Cisco Firepower 7010, Firepower 7020, Firepower 7030, Firepower 7050, Firepower 7110, Firepower 7120, Firepower 7115, Firepower... User manual

Cisco Systems, Inc.
www.cisco.com
Cisco has more than 200 offices worldwide.
Addresses, phone numbers, and fax numbers
are listed on the Cisco website at
www.cisco.com/go/offices.
Firepower 7000 Series Hardware
Installation Guide
First Published: July 22, 2016
Last Updated: July 12, 2018

THE SPECIFICATIONS AND INFORMATION REGARDING THE PRODUCTS IN THIS MANUAL ARE SUBJECT TO CHANGE WITHOUT NOTICE. ALL
STATEMENTS, INFORMATION, AND RECOMMENDATIONS IN THIS MANUAL ARE BELIEVED TO BE ACCURATE BUT ARE PRESENTED WITHOUT
WARRANTY OF ANY KIND, EXPRESS OR IMPLIED. USERS MUST TAKE FULL RESPONSIBILITY FOR THEIR APPLICATION OF ANY PRODUCTS.
THE SOFTWARE LICENSE AND LIMITED WARRANTY FOR THE ACCOMPANYING PRODUCT ARE SET FORTH IN THE INFORMATION PACKET THAT
SHIPPED WITH THE PRODUCT AND ARE INCORPORATED HEREIN BY THIS REFERENCE. IF YOU ARE UNABLE TO LOCATE THE SOFTWARE LICENSE
OR LIMITED WARRANTY, CONTACT YOUR CISCO REPRESENTATIVE FOR A COPY.
The Cisco implementation of TCP header compression is an adaptation of a program developed by the University of California, Berkeley (UCB) as part of UCB’s public
domain version of the UNIX operating system. All rights reserved. Copyright © 1981, Regents of the University of California.
NOTWITHSTANDING ANY OTHER WARRANTY HEREIN, ALL DOCUMENT FILES AND SOFTWARE OF THESE SUPPLIERS ARE PROVIDED “AS IS” WITH
ALL FAULTS. CISCO AND THE ABOVE-NAMED SUPPLIERS DISCLAIM ALL WARRANTIES, EXPRESSED OR IMPLIED, INCLUDING, WITHOUT
LIMITATION, THOSE OF MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE AND NONINFRINGEMENT OR ARISING FROM A COURSE OF
DEALING, USAGE, OR TRADE PRACTICE.
IN NO EVENT SHALL CISCO OR ITS SUPPLIERS BE LIABLE FOR ANY INDIRECT, SPECIAL, CONSEQUENTIAL, OR INCIDENTAL DAMAGES, INCLUDING,
WITHOUT LIMITATION, LOST PROFITS OR LOSS OR DAMAGE TO DATA ARISING OUT OF THE USE OR INABILITY TO USE THIS MANUAL, EVEN IF CISCO
OR ITS SUPPLIERS HAVE BEEN ADVISED OF THE POSSIBILITY OF SUCH DAMAGES.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks, go to this
URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner does not imply a partnership
relationship between Cisco and any other company. (1110R)
Any Internet Protocol (IP) addresses and phone numbers used in this document are not intended to be actual addresses and phone numbers. Any examples, command display
output, network topology diagrams, and other figures included in the document are shown for illustrative purposes only. Any use of actual IP addresses or phone numbers in
illustrative content is unintentional and coincidental.
© 2016-2018 Cisco Systems, Inc. All rights reserved.

