Chrysler Pacifica Hybrid 2018 User manual

Pacifica Hybrid
OWNER’S MANUAL
First Edition Rev 1
Printed in the U.S.A.
18RUPHEV-126-AA
©2017 FCA US LLC. All Rights Reserved.
Chrysler is a registered trademark of FCA US LLC.

STICK WITH THE SPECIALISTS®
 PACIFICA HYBRID

VEHICLES SOLD IN CANADA
With respect to any Vehicles Sold in Canada, the name
FCA US LLC shall be deemed to be deleted and the name
FCA Canada Inc. used in substitution therefore.
DRIVING AND ALCOHOL
Drunken driving is one of the most frequent causes of
accidents.
Your driving ability can be seriously impaired with blood
alcohol levels far below the legal minimum. If you are
drinking, don’t drive. Ride with a designated non-
drinking driver, call a cab, a friend, or use public trans-
portation.
WARNING!
Driving after drinking can lead to an accident.
Your perceptions are less sharp, your reflexes are
slower, and your judgment is impaired when you
have been drinking. Never drink and then drive.
This manual illustrates and describes the operation of
features and equipment that are either standard or op-
tional on this vehicle. This manual may also include a
description of features and equipment that are no longer
available or were not ordered on this vehicle. Please
disregard any features and equipment described in this
manual that are not on this vehicle.
FCA US LLC reserves the right to make changes in design
and specifications, and/or make additions to or improve-
ments to its products without imposing any obligation
upon itself to install them on products previously manu-
factured.
Copyright © 2017 FCA US LLC

TABLE OF CONTENTS
SECTION PAGE
1INTRODUCTION ...................................................................3
2GRAPHICAL TABLE OF CONTENTS ......................................................7
3GETTING TO KNOW YOUR VEHICLE ...................................................13
4GETTING TO KNOW YOUR INSTRUMENT PANEL .........................................159
5SAFETY ........................................................................187
6STARTINGANDOPERATING.........................................................281
7INCASEOFEMERGENCY ...........................................................387
8SERVICING AND MAINTENANCE .....................................................439
9TECHNICAL SPECIFICATIONS ........................................................503
10 MULTIMEDIA ....................................................................515
11 CUSTOMER ASSISTANCE ............................................................593
12 INDEX..........................................................................599
1
2
3
4
5
6
7
8
9
10
11
12

INTRODUCTION
CONTENTS
䡵INTRODUCTION .........................4
䡵HOW TO USE THIS MANUAL ...............4
▫Essential Information ......................4
▫Symbols ...............................5
䡵WARNINGS AND CAUTIONS ................6
䡵VEHICLE MODIFICATIONS/ALTERATIONS .....6
1

INTRODUCTION
Dear Customer,
Congratulations on selecting your new vehicle. Be assured
that it represents precision workmanship, distinctive styl-
ing, and high quality. This Owner’s Manual has been
prepared with the assistance of service and engineering
specialists to acquaint you with the operation and mainte-
nance of your vehicle. It is supplemented by Warranty
Information, and customer oriented documents. In the
attached Warranty Booklet you will find a description of
the services that FCA offers to its customers, the Warranty
Certificate and the details of the terms and conditions for
maintaining its validity. Please take the time to read all of
these publications carefully before driving your vehicle for
the first time. Following the instructions, recommenda-
tions, tips, and important warnings in this manual will
help assure safe and enjoyable operation of your vehicle.
Be sure you are familiar with all vehicle controls, particu-
larly those used for braking, steering, transmission, and
transfer case shifting. Learn how your vehicle handles on
different road surfaces. Your driving skills will improve
with experience.
This Owner’s Manual describes all versions of this vehicle.
Options and equipment dedicated to specific markets or
versions are not expressly indicated in the text. Therefore,
you should only consider the information which is related
to the trim level, engine, and version that you have
purchased. Any content introduced throughout the Own-
er’s Information, that may or may not be applicable to your
vehicle, will be identified with the wording “If Equipped”.
All data contained in this publication are intended to help
you use your vehicle in the best possible way. FCA aims at
a constant improvement of the vehicles produced. For this
reason, it reserves the right to make changes to the model
described for technical and/or commercial reasons. For
further information, contact an authorized dealer.
NOTE: After reviewing the Owner’s Information, it should
be stored in the vehicle for convenient referencing, and
remain with the vehicle when sold.
When it comes to service, remember that your authorized
dealer knows your vehicle best, has factory-trained techni-
cians and genuine MOPAR® parts, and cares about your
satisfaction.
HOW TO USE THIS MANUAL
Essential Information
Consult the Table of Contents to determine which section
contains the information you desire.
4 INTRODUCTION

Since the specification of your vehicle depends on the items
of equipment ordered, certain descriptions and illustra-
tions may differ from your vehicle’s equipment.
The detailed index at the back of this Owner’s Manual
contains a complete listing of all subjects.
Symbols
Consult the following table for a description of the symbols
that may be used on your vehicle or throughout this
Owner’s Manual:
1
INTRODUCTION 5

