Cisco ONS 15454 Instruction sheet

CHAPTER
1-1
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
1
Install the Shelf and Backplane Cable
This chapter provides procedures for installing the Cisco ONS 15454. For a summary of the tools and
equipment required for installation, see the “Required Tools and Equipment” section on page 1-2.
Before You Begin
This section lists the chapter procedures (NTPs). Turn to a procedure for applicable tasks (DLPs).
1. NTP-A1 Unpack and Inspect the ONS 15454 Shelf Assembly, page 1-4—Complete this procedure
before continuing with the “NTP-A2 Install the Shelf Assembly” procedure on page 1-5.
2. NTP-A2 Install the Shelf Assembly, page 1-5—Complete this procedure to install the shelf
assembly in a rack.
3. NTP-A3 Open and Remove the Front Door, page 1-6—Complete this procedure to access the
equipment before continuing with other procedures.
4. NTP-A4 Remove the Backplane Covers, page 1-7—Complete this procedure to access the
backplane before continuing with other procedures.
5. NTP-A5 Install the EIAs, page 1-7—Complete this procedure if you plan to install electrical cards.
This procedure is a prerequisite to the “NTP-A9 Install the Electrical Card Cables on the Backplane”
procedure on page 1-22.
6. NTP-A6 Install the Power and Ground, page 1-9—Complete this procedure before continuing with
the “NTP-A7 Install the Fan-Tray Assembly” procedure on page 1-10.
7. NTP-A7 Install the Fan-Tray Assembly, page 1-10—Complete this procedure to install the fan-tray
assembly in the shelf.
8. NTP-A119 Install the Alarm Expansion Panel, page 1-12—Complete this procedure if you are
planning to install the Alarm Interface Controller–International (AIC-I) card and want to increase
the number of alarm contacts provided by the AIC-I card.
9. NTP-A8 Attach Wires to Alarm, Timing, LAN, and Craft Pin Connections, page 1-15—Complete
this procedure as needed to set up wire-wrap pin connections.
10. NTP-A120 Install an External Wire-Wrap Panel to the AEP, page 1-16—Complete this procedure to
connect an external wire-wrap panel to the alarm expansion panel (AEP).
11. NTP-A9 Install the Electrical Card Cables on the Backplane, page 1-22—Complete this procedure
if you plan to install electrical card cables.
12. NTP-A10 Route Electrical Cables, page 1-23—Complete this procedure as needed before
continuing with the “NTP-A11 Install the Rear Cover” procedure on page 1-23.

1-2
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
Required Tools and Equipment
13. NTP-A11 Install the Rear Cover, page 1-23—Complete this procedure as needed to install the rear
cover.
14. NTP-A13 Perform the Shelf Installation Acceptance Test, page 1-31—Complete this procedure to
determine if you have correctly completed all other procedures in the chapter.
Warning Only trained and qualified personnel should be allowed to install, replace, or service this equipment.
Statement 1030
Warning This unit is intended for installation in restricted access areas. A restricted access area is where
access can only be gained by service personnel through the use of a special tool, lock and key, or
other means of security, and is controlled by the authority responsible for the location. Statement 37
Warning Suitable for mounting on concrete or other non-combustible surface only. Statement 345
Warning The covers are an integral part of the safety design of the product. Do not operate the unit without the
covers installed.
Required Tools and Equipment
You need the following tools and equipment to install and test the ONS 15454.
Cisco-Supplied Materials
The following materials are required and are shipped with the ONS 15454 shelf (wrapped in plastic).
The number in parentheses gives the quantity of the item included in the package.
•#12-24 x 3/4 pan-head Phillips mounting screws (48-1004-XX, 48-1007-XX) (8)
•#12 -24 x 3/4 socket set screws (48-1003-XX) (2)
•T-handle #12-24 hex tool for set screws (1)
•ESD wrist strap with 1.8 m (6 ft) coil cable (1)
•Tie wraps (10)
•Pinned hex (Allen) key for front door (1)
•Spacers (50-1193-XX) (4)
•Spacer mounting brackets (2)
•Clear plastic rear cover (1)
•External (bottom) brackets for the fan-tray air filter
•Shelf accessory kit (53-2329-XX ) (optional)
– Two mounting bars (700-19701-XX)
– Four 1-inch standoffs (50-1193-01)

