Cisco PA-4C-E 1 Operator's manual

Americas Headquarters:
© 2007 Cisco Systems, Inc. All rights reserved.
Cisco Systems, Inc., 170 West Tasman Drive, San Jose, CA 95134-1706 USA
PA-4C-E 1-Port High-Performance
ESCON Channel Port Adapter Installation and
Configuration
Product Number: PA-4C-E(=)
Platforms Supported: Cisco 7200 Series Routers, including the Cisco 7200 VXR Routers
Document part number: OL-3473-02

2
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration OL-3743-02
Preface
Preface
This preface describes the objectives and organization of this document and explains how to find
additional information on related products and services. This preface contains the following sections:
•Document Revision History, page 2
•Objectives, page 2
•Organization, page 2
•Related Documentation, page 3
•Obtaining Documentation, Obtaining Support, and Security Guidelines, page 3
Document Revision History
The Document Revision History table below, beginning with version OL-3473-03, records technical
changes to this document.
Objectives
This document describes how to install and configure the 1-Port High-Performance Enterprise Systems
Connection (ESCON) IBM Channel Port Adapter (PA-4C-E), hereafter referred to as the HP ESCON
PA, which is supported on Cisco 7200 series routers, including the Cisco 7200 VXR routers.
Organization
This document contains the following four sections:
Document Version Date Change Summary
OL-3473-02 April, 2007 Restructured to parallel other port adapter
documentation.
Title Description
Overview Describes the HP ESCON PA and its LED displays,
cables, and receptacles.
Preparing for Installation Describes safety considerations, tools required, and
procedures you should perform before the actual
installation.
Removing and Installing Port Adapters Describes the procedures for installing and removing
HP ESCON PA port adapters in the supported platforms.
Configuring the HP ESCON PA Provides instructions for configuring the HP ESCON PA
on the supported platforms.

3
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration
OL-3743-02
Preface
Related Documentation
Your router, switch, or gateway and the Cisco IOS software running on it contain extensive features and
functionality, which are documented in the following resources:
•Cisco IOS software:
For configuration information and support, refer to the modular configuration and modular
command reference publications in the Cisco IOS software configuration documentation set that
corresponds to the software release installed on your Cisco hardware.
Note You can access Cisco IOS software configuration and hardware installation and maintenance
documentation on the World Wide Web at http://www.cisco.com,
http://www-china.cisco.com,or http://www-europe.cisco.com.
•Cisco 7200 series routers:
– For an online directory to quickly access documents for Cisco 7200 series routers, refer to the
Cisco 7200 Series Routers Documentation Roadmap at the following URL:
http://www.cisco.com/en/US/products/hw/routers/ps341/products_documentation_roadmap09
186a00801c0915.html
– For hardware installation and configuration information (including the Cisco 7206 or
Cisco 7206VXR as a router shelf in a Cisco AS5800 Universal Access Server), refer to the
online installation and configuration guide and quick start for your Cisco 7200 series router.
– For port adapter hardware and memory configuration guidelines, refer to the Cisco 7200 Series
Port Adapter Hardware Configuration Guidelines.
– For information on network processing engines or network services engines, refer to the
Network Processing Engine and Network Services Engine Installation and Configuration
document.
•Cisco 7200 VXR routers:
– For an online directory to quickly access documents for Cisco 7200 VXR routers, refer to the
Cisco 7200 Series Routers Documentation Roadmap at the following URL:
http://www.cisco.com/en/US/products/hw/routers/ps341/products_documentation_roadmap09
186a00801c0915.html
– For hardware installation and maintenance information, refer to the Cisco 7200 VXR
Installation and Configuration Guide or the Cisco 7200 VXR Routers Quick Start Guide.
•For international agency compliance, safety, and statutory information for WAN interfaces, refer to
the following document. Use the documentation roadmap for the Cisco 7200 series routers to link
to this document:
– Regulatory Compliance and Safety Information for the Cisco 7200 Series Routers
Obtaining Documentation, Obtaining Support, and Security Guidelines
For information on obtaining documentation, obtaining support, providing documentation feedback,
security guidelines, and also recommended aliases and general Cisco documents, see the monthly
What’s New in Cisco Product Documentation, which also lists all new and revised technical
documentation at:

4
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration OL-3743-02
Preface
http://www.cisco.com/en/US/docs/general/whatsnew/whatsnew.html