i
Firepower 7000 Series Hardware Installation Guide
CONTENTS
About This Guide v
Organization v
Document Conventions vi
Installation Warnings vii
Where to Find Safety and Warning Information ix
Related Documentation x
Obtaining Documentation and Submitting a Service Request x
About the Firepower 7000 Series 1-1
Firepower 7000 Series Managed Devices Delivered with the Firepower System 1-1
7000 Series Device Chassis Designations 1-1
Hardware Specifications 2-1
Rack and Cabinet Mounting Options 2-1
Firepower 7000 Series Devices 2-1
Firepower 7010, 7020, 7030, and 7050 2-1
Firepower 7110 and 7120 2-6
Firepower 7115, 7125, and AMP7150 2-13
Installing a Firepower 7000 Series Managed Device 3-1
Unpacking and Inspecting the Appliance 3-1
Security Considerations 3-2
Identifying the Management Interfaces 3-2
Firepower 7000 Series 3-2
Identifying the Sensing Interfaces 3-3
Firepower 7000 Series 3-3
Installing the Firepower Device in a Rack 3-7
Testing an Inline Bypass Interface Installation 3-9
Using the LCD Panel on a Firepower Device 4-1
Understanding LCD Panel Components 4-2
Using the LCD Multi-Function Keys 4-3
Idle Display Mode 4-3
Network Configuration Mode 4-4

Contents
ii
Firepower 7000 Series Hardware Installation Guide
Allowing Network Reconfiguration Using the LCD Panel 4-6
System Status Mode 4-6
Information Mode 4-8
Error Alert Mode 4-9
Deploying on a Management Network 5-1
Management Deployment Considerations 5-1
Understanding Management Interfaces 5-2
Single Management Interface 5-2
Multiple Management Interfaces 5-2
Deployment Options 5-3
Deploying with Traffic Channels 5-3
Deploying with Network Routes 5-4
Security Considerations 5-5
Special Case: Connecting 8000 Series Devices 5-5
Deploying Firepower Managed Devices 6-1
Sensing Deployment Considerations 6-1
Understanding Sensing Interfaces 6-2
Passive Interfaces 6-2
Inline Interfaces 6-2
Switched Interfaces 6-3
Routed Interfaces 6-3
Hybrid Interfaces 6-4
Connecting Devices to Your Network 6-4
Using a Hub 6-4
Using a Span Port 6-5
Using a Network Tap 6-5
Cabling Inline Deployments on Copper Interfaces 6-5
Special Case: Connecting Firepower 8000 Series Devices 6-6
Deployment Options 6-7
Deploying with a Virtual Switch 6-7
Deploying with a Virtual Router 6-8
Deploying with Hybrid Interfaces 6-9
Deploying a Gateway VPN 6-10
Deploying with Policy-Based NAT 6-11
Deploying with Access Control 6-11
Using Multiple Sensing Interfaces on a Managed Device 6-16
Complex Network Deployments 6-18

Contents
iii
Firepower 7000 Series Hardware Installation Guide
Integrating with VPNs 6-18
Detecting Intrusions on Other Points of Entry 6-19
Deploying in Multi-Site Environments 6-20
Integrating Multiple Management Interfaces within a Complex Network 6-22
Integrating Managed Devices within Complex Networks 6-23
Power Requirements for Firepower 7000 Series Devices A-1
Warnings and Cautions A-1
Static Control A-1
Firepower 70xx Family Appliances A-1
Installation A-2
Grounding/Earthing Requirements A-2
Firepower 71xx Family Appliances A-3
Installation A-4
Grounding/Earthing Requirements A-5
Using SFP Transceivers in Firepower 71x5 and AMP7150 Devices B-1
Firepower 71x5 and AMP7150 SFP Sockets and Transceivers B-1
Inserting an SFP Transceiver B-2
To insert an SFP transceiver: B-2
Removing an SFP Transceiver B-3

Contents
iv
Firepower 7000 Series Hardware Installation Guide

v
Firepower 7000 Series Hardware Installation Guide
About This Guide
Released: July 22, 2016
This guide describes how to install and maintain the Cisco Firepower 7000 Series appliances.
Information in this guide applies to the Cisco 70xx Family and the 71xx Family models.
This preface includes the following sections:
Organization, page v
Document Conventions, page vi
Installation Warnings, page vii
Where to Find Safety and Warning Information, page ix
Related Documentation, page x
Obtaining Documentation and Submitting a Service Request, page x
Organization
This guide is organized as follows:
Chapter Title Description
Chapter 1 About the Firepower 7000 Series Provides an overview of the devices
included in the 7000 Series.
Chapter 2 Hardware Specifications Describes the hardware specifications for the
Firepower 7000 Series models.
Chapter 3 Installing a Firepower 7000 Series
Managed Device
Describes how to install a Firepower
7000 Series device in a rack, how to connect
the management interface, and how to power
on the chassis.
Chapter 4 Using the LCD Panel on a Firepower
Device
Describes how to view device information or
configure certain settings using an LCD
panel on the front of the device instead of the
system’s web interface.
Chapter 5 Deploying on a Management Network Describes Firepower System deployment
options available to accommodate the needs
of unique network architectures.