1-3
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
Required Tools and Equipment
– Four 1 3/8-inch standoffs (50-1492-01)
– Eight 2-inch standoffs (50-1453-01)
– Four flathead screws, 6-32 x 0.5 (48-2116-01)
•Standoff kit (53-0795-XX):
– Plastic fiber management guides (2)
– Fan filter bracket screws (53-48-0003) (6)
The following materials are required to install the optional air ramp. The number in parentheses gives
the quantity of the item included in the package:
•M4.0x 8mm, SS pan-head Phillips mounting screws (2)
•Mounting brackets, 19 inch (482.6 mm), 23 inch (584.2 mm) (2)
User-Supplied Materials
The following materials and tools are required but are not supplied with the ONS 15454:
•One or more of the following equipment racks:
– 19-inch ANSI Standard (Telcordia GR-63-CORE) (482.6 mm) rack; total width 22 inches
(558.8 mm)
– 23-inch ANSI Standard (Telcordia GR-63-CORE) (584.2 mm) rack; total width 26 inches
(660.4 mm)
•Fuse panel
•Power cable (from fuse and alarm panel to assembly), #10 AWG, copper conductors,
194 degrees Fahrenheit (90 degrees Celsius)
Note If you are installing power on a 15454-SA-NEBS3E, 15454-SA-NEBS3, or 15454-SA-R1,
P/N: 800-07149 shelf assembly, a #10 to #12 AWG power cable is required.
•Ground cable #6 AWG stranded
Note If you are installing power on a 15454-SA-NEBS3E, 15454-SA-NEBS3 or 15454-SA-R1,
P/N: 800-07149 shelf assembly, the #10 AWG ground cable is required.
•Alarm cable pairs for all alarm connections, #22 or #24 AWG (0.51 mm² or 0.64 mm²), solid tinned
•100-ohm shielded building integrated timing supply (BITS) clock cable pair #22 or #24 AWG
(0.51 mm² or 0.64 mm²), twisted-pair T1-type
•Single-mode SC fiber jumpers with UPC polish (55 dB or better) for optical (OC-N) cards
•Shielded coaxial cable terminated with SMB or BNC connectors for DS-3 cards
•Shielded ABAM cable terminated with AMP Champ connectors or unterminated for DS1N-14 cards
with #22 or #24 AWG (0.51 mm² or 0.64 mm²) ground wire (typically about two ft [61 cm] in length)
•6-pair #29 AWG double-shielded cable
•Tie wraps and/or lacing cord
•Labels

1-4
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A1 Unpack and Inspect the ONS 15454 Shelf Assembly
•Listed pressure terminal connectors such as ring and fork types; connectors must be suitable for
#10 AWG copper conductors
Tools Needed
The following tools are needed to install an ONS 15454:
•#2 Phillips screwdriver
•Medium slot-head screwdriver
•Small slot-head screwdriver
•Wire wrapper
•Wire cutters
•Wire strippers
•Crimp tool
•BNC insertion tool
Test Equipment
The following test equipment is needed to install an ONS 15454:
•Voltmeter
•Optical power meter (for use with fiber optics only)
•Bit error rate (BER) tester, DS-1 and DS-3
NTP-A1 Unpack and Inspect the ONS 15454 Shelf Assembly
Note The ONS 15454 high-density shelf (15454-SA-HD) is required if you want to use the high-density
electrical cards (48-port DS-3 and 56-port DS-1), available in a future release.
Step 1 Complete the “DLP-A1 Unpack and Verify the Shelf Assembly” task on page 17-1.
Step 2 Complete the “DLP-A2 Inspect the Shelf Assembly” task on page 17-2.
Step 3 Continue with the “NTP-A2 Install the Shelf Assembly” procedure on page 1-5.
Stop. You have completed this procedure.
Purpose This procedure unpacks the ONS 15454 and verifies the contents.
Tools/Equipment Pinned hex (Allen) key for front door
Prerequisite Procedures None
Required/As Needed Required
Onsite/Remote Onsite
Security Level None