5
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration
OL-3743-02
Overview
Overview
This section describes the HP ESCON PA, including channel attachment, the LED functions, the
memory and cable requirements, and contains the following subsections:
•Port Adapter Overview, page 5
•ESCON Specifications, page 7
•LEDs, page 7
•ESCON Cable, page 9
•Port Adapter Slot Locations on the Supported Platforms, page 9
•Identifying Interface Addresses, page 10
Port Adapter Overview
The HP ESCON PA is a high-speed (100 bandwidth points) port adapter for Cisco 7200 series routers,
including the Cisco 7200 VXR routers, that supports IP Datagram, TCP/IP Offload, TN3270 Server, TCP
Assist, Cisco MultiPath Channel (CMPC), CMPC+, and Cisco SNA (CSNA) software applications.
The HP ESCON PA provides a single channel interface for Cisco 7200 series routers
A mainframe channel (referred to as a channel) is an intelligent processor that manages the protocol on
the communications media and controls the data transfer to and from the main central processing unit
(CPU) storage. Devices called input/output processors (IOPs) communicate between the host CPU and
the channel. One IOP controls multiple channels. There is no relationship between the number of CPUs
and the number of IOPs.
The channel relieves the mainframe CPU of direct communication with input/output (I/O) devices,
which saves processing cycles and allows data processing and communications tasks to run concurrently.
Channels use one or more channel paths as the links between mainframes and I/O devices. I/O devices
are connected directly to control units, which provide the logical capabilities required to operate and
control the I/O devices.
In some situations, this interface can eliminate the need for a separate front-end processor (FEP). The
HP ESCON PA contains one ESCON I/O connector.
The HP ESCON PA (Figure 1) provides a single channel attachment interface for connecting Cisco 7200
series routers to an ESCON director or to a mainframe channel.
Note The Cisco 7200 series routers support the OIR of all port adapter types.
Figure 1 ESCON Channel Port Adapter, Faceplate View
The HP ESCON PA has a single female duplex connector and has 128 MB of DRAM. There are no
memory options for the HP ESCON PA.
45335
EN
SIGNAL
ONLINE
LOADED
PRESENT
HP ESCON PA

6
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration OL-3743-02
Overview
You can install the HP ESCON PA in any of the available port adapter slots in a Cisco 7200 series router.
Figure 2 shows an HP ESCON PA installed in port adapter slot 1 of a Cisco 7206.
Figure 2 Cisco 7206 with an HP ESCON PA in Port Adapter Slot 1
Note The HP ESCON PA supports online insertion and removal (OIR), which allows you to install or remove
an HP ESCON PA while the system is operating without shutting down system power.
The entire HP ESCON PA microcode image is delivered on a router Flash memory card or SanDisk
memory device, or you can download it from Cisco.com.
•When ordered as a spare, the HP ESCON PA microcode is available via Cisco.com.
•When ordered as part of a new system, the HP ESCON PA microcode is available on Flash memory
cards and SanDisk memory devices (which also include the Cisco IOS release compatible with the
microcode version) and via Cisco.com.
•When shipped with a new system, there is a default setting in Cisco IOS that points to the HP
ESCON PA microcode with which it has been virtually bundled (separately bundled and preloaded
onto the Flash memory card or SanDisk memory device along with the compatible Cisco IOS
software). The Cisco IOS software loads the HP ESCON PA microcode image onto the port adapter
when the router boots and when an HP ESCON PA is inserted into a router that has already been
booted.
We recommend that you use the version of the HP ESCON PA microcode that is virtually bundled with
your Cisco IOS software. If you choose not to, you must copy a microcode image onto the router Flash
memory card or SanDisk memory device and use the microcode router configuration command to
instruct the Cisco IOS software to use the microcode image you copied instead of the microcode image
virtually bundled with your version of the Cisco IOS software.
•For instructions on placing HP ESCON PA microcode on the router Flash memory card, see the
“Copying a New Image to the Flash Memory Card on a Cisco 7200 Series Router” section on
page 36.
•For instructions on placing HP ESCON PA microcode on the SanDisk memory device, see the
“Using SanDisk Devices” section on page 38.
•For instructions on configuring Cisco IOS to use an HP ESCON PA image from the router Flash
memory card or SanDisk memory device, refer to the “Configuring the HP ESCON PA Microcode”
section on page 34.
H11717
ETHERNET 10BT
ENABLED
0
2
1
3
LINK
0
1
2
3
ENABLED
MII
LINK
RJ45
FAST ETHERNET
0
TOKEN RING
0
1
2
3
0
2
4
1
3
5
6
ETHERNET-10BFL
EN
RX
0
1
2
3
4
TX
RX
TX
RX
TX
RX
TX
RX
TX
FAST ETHERNET INPUT/OUTPUT CONTROLLER
ENABLED
PCMCIA
EJECT
SLOT 0
FE
ENABLE
FE LINK
CPU RESET 1O POWER
OK
SLOT 1
FE MII
Cisco 7200
Series
EN
PRESENT LOADED SIGNAL ONLINE
Parallel channel
port adapter