WARNINGS AND CAUTIONS
This Owner’s Manual contains WARNINGS against oper-
ating procedures that could result in a collision, bodily
injury and/or death. It also contains CAUTIONS against
procedures that could result in damage to your vehicle. If
you do not read this entire Owner’s Manual, you may miss
important information. Observe all Warnings and Cau-
tions.
VEHICLE MODIFICATIONS/ALTERATIONS
WARNING!
Any modifications or alterations to this vehicle could
seriously affect its roadworthiness and safety and may
lead to a collision resulting in serious injury or death.
6 INTRODUCTION

GRAPHICAL TABLE OF CONTENTS
CONTENTS
䡵FRONT VIEW ............................8
䡵REAR VIEW .............................9
䡵INSTRUMENT PANEL .....................10
䡵INTERIOR ..............................11
2

FRONT VIEW
Front View
1 — Hood/Engine Compartment
2 — Headlights
3 — Wheels/Tires
4 — Windshield
5 — Charging Port Door
6 — Exterior Mirrors
7 — Doors
8 — Fuel Door
8 GRAPHICAL TABLE OF CONTENTS

REAR VIEW
Rear View
1 — Tail Lamps
2 — Rear Windshield Wiper
3 — Liftgate
2
GRAPHICAL TABLE OF CONTENTS 9

INSTRUMENT PANEL
Instrument Panel
1 — Air Vents 5 — Charge Indicator 9 — Headlight Switch
2 — Multifunction Lever 6 — Glove Compartment/Storage
3 — Instrument Cluster 7 — Push Button Ignition
4 — Windshield Wiper Lever 8 — Steering Wheel
10 GRAPHICAL TABLE OF CONTENTS

INTERIOR
Interior Features
1 — Power Window/Door Lock Switches 5 — Door Handle
2 — Electronic Gear Selector 6 — Climate Control
3 — Uconnect Radio 7 — Center Console
4 — Switch Panel 8 — Seats
2
GRAPHICAL TABLE OF CONTENTS 11

GETTING TO KNOW YOUR VEHICLE
CONTENTS
䡵HIGH VOLTAGE BATTERY..................18
䡵HIGH VOLTAGE CHARGING OPERATION ......20
▫SAE J1772 Charging Inlet ..................20
▫AC Level 1 Charging (120V, 15 Amp)..........20
▫AC Level 2 Charging (240V, 30 Amp)..........30
▫Charging Times .........................31
▫Vehicle Charge Indicators ..................32
▫Hybrid Electric Pages.....................34
䡵KEYS .................................37
▫KeyFob..............................37
䡵IGNITION SWITCH .......................46
䡵REMOTE STARTING SYSTEM — IF EQUIPPED . . .49
▫Remote Start Cancel Message — If Equipped ....49
▫How To Use Remote Start..................50
▫To Enter Remote Start Mode ................50
▫To Exit Remote Start Mode Without Driving The
Vehicle ...............................51
▫To Exit Remote Start Mode And Drive The
Vehicle ...............................51
▫Remote Start Comfort Systems — If Equipped . . .51
▫Remote Start Windshield Wiper De–Icer Activation
— If Equipped..........................51
▫General Information .....................52
䡵SENTRY KEY ............................52
▫Customer Key Programming ...............53
▫Replacement Keys .......................53
▫General Information .....................53
䡵VEHICLE SECURITY ALARM — IF EQUIPPED . . .54
▫Rearming Of The System ..................54
3

▫To Arm The System .....................54
▫To Disarm The System ...................54
䡵DOORS ...............................55
▫Manual Lock ...........................55
▫Central Lock/Unlock — If Equipped ..........58
▫Unlock Doors Automatically On Exit — If
Equipped .............................58
▫Keyless Enter-N-Go — Passive Entry .........58
▫Manual Sliding Side Door..................62
▫Power Sliding Side Door — If Equipped .......63
▫Hands-Free Sliding Doors — If Equipped.......66
▫Child Locks............................67
䡵SEATS ................................68
▫Manual Adjustment (Front Seats) — If Equipped .69
▫Manual Adjustment (Rear Seats) ............71
▫Power Adjustment (Front Seats) — If Equipped . .73
▫Heated Seats ...........................75
▫Ventilated Seats — If Equipped ..............76
▫Easy Entry Slide Second Row Seating .........77
▫Fold-Flat ..............................78
▫Second Row Removable Seat ...............78
▫Manually Folding Third Row Seats — If
Equipped .............................81
䡵HEAD RESTRAINTS ......................84
▫Head Restraints — Front Seats ..............84
▫Head Restraints — Second Row .............86
▫Head Restraints — Third Row ..............88
䡵STEERING WHEEL .......................89
▫Tilt/Telescoping Steering Column ............89
▫Heated Steering Wheel — If Equipped ........89
䡵MIRRORS ..............................90
▫Inside Day/Night Mirror — If Equipped ......90
▫Automatic Dimming Mirror — If Equipped .....91
▫Outside Mirrors ........................92
14 GETTING TO KNOW YOUR VEHICLE