1-5
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A2 Install the Shelf Assembly
NTP-A2 Install the Shelf Assembly
Warning To prevent the system from overheating, do not operate it in an area that exceeds the maximum
recommended ambient temperature of:
131°F (55°C). Statement 1047
Warning To prevent airflow restriction, allow at least 1 inch (25.4 mm) of clearance around the ventilation
openings.
Warning The ONS 15454 must have 1 inch (25.4 mm) of airspace below the installed shelf assembly to allow air
flow to the fan intake. The air ramp (the angled piece of sheet metal on top of the shelf assembly)
provides this spacing and should not be modified in any way.
Note The 10-Gbps-compatible shelf assembly (15454-SA-10G) and fan-tray assembly (15454-FTA3) are
required with the ONS 15454 XC10G, OC-192, and OC-48 any slot (AS) cards.
Purpose This procedure reverses the mounting bracket and mounts shelf assemblies
in a rack.
Tools/Equipment #2 Phillips screwdriver
Medium slot-head screwdriver
Small slot-head screwdriver
Pinned hex key
Two set screws (48-1003-XX)
Prerequisite Procedures NTP-A1 Unpack and Inspect the ONS 15454 Shelf Assembly, page 1-4
Required/As Needed Required
Onsite/Remote Onsite
Security Level None
Warning To prevent bodily injury when mounting or servicing this unit in a rack, you must take special
precautions to ensure that the system remains stable. The following guidelines are provided to
ensure your safety:
• This unit should be mounted at the bottom of the rack if it is the only unit in the rack.
• When mounting this unit in a partially filled rack, load the rack from the bottom to the top with the heaviest
component at the bottom of the rack.
• If the rack is provided with stabilizing devices, install the stabilizers before mounting or servicing the unit in
the rack.
Statement 1006

1-6
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A3 Open and Remove the Front Door
Step 1 Complete the “DLP-A3 Reverse the Mounting Bracket to Fit a 19-inch (482.6 mm) Rack” task on
page 17-2 if you need to convert from a 23-inch (584.2 mm) to a 19-inch (482.6 mm) rack.
Step 2 To install the air filter on the bottom of the shelf rather than below the fan-tray assembly, complete the
“DLP-A4 Install the External Brackets and Air Filter” task on page 17-4.
Step 3 Complete the necessary rack mount task:
•DLP-A5 Mount the Shelf Assembly in a Rack (One Person), page 17-5
•DLP-A6 Mount the Shelf Assembly in a Rack (Two People), page 17-6
•DLP-A7 Mount Multiple Shelf Assemblies in a Rack, page 17-7
Step 4 Continue with the “NTP-A3 Open and Remove the Front Door” procedure on page 1-6.
Stop. You have completed this procedure.
NTP-A3 Open and Remove the Front Door
Step 1 Complete the “DLP-A8 Open the Front Door” task on page 17-8.
Step 2 As needed, complete the “DLP-A9 Remove the Front Door” task on page 17-9.
Step 3 Continue with the “NTP-A4 Remove the Backplane Covers” procedure on page 1-7.
Stop. You have completed this procedure.
Purpose This procedure opens and removes the front door to access the equipment.
Tools/Equipment Open-end wrench
Pinned hex key
Prerequisite Procedures NTP-A2 Install the Shelf Assembly, page 1-5
Required/As Needed Required
Onsite/Remote Onsite
Security Level None