7
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration
OL-3743-02
Overview
•For general information on HP ESCON PA microcode, refer to the “HP ESCON PA Microcode
Overview” section on page 12. For specific instructions to configure the Cisco IOS software to
download microcode from the router Flash memory card or SanDisk memory device, refer to the
“Upgrading the HP ESCON PA Microcode from Cisco.com” section on page 33.
ESCON Specifications
Table 1 lists the specifications for the ESCON interfaces.
LEDs
The functions of the HP ESCON PA LEDs are as follows:
•Enabled—Indicates that the HP ESCON PA is enabled for operation by the system.
•Present—Indicates that the ESCON channel is detected by the HP ESCON PA.
•Loaded—Indicates that the ESCON channel firmware is completely loaded.
•Signal—Indicates that the sync signal has been detected from the ESCON neighbor node.
•Online—Indicates that an establish-logical-path request has been received from the channel and that
the establish-logical-path request matches one of the paths configured on the HP ESCON PA.
Table 1 ESCON Specifications
Characteristic ESCON Specification
Supported processor I/O architectures ESA/390
Bit transmission Serial
Maximum distance (for LED with
ESCON) 1.9 miles (3.1 km) point-to-point 5.7 miles (9.2 km) with two ESCON Directors and each hop
not exceeding 3 km.
Channel data rate Up to 17 MBps
Signaling rate 200 Mbps
Cable types Fiber-optic (62.5/125 micron multimode)
Addition of devices to running systems Dynamic1
Number of addressable devices per
channel 256 x 16 x 16 x 2532
Connectable control units per channel Up to 59 (through a 9032 ESCON Director)
Connectable channels per adapter Up to 59 (through a 9032 ESCON Director); varies by
control unit
1. The HP ESCON PA requires dynamic = NO with HCD.
2. Where 256 represents available unit addresses, 16 represents the number of logical partitions (LPARs), 16 represents the
number of control unit images, and 253 represents the number of ESCON director paths. It is unlikely a system would have
the resources to support the total number of available addresses.

8
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration OL-3743-02
Overview
Figure 3 shows the LED indicators.
Figure 3 HP ESCON PA LED Indicators
Table 2 shows the HP ESCON PA LED indicator sequences during a cold boot. The ENABLED LED is
not part of the following sequences; it remains on during the boot sequence (Figure 4).
Figure 4 LED Boot Sequence
46956
EN
SIGNAL
ONLINE
LOADED
PRESENT
Table 2 Cold Boot LED Sequence
Sequence Present Loaded Signal Online
1 Off On Off Off
2 Off Off Off On
3 Off On Off On
4 On Off Off Off
5 OnOnOffOff
6OnOffOffOn
7 OnOnOffOn
8 Off Off On Off
91
1. Indicates that the HP ESCON PA is starting to execute the microcode
and waiting for commands
Off Off Off Off
EN
SIGNAL
ONLINE
LOADED
PRESENT
EN
SIGNAL
ONLINE
LOADED
PRESENT
EN
SIGNAL
ONLINE
LOADED
PRESENT
EN
SIGNAL
ONLINE
LOADED
PRESENT
EN
SIGNAL
ONLINE
LOADED
PRESENT
EN
SIGNAL
ONLINE
LOADED
PRESENT
EN
SIGNAL
ONLINE
LOADED
PRESENT
EN
SIGNAL
ONLINE
LOADED
PRESENT
EN
SIGNAL
ONLINE
LOADED
PRESENT
46957
1*
* Because of the short duration of the LEDs, you will typically
see onl
y
these LED se
q
uences.
2
3
4
5
6
7*
8*
9

