300C SRT8®
Information is current as of September 1, 2009
www.media.chrysler.com
Note: Information shown is based on data available at time of publication (September 1, 2009).
Specifications are valid for Europe and may vary in other international markets. Vehicle model availability
may change per individual markets.
Chrysler 300C SRT8®
SPECIFICATIONS
Dimensions are in millimeters (inches) unless otherwise noted.
GENERAL INFORMATION
Body Style
Four-door sedan
Assembly Plant
Magna Steyer, Graz, Austria
Vehicle Segment
E-Segment
ENGINE: 6.1-LITER HEMI®V-8
Availability
Standard
Type and Description
90-degree V-type, liquid-cooled
Displacement
6063 cu. cm (370 cu. in.)
Bore x Stroke
103.0 x 90.9 (4.06 x 3.58)
Valve System
Pushrod-operated overhead valves, 16 valves,
16 conventional hydraulic lifters, all with roller followers
Fuel Injection
Sequential, multi-port, electronic, returnless
Construction
Deep-skirt cast-iron block with cross-bolted main bearing caps,
aluminum alloy heads with hemispherical combustion chambers
Compression Ratio
10.3:1
Power
317 kW (431 hp DIN) @ 6000 rpm (70.6 hp DIN/L)
Torque
569 N•m (420 lb.-ft.) @ 4600 rpm
Max. Engine Speed
6200 rpm (electronically limited)
Fuel Requirement
95 RON unleaded petrol
Oil Capacity
6.6 L (7 qt.)
Coolant Capacity
13.25 L (14 qt.)
Emission Controls
Close-coupled 3-way catalyst with closed loop fuel control
Emission Class
Euro IV
Fuel Consumption
Urban Cycle
21.0 L/100 km
Ex-urban Cycle
9.9 L/100 km
Combined Cycle
14.0 L/100 km

5
300C SRT8®
Information is current as of September 1, 2009
www.media.chrysler.com
TRANSMISSION: FIVE-SPEED AUTOMATIC WITH AUTO STICK (W5A580)
Availability
Standard
Description
Adaptive electronic control, performance-tuned Auto Stick driver-
interactive manual control and electronically modulated torque
converter clutch
Gear Ratios
1st
3.59
2nd
2.19
3rd
1.41
4th
1
5th
0.83
Reverse
3.16
Final-drive Ratio
3.06
Overall Top-gear
2.54
DIMENSIONS AND CAPACITIES(d)
Wheelbase
3050 (120)
Track, Front
1600 (63.0)
Track, Rear
1605 (63.2)
Overall Length
5015 (197.4)
Overall Width
1880 (74.0)
Overall Height
1462 (57.6)
Ground Clearance
131 (5.2)
Frontal Area, sq. m (sq. ft.)
25.8 (2.4)
Fuel Tank Capacity, L (gal.)
72 (19)
Curb Weight, kg (lbs.)
1915 – 1955 (4222 – 4310)
Gross Vehicle Weight, kg (lbs.)
2365 (5214)
Maximum Trailer Mass (braked),
kg (lbs.)
1725 (3795)
Maximum Trailer Mass (unbraked),
kg (lbs.)
450 (990)
Maximum Tongue Load, kg (lbs.)
85 (187)
(d) All dimensions measured at curb weight with standard tires.
ACCOMMODATIONS
Seating Capacity, F/R
2/3
Front
Head room
942 (37.1)
Leg room
1024 (40.3)
Shoulder room
1510 (59.4)
Hip room
1402 (55.2)
Seat travel
Driver—270 (10.6), passenger—220 (8.66)
Recliner angle range
Driver—70º, passenger—69º

6
300C SRT8®
Information is current as of September 1, 2009
www.media.chrysler.com
Rear
Head room
966 (38.0)
Leg room
1020 (40.2)
Knee clearance
171.8 (6.8)
Shoulder room
1466 (57.7)
Hip room
1421 (55.9)
DIN Trunk Volume, L (cu. ft)
442 (15.6)
BODY
Layout
Longitudinal front engine, rear-wheel drive
Construction
Steel unibody
SUSPENSION
SRT-tuned Front and Rear
Front
Independent: SLA with tall spindle, dual lower ball joint, upper and
lower A arms, coil springs, monotube shocks
Rear
Independent: 5-Link with aluminum knuckle, coil springs,
monotube shocks, anti-roll bar
