Cimetrics B6130 Quick guide

1
1
Your B6130
device must be configured before use!
(NOTE: An Ethernet HUB or crossover cable is required)
Access the B6130 configuration screen using your browser. Here is an explanation of
how to do this:
Connect the B6130 Ethernet connector to an Ethernet hub, and run another Ethernet cable from that hub to
your laptop or PC. Make sure that the laptop or PC is the only other unit in this small LAN. NOTE: If you do
not have a hub, you can use a "crossover cable" to connect between the B6130 and your laptop.
Set your PC's IP address to 192.168.88.90 with a subnet mask of 255.255.255.252 .

2
2
Open your browser andenter thefollowing URL: http://192.168.88.89
You will be prompted to login:
User=admin password=admin
The Cimetrics default password is a secure mixture of letters and numbers but also can be
remembered because of the relationships of these keys on your computer keyboard.
From within the browser interface you can change all settings in the entry fields to configure your
router
For improved access security, you should change your password from the default values. Make
sure you SAVE your new password! When you press "Activate Configuration" and “confirm”
then the configuration process is completed.
Now disconnect your laptop and connect the B6130 into your BACnet networks.
