Circuit Slices ADSR User manual

Circuit Slices, LLC ADSR Envelope Generator User Manual CS017n
CS017
-
UM
v
3
.0 www.circuitslices.com
1
The Circuit Slices ADSR module is a re-triggerable envelope generator for modular Eurorack-compatible
synthesizers. This popular module has been revised (V4) to include a jumper option to limit the output
to 5V, which allows the module to be used with a wider variety of systems. The front panel includes a
green LED that indicates the state of the output.
Specifications for the CS ADSR
Attack time: <1mS to over 5s
Decay time: <1mS to over 12s
Sustain level: 0 to 10V OR 0 to 5V with a shorting jumper on J5
Release time: <1mS to over 12s
Output level: 10V OR 5V with shorting jumper on J5
Gate threshold: 2.5V
Power (standby): +12VDC @ 3mA, -12DC @ 2mA
Depth: 35mm (with power cable plugged in)
Panel width: 6 HP
Features for CS ADSR
“TRIG” input for re-triggered attacks
Logarithmic potentiometers for A, D, R
High-quality anodized aluminum panel
User selectable power-bus ‘gate’ using PCB shorting jumper (J4)
Low power consumption
Includes power cable, case screws, and shorting jumpers
Narrow 6 HP width
User selectable 5V or 10V output using PCB shorting jumper (J5) -- for PCB V4.0 and above

Circuit Slices, LLC ADSR Envelope Generator User Manual CS017n
CS017
-
UM
v
3
.0 www.circuitslices.com
2
Installation
The ADSR module is ready to install in your Eurorack. Simply mount the panel using the supplied screws
and route the ribbon-cable power connector to your power bus.
Be careful making the connection to your power bus and double check your connection before applying
power. The red stripe on the ribbon cable must be toward the -12V pin on the power bus.
WARNIN : Reversed power may damage the module and your power supply.
The ADSR module includes a printed circuit board jumper option that enables the use of the power bus
GATE signal. See “The Bus Gate” paragraph below.
The Trigger Input
A Gate input alone will produce the typical ADSR response at the Output:
A Gate input accompanied with multiple triggers will produce the following response:

Circuit Slices, LLC ADSR Envelope Generator User Manual CS017n
CS017
-
UM
v
3
.0 www.circuitslices.com
3
Some MIDI-CV interfaces will produce a trigger output with every Note-On event, even as the gate signal
stays high throughout. This would normally happen when playing “legato” on a keyboard -- when
playing a series of notes and only releasing the last note after the next is played. This gate and trigger
system was typical of some older analog synthesizers.
If you don’t have a keyboard or MIDI-CV interface that produces a trigger output, you will still find the
re-trigger input useful. As an example, imagine using a master or MIDI clock signal in your patch to
synchronize a sequence. The clock signal could be patched into the ADSR’s TRIG input. This would
produce an ADSR output with an initial attack, when the gate is high, and more attacks for every clock
pulse, until the gate goes back low. Interesting modulation-like effects -- or multiple attacks -- would be
produced and the effect would be synchronized to the over-all clock.
The Bus Gate
The Circuit Slices ADSR module can be triggered from the GATE signal on the Eurorack power
connection. The standard power bus includes, along with power, CV and GATE. If you would like to
have your ADSR module controlled from the system bus, simply install a shorting jumper across the two
pins of header J4. This header is found on the circuit board, below the power connector.
10V or 5V Output Level
Most Eurorack-format modules will accept (and attenuate) the full 10V swing from this module. If you
must limit the output to a maximum of 5V, simply install the supplied shorting jumper to J5. This
jumper-header is below the power connector on the printed circuit board, to the right of J4.
This module is warranted for one year with parts, under normal use – not including the application of
reverse or over-voltage power by customer. Return shipping to Circuit Slices from customer not
included. Return to Circuit Slices, LLC for repairs. Circuit Slices, LLC reserves the right to replace the
module if necessary. Please keep your receipt / packing slip for warranty information.