9
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration
OL-3743-02
Overview
ESCON Cable
The ESCON channel interface uses 62.5/125 micrometer, multimode, fiber-optic cable with male duplex
connectors at each end (Figure 5). ESCON cables are not available from Cisco. Refer to the ESCON
specifications in and contact your cable supplier or the vendor of your host CPU to order the correct
ESCON cable.
Figure 5 ESCON Interface Duplex Connector for the ESCON Channel Port Adapter
Port Adapter Slot Locations on the Supported Platforms
The following sections provide port adapter slot locations and related information:
•Cisco 7200 Series Routers and Cisco 7200 VXR Routers Slot Numbering, page 9
Cisco 7200 Series Routers and Cisco 7200 VXR Routers Slot Numbering
Cisco 7204 routers and Cisco 7204VXR routers have four slots for port adapters, and one slot for an
input/output (I/O) controller. The slots are numbered from the lower left to the upper right, beginning
with slot 1 and continuing through slot 4. You can place a port adapter in any of the slots (slot 1 through
slot 4). Slot 0 is always reserved for the I/O controller. The Cisco 7204 router and Cisco 7204VXR router
are not shown.
Cisco 7206 routers and Cisco 7206VXR routers have six slots for port adapters, and one slot for an
input/output (I/O) controller. The slots are numbered from the lower left to the upper right, beginning
with slot 1 and continuing through slot 6. You can place a port adapter in any of the six slots (slot 1
through slot 6). Slot 0 is always reserved for the I/O controller. Figure 6 shows the slot numbering on a
Cisco 7206 router. The Cisco 7206VXR router is not shown.
Note Interface ports are numbered from left to right starting with 0.
H2454

10
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration OL-3743-02
Overview
Figure 6 Port Adapter Slots in the Cisco 7206 Router
Identifying Interface Addresses
This section describes how to identify the interface addresses for the port adapter slots and ESCON
channel port numbers. Interface addresses specify the actual physical location of each interface port on
the router.
This address is composed of a two-part number in the format port-adapter-slot
number/interface-port-number, as follows:
•The first number identifies the port adapter slot in which the HP ESCON PA is installed.
•The second number identifies the interface port on the HP ESCON PA, which is always numbered
as interface 0 for the HP ESCON PA.
Note Some IBM channel attach software features are configured on a virtual port. On the CIP cards installed
in a Cisco 7500-series router, there are up to two physical ports, numbered 0 and 1, and a virtual port,
numbered 2. However, on the HP ESCON PA installed in a Cisco 7200 series router, the single physical
port and the virtual port are configured using the same port number identifier, number 0.
Interface ports maintain the same address regardless of whether other port adapters are installed or
removed from the slot. However, when you move a port adapter to a different slot, the first number in
the address changes to reflect the new port adapter slot number.
Note The HP ESCON PA is considered a high-speed port adapter; there are specific configuration guidelines
that must be observed. Refer to the publication Cisco 7200 Series Port Adapter Hardware Configuration
Guidelines (Document Number 78-3471-xx), which shipped with your Cisco 7200 series chassis and is
also available on the Cisco Connection Documentation, Enterprise Series CD-ROM.
The following subsections describe the interface address formats for the supported platforms:
•Cisco 7200 Series Routers and Cisco 7200 VXR Routers Interface Addresses, page 11
H6422
2
ETHERNET 10BT
ENABLED
0
2
1
3
LINK
0
1
2
3
ENABLED
MII
LINK
RJ45
FAST ETHERNET
0
0
4
1
3
5
6
Port adapter slot 5
Port adapter slot 3
Port adapter slot 1
FAST SERIAL
EN
TD
TC
RD
RC
LB
CD
TD
TC
RD
RC
LB
CD
TD
TC
RD
RC
LB
CD
TD
TC
RD
RC
LB
CD
TOKEN RING
0
1
2
3
ETHERNET-10BFL
EN
RX
0
1
2
3
4
TX
RX
TX
RX
TX
RX
TX
RX
TX
Blank port adapter
Port adapter slot 6
Port adapter slot 4
Port adapter slot 2
MII
EN
RJ45
EN
RJ45
LINK
1O PWR
OK
RJ-45
CPU RESET
FAST ETHERNET INPUT/OUTPUT CONTROLLER
ENABLED
PCMCIA
EJECT
SLOT 0
SLOT 1
FE MII
Port adapter slot 0

