Meraki-managed Catalyst 9300 Series Installation Guide
About this Guide
This guide provides instruction on how to install and configure your C9300 series switch in the Meraki-managed mode.
Product Overview
Models
Model number Description
C9300-24T Stackable Layer-3 24-port Gbe switch with hot-swappable 10G/40G modular uplinks, hot-swappable power supplies
and hot-swappable fans
C9300-24P Stackable Layer-3 24-port Gbe POE+ switch with hot-swappable 10G/40G modular uplinks, hot-swappable power
supplies and hot-swappable fans
C9300-24U Stackable Layer-3 24-port Gbe UPOE/802.3bt switch with hot-swappable 10G/40G modular uplinks, hot-swappable
power supplies and hot-swappable fans
C9300-24UX Stackable Layer-3 24-port mGbe UPOE/802.3bt switch with hot-swappable 10G/40G modular uplinks, hot-swappable
power supplies and hot-swappable fans
C9300-48T Stackable Layer-3 48-port Gbe switch with hot-swappable 10G/40G modular uplinks, hot-swappable power supplies
and hot-swappable fans
C9300-48P Stackable Layer-3 48-port Gbe POE+ switch with hot-swappable 10G/40G modular uplinks, hot-swappable power
supplies and hot-swappable fans
C9300-48U Stackable Layer-3 48-port Gbe UPOE/802.3bt switch with hot-swappable 10G/40G modular uplinks, hot-swappable
power supplies and hot-swappable fans
C9300-48UXM Stackable Layer-3 36-port 2.5Gbe and 12-port mGbe UPOE/802.3bt switch with hot-swappable 10G/40G modular
uplinks, hot-swappable power supplies and hot-swappable fans
C9300-48UN Stackable Layer-3 48-port 5Gbe UPOE/802.3bt switch with hot-swappable 10G/40G modular uplinks, hot-swappable
1

power supplies and hot-swappable fans
Technical Specifications
•Each model has 1 dedicated management interface
•Each model has two 120G stack ports
•Each of the model has modular uplinks where you can choose from 3 different options of 10G and 40G SFP+ and QSFP+ uplink modules
•Operating temperature for each of the model: -5°C to 45°C
•Storage and Transportation Temperature: -20°C - 70°C
•umidity: 5 to 90%
Model Interfaces PoE/ UPoE
Capabilities
Power Load (idle/max) Available PoE Hot Swap Power Supply
C9300-24T 24 x 1GbE RJ45 n/a 79.2 / 99 W - Yes, Dual
C9300-24P 24 x 1GbE RJ45 PoE 84.1 / 554.4 W 445W Yes, Dual
C9300-24U 24 x 1GbE RJ45 UPoE/802.3bt 85.4 / 990.3 W 830W Yes, Dual
C9300-24UX 24 x mGbE RJ45 UPoE/802.3bt 162.7 / 809.9 W 560W Yes, Dual
C9300-48T 48 x 1GbE RJ45 n/a 83.9 / 109.9 W - Yes, Dual
C9300-48P 48 x 1GbE RJ45 PoE 92.6 / 555 W 437W Yes, Dual
C9300-48U 48 x 1GbE RJ45 UPoE/802.3bt 145 / 844.9 W 822W Yes, Dual
C9300-48UXM 36 x 100M/1G/2.5G +
12 x 100M/1G/2.5G/5G/10G
UPoE/802.3bt 218.5 / 785.5 W 490W Yes, Dual
C9300-48UN 48 x 100M/1G/2.5G/5G UPoE/802.3bt 157.9 / 843.8 W 645W Yes, Dual
Product View and Physical Features
Front Panel Components
Inactive components: When operating in the Meraki-managed mode, the C9300 will disable the STAT, Duplex, Speed, Stack, PoE, XPS and
Console LEDs, as well as the USB Type-A storage and the USB Type-B console ports.
2

Item Component Purpose
1 Blue Beacon LED
Reports systems status (along with the System LED)
Please refer to the LED indicators in the Meraki-managed mode table for details
2 Reset (Mode) button Reset switch to factory settings.
Please refer to the Factory Reset Process section for details
3System LED Reports status of the (along with the Blue Beacon LED)
4 Active LED Identifies the switch's role in the stack
5 StackPower LED Indicates StackPower operation states.
LED Indicators in the Meraki-managed mode
System status Blue Beacon LED System LED
1 Switch is powered off or not receiving power.
Off
Off
2 Switch if powered on and is loading the bootstrap firmware. Solid amber
3 Switch is loading the operating system. Blinking green
4 System error: Switch failed to load operating system or bootstrap firmware. Blinking amber
5
Setting up local management and cloud-connectivity requirements.
Note: If the switch has not been assigned a static management IP previously, it will
try to obtain an IP via DHCP in this stage. Flashing Blue
Cycling b/w green & amber
(OR blinking green)
6 System error: Switch failed to complete local provisioning. Solid amber
7 Switch is completely provisioned but unable to connect to Meraki cloud.
Solid Blue
Solid amber
8 Firmware download / upgrade in progress Blinking green
9 There is a fault with the power supply, fan, or network module (not traffic-related) Blinking amber
3