vi
Firepower 7000 Series Hardware Installation Guide
About This Guide
Document Conventions
Document Conventions
This document uses the following conventions:
Note Means reader take note.
Tip Means the following information will help you solve a problem.
Chapter 6 Deploying Firepower Managed
Devices
Describes how different sensing interfaces
affect the capabilities of the Firepower
System, including passive, inline, routed,
switched, and hybrid interfaces.
Appendix A Power Requirements for Firepower
7000 Series Devices
Describes power requirements for Firepower
7000 Series devices.
Appendix B Using SFP Transceivers in Firepower
71x5 and AMP7150 Devices
Describes the small form-factor pluggable
(SFP) sockets and transceivers for the
Firepower 71x5 and AMP7150 appliances.
Chapter Title Description
Convention Indication
bold type Commands and keywords and user-entered text appear in bold type.
italic type Document titles, new or emphasized terms, and arguments for which you supply
values are in italic type.
[ ] Elements in square brackets are optional.
{x | y | z } Required alternative keywords are grouped in braces and separated by
vertical bars.
[ x | y | z ] Optional alternative keywords are grouped in brackets and separated by
vertical bars.
string An unquoted set of characters. Do not use quotation marks around the string, or
the string will include the quotation marks.
monospace type Terminal sessions and information the system displays appear in monospace
type.
monospace bold type Commands and keywords and user-entered text appear in monospace courier
type.
monospace italic
type
Arguments for which you supply values are in monospace italic type.
< > Non-printing characters such as passwords are presented in angle brackets.
[ ] Default responses to system prompts are presented in square brackets.
!, # An exclamation point (!) or a hash sign (#) at the beginning of a line of code
indicates a comment line.

vii
Firepower 7000 Series Hardware Installation Guide
About This Guide
Installation Warnings
Caution Means reader be careful. In this situation, you might perform an action that could result in equipment
damage or loss of data.
Installation Warnings
Be sure to read the Regulatory Compliance and Safety Information document
(http://www.cisco.com/c/en/us/td/docs/security/firesight/hw-docs/regulatory/compliance/firesight-firep
ower-rcsi.html) before installing the device.
This section presents these important safety warnings:
•Power Supply Disconnection Warning, page vii
•Jewelry Removal Warning, page vii
•Wrist Strap Warning, page viii
•Work During Lightning Warning, page viii
•Installation Instructions Warning, page viii
•Chassis Warning for Rack-Mounting and Servicing, page viii
•Short-Circuit Protection Warning, page viii
•SELV Circuit Warning, page viii
•Ground Conductor Warning, page viii
•Faceplates and Cover Panels Warning, page ix
•Product Disposal Warning, page ix
•Compliance with Local and National Electrical Codes Warning, page ix
•Grounded Equipment Warning, page ix
•Safety Cover Requirement, page ix
Power Supply Disconnection Warning
Warning Before working on a chassis or working near power supplies, unplug the power cord on AC units;
disconnect the power at the circuit breaker on DC units. Statement 12
Jewelry Removal Warning
Warning Before working on equipment that is connected to a power source, remove jewelry (including rings,
necklaces, and watches). Metal objects will heat when connected to power and ground, and can
cause serious burns or weld the metal object to the terminals. Statement 43

