INSTALLATION GUIDE
(M273A01-03-19A)
Canopies
PVS2

2
PVS2
Installation Guide

SAFETY PRECAUTIONS
DISCLAIMER
CIRCUTOR, SA reserves the right to make modi cations to the device or the unit speci ca-
tions set out in this instruction manual without prior notice.
CIRCUTOR, SA on its web site, supplies its customers with the latest versions of the device
speci cations and the most updated manuals.
www.circutor.com
CIRCUTOR, recommends using the original cables and accessories that are
supplied with the device.
DANGER
Warns of a risk, which could result in personal injury or material damage.
ATTENTION
Indicates that special attention should be paid to a speci c point.
Follow the warnings described in this manual with the symbols shown below.
If you must handle the unit for its installation, start-up or maintenance, the following
should be taken into consideration:
Incorrect handling or installation of the unit may result in injury to personnel as well as damage
to the unit. In particular, handling with voltages applied may result in electric shock, which may
cause death or serious injury to personnel. Defective installation or maintenance may also
lead to the risk of re.
Read the manual carefully prior to connecting the unit. Follow all installation and maintenance
instructions throughout the unit’s working life. Pay special attention to the installation stan-
dards of the National Electrical Code.
Refer to the instruction manual before using the unit
In this manual, if the instructions marked with this symbol are not respected or carried out correctly, it can
result in injury or damage to the unit and /or installations.
CIRCUTOR, SA reserves the right to modify features or the product manual without prior noti cation.
3
Installation Guide
PVS2