11
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration
OL-3743-02
Overview
Table 3 describes the interface addresses for the Cisco 7200 series routers, includingCisco 7200 VXR
routers.
Cisco 7200 Series Routers and Cisco 7200 VXR Routers Interface Addresses
In Cisco 7200 series routers, port adapter slot numbers port adapter slots are numbered from the lower
left to the upper right, beginning with port adapter slot 1 and continuing through port adapter slot 4 for
the Cisco 7204, and slot 6 for the Cisco 7206. Port adapter slot 0 is reserved for the optional Fast
Ethernet port on the I/O controller. For ESCON ports, the individual interface port numbers are always 0.
The interface address is composed of a two-part number in the format
port-adapter-slot-number/interface-port-number. For example, the ESCON port on an HP ESCON PA
in port adapter slot 3 would have the address 3/0. If the HP ESCON PA was in port adapter slot 1, the
interface address would be 1/0.
Table 3 Identifying Interface Addresses
Platform Interface Address Format Numbers Syntax
Cisco 7200 series
routers and
Cisco 7200 VXR
routers (,7204,
7204VXR, 7206,
7206VXR)
Port-adapter-slot-number/interface-port-number Port adapter slot—11through 6 (depends
on the number of slots in the router)
Interface port—0
1. Port adapter slot 0 is reserved for the Fast Ethernet port on the I/O controller (if present).
1/0

12
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration OL-3743-02
Preparing for Installation
Preparing for Installation
This section describes the general equipment, safety, and site preparation requirements for installing the
HP ESCON PA. It also includes microcode overview information.This section contains the following
subsections:
•Required Tools and Equipment, page 12
•HP ESCON PA Microcode Overview, page 12
•Hardware and Software Requirements, page 13
•Checking Hardware and Software Compatibility, page 14
•Safety Guidelines, page 15
•Laser LED Safety Information, page 18
Required Tools and Equipment
You need the following parts and tools to install an HP ESCON PA. If you need additional equipment,
contact a service representative for ordering information.
•HP ESCON PA
•ESCON interface cables
•ESD-prevention equipment or the disposable grounding wrist strap included with all upgrade kits,
field-replaceable units (FRUs), and spares
•An antistatic mat on which you can place the removed port adapter
•An antistatic container in which you can place the failed port adapter for shipment to the factory
HP ESCON PA Microcode Overview
Microcode, also known as firmware, is a set of processor-specific software instructions that enables and
manages the features and functions of a specific port adapter type. At system startup or reload, the
system loads the microcode for each port adapter type present in the system.
The entire HP ESCON PA microcode image is delivered on a router Flash memory card or SanDisk
memory device, or you can download it from Cisco.com.
New microcode is released to enable new features, improve performance, or fix known problems in
earlier versions. The Cisco 7200 series routers support downloadable software and microcode images
for most upgrades. This support lets you download new or upgraded images remotely, store the images
in router memory, and load the new images at system startup without physically accessing the router.
You can store multiple versions of an image in Flash or SanDisk memory for a specific processor type,
and use configuration commands to specify which version of the image loads at startup. All port adapters
of the same type (for example, all HP ESCON PA port adapters) use the same microcode image.
By default, the HP ESCON PA microcode is loaded from the router Flash memory card or SanDisk
memory devicefor the Cisco 7200 series routers. The default HP ESCON PA microcode version is found
by entering the show microcode command.