viii
Firepower 7000 Series Hardware Installation Guide
About This Guide
Installation Warnings
Wrist Strap Warning
Warning During this procedure, wear grounding wrist straps to avoid ESD damage to the card. Do not directly
touch the backplane with your hand or any metal tool, or you could receive a shock. Statement 94
Work During Lightning Warning
Warning Do not work on the system, or connect or disconnect cables during periods of lightning. Statement
1001
Installation Instructions Warning
Warning Read all installation instructions before connecting the system to a power source. Statement 1004
Chassis Warning for Rack-Mounting and Servicing
Warning To prevent bodily injury when mounting or servicing this unit in a rack, you must take special precautions to
ensure that the system remains stable. The following guidelines are provided to ensure your safety: This unit
should be mounted at the bottom of the rack if it is the only unit in the rack. When mounting this unit in a partially
filled rack, load the rack from the bottom to the top with the heaviest component at the bottom of the rack.If the
rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the unit in the rack.
Statement 1006
Short-Circuit Protection Warning
Warning This product requires short-circuit (overcurrent) protection, to be provided as part of the building
installation. Install only in accordance with national and local wiring regulations. Statement 1045
SELV Circuit Warning
To avoid electric shock, do not connect safety extra-low voltage (SELV) circuits to telephone-network
voltage (TNV) circuits. LAN ports contain SELV circuits, and WAN ports contain TNV circuits. Some
LAN and WAN ports both use RJ-45 connectors. Use caution when connecting cables.
Statement 1021
Ground Conductor Warning
Warning This equipment must be grounded. Never defeat the ground conductor, or operate the equipment in the
absence of a suitably installed ground conductor. Contact the appropriate electrical inspection
authority, or an electrician if you are not certain that suitable grounding is available. Statement 1024

ix
Firepower 7000 Series Hardware Installation Guide
About This Guide
Where to Find Safety and Warning Information
Faceplates and Cover Panels Warning
Warning Blank faceplates and cover panels serve three important functions: they prevent exposure to
hazardous voltages and currents inside the chassis; they restrict electromagnetic interference
(EMI) that might disrupt other equipment; and they direct the flow of cooling air through the chassis.
Do not operate the system unless all cards, faceplates, front covers, and rear covers are in place.
Statements 1029 and 142
Product Disposal Warning
Warning Ultimate disposal of this product should be handled according to all national laws and regulations.
Statement 1040
Compliance with Local and National Electrical Codes Warning
Warning Installation of the equipment must comply with local and national electrical codes. Statement 1074
Grounded Equipment Warning
Warning This equipment is intended to be grounded. Ensure that the host is connected to earth ground during
normal use. Statement 39
Safety Cover Requirement
Warning The safety cover is an integral part of the product. Do not operate the unit without the safety cover
installed. Operating the unit without the cover in place will invalidate the safety approvals and pose
a risk of fire and electrical hazards. Statement 117
Where to Find Safety and Warning Information
For safety and warning information, see the Regulatory Compliance and Safety Information document
at the following URL:
http://www.cisco.com/c/en/us/td/docs/security/firesight/hw-docs/regulatory/compliance/firesight-firep
ower-rcsi.html
This RCSI document describes the international agency compliance and safety information for the
Cisco Firepower series.

x
Firepower 7000 Series Hardware Installation Guide
About This Guide
Related Documentation
Related Documentation
For a complete list of the Cisco Firepower series documentation and where to find it, see the
documentation roadmap at the following URL:
http://www.cisco.com/c/en/us/td/docs/security/firepower/roadmap/firepower-roadmap.html
Obtaining Documentation and Submitting a Service Request
For information on obtaining documentation, using the Cisco Bug Search Tool (BST), submitting a
service request, and gathering additional information, see What’s New in Cisco Product Documentation
at: http://www.cisco.com/c/en/us/td/docs/general/whatsnew/whatsnew.html.
Subscribe to What’s New in Cisco Product Documentation, which lists all new and revised
Cisco technical documentation as an RSS feed and delivers content directly to your desktop using a
reader application. The RSS feeds are a free service.