CONTENTS
SAFETY PRECAUTIONS ��������������������������������������������������������������������������������������������������������������������������������������� 3
DISCLAIMER ���������������������������������������������������������������������������������������������������������������������������������������������������������� 3
CONTENTS������������������������������������������������������������������������������������������������������������������������������������������������������������� 4
REVISION LOG������������������������������������������������������������������������������������������������������������������������������������������������������� 6
1�- WARRANTY CERTIFICATE FOR THE CANOPIES ����������������������������������������������������������������������������������������� 7
2�- FORESEEABLE MISUSE���������������������������������������������������������������������������������������������������������������������������������� 8
3�- PVS2 MODELS�������������������������������������������������������������������������������������������������������������������������������������������������� 9
4�- COMPONENTS������������������������������������������������������������������������������������������������������������������������������������������������ 11
4�1�- FEET AND WINGS ���������������������������������������������������������������������������������������������������������������������������������� 12
4�2�- BEAMS, PROFILES AND FASTENING OF MODULES ������������������������������������������������������������������������� 13
5�- PREPARATION OF THE INSTALLATION������������������������������������������������������������������������������������������������������� 14
5�1�- STUDY INTO THE ELECTRICAL PROJECT������������������������������������������������������������������������������������������ 14
5�1�1�- STANDARD INSTALLATION WITH RECHARGE POINT IN START FOOT ���������������������������������� 14
5�1�2�-STANDARD INSTALLATION WITH RECHARGE POINT IN START AND END FOOT������������������ 14
5�1�3�- MAJOR INSTALLATION ����������������������������������������������������������������������������������������������������������������� 15
5�1�4�- INTERNAL CONNECTION OF FEET���������������������������������������������������������������������������������������������� 15
5�2�- PREPARATION OF FOOTINGS��������������������������������������������������������������������������������������������������������������� 16
5�3�- EARTH CONNECTION����������������������������������������������������������������������������������������������������������������������������� 17
5�4�- ASSEMBLE TEMPLATES������������������������������������������������������������������������������������������������������������������������ 17
5�5�- FILLING THE FOOTINGS ������������������������������������������������������������������������������������������������������������������������ 18
5�6�- REMOVE UPPER TEMPLATE ����������������������������������������������������������������������������������������������������������������� 18
6�- ASSEMBLY OF FEET AND WINGS ��������������������������������������������������������������������������������������������������������������� 19
6�1�- FOOT INSTALLATION (A) ��������������������������������������������������������������������������������������������������������������������� 19
6�2�- FOOT INSTALLATION (B) ��������������������������������������������������������������������������������������������������������������������� 20
6�3�- INSTALLATION OF FEET REINFORCEMENT��������������������������������������������������������������������������������������� 21
6�4- INSTALLATION OF WINGS (A) ��������������������������������������������������������������������������������������������������������������� 22
6�5- ALIGNMENT OF THE FEET��������������������������������������������������������������������������������������������������������������������� 23
7�- ASSEMBLY OF BEAMS���������������������������������������������������������������������������������������������������������������������������������� 24
7�1- FITTING OF ANGLES ������������������������������������������������������������������������������������������������������������������������������ 24
7�2- BEAM ANGLES���������������������������������������������������������������������������������������������������������������������������������������� 25
7�3 - FITTING OF BEAMS ����������������������������������������������������������������������������������������������������������������������������� 26
7�4 - INSTALLATION OF EARTHING POINT ������������������������������������������������������������������������������������������������� 27
8�- PROFILES AND MODULES���������������������������������������������������������������������������������������������������������������������������� 28
8�1 - INTERMEDIATE PROFILES ������������������������������������������������������������������������������������������������������������������� 28
8�2 - FINAL PROFILES������������������������������������������������������������������������������������������������������������������������������������ 28
8�3 - PREPARATION OF PROFILES ������������������������������������������������������������������������������������������������������������� 29
8�4 - FITTING OF INTERMEDIATE PROFILES (1) ����������������������������������������������������������������������������������������� 30
8�5 - FITTING OF INTERMEDIATE PROFILES (2) ����������������������������������������������������������������������������������������� 31
8�6 - FITTING OF FINAL PROFILES (3) ��������������������������������������������������������������������������������������������������������� 32
8�7 - FITTING OF FINAL PROFILES (4) ��������������������������������������������������������������������������������������������������������� 33
8�8 - SETTING MODULES A ��������������������������������������������������������������������������������������������������������������������������� 34
8�9 - SETTING MODULES B ��������������������������������������������������������������������������������������������������������������������������� 35
8�10 - CONNECTION OF STRINGS ���������������������������������������������������������������������������������������������������������������� 36
9�- FINAL FOUNDATIONS������������������������������������������������������������������������������������������������������������������������������������ 37
10�- INSTALLATION OF THE CHARGER ������������������������������������������������������������������������������������������������������������ 38
11�- USAGE AND MAINTENANCE ���������������������������������������������������������������������������������������������������������������������� 40
11�1 - INSTALLATION�������������������������������������������������������������������������������������������������������������������������������������� 40
11�1�1�- ASSEMBLY ACCORDING TO MANUFACTURER SPECIFICATIONS ���������������������������������������� 40
11�1�2�- DIFFICULTIES AND VARIATIONS DURING ASSEMBLY ������������������������������������������������������������ 40
11�1�3�- BONDING OF PARTS AND TIGHTENING TORQUE ������������������������������������������������������������������� 40
11�1�4�- FOUNDATIONS, ALIGNMENT AND LEVELLING OF THE CANOPIES �������������������������������������� 40
11�1�5�- LOCATION AND CHARACTERISTICS OF THE INSTALLATION ZONE������������������������������������� 40
11�2 - USE AND UPKEEP��������������������������������������������������������������������������������������������������������������������������������� 41
11�2�1�- STRUCTURAL ELEMENTS MUST NOT BE MODIFIED�������������������������������������������������������������� 41
11�2�2�- USAGE OVERLOAD INDICATED IN THE PROJECT MUST NOT BE EXCEEDED ������������������� 41
11�2�3�- THE ORIGINAL STATUS OF THE ELEMENTS OF THE CANOPY CANNOT BE MODIFIED ���� 41
11�2�4�- AVOID THE CONTACT OF THE STEEL WITH OXIDISING OR AGGRESSIVE ELEMENTS������ 41
11�3 - REVISION AND MAINTENANCE ��������������������������������������������������������������������������������������������������������� 42
11�3�1�- GENERAL CONDITIONS �������������������������������������������������������������������������������������������������������������� 42
4
PVS2
Installation Guide

11�3�2�- REVISION AND MAINTENANCE TASKS������������������������������������������������������������������������������������� 42
11�3�3�- CASES THAT INVOLVE SPECIAL REVIEWS������������������������������������������������������������������������������ 43
12�- MAINTENANCE AND TECHNICAL SERVICE����������������������������������������������������������������������������������������������44
5
Installation Guide
PVS2

REVISION LOG
Table 1: Revision log�
Date Revision Description
08/19 M273A01-01-19A Initial version
Note : The images of the devices are for illustrative purposes only and may differ from the
original device.
6
PVS2
Installation Guide