1-7
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A4 Remove the Backplane Covers
NTP-A4 Remove the Backplane Covers
Warning The covers are an integral part of the safety design of the product. Do not operate the unit without the
covers installed.
Step 1 Complete the “DLP-A10 Remove the Lower Backplane Cover” task on page 17-10.
Step 2 Complete the “DLP-A11 Remove the Backplane Sheet Metal Cover” task on page 17-11.
Step 3 If you plan to install electrical interface assemblies (EIAs), continue with the “NTP-A5 Install the EIAs”
procedure on page 1-7. If not, continue with the “NTP-A6 Install the Power and Ground” procedure on
page 1-9.
Stop. You have completed this procedure.
NTP-A5 Install the EIAs
Purpose This procedure describes how to access the backplane by removing the
covers. The backplane has two sheet metal covers (one on either side)
and a lower backplane cover at the bottom.
Tools/Equipment #2 Phillips screwdriver
Medium slot-head screwdriver
Small slot-head screwdriver
Prerequisite Procedures NTP-A2 Install the Shelf Assembly, page 1-5
NTP-A3 Open and Remove the Front Door, page 1-6
Required/As Needed Required
Onsite/Remote Onsite
Security Level None
Purpose This procedure describes how to install electrical interface assemblies
(EIAs). Typically, an EIA panel is installed on the backplane during
manufacturing, but EIA panels can be ordered separately. Refer to the
Cisco ONS 15454 Reference Manual for descriptions of the EIAs.
Tools/Equipment #2 Phillips screwdriver
Medium slot-head screwdriver
Small slot-head screwdriver
Perimeter screws (9)
Inner screws (12)
Backplane cover screws (5)
EIA card (SMB, BNC, AMP Champ, UBIC-V, UBIC-H, MiniBNC)
Prerequisite Procedures NTP-A4 Remove the Backplane Covers, page 1-7
Required/As Needed Required if the node will use electrical signals

1-8
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A5 Install the EIAs
Caution Always use the supplied ESD wristband when working with a powered ONS 15454. Plug the wristband
cable into the ESD jack located on the lower-right outside edge of the shelf assembly.
Note EIAs are normally factory installed. Verify that the correct EIA is installed on the shelf assembly. If not,
install the correct EIA.
Note You do not need to power down the shelf before removing or installing an EIA. An in-service upgrade
of one EIA (A side or B side) is possible if all electrical traffic (DS-1, DS-3, DS3XM-6, and EC-1) is
being carried on the other side.
Step 1 Complete the “DLP-A12 Install a BNC or High-Density BNC EIA” task on page 17-12 as needed. BNCs
are locking connectors; the high-density BNC provides access to every port on every card.
Step 2 Complete the “DLP-A373 Install a MiniBNC EIA” task on page 20-57 as needed. The MiniBNC allows
up to 96 DS-3 circuits on each side of the ONS 15454.
Step 3 Complete the “DLP-A13 Install an SMB EIA” task on page 17-15 as needed. SMBs allow you to access
every port on every card using more space and efficient cabling.
Step 4 Complete the “DLP-A14 Install the AMP Champ EIA” task on page 17-16 as needed. AMP Champs are
exclusive to DS-1 cables.
Step 5 Complete the “DLP-A190 Install a UBIC-V EIA” task on page 18-61 as needed. The UBIC-V (vertical)
EIAs allow you to use high-density electrical cards. The UBIC-V EIAs provide SCSI connectors.
Step 6 Complete the “DLP-A399 Install a UBIC-H EIA” task on page 20-97 as needed. The UBIC-H
(horizontal) EIAs allow you to use high-density electrical cards. The UBIC-H EIAs provide SCSI
connectors.
Note To attach cables to the EIAs, see the “NTP-A9 Install the Electrical Card Cables on the
Backplane” procedure on page 1-22.
Step 7 Continue with the “NTP-A6 Install the Power and Ground” procedure on page 1-9.
Stop. You have completed this procedure.
Onsite/Remote Onsite
Security Level None

1-9
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A6 Install the Power and Ground
NTP-A6 Install the Power and Ground
Warning Shut off the power from the power source or turn off the breakers before beginning work.
Warning This equipment is intended to be grounded. Ensure that the host is connected to earth ground during
normal use. Statement 39
Warning Do not mix conductors of dissimilar metals in a terminal or splicing connector where physical contact
occurs (such as copper and aluminum, or copper and copper-clad aluminum), unless the device is
suited for the purpose and conditions of use.
Warning Connect the unit only to DC power source that complies with the safety extra-low voltage (SELV)
requirements in IEC 60950 based safety standards. Statement 1033
Warning The ONS 15454 relies on the protective devices in the building installation to protect against short
circuit, overcurrent, and grounding faults. Ensure that the protective devices are properly rated to
protect the system, and that they comply with national and local codes.
Purpose This procedure installs power feeds and grounds the ONS 15454.
Tools/Equipment #2 Phillips screwdriver
Medium slot-head screwdriver
Small slot-head screwdriver
Screws
Power cable (from fuse and alarm panel to assembly), #10 AWG, copper
conductors, 194 degrees F [90 degrees C])
Ground cable #6 AWG stranded
Listed pressure terminal connectors such as ring and fork types; connectors
must be suitable for #10 AWG copper conductors
Wire wrapper
Wire cutters
Wire strippers
Crimp tool
Fuse panel
Prerequisite Procedures NTP-A4 Remove the Backplane Covers, page 1-7
Required/As Needed Required
Onsite/Remote Onsite
Security Level None