CHAPTER
1-1
Firepower 7000 Series Installation Guide
1
About the Firepower 7000 Series
This chapter describes the Cisco Firepower 7000 Series devices, which are fault-tolerant, purpose-built
network appliances available with a range of throughputs and capabilities.
Devices deployed on network segments within your organization monitor traffic for analysis. Devices
deployed passively help you gain insight into your network traffic. Deployed inline, you can use
Firepower devices to affect the flow of traffic based on multiple criteria.
Yo u must manage Firepower 7000 Series devices with a Firepower Management Center.
Warning Only trained and qualified personnel should install, replace, or service this equipment. Statement 49
Firepower 7000 Series Managed Devices Delivered with the Firepower System
The following table lists the managed devices that Cisco delivers with the Firepower System.
7000 Series Device Chassis Designations
The following table lists the chassis designations for the 7000 Series models available world-wide. The
chassis code appears on the regulatory label on the outside of the chassis, and is the official reference
code for hardware certifications and safety.
Table 1-1 7000 Series Firepower System Appliances
Models/Family Series/Grouping Type
70xx Family:
•7010, 7020, 7030, 7050
7000 Series device
71xx Family:
•7110, 7120
•7115, 7125
•AMP7150
7000 Series device

1-2
Firepower 7000 Series Installation Guide
Chapter 1 About the Firepower 7000 Series
Table 1-2 7000 Series Chassis Models
Firepower and AMP Device
Model Hardware Chassis Code
7010, 7020, 7030 CHRY-1U-AC
7050 NEME-1U-AC
7110, 7120 (Copper) GERY-1U-8-C-AC
7110, 7120 (Fiber) GERY-1U-8-FM-AC
7115, 7125, AMP7150 GERY-1U-4C8S-AC

CHAPTER
2 -1
Firepower 7000 Series Hardware Installation Guide
2
Hardware Specifications
Firepower 7000 Series devices are delivered on a variety of platforms to meet the needs of your
organization.
Rack and Cabinet Mounting Options
You can mount Firepower devices in racks and server cabinets. The appliance comes with a
rack-mounting kit except for the Firepower 7010, 7020, 7030, and 7050. For information on mounting
the appliance in a rack, refer to the instructions delivered with the rack-mounting kit.
The Firepower 7010, 7020, 7030, and 7050 require a tray and rack-mounting kit, available separately.
You can purchase rack and cabinet mounting kits for other appliances separately.
Firepower 7000 Series Devices
All Firepower 7000 Series devices have an LCD panel on the front of the appliance where you can view
and, if enabled, configure your appliance. See the following sections for information:
•Firepower 7010, 7020, 7030, and 7050, page 2-1
•Firepower 7110 and 7120, page 2-7
•Firepower 7115, 7125, and AMP7150, page 2-13
Firepower 7010, 7020, 7030, and 7050
The Firepower 7010, 7020, 7030, and 7050 devices, also called the 70xx Family, are 1U appliances,
one-half the width of the rack tray and delivered with eight copper interfaces, each with configurable
bypass capability. See the Regulatory Compliance and Safety Information for FirePOWER and
FireSIGHT Appliances document for safety considerations for Firepower 70xx Family appliances.
See the following sections for more information:
•Firepower 70xx Family Front View, page 2-2
•Firepower 70xx Family Rear View, page 2-5
•Firepower 70xx Family Physical and Environmental Parameters, page 2-5

2 -2
Firepower 7000 Series Hardware Installation Guide
Chapter 2 Hardware Specifications
Firepower 7000 Series Devices
Firepower 70xx Family Front View
The front of the chassis contains the LCD panel, sensing interfaces, front panel, and management
interface.
Figure 2-1 Firepower 70xx Family (Chassis: CHRY-1U-AC; NEME-1U-AC) Front View
The following table describes the features on the front of the appliance.
.
Figure 2-2 Firepower 70xx Family Front Panel
Table 2-1 Firepower 70xx Family System Components: Front View
Feature Description
LCD panel Operates in multiple modes to configure the device, display error messages, and view system
status. For more information, see Using the LCD Panel on a Firepower Device, page 4-1.
Sensing interfaces Contain the sensing interfaces that connect to the network. For information, see Sensing
Interfaces, page 2-4.
10/100/1000 Ethernet
management interface
Provides for an out-of-band management network connection. The management interface is
used for maintenance and configuration purposes only and is not intended to carry service
traffic.
Front panel Houses LEDs that display the system’s operating state, as well as various controls, such as the
power button. For more information, see Table 2-11Firepower 7110 and 7120 Front Panel
Components, page 2-8.
Table 2-2 Front Panel Components
A Reset button D System ID button
B System status LED E Power button and LED
C Solid-state drive activity LED