1�- WARRANTY CERTIFICATE FOR THE CANOPIES
10 year Warranty for defects in materials or manufacturing aws
CIRCUTOR hereby guarantees, for a period of 10 years, from the date of delivery to the buyer,
that its canopies are free of any defect in their materials or manufacture that hinder their normal
operation under proper conditions of usage, installation and maintenance.
If, at any time, during the period of validity of this guarantee, the appearance of defects in
their materials or their manufacture occurs, CIRCUTOR undertakes to replace the defective
structure.
The guarantees contained in this Certicate will be provided by CIRCUTOR subject to the
general terms and conditions expressed below:
Exclusions and Limitations of Guarantees
Those damages and faults established herein will be exempt from the warranty rights whenever
these arise from:
1�- Accidents or negligent, improper or unsuitable use.
2�- Failing to respect the installation, usage and maintenance instructions set forth.
CIRCUTOR reserves the right to supply a different model of structure to handle the accepted
warranty claims, for replacement or expansion, in the event that the original model was no
longer manufactured.
Admitted usage
This type of canopy is a metallic structure with two basic functions:
To support a cover of photovoltaic solar modules or thermal solar panels, for the production
of running or hot water respectively.
To protect motor vehicles, motorcycles, bicycles, people, etc. from the sun and the rain under
the cover.
7
Installation Guide
PVS2

2�- FORESEEABLE MISUSE
This type of canopy is not intended to:
To withstand overloads higher than those indicated in the corresponding certicate of
technical characteristics, due to meteorological conditions (snow and wind) of the site and the
own weight of the solar panels.
People will not be allowed to climb onto the canopy, with the exception of those who access
it to carry out maintenance and assembly tasks. No more than one person with their personal
work material (100 kg) may climb onto the canopy.
It is not allowed to cover the sides, front or rear with any type of enclosure that wholly or
partially prevents the passage of the wind.
The installation of posters or jutting elements is not allowed, nor in general, any added
element that increases the surface exposed to the wind.
Only the assembly of original parts and components supplied by CIRCUTOR is allowed.
CIRCUTOR will not be held liable for any unauthorised modication to the canopy, once the
same has been put into service.
If a wall is installed along the entire length of the canopy, a special study will be required to
vary the coefcient of obstruction contemplated in the calculation.
Figure 1: Variation of the obstruction coefcient.
If the canopy is installed in the vicinity of a height change or on a steep wall or mound that
increases the height of the canopy above the ground level to more than 3 m in height at the
centre point of the roong, a special study will be required owing to the modication of the
pressure and suction coefcients considered in the calculation.
8
PVS2
Installation Guide

3�- PVS2 MODELS
PVS2-2
3 5 17
2578
11°
PVS2-3
3 5 17
2578
11°
PVS2-4
3 5 17
2578
11°
PVS2-5
3 5 17
2578
11°
PVS2-6
3 5 17
2578
11°
PVS2-8
3 5 17
2578
11°
PVS2-10
3 5 17
2578
11°
Figure 2: PVS2 models�
9
Installation Guide
PVS2

Table 2: PVS2 models�
Model Length kWp Modules Feet
PVS2-2 5,0 m 4,20 kWp 15 1
PVS2-3 8,0 m 6,72 kWp 24 2
PVS2-4 10,0 m 8,40 kWp 30 2
PVS2-5 13,0 m 10,92 kWp 39 2
PVS2-6 15,0 m 12,60 kWp 45 3
PVS2-8 20,0 m 16,80 kWp 60 3
PVS2-10 25,0 m 21,00 kWp 75 4
10
PVS2
Installation Guide

4�- COMPONENTS
M
WING
FOOT
PPV10APLI
BEAM
Figure 3: PVS2 components�
11
Installation Guide
PVS2

4.1.- FEET AND WINGS
DIN 931
DIN 6923
DIN 934
DIN 9021
M20X280
M10
M24 Zn
M24
M20
M24
(17u. )
(16u. )
(24u. )
(4u. )
(26u. )
(8u. )
DIN 603 M10X25
M10X50 (8u. )
(8u. )
M20 (17u. )
RIGHT VIEW
LEFT VIEW
[M239700000000]
WING START
[M326100000000]
PV ANGLE BEAM C
[M302100000000]
V WING ANGLE
[M2L5700000001]
PVS CNJTO. PATA CON REG.
12
PVS2
Installation Guide