1-10
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A7 Install the Fan-Tray Assembly
Warning A readily accessible two-poled disconnect device must be incorporated in the fixed wiring. Statement
1022
Warning When installing redundant power feeds, do not use aluminum conductors.
Warning If you use redundant power leads to power the ONS 15454, disconnecting one lead will not remove
power from the node.
Caution Always use the supplied ESD wristband when working with a powered ONS 15454. Plug the wristband
cable into the ESD jack located on the lower-right outside edge of the shelf assembly.
Step 1 Verify one of the following:
•If you have the 15454-SA-ANSI or 15454-SA-HD shelf, a 100-A fuse panel (30-A fuse per shelf
minimum) should be installed. If not, install one according to manufacturer’s instructions.
•If you have the 15454-SA-NEBS3 shelf, a standard 80-A fuse panel (20-A fuse per shelf minimum)
should be installed. If not, install one according to manufacturer’s instructions.
Step 2 Complete the “DLP-A16 Connect the Office Ground to the ONS 15454” task on page 17-18.
Step 3 Complete the “DLP-A17 Connect Office Power to the ONS 15454 Shelf” task on page 17-19.
Step 4 Complete the “DLP-A18 Turn On and Verify Office Power” task on page 17-21.
Step 5 Continue with the “NTP-A7 Install the Fan-Tray Assembly” procedure on page 1-10.
Stop. You have completed this procedure.
NTP-A7 Install the Fan-Tray Assembly
Purpose This procedure installs the fan-tray assembly.
Tools/Equipment #2 Phillips screwdriver
Medium slot-head screwdriver
Small slot-head screwdriver
Prerequisite Procedures NTP-A3 Open and Remove the Front Door, page 1-6
NTP-A6 Install the Power and Ground, page 1-9
Required/As Needed Required
Onsite/Remote Onsite
Security Level None

1-11
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A7 Install the Fan-Tray Assembly
Caution Do not operate an ONS 15454 without a fan-tray air filter. A fan-tray air filter is mandatory in order to
comply with Telcordia GR-78-CORE, except for applications in an outside plant cabinet.
Caution The 15454-FTA3 fan-tray assembly can only be installed in ONS 15454 Release 3.1 or later shelf
assemblies (15454-SA-ANSI, 800-19857; 15454-SA-HD, 800-24848). It includes a pin that does not
allow it to be installed in ONS 15454 shelf assemblies released earlier than ONS 15454 Release 3.1
(15454-SA-NEBS3E, 15454-SA-NEBS3, and 15454-SA-R1, P/N 800-0714915454). Installing the
15454-FTA3 in a noncompliant shelf assembly might result in failure of the alarm interface panel (AIP),
which in turn, will result in power loss to the fan-tray assembly.
Caution You must place the edge of the air filter flush against the front of the fan-tray assembly compartment
when installing the fan tray on top of the filter. Failure to do so could result in damage to the filter, the
fan tray, or both.
Caution Do not force a fan-tray assembly into place. Doing so can damage the connectors on the fan tray and/or
the connectors on the back panel of the shelf assembly.
Note If you are installing the ONS 15454 in an outside plant cabinet, remove the air filter to provide maximum
cooling capabilities and to comply with Telcordia GR-487-CORE.
Note To install the fan-tray assembly, it is not necessary to move any of the cable-management facilities.
Step 1 Install the air filter. The air filter can be installed internally between the fan tray and shelf assembly, or
externally by mounting the air filter bracket on the bottom of the shelf assembly. Slide the air filter into
the bracket.
Step 2 Slide the fan tray into the shelf assembly until the electrical plug at the rear of the tray plugs into the
corresponding receptacle on the backplane.
Step 3 To verify that the tray has plugged into the backplane, look at the fan tray and listen to determine that
the fans are running.
Figure 1-1 shows the location of the fan tray.