2 -3
Firepower 7000 Series Hardware Installation Guide
Chapter 2 Hardware Specifications
Firepower 7000 Series Devices
The front panel of the chassis houses LEDs, which display the system’s operating state. The following
table describes the LEDs on the front panel.
The following table describes the conditions under which the system status LEDs might be lit.
Table 2-3 Firepower 70xx Family Front Panel LEDs
LED Description
Reset button Allows you to reboot the appliance without disconnecting it from the power supply.
System status Indicates the system status:
•A green light indicates the system is powered up and operating normally, or powered down
and attached to AC power.
•An amber light indicates a system fault.
See Table 2-4 on page 2-3 for more information.
Solid-state drive (SSD)
activity
Indicates the SSD status:
•A blinking green light indicates the fixed disk drive is active.
•If the light is off, there is no drive activity or the system is powered off.
System ID When pressed, the ID button displays a blue light, and a blue light is visible at the rear of the
chassis.
Power button and LED Indicates whether the appliance has power:
•A green light indicates that the appliance has power and the system is on.
•No light indicates the system is shut down or does not have power.
Table 2-4 Firepower 70xx Family System Status
Condition Description
Critical Any critical or non-recoverable threshold crossing associated with the following events:
•temperature, voltage, or fan critical threshold crossing
•power subsystem failure
•system inability to power up due to incorrectly installed processors or processor
incompatibility
•critical event logging errors, including System Memory Uncorrectable ECC error and
fatal/uncorrectable bus errors, such as PCI SERR and PERR
Non-critical A non-critical condition is a threshold crossing associated with the following events:
•temperature, voltage, or fan non-critical threshold crossing
•Set Fault Indication command from system BIOS; the BIOS may use the command to
indicate additional, non-critical status such as system memory or CPU configuration
changes
Degraded A degraded condition is associated with the following events:
•one or more processors are disabled by Fault Resilient Boot (FRB) or BIOS
•some system memory disabled or mapped out by BIOS
•one of the power supplies unplugged or not functional

2 -4
Firepower 7000 Series Hardware Installation Guide
Chapter 2 Hardware Specifications
Firepower 7000 Series Devices
Sensing Interfaces
The Firepower 70xx Family appliances are delivered with eight copper interfaces, each with
configurable bypass capability.
Figure 2-3 Eight-Port 1000BASE-T Copper Interfaces
Use the following table to understand the activity and link LEDs on the copper interfaces.
Use the following table to understand bypass LEDs on the copper interfaces.
The 10/100/1000 management interface is located on the front of the appliance. The following table
describes the LEDs associated with the management interface.
Table 2-5 Firepower 70xx Family Copper Link/Activity LEDs
Status Description
Both LEDs off The interface does not have link.
Link amber The speed of the traffic on the interface is 10Mb or 100Mb.
Link green The speed of the traffic on the interface is 1Gb.
Activity blinking green The interface has link and is passing traffic.
Table 2-6 Firepower 70xx Family Copper Bypass LEDs
Status Description
Off The interface pair is not in bypass mode or has no power.
Steady green The interface pair is ready to enter bypass mode.
Steady amber The interface pair has been placed in bypass mode intentionally, or has
entered bypass mode gracefully, and is not inspecting traffic.
Blinking amber The interface pair has unexpectedly entered bypass mode; that is, it has failed
open.
Table 2-7 Firepower 70xx Family Management Interface LEDs
LED Description
Left (link) 7010/20/30 Indicates whether the link is up. If the light is on, the link is
up. If the light is off, there is no link.
7050 For 10Mbps links, the link light does not illuminate. Link
status is shared with the right (activity) LED.