4.2.- BEAMS, PROFILES AND FASTENING OF MODULES
MODULES
BEAMS
PLACKET
M10
M14
Model MODULES BEAM M103200000002 M109200000002 S273200000001 S268100000001 TORN M104200000005 M106200000001 M108A00000000 TORN
PVS2-2 15 4 4 2 0 0 24 10 60 12 12
PVS2-3 24 4 7 0 0 2 36 16 96 18 18
PVS2-4 30 4 92 2 0 52 20 120 22 22
PVS2-5 39 412 2 0 0 56 26 156 24 24
PVS2-6 45 8 14 2 3 0 76 30 180 28 28
PVS2-8 60 8 18 210 84 40 240 40 40
PVS2-10 75 12 23 1 1 1 104 50 300 48 48
13
Installation Guide
PVS2

5�- PREPARATION OF THE INSTALLATION
5.1.- STUDY INTO THE ELECTRICAL PROJECT
5�1�1�- STANDARD INSTALLATION WITH RECHARGE POINT IN START FOOT
Lowering of strings (DC wiring) per start foot.
Power supply to recharging point in start foot (AC wiring).
Figure 4: Standard installation with recharging point in start foot�
5�1�2�-STANDARD INSTALLATION WITH RECHARGE POINT IN START AND END FOOT
Lowering of strings (DC wiring) per start foot.
Power supply to recharging point in start and end foot (AC wiring).
Figure 5: Standard installation with recharging point in start and end foot�
14
PVS2
Installation Guide

5�1�3�- MAJOR INSTALLATION
Lowering of strings (DC wiring) per start and central foot.
Power supply of recharging points in each foot. (AC wiring)
Figure 6: Major installation�
5�1�4�- INTERNAL CONNECTION OF FEET
STRINGS
CONDUCTION OF DC
WIRING THROUGH THE
BEAMS
EARTH
CONNECTION
(SEE POINT 7.4)
Figure 7:Internal connection of feet�
15
Installation Guide
PVS2

5.2.- PREPARATION OF FOOTINGS
MAX
10º
300mm
MAX
D
D
CASKET
REINFORCED
TWIN-LAYER PIPE
-PROJECTION OF A LENGTH OF 6 M APPROXIMATELY FROM CASKET SPLICE FOR THE
LOWERING OF STRINGS, DC WIRING.
-IF IT IS ONLY FOR AC WIRING OF THE CHARGER, PROJECTION OF 4 M APPROXIMATELY
OF CASKET SPLICE.
LEAVE CABLES IN
PLACE
CASKET FOOTING
FOOTING ALIGNMENT
SPLICE BOX
Figure 8: Preparation of footings�
16
PVS2
Installation Guide

5.3.- EARTH CONNECTION
ON EACH FOOT
CASKET
FOOT TUBE
Figure 9: Earth connection�
5.4.- ASSEMBLE TEMPLATES
Torque kp·m 71
M24
36x
50
50
500
950
Figure 10: Assembly of templates�
17
Installation Guide
PVS2

5.5.- FILLING THE FOOTINGS
Figure 11: Filling the footings�
5.6.- REMOVE UPPER TEMPLATE
Figure 12: Remove upper template�
18
PVS2
Installation Guide

6�- ASSEMBLY OF FEET AND WINGS
6.1.- FOOT INSTALLATION (A)
Torque kp·m 71
M24 D24
6x 6x
PULL PIPES WHEN
LIFTING
DO NOT STEP ON TUBES
OR PIPES
Figure 13: Foot installation (A)
19
Installation Guide
PVS2

6.2.- FOOT INSTALLATION (B)
Torque kp·m 71
M24 D24
6x 6x
Figure 14: Foot installation (B)
20
PVS2
Installation Guide
Other manuals for PVS2
1
Table of contents
Other Circutor Tent manuals
Popular Tent manuals by other brands

GigaTent
GigaTent GT005 owner's manual

Outdoor Revolution
Outdoor Revolution Movelite Oxygen 3 quick start guide

Caravan canopy
Caravan canopy MAGNUM Series Reference manual

PNH
PNH Super Dome instruction manual

Profizelt24
Profizelt24 PVC-Tent 6x12 m Assembly instruction

REDVERZ
REDVERZ SOLO EXPEDITION Setup instructions