1-12
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A119 Install the Alarm Expansion Panel
Figure 1-1 Installing the Fan-Tray Assembly
Step 4 Continue with the “NTP-A119 Install the Alarm Expansion Panel” procedure on page 1-12 if you plan
to install an alarm expansion panel (AEP). If not, continue with the “NTP-A8 Attach Wires to Alarm,
Timing, LAN, and Craft Pin Connections” procedure on page 1-15.
Stop. You have completed this procedure.
NTP-A119 Install the Alarm Expansion Panel
FANFAIL CRIT MAJMIN
38532
Fan tray
assembly
LCD
Purpose This procedure installs an alarm expansion panel (AEP) onto the
15454-SA-ANSI or 15454-SA-HD shelf backplane. The AEP provides
alarm contacts in addition to the 16 provided by the AIC-I card. Typically,
the AEP is preinstalled when ordered with the ONS 15454; however, the
AEP can be ordered separately. The AIC-I card must be installed before
you can provision the alarm contacts enabled by the AEP.
Tools/Equipment #2 Phillips screwdriver
Medium slot-head screwdriver
Small slot-head screwdriver
Wire wrapper
6-pair #29 AWG double-shielded cable
Standoffs (4)
Prerequisite Procedures DLP-A10 Remove the Lower Backplane Cover, page 17-10

1-13
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A119 Install the Alarm Expansion Panel
Note The AIC-I card provides direct alarm contacts (external alarm inputs and external control outputs). In
the ANSI shelf, these AIC-I alarm contacts are routed through the backplane to wire-wrap pins
accessible from the back of the shelf. When you install an AEP, the direct AIC-I alarm contacts cannot
be used. Only the AEP alarm contacts can be used.
Step 1 Remove the two backplane screws. Replace the two screws with standoffs. Insert the longer standoff on
the left and the shorter standoff on the right (Figure 1-2).
Figure 1-2 Replace Backplane Screws with Standoffs
Step 2 Attach the remaining two standoffs on either side of the backplane (Figure 1-3).
Step 3 Position the AEP board over the standoffs.
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
78402
Longer
Shorter

1-14
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A119 Install the Alarm Expansion Panel
Figure 1-3 Installing Standoffs and the AEP
Step 4 Insert and tighten three screws to secure the AEP to the backplane.
Step 5 Connect the AEP cable to the backplane and AEP:
a. Connect the 10 colored wires to the wire-wrap pins on the backplane. Figure 1-4 shows where the
cable wires are connected. Table 1-1 shows AEP and AIC-I signals that each wire carries.
b. Plug the other end of the AEP cable into AEP connector port. The brown pin is on the top.
78403
AEP cable
Connector
Wires

1-15
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A8 Attach Wires to Alarm, Timing, LAN, and Craft Pin Connections
Figure 1-4 AEP Wire-Wrap Connections to Backplane Pins
Step 6 Continue with the “NTP-A8 Attach Wires to Alarm, Timing, LAN, and Craft Pin Connections”
procedure on page 1-15.
Stop. You have completed this procedure.
NTP-A8 Attach Wires to Alarm, Timing, LAN, and Craft Pin
Connections
Table 1-1 Pin Assignments for the AEP
AEP Cable Wire Backplane Pin AIC-I Signal AEP Signal
Black A1 GND AEP_GND
White A2 AE_+5 AEP_+5
Slate A3 VBAT– VBAT–
Violet A4 VB+ VB+
Blue A5 AE_CLK_P AE_CLK_P
Green A6 AE_CLK_N AE_CLK_N
Yellow A7 AE_DIN_P AE_DOUT_P
Orange A8 AE_DIN_N AE_DOUT_N
Red A9 AE_DOUT_P AE_DIN_P
Brown A10 AE_DOUT_N AE_DIN_N
1
2
3
4
A
FG4FG3FG2FG1
BITS LAN
1
2
3
4
AB
1
2
3
4
AB
IN
1
2
3
4
AB
IN/OUT
FG6FG5
7
8
9
5
10
6
ABAB
ENVIRONMENTAL ALARMS
IN
ACO
FG7
1
2
3
4
IN
AB
FG8
1
2
3
4
AB
MODEM
FG9
1
2
3
4
A
CRAFT
AUDVIS
FG10
1
2
3
4
AB
LOCAL ALARMS
IN
FG12FG11
11
12
ABB
96618
White
Black
Blue
Green
Slate
Violet
Orange
Yellow
Red
Brown
Purpose This procedure describes how to install alarm, timing, LAN, and craft
wires.
Tools/Equipment Wire wrapper
#22 or #24 AWG (0.51 mm² or 0.64 mm²) alarm wires
Prerequisite Procedures NTP-A4 Remove the Backplane Covers, page 1-7