2 -5
Firepower 7000 Series Hardware Installation Guide
Chapter 2 Hardware Specifications
Firepower 7000 Series Devices
Firepower 70xx Family Rear View
The rear of the chassis contains the system ID LED, connection ports, grounding stud, and power supply
connector.
Figure 2-4 Firepower 70xx Family (Chassis: CHRY-1U-AC) Rear View
The following table describes the features that appear on the rear of the appliance.
Firepower 70xx Family Physical and Environmental Parameters
The following table describes the physical attributes and the environmental parameters for the appliance.
Right (activity) 7010/20/30 Indicates activity on the port. If the light is blinking, there is
activity. If the light is off, there is no activity.
7050 For 10Mbps links, if the light is on, there is link and activity.
If the light is off, there is no link or activity.
Table 2-7 Firepower 70xx Family Management Interface LEDs (continued)
LED Description
Table 2-8 Firepower 70xx Family System Components: Rear View
Feature Description
System ID LED Helps identify a system installed in a high-density rack with other similar systems. The blue
LED indicates that the ID button is pressed.
2.0 USB ports
VGA port
Serial port
Allows you to attach a monitor and keyboard to the device to establish a direct
workstation-to-appliance connection.
Grounding stud Allows you to connect the appliance to the common bonding network. See the Power
Requirements for Firepower 7000 Series Devices, page A-1 for more information.
12V Power supply
connector
Provides a power connection to the device through an AC power source.

2 -6
Firepower 7000 Series Hardware Installation Guide
Chapter 2 Hardware Specifications
Firepower 7000 Series Devices
Table 2-9 Firepower 70xx Family Physical and Environmental Parameters
Parameter Description
Form factor 1U, half rack width
Dimensions (D x W x H) Single chassis: 12.49 in. x 7.89 in. x 1.66 in. (31.74 cm x 20.04 cm x 4.21 cm)
2-Chassis Tray: 25.05 in. x 17.24 in. x 1.73 in. (63.62 cm x 43.8 cm x 4.44 cm)
Chassis weight
maximum installed
Chassis: 7 lbs (3.17 kg)
Single chassis and power supply in tray: 17.7 lbs (8.03 kg)
Double chassis and power supplies in single tray: 24.7 lbs (11.2 kg)
Copper 1000BASE-T Gigabit copper Ethernet bypass-capable interfaces in a paired configuration
Cable and distance: Cat5E at 50 m
Power supply 200 W AC power supply
Voltage: 100 VAC to 240 VAC nominal (90 VAC to 264 VAC maximum)
Current: 2A maximum over the full range
Frequency range: 50/60 Hz nominal (47 Hz to 63 Hz maximum)
Solid-state drive (SSD) 240GB 2.5-inch SSD
Operating temperature 7010/20/30 32°F to 104°F (0°C to 40°C)
7050 23°F to 104°F (-5°C to 40°C)
Non-operating temperature 7010/20/30 -4°F to 158°F (-20°C to 70°C)
7050 14°F to 140°F (-10°C to 60°C)
Operating humidity 7010/20/30 5% to 95%, non-condensing
Operation beyond these limits is not guaranteed and not recommended.
7050 5% to 85%, non-condensing
Operation beyond these limits is not guaranteed and not recommended.
Non-operating humidity 7010/20/30 0% to 95%, non-condensing
7050 0% to 85%, non-condensing
Store the unit below the maximum non-condensing relative humidity. Acclimate below
maximum operating humidity at least 48 hours prior to placing the unit in service.
Altitude 0 ft (sea level) to 5905 ft (0 m to 1800 m)
Cooling requirements 682 BTU/hour
You must provide sufficient cooling to maintain the appliance within its required operating
temperature range. Failure to do this may cause a malfunction or damage to the appliance.
Acoustic noise 53 dBA when idle. 62 dBA at full processor load
Operating shock No errors with half a sine wave shock of 5G (with 11 ms duration)
Airflow 20 ft3(0.57 m3) per minute
Airflow through the appliance enters at the front and sides and exits at the rear.
