created fro an external DMX console can be recorded in any of the 5 Look nu bers and will be
preserved on power down.
•
Looks that have been recorded can be odified in stand-alone operation.
•
Looks will be returned to default setting if reset is perfor ed.
To recall a Look in stand-alone operation,
1. Fro the Main Menu, press Up
UpUp
Up or Down
DownDown
Down to access 3-Look Store.
2. Press Enter
EnterEnter
Enter and press Up
UpUp
Up or Down
DownDown
Down to select fro Look 1 to 5.
3. Press Up
UpUp
Up or Down
DownDown
Down to increase or decrease the color te perature “CT
CTCT
CT” and intensity “I
II
I” fro 0 to 100.
4. Press and hold Enter
EnterEnter
Enter to save the Look, the display shows Recorded and the Look turns On.
To record a Look created fro a re ote DMX console:
1. Set the fixture to the desired Personality.
2. Use an external DMX console to adjust the assigned channel levels and create the desired look or effect.
3. Fro the Main Menu, press Up
UpUp
Up or Down
DownDown
Down to select 3-Look Store
4. Press Enter
EnterEnter
Enter, press Up
UpUp
Up or Down
DownDown
Down to select the Look nu ber and the display shows Record?
5. Press Enter
EnterEnter
Enter to record the Look and the display shows Recorded.
To create or odify a Look in stand-alone operation:
1. Fro the Main Menu, press Up
UpUp
Up or Down
DownDown
Down to select 3-Look Store
2. Press Enter
EnterEnter
Enter, press Up
UpUp
Up or Down
DownDown
Down to recall the Look nu ber
3. Press Enter
EnterEnter
Enter and the display shows “CT” and “I” (Color Te perature and Intensity) at the top row and the
value below
4. Press Up
UpUp
Up or Down
DownDown
Down to increase or decrease the Intensity value.
5. Press and hold Enter
EnterEnter
Enter until the display shows Recorded.

Studio One 100 V User Manual 12 V1.0 Septe ber 2015
www.chroma
-
q.com
4-Technical
In this ode,
•
Software Version is displayed
•
DMX Data (value) of the channels are displayed
•
Internal te perature is displayed
•
The fixture can be set to 4 frequency options. The LED scan rate can be synchronised with the video
ca era to avoid a flickering effect.
Frequency options:
750 Hz 1500 Hz 3000 Hz 000 Hz
•
Calibration data of the channels are displayed
To display the Software Version,
1. Fro the Main Menu, press Up
UpUp
Up or Down
DownDown
Down to access 4-Technical
2. Press Enter
EnterEnter
Enter, the display shows the Software Version
To display DMX Data,
1. Fro the Main Menu, press Up
UpUp
Up or Down
DownDown
Down to access 4-Technical
2. Press Enter
EnterEnter
Enter, Up
UpUp
Up or Down
DownDown
Down and select DMX Data
3. Press Enter
EnterEnter
Enter, the display shows the DMX channel value
To display the te perature of the LED Engine in the fixture,
1. Fro the Main Menu, press Up
UpUp
Up or Down
DownDown
Down to access 4-Technical
2. Press Enter
EnterEnter
Enter, Up
UpUp
Up or Down
DownDown
Down and select Te perature
3. Press Enter
EnterEnter
Enter, the display shows the LED Engine Te perature
To set the Frequency,
1. Fro the Main Menu, press Up
UpUp
Up or Down
DownDown
Down to access 4-Technical
2. Press Enter
EnterEnter
Enter, Up
UpUp
Up or Down
DownDown
Down and select PWM Frequency
3. Press Enter
EnterEnter
Enter, Up
UpUp
Up or Down
DownDown
Down and select a frequency option
4. Press Enter
EnterEnter
Enter to save
The display shows Done and returns 4-Technical and then Main Menu.
To display the Calibration data,
1. Fro the Main Menu
Main MenuMain Menu
Main Menu, press Up
UpUp
Up or Down
DownDown
Down to access 4-Technical
2. Press Enter
EnterEnter
Enter, Up
UpUp
Up or Down
DownDown
Down and select Calibration
3. Calibration data of the channels are displayed

