Cisco LINKSYS PLTS200 User manual

QUICK INSTALLATION GUIDE
Powerline 4-Port
Network Adapter
Model: PLTS200
Package Contents
Powerline 4-Port Network Adapter•
Powerline Utility and User Guide•
on CD-ROM
Ethernet Network Cable•
Power Cord•
Quick Installation Guide•
Stand•
All manuals and user guides at all-guides.com
all-guides.com

Overview
Before you begin, you should have a powerline network already set up, with
your router connected to a Powerline Adapter. The following instructions
describe how to connect the Powerline 4-Port Network Adapter (model
number: PLTS200) to additional computers or other network devices.
Internet
Modem
Router
Powerline Network
Adapter
Powerline 4-Port
Network Adapter
Gaming Console
Computer
Powerline
Computer
Powerline 4-Port
Network Adapter Network
Storage
Diagram of a Typical Powerline Network
Installation
A. Connect one end of an Ethernet
network cable to the Ethernet
port of the Adapter.
Connect Ethernet Network Cable
All manuals and user guides at all-guides.com

B. Connect the other end to the
Ethernet port of your computer
or other network device.
NOTE: You can connect additional computers or other network
devices to the remaining Ethernet ports of the Adapter.
C. Connect the power cord to the
Power port.
D. Plug the other end into an
electrical outlet.
NOTE: Because the Adapter sends data over the power lines
of your home, Linksys recommends that you plug the Adapter
directly into an electrical outlet. The Adapter has its own power
filter to help protect against surges.
Connect Other End of Network Cable
Connect Power Cord
Plug Power into Outlet
All manuals and user guides at all-guides.com

For additional information or troubleshooting help, refer to the User Guide on the CD-ROM.
Additional support is also available by phone or online.
24-Hour Technical Support
800-326-7114
RMA (Return Merchandise Authorization)
http://www.linksys.com/warranty
Website
http://www.linksys.com
FTP Site
ftp://ftp.linksys.com
Support
http://www.linksys.com/support
Sales Information
800-546-5797 (800-LINKSYS)
Linksys, Cisco and the Cisco Logo are registered trademarks or trademarks of Cisco Systems,Inc. and/or its affiliates in the U.S. and certain other
countries. Copyright © 2008 Cisco Systems, Inc. All rights reserved. Other brands and product names are trademarks or registered trademarks of
their respective holders.
8070910NC-JL
E. The Power, Ethernet, and
Powerline LEDs light up. (The
number of lit Ethernet LEDs
depends on how many devices
are connected.)
NOTE: The Powerline
LED indicates that
the connection between
the Adapter and your
powerline network has
been established.
Hardware installation is complete.
NOTE: If you want to configure advanced security for your
powerline network, install the Powerline Utility from the included
CD-ROM. For more information, refer to the User Guide on
the CD-ROM.
Power, Ethernet, and Powerline LEDs