▫Driver’s Outside Automatic Dimming Mirror — If
Equipped .............................92
▫Conversation Mirror .....................92
▫Power Mirrors — If Equipped ..............93
▫Outside Mirrors Folding Feature ............93
▫Heated Mirrors — If Equipped .............93
▫Power Folding Mirrors — If Equipped.........94
▫Illuminated Vanity Mirrors — If Equipped .....95
䡵EXTERIOR LIGHTS .......................95
▫Multifunction Lever .....................95
▫Headlight Switch ........................96
▫Daytime Running Lights — If Equipped .......96
▫High/Low Beam Switch ..................96
▫Automatic High Beam — If Equipped ........96
▫Flash-To-Pass ..........................97
▫Automatic Headlights — If Equipped .........97
▫Headlights On With Wipers — If Equipped .....98
▫Headlight Delay — If Equipped .............98
▫Lights-On Reminder .....................98
▫Front Fog Lights — If Equipped .............98
▫Turn Signals ...........................99
▫Lane Change Assist — If Equipped ..........99
▫Battery Protection .......................99
䡵INTERIOR LIGHTS ......................100
▫Courtesy/Interior Lighting ................100
䡵WINDSHIELD WIPER AND WASHERS ........102
▫Windshield Wiper Operation ...............102
▫Rain Sensing Wipers — If Equipped .........104
▫Rear Wiper And Washer ..................105
䡵CLIMATE CONTROLS ....................105
▫Overview ............................105
▫Automatic Temperature Control (ATC) — If
Equipped ............................
113
▫Operating Tips ........................120
3
GETTING TO KNOW YOUR VEHICLE 15

䡵WINDOWS ............................122
▫Power Windows........................122
䡵TRI-PANE PANORAMIC SUNROOF — IF
EQUIPPED ............................125
▫Opening Sunroof .......................126
▫Closing Sunroof ........................127
▫Wind Buffeting ........................127
▫Power Sun Shade — If Equipped............127
▫Pinch Protect Feature ....................128
▫Sunroof Maintenance ....................128
▫Ignition Off Operation ...................128
䡵HOOD ...............................128
▫Opening .............................128
▫Closing ..............................130
䡵LIFTGATE .............................130
▫Opening .............................130
▫Closing .............................131
▫Power Liftgate — If Equipped ..............132
▫Hands-Free Liftgate — If Equipped ..........134
▫Cargo Area Features ....................136
䡵GARAGE DOOR OPENER — IF EQUIPPED . . . .136
▫Before You Begin Programming HomeLink.....137
▫Canadian/Gate Operator Programming .......140
▫Using HomeLink .......................141
▫Security..............................141
▫Troubleshooting Tips ....................141
▫General Information .....................142
16 GETTING TO KNOW YOUR VEHICLE

䡵INTERNAL EQUIPMENT ..................143
▫Storage ..............................143
▫Power Outlets .........................146
▫Power Inverter — If Equipped..............150
▫Cigar Lighter — If Equipped...............150
▫Smoker’s Package Kit — If Equipped ........151
▫Overhead Storage With Sunglass Storage ......151
䡵ROOF LUGGAGE RACK — IF EQUIPPED ......152
▫Deploying The Crossbars .................153
▫Stowing The Crossbars ...................155
3
GETTING TO KNOW YOUR VEHICLE 17

HIGH VOLTAGE BATTERY
Your vehicle is equipped with a Lithium-ion high voltage
battery that is used to power the electric powertrain
systems and the 12 volt vehicle electrical system.
The high voltage battery is located under the middle
section of the vehicle, below and in front of the second row
seating. The high voltage battery is maintenance free and
designed to last for the life of the vehicle.
Lithium-ion batteries provide the following benefits:
•Lithium-ion batteries are much lighter than other types
of rechargeable batteries of the same size.
•Lithium-ion batteries hold their charge; they only lose
approximately 3 percent of their charge per month.
•Lithium-ion batteries have no memory, which means
that you do not have to completely discharge them
before recharging, as with some other batteries.
•Lithium-ion batteries can be recharged and discharged
thousands of times.
High Voltage Battery Service Disconnect
The High Voltage Battery Service Disconnect is located
under the access panel, in front of the second row passen-
ger seating.
If your vehicle requires high voltage battery service, see
your authorized dealer.
WARNING!
Never try to remove the high voltage service discon-
nect. The high voltage service disconnect is used when
your vehicle requires service by a trained technician at
an authorized dealer. Failure to follow this warning
can cause severe burns or electrical shock that may
result in serious injury or death.
Disposal of the High Voltage Battery
Your vehicle’s high voltage battery is designed to last the
life of your vehicle. See your authorized dealer for infor-
mation on the disposal of the battery if it should require
replacement.
18 GETTING TO KNOW YOUR VEHICLE