Studio One 100 V User Manual 13 V1.0 Septe ber 2015
www.chroma
-
q.com
5-Reset
To reset the fixture to the factory default settings,
1. Fro the Main Menu, press Up
UpUp
Up or Down
DownDown
Down to access 5-Reset
2. Press Enter
EnterEnter
Enter, display shows reset?
3. Press and hold Enter
EnterEnter
Enter for 2 seconds, display shows Hold for 2 sec. and Done after 2 seconds, then
back to the Main Menu.
All control enu co ands are reset to factory defaults:
DMX address 1
Personality CTI
No DMX Present Hold Last
Look Store 1
PWM Frequency 750Hz
2. DMX Protocol
DMX Personality:
Studio
StudioStudio
Studio One
OneOne
One 100
100100
100 V
VV
V
V1.
V1.V1.
V1.6
66
6
1-CTI
[2 ch]
2-WW CW
[2 ch]
Channel 1 Color Te perature War White
Channel 2 Intensity Cold White
Total 2 DMX channels 2 DMX channels
2.7 Thermal Performance
The internal cooling syste of the Studio One fixture is by convection and built with auto atic protection. The fixture’s
auto atic protection reduces the output when the internal te perature reaches the axi u li it due to extre e a bient
conditions.
3. Troubleshooting
Troubleshooting is a process of eli ination. First, rule out the other field factors (i.e. bad connections, faulty cables and
power supplies). For technical support and/or parts, please contact your selling dealer or the offices listed in this anual.
Symptom Possible Cause Solution
Fixture does not respond
to DMX control.
Set to wrong or different DMX address.
Bad cable connecting DMX control and fixture.
Bad in/through connection between adjacent
fixtures.
Check DMX address and Mode
settings.
Check/replace DMX run fro the
console.
Low LED output. Internal te perature is over the li it. Check area ventilation.

Studio One 100 V User Manual 14 V1.0 Septe ber 2015
www.chroma
-
q.com
4. Specification
4.1Technical Specifications
Product Code CHSONE100V
Net Di ensions**
(Without Fixings – W x H x D)
214 x 267 x 232 / 8.5" x 10.5" x 9" (Full open yoke)
Net Weight (Without Fixings) 3.8 kg / 8.5 lb
Shipping Di ensions –
Width x Height x Depth
406 x 228 x 292 / 16" x 9" x 11.5"
Shipping Weight 5.5 kg / 12 lb
Power & Connections
Power Supply Built-in
Power Input Rating 100-240V AC 50-60Hz 125VA
Power Factor 0.5
Power Consu ption 58W @ 120/230V AC
Idle Power Consu ption 3.5W @ 120V AC; 5.6W @ 230V AC
Inrush Current 15A @ 120V AC; 36A @ 230V AC
Typical Power & Current Measure ents done with all LEDs at axi u intensity. Measure ents ade at no inal
voltage. Allow for a deviation of +/- 10%.
Power connector In/Out powerCon
Data Connectors In/Out XLR 5-pin
Control Protocol ANSI E1.11 USITT DMX 512-A
Cooling Syste Convection
Operating Te perature 0°C to 40°C
Construction Cast achined alu iniu
Colour Black (custo colours available on request)
Built-In Hardware Split yoke, 6.25” Accessory Holder
IP Rating IP20
Approvals CISPR 15/EN55015& EN61547, FCC Part 15 Subpart B:2012 /
ICES-003:2012, CSA C22.2, UL 1573, IEC 60598
Control & Photo etric
LED Engines 1
LEDs Per Engine War White + Cold White
Control Modes 2 channels Color Te perature + Intensity, 2 channels War White + Cold White
Di ing Curve Theatrical
Wireless Control On / Off, Fade In, Fade Out
Hot Lu en Output 2,100
Optics Fully Ho ogenised
Bea Angle 18° (approx)
Bea Distribution Sy etrical direct illu ination
CCT 3,000K - 6,100K
CRI 86
La p Life L70 at 50,000 hours
**For exact easure ents please refer to the line drawings below

Studio One 100 V User Manual 15 V1.0 Septe ber 2015
www.chroma
-
q.com
4.2Drawings – Dimensions
5. aintenance
With care, the Studio One 100 requires little aintenance. However, as the unit is likely to be used in a stage environ ent
we reco end periodical internal inspection and cleaning of any resulting dust and cracked oil residue. If the front
enclosure requires cleaning, wipe with a ild detergent on a da p cloth.