13
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration
OL-3743-02
Preparing for Installation
The following example is a partial display of the show microcode command output:
Router# show microcode
Microcode images for downloadable hardware
HW Type Microcode image names
------------------------------------------
ecpa default slot0:xcpa28-0
configured slot0:xcpa218-2
pcpa default slot0:xcpa28-0
Note In Cisco IOS Release 12.1(5)T or later, the filenames of all released HP ESCON PA microcode images
use the conventions xcpa28-nn (for example, xcpa28-1). Interim pre-release versions of HP ESCON PA
microcode images use the convention xcpa218-nnn (for example, xcpa218-2).
Hardware and Software Requirements
The show version command displays the current hardware configuration of the router, including the
system software version that is loaded and running. For the HP ESCON PA, the show microcode
command lists the recommended and the configured microcode version. The show controller command
shows the microcode version running on the HP ESCON PA in the router.
To view the current version of software or microcode stored on the router Flash memory card, use the
show flash slot0: or the dir slot0: EXEC commands. Refer to the “Upgrading Your HP ESCON PA
Microcode” section on page 33 for basic configuration information.
If the displays indicate that the required system software and microcode are not available in your system,
refer to the “Obtaining Documentation, Obtaining Support, and Security Guidelines” section on page 3
or contact a service representative for upgrade information.
The following subsections indicate the minimum hardware and software requirements for each
supported platform:
•Cisco 7200 Series Routers and Cisco 7200 VXR Routers Hardware and Software Requirements,
page 13
Cisco 7200 Series Routers and Cisco 7200 VXR Routers Hardware and Software Requirements
The minimum hardware and software requirements for the HP ESCON PA on Cisco 7200 series and
Cisco 7200 VXR series routers are:
•The HP ESCON PA is used in the Cisco 7200 series routers and can be installed in any available
port adapter slot.
•The Cisco 7200 series router requires a minimum of 32 MB of dynamic RAM (DRAM). The HP
ESCON PA is a high-speed interface (100 bandwidth points).
Note For port adapter hardware and memory configuration guidelines for the Cisco 7200 series routers, refer
to the document Cisco 7200 Series Port Adapter Hardware Configuration Guidelines at the following
URL:
http://www.cisco.com/en/US/products/hw/modules/ps2033/products_configuration_guide_book09186a
00801056ef.htm
•The HP ESCON PA requires that the Cisco 7200 series router is running Cisco IOS
Release 12.1(5)T or later.

14
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration OL-3743-02
Preparing for Installation
Table 4 lists the specific Cisco IOS software images that are compatible with the HP ESCON PA.
Table 5 specifies the recommended minimum level of HP ESCON PA microcode for the corresponding
Cisco IOS release.
For the latest Cisco IOS release that supports the HP ESCON PA on the Cisco 7200 series routers, refer
to “Checking Hardware and Software Compatibility” section on page 14.
Checking Hardware and Software Compatibility
To check the minimum software requirements of Cisco IOS software with the hardware installed on your
router, Cisco maintains the Software Advisor tool on Cisco.com. This tool does not verify whether
modules within a system are compatible, but it does provide the minimum IOS requirements for
individual hardware modules or components.
Note Access to this tool is limited to users with Cisco.com login accounts.
To access Software Advisor, click Log In at Cisco.com and go to Support > Tools and Resources. You
can also access the tool by pointing your browser directly to
http://www.cisco.com/en/US/support/tsd_most_requested_tools.html.
Choose a product family or enter a specific product number to search for the minimum supported
software release needed for your hardware.
Table 4 Cisco IOS Release Image Names
Cisco IOS Release Image Names
Release 12.1(5)T c7200-aejs-mz
c7200-aejs40-mz
c7200-aejs56i-mz
c7200-ajs-mz
c7200-ajs40-mz
c7200-ajs56i-mz
c7200-js-mz
c7200-js40-mz
c7200-js56i-mz
c7200-ds-mz
c7200-ds40-mz
c7200-ds56i-mz
Table 5 Cisco IOS Releases and HP ESCON PA Microcode Image
Cisco IOS Release HP ESCON PA Image
Release 12.1(5)T xcpa28-0

15
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration
OL-3743-02
Preparing for Installation
Safety Guidelines
This section provides safety guidelines that you should follow when working with any equipment that
connects to electrical power or telephone wiring.
Safety Warnings
Safety warnings appear throughout this publication in procedures that, if performed incorrectly, might
harm you. A warning symbol precedes each warning statement.
Warning IMPORTANT SAFETY INSTRUCTIONS
This warning symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, be aware of the hazards involved with electrical circuitry and be familiar
with standard practices for preventing accidents. Use the statement number provided at the end of
each warning to locate its translation in the translated safety warnings that accompanied this
device. Statement 1071
SAVE THESE INSTRUCTIONS
Waarschuwing
BELANGRIJKE VEILIGHEIDSINSTRUCTIES
Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die lichamelijk letsel kan
veroorzaken. Voordat u aan enige apparatuur gaat werken, dient u zich bewust te zijn van de bij
elektrische schakelingen betrokken risico's en dient u op de hoogte te zijn van de standaard
praktijken om ongelukken te voorkomen. Gebruik het nummer van de verklaring onderaan de
waarschuwing als u een vertaling van de waarschuwing die bij het apparaat wordt geleverd, wilt
raadplegen.
BEWAAR DEZE INSTRUCTIES
Varoitus
TÄRKEITÄ TURVALLISUUSOHJEITA
Tämä varoitusmerkki merkitsee vaaraa. Tilanne voi aiheuttaa ruumiillisia vammoja. Ennen kuin
käsittelet laitteistoa, huomioi sähköpiirien käsittelemiseen liittyvät riskit ja tutustu
onnettomuuksien yleisiin ehkäisytapoihin. Turvallisuusvaroitusten käännökset löytyvät laitteen
mukana toimitettujen käännettyjen turvallisuusvaroitusten joukosta varoitusten lopussa näkyvien
lausuntonumeroiden avulla.
SÄILYTÄ NÄMÄ OHJEET
Attention
IMPORTANTES INFORMATIONS DE SÉCURITÉ
Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une situation pouvant
entraîner des blessures ou des dommages corporels. Avant de travailler sur un équipement, soyez
conscient des dangers liés aux circuits électriques et familiarisez-vous avec les procédures
couramment utilisées pour éviter les accidents. Pour prendre connaissance des traductions des
avertissements figurant dans les consignes de sécurité traduites qui accompagnent cet appareil,
référez-vous au numéro de l'instruction situé à la fin de chaque avertissement.
CONSERVEZ CES INFORMATIONS