1-16
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A120 Install an External Wire-Wrap Panel to the AEP
Warning The covers are an integral part of the safety design of the product. Do not operate the unit without the
covers installed.
Step 1 Complete the “DLP-A19 Install Alarm Wires on the Backplane” task on page 17-22 if you are using an
AIC or AIC-I card and are not using an AEP.
Step 2 Complete the “DLP-A20 Install Timing Wires on the Backplane” task on page 17-25 as needed. Timing
wires are necessary to provision external timing.
Step 3 Complete the “DLP-A21 Install LAN Wires on the Backplane” task on page 17-26 as needed. LAN wires
(or the LAN port on the TCC2/TCC2P) are necessary to create an external LAN connection.
Step 4 Complete the “DLP-A22 Install the TL1 Craft Interface” task on page 17-27 as needed. Craft wires (or
the EIA/TIA-232 port on the TCC2/TCC2P) are required to access TL1 using the craft interface.
Caution Always use the supplied ESD wristband when working with a powered ONS 15454. Plug the
wristband cable into the ESD jack located on the lower-right outside edge of the shelf
assembly.
Step 5 Complete one of the following:
•If you installed an AEP, continue with the “NTP-A120 Install an External Wire-Wrap Panel to the
AEP” procedure on page 1-16.
•If you did not install an AEP and you plan to install electrical cards, continue with the “NTP-A9
Install the Electrical Card Cables on the Backplane” procedure on page 1-22.
•If you did not install an AEP and do not plan to install electrical cards, continue with the “NTP-A11
Install the Rear Cover” procedure on page 1-23.
Stop. You have completed this procedure.
NTP-A120 Install an External Wire-Wrap Panel to the AEP
Step 1 Position the lower cover over the AEP. Make sure that the AEP AMP Champ connectors protrude
through the cutouts in the lower cover (Figure 1-5).
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None
Purpose This procedure connects an external wire-wrap panel to the AEP to provide
the physical alarm contacts for the AEP.
Tools/Equipment External wire-wrap panel
Prerequisite Procedures NTP-A119 Install the Alarm Expansion Panel, page 1-12
Required/As Needed As needed
Onsite/Remote Onsite
Security Level None

1-17
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A120 Install an External Wire-Wrap Panel to the AEP
Figure 1-5 Installing the AEP Cover
Step 2 Insert and tighten the eight screws to secure the AEP cover to the AEP.
Step 3 Connect the cables from the external wire-wrap panel to the AMP Champ connectors on the AEP.
Table 1-2 lists the alarm input pin assignments.
Table 1-2 Alarm Input Pin Assignments
AMP Champ Pin Signal Name AMP Champ Pin Signal Name
1 ALARM_IN_1– 27 GND
2 GND 28 ALARM_IN_2–
3 ALARM_IN_3– 29 ALARM_IN_4–
4 ALARM_IN_5– 30 GND
78404