10 Switch is fully operational and connected to the Meraki cloud Solid green
Back Panel Components
Item Component LED Status Description
1 Management Interface (Aux Port) Green Connected, used for easy access to the local status page
2 Stack Ports N/A Stack Cables are connected here
3 Redundant Fans Green Active and operational
4 StackPower Ports N/A StackPower cables are connected here
5 Power Supplies Green Active and functional power supplies
Factory Reset Button
To perform a factory reset, keep the mode button pressed for 20 seconds or more. The switch will reboot and revert to its original factory settings.
Safety and Warnings
These operations are to be taken with respect to all local laws. Please take the following into consideration for safe operation:
• Power off the unit before you begin. Read the installation instructions before connecting the system to the power
source.
• Before you work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar with
standard practices for preventing accidents.
• Read the mounting instructions carefully before beginning installation. Failure to use the correct hardware or to
follow the correct procedures could result in a hazardous situation to people and damage to the system.
• This product relies on the building’s installation for short-circuit (overcurrent) protection. Ensure that the protective
device is rated not greater than: 15 A, 125 Vac, or 10A, 240 Vac.
• Please only power the device with the provided power cables to ensure regulatory compliance.
C9300-M Deployment Best Practices
Before powering on devices or connecting an uplink port to the LAN, ensure to follow the steps outlined below or watch this short video.
Inactive components: When operating in the Meraki-managed mode, the C9300 will disable the RJ45 console port.
4

Configure your Dashboard Network
To add devices to your Meraki dashboard network please refer to the Creating a Dashboard Account and Organization document.
Check and Set Network Firmware
Ensure that the switch network is set to the correct firmware version. As of September 24th, 2021 MS 14.31 is the recommended version. Recommended
versions are subject to change and are available in each dashboard by navigating to Organization > Firmware Upgrades
You can refer to Managing Firmware Upgrades for steps to set network firmware to the desired version.
Check and Configure Upstream Firewall Settings
If a firewall is in place, it must allow outgoing connections on particular ports to particular IP addresses. The most current list of outbound ports and IP addresses
for your particular organization can be found under elp → Firewall info. The help button is located on the top right corner of any dashboard page. For more
information refer to Upstream Firewall Rules for Cloud Connectivity.
Stacking
For stacking please refer to this section Stack Cabling Installation
Assigning an IP Address
All switches must be assigned routable IP addresses. These IP addresses can be dynamically assigned via D CP or statically assigned. C9300 switches can
support a total count of 1000 VLANs per stand-alone switch or switch stack. VLAN ID 1-1000 are configured by default, however, the active VLANs can be
changed via the local status page or dashboard. When installing an C9300, it is important to ensure that any D CP services or IP address assignments used for
management fall within the active VLAN range.
Note: To utilize any VLANs outside of 1-1000 on a C9300-M, the switch or switch stack must have ALL of its trunk interfaces set to an allowed
vlan list that contains a total that is less than or equal to 1000 VLANs, including any of the module interfaces that are not in use. For example: If a
switch needs to utilize VLANs 1,100-200,300-400,2100-2200,3000-3100,EVERY trunk interface on that switch must be configured with that allowed
VLAN list or a subset of it.
The easiest method to do this is to perform the following:
1. Navigate to Switch > Switch ports
2. in the search bar use the following search term depending on if it is a stack or a single switch:
1. switch:"{name of switch}" is:trunk
2. stack:"{name of stack}" is:trunk
3. Select all trunks configured with the allowed VLANs of 1-1000
4. set to new list including new range of VLANs. (example: 1,100-200,300-400,2100-2200,3000-3100)
5. Click Update
5

Dynamic Assignment
When using D CP, the D CP server should be configured to assign a static IP address for each MAC address belonging to a Meraki switch. Other features of
the network, such as 802.1X authentication, may rely on the property that the switches have static IP addresses.
Please make sure that the D CP server used for providing a management IP address to the switch has an available address pool that falls within the active
VLAN range.
Static Assignment
Static IPs can be assigned using the local status page on each switch. For more information on how to configure static IP from the local status page refer to this
documentation.
Static IP via DHCP Reservations
Instead of associating each Meraki switch individually to configure static IP addresses, an administrator can assign static IP addresses on the upstream D CP
server. Through “D CP reservations,” IP addresses are “reserved” for the MAC addresses of the Meraki switches. Please consult the documentation for the
D CP server to configure D CP reservations.
Check upstream VLAN configuration
Ensure the upstream switch/router port is configured properly and there is no VLAN mismatch.
6