16
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration OL-3743-02
Preparing for Installation
Warnung
WICHTIGE SICHERHEITSHINWEISE
DiesesWarnsymbolbedeutetGefahr.Siebefindensichin einer Situation, diezuVerletzungen führen
kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und
den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder
Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten
Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
BEWAHREN SIE DIESE HINWEISE GUT AUF.
Avvertenza
IMPORTANTI ISTRUZIONI SULLA SICUREZZA
Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe causare infortuni alle
persone. Prima di intervenire su qualsiasi apparecchiatura, occorre essere al corrente dei pericoli
relativi ai circuiti elettrici e conoscere le procedure standard per la prevenzione di incidenti.
Utilizzare il numero di istruzione presente alla fine di ciascuna avvertenza per individuare le
traduzioni delle avvertenze riportate in questo documento.
CONSERVARE QUESTE ISTRUZIONI
Advarsel
VIKTIGE SIKKERHETSINSTRUKSJONER
Dette advarselssymbolet betyr fare. Du er i en situasjon som kan føre til skade på person. Før du
begynner å arbeide med noe av utstyret, må du være oppmerksom på farene forbundet med
elektriske kretser, og kjenne til standardprosedyrer for å forhindre ulykker. Bruk nummeret i slutten
av hver advarsel for å finne oversettelsen i de oversatte sikkerhetsadvarslene som fulgte med denne
enheten.
TA VARE PÅ DISSE INSTRUKSJONENE
Aviso
INSTRUÇÕES IMPORTANTES DE SEGURANÇA
Este símbolo de aviso significa perigo. Você está em uma situação que poderá ser causadora de
lesões corporais. Antes de iniciar a utilização de qualquer equipamento, tenha conhecimento dos
perigos envolvidos no manuseio de circuitos elétricos e familiarize-se com as práticas habituais de
prevenção de acidentes. Utilize o número da instrução fornecido ao final de cada aviso para
localizar sua tradução nos avisos de segurança traduzidos que acompanham este dispositivo.
GUARDE ESTAS INSTRUÇÕES
¡Advertencia!
INSTRUCCIONES IMPORTANTES DE SEGURIDAD
Este símbolo de aviso indica peligro. Existe riesgo para su integridad física. Antes de manipular
cualquier equipo, considere los riesgos de la corriente eléctrica y familiarícese con los
procedimientos estándar de prevención de accidentes. Al final de cada advertencia encontrará el
número que le ayudará a encontrar el texto traducido en el apartado de traducciones que acompaña
a este dispositivo.
GUARDE ESTAS INSTRUCCIONES

17
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration
OL-3743-02
Preparing for Installation
Varning!
VIKTIGA SÄKERHETSANVISNINGAR
Denna varningssignal signalerar fara. Du befinner dig i en situation som kan leda till personskada.
Innan du utför arbete på någon utrustning måste du vara medveten om farorna med elkretsar och
känna till vanliga förfaranden för att förebygga olyckor. Använd det nummer som finns i slutet av
varje varning för att hitta dess översättning i de översatta säkerhetsvarningar som medföljer denna
anordning.
SPARA DESSA ANVISNINGAR