1-18
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A120 Install an External Wire-Wrap Panel to the AEP
Table 1-3 lists the alarm output pin assignments.
5 GND 31 ALARM_IN_6–
6 ALARM_IN_7– 32 ALARM_IN_8–
7 ALARM_IN_9– 33 GND
8 GND 34 ALARM_IN_10–
9 ALARM_IN_11– 35 ALARM_IN_12–
10 ALARM_IN_13– 36 GND
11 GND 37 ALARM_IN_14–
12 ALARM_IN_15– 38 ALARM_IN_16–
13 ALARM_IN_17– 39 GND
14 GND 40 ALARM_IN_18–
15 ALARM_IN_19– 41 ALARM_IN_20–
16 ALARM_IN_21– 42 GND
17 GND 43 ALARM_IN_22–
18 ALARM_IN_23– 44 ALARM_IN_24–
19 ALARM_IN_25– 45 GND
20 GND 46 ALARM_IN_26–
21 ALARM_IN_27– 47 ALARM_IN_28–
22 ALARM_IN_29– 48 GND
23 GND 49 ALARM_IN_30–
24 ALARM_IN_31– 50 —
25 ALARM_IN_+ 51 GND1
26 ALARM_IN_0- 52 GND2
Table 1-2 Alarm Input Pin Assignments (continued)
AMP Champ Pin Signal Name AMP Champ Pin Signal Name
Table 1-3 Alarm Output Pin Assignments
AMP Champ Pin Signal Name AMP Champ Pin Signal Name
1— 27COM_0
2COM_128—
3 NO_1 29 NO_2
4— 30COM_2
5COM_331—
6 NO_3 32 NO_4
7— 33COM_4
8COM_534—
9 NO_5 35 NO_6

1-19
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A120 Install an External Wire-Wrap Panel to the AEP
Figure 1-6 illustrates the alarm input connectors.
10 — 36 COM_6
11 COM_7 37 —
12 NO_7 38 NO_8
13 — 39 COM_8
14 COM_9 40 —
15 NO_9 41 NO_10
16 — 42 COM_10
17 COM_11 43 —
18 NO_11 44 NO_12
19 — 45 COM_12
20 COM_13 46 —
21 NO_13 47 NO_14
22 — 48 COM_14
23 COM_15 49 —
24 NO_15 50 —
25 — 51 GND1
26 NO_0 52 GND2
Table 1-3 Alarm Output Pin Assignments (continued)
AMP Champ Pin Signal Name AMP Champ Pin Signal Name

1-20
Cisco ONS 15454 Procedure Guide, R5.0
March 2005
Chapter 1 Install the Shelf and Backplane Cable
NTP-A120 Install an External Wire-Wrap Panel to the AEP
Figure 1-6 Alarm Input Connector
Figure 1-7 illustrates the alarm output connectors.
ALARM_IN_8-
XREF=5
Connector
Alarm Input
GND
ALARM_IN_0-
XREF=5
XREF=5 ALARM_IN_2- XREF=5
ALARM_IN_3- XREF=5 ALARM_IN_4-
XREF=5
ALARM_IN_5-
ALARM_IN_6-
XREF=5
ALARM_IN_7- XREF=5
XREF=5
ALARM_IN_9-
XREF=5 ALARM_IN_10- XREF=5
ALARM_IN_11- XREF=5 ALARM_IN_12-
XREF=5
ALARM_IN_13-
XREF=5 ALARM_IN_14- XREF=5
ALARM_IN_15- XREF=6 ALARM_IN_16-
XREF=6
ALARM_IN_17-
XREF=6 ALARM_IN_18- XREF=6
ALARM_IN_19- XREF=6 ALARM_IN_20-
ALARM_IN_21- XREF=6
XREF=6 ALARM_IN_22-
XREF=6 ALARM_IN_24- XREF=6
ALARM_IN_25-
XREF=6 ALARM_IN_26- XREF=6
ALARM_IN_27- XREF=6 ALARM_IN_28-
XREF=6
ALARM_IN_29-
XREF=6 ALARM_IN_30- XREF=6
ALARM_IN_31- XREF=5
ALARM_IN_+
GND
GND1
GND2
52
51
9
8
7
6
50
5
49
48
47
46
45
44
43
42
41
40
4
39
38
37
36
35
34
33
32
31
30
3
29
28
27
26
25
24
23
22
21
20
2
19
18
17
16
15
14
13
12
11
10
1
P3
XREF=6
ALARM_IN_23-
ALARM_IN_1- XREF=5
79875