Check STP configuration
Meraki-managed C9300 series switches run a single instance of MST out of the box. Please refer to this document for interoperability.
Device reboot/ reset precaution
After powering on the unit or a device reboot, the power LED goes through the following cycle -
1. Solid amber
2. Cycle through different colors
3. Solid white if dashboard connectivity is successful or, remain solid amber if dashboard connectivity is unsuccessful. Different power LED colors and their
interpretation are listed under this section. It may take some time for a device to boot up so refer to the power LED indicators to understand what the switch is
doing during boot up. Be patient and let the switch complete the whole boot-up process and connect to the Meraki cloud.
Do not power down or reset the device during a firmware upgrade. A device which has its power LED blinking white is indicating that it is going through a
firmware upgrade.
Once the devices are upgraded to the latest version continue configuring other switch features/settings. For details refer to the MS documentation
Installation Instructions
1. Attach the rack mount bracket to both sides of the switch as shown below:
7

2. Align the rack mount brackets on the sides of the switch onto the rack.
8

3. Secure and screw in the rack mount bracket on to the rack.
9

4. Insert the Uplink module.
10

Stack Cabling Installation
• Connect the cable to the stack port on the switch back panel (as shown in the back panel diagram). Align the
connector and connect the stack cable to the stack port on the switch back panel and finger-tighten the screws
(clockwise direction). Make sure the Cisco logo is on the top side of the connector.
• Connect the other end of the cable to the port on the other switch and finger-tighten the screws. Avoid over tightening
the screws.
Note: The C9300 10G and 40G SFP+ and QSFP+ uplink modules are hot-swappable.
11

StackPower Cabling Installation
• StackPower on C9300 supports a ring topology of up to 4 switches.
• Connect the end of the cable with a green band to either StackPower port on the first switch (see back panel diagram
to locate the StackPower ports). Align the connector correctly, and insert it into a StackPower port on the switch rear
panel.
• Connect the end of the cable with the yellow band to another switch. and-tighten the captive screws to secure the
StackPower cable connectors in place.
• StackPower feature doesn't need any dashboard configuration but is automatically enabled when the cables are
installed.
Basic Troubleshooting
The following steps can be used for troubleshooting basic connectivity issues with your switch.
• Factory reset the switch by holding the factory reset button for 10-15 seconds
• Try switching cables, or testing your cable on another device
Reference https://documentation.meraki.com/MS for additional information and troubleshooting tips.
If you are still experiencing hardware issues, please contact Cisco Meraki support by logging in to dashboard and using the Help option near the top of the page,
then opening and email case or calling using the contact information on that page.
Warranty
MS Warranty coverage periods are as follows:
Please refer to these instructions here before stacking C9300 out of the box.
12

Time
Period Comments
C9300 Series Lifetime -
MS
Accessories 1 Year The following are considered accessories: SFP Modules, twinax/SFP+ cables, stacking cables, all mounting kits and stands,
interface modules, additional power cords, PoE injectors
Note: The above table is a general guideline for warranty terms and is not final. Warranty terms are subject to printed warranty information on the online Meraki
Returns and Policy section.
If your Cisco Meraki device fails and the problem cannot be resolved by troubleshooting, contact support to address the issue. Once support determines that the
device is in a failed state, they can process an RMA and send out a replacement device free of charge. In most circumstances, the RMA will include a pre-paid
shipping label so the faulty equipment can be returned.
Additional warranty information can be found on: https://meraki.cisco.com/support#process:warranty
Support and Additional Information
If issues are encountered with device installation or additional help is required, contact Meraki Support by logging in to dashboard.meraki.com and opening a
case by visiting the Get Help section.
• The equipment is intended for industrial or other commercial activities.
• The equipment is used in areas without exposure to harmful and dangerous production factors, unless otherwise
specified in the operational documentation and/or on the equipment labeling.
• The equipment is not for domestic use. The equipment is intended for operation without the constant presence of
maintenance personnel.
• The equipment is subject to installation and maintenance by specialists with the appropriate qualifications, sufficient
specialized knowledge, and skills.
• Rules and conditions for the sale of equipment are determined by the terms of contracts concluded by Cisco or
authorized Cisco partners with equipment buyers.
• Disposal of a technical device at the end of its service life should be carried out in accordance with the requirements
of all state regulations and laws.
• Do not throw in the device with household waste. The technical equipment is subject to storage and disposal in
accordance with the organization's disposal procedure.
• The equipment should be stored in its original packaging in a room protected from atmospheric precipitation. The
In order to initiate a hardware replacement for non-functioning hardware that is under warranty, you must have access to the original packaging
the hardware was shipped in. The original hardware packaging includes device serial number and order information, and may be required for return
shipping.
Meraki C9300 devices have been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC rules. A digital
device that is marketed for use in a residential environment notwithstanding use in commercial, business and industrial environments.
13

permissible temperature and humidity ranges during storage are specified in the Operation (Installation) Manual.
• Transportation of equipment should be carried out in the original packaging in covered vehicles by any means of
transport. The temperature and humidity during transportation must comply with the permissible established ranges
of temperature and humidity during storage (in the off state) specified in the Operation Manual (Installation).
For additional information on Meraki hardware and for other installation guides, please refer to documentation.meraki.com.
14