18
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration OL-3743-02
Preparing for Installation
Electrical Equipment Guidelines
Follow these basic guidelines when working with any electrical equipment:
•Before beginning any procedures requiring access to the chassis interior, locate the emergency
power-off switch for the room in which you are working.
•Disconnect all power and external cables before moving a chassis.
•Do not work alone when potentially hazardous conditions exist and never assume that power has
been disconnected from a circuit; always check.
•Do not perform any action that creates a potential hazard to people or makes the equipment unsafe.
Carefully examine your work area for possible hazards such as moist floors, ungrounded power
extension cables, and missing safety grounds.
Preventing Electrostatic Discharge Damage
Electrostatic discharge (ESD) damage, which can occur when electronic cards or components are
improperly handled, results in complete or intermittent failures. Port adapters and processor modules
comprise printed circuit boards that are fixed in metal carriers. Electromagnetic interference (EMI)
shielding and connectors are integral components of the carrier. Although the metal carrier helps to
protect the board from ESD, use a preventive antistatic strap during handling.
The following guidelines help prevent ESD damage:
•Always use an ESD wrist or ankle strap and ensure that it makes good skin contact.
•Connect the equipment end of the strap to an unfinished chassis surface.
•When installing a component use any available ejector levers or captive installation screws to
properly seat the bus connectors in the backplane or midplane. These devices prevent accidental
removal, provide proper grounding for the system, and help to ensure that bus connectors are
properly seated.
•When removing a component use any available ejector levers or captive installation screws to
release the bus connectors from the backplane or midplane.
•Handle carriers by available handles or edges only; avoid touching the printed circuit boards or
connectors.
•Place a removed component board-side-up on an antistatic surface or in a static shielding container.
If you plan to return the component to the factory, immediately place it in a static shielding
container.
•Avoid contact between the printed circuit boards and clothing. The wrist strap only protects
components from ESD voltages on the body; ESD voltages on clothing can still cause damage.
•Never attempt to remove the printed circuit board from the metal carrier.
Caution For safety, periodically check the resistance value of the antistatic strap. The measurement should be
between 1 and 10 megohm.
Laser LED Safety Information
The HP ESCON PA contains laser LEDs. The expansion module is classified as a Class 1 laser product
and is certified to conform to the requirements of EN60825-1:1994 and IEC825-1:1993.

19
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration
OL-3743-02
Preparing for Installation
Class 1 laser products are not considered hazardous. The HP ESCON PA has embedded Class 3a laser
LED assemblies operating at a nominal wavelength of 850 nanometer and a maximum potential output
power of 1.25 milliwatts. The design of the HP ESCON PA incorporates engineering features including
current limiting, which ensures that there is no human access to LED radiation greater than Class 1 under
any set of operating, maintenance, or service conditions, including a single fault.
There are fewer than 0.442 milliwatts propagating in the link or in any portion of the module. Therefore,
according to IEC825-2:1993, Hazard Level 1 prevails in all parts of the system.
The LEDs are located on the front face of the module.
Laser Radiation
Warning Laser radiation is present when the system is open. Statement 1009
Waarschuwing
Laserstraling is aanwezig wanneer het systeem open is.
Varoitus
Lasersäteitä järjestelmän ollessa avoinna.
Attention
Production d'un rayonnement laser en position ouverte.
Warnung
Laserstrahlung in geöffnetem Zustand.
Avvertenza
Emissione di radiazioni laser quando il sistema è aperto.
Advarsel
Laserstråling er til stede når enheten er åpen.
Aviso
Radiação laser presente quando aberto.
¡Advertencia!
Radiación láser presente cuando el sistema está abierto.
Varning!
Laserstrålning pågår när enheten är öppen.

20
PA-4C-E 1-Port High-Performance ESCON Channel Port Adapter Installation and Configuration OL-3743-02
Preparing for Installation
Staring into Laser Beam
Warning Do not stare into the laser beam. Statement 1010
Waarschuwing
Niet in de straal staren.
Varoitus
Älä katso säteeseen.
Attention
Ne pas fixer le faisceau des yeux.
Warnung
Nicht direkt in den Strahl blicken.
Avvertenza
Non fissare il raggio con gli occhi.
Advarsel
Stirr ikke på strålen.
Aviso
Não olhe fixamente para o raio.
¡Advertencia!
No mirar fijamente el haz.
Varning!
Laserstrålning när enheten är öppen.
