About This Guide
This section discusses the objectives, audience, organization, and conventions of the
Cisco Redundant Power System Hardware Installation Guide.
Document Objectives
This publication provides installation instructions and troubleshooting information for the
Cisco Redundant Power System (RPS) in the following product lines:
•Cisco FastHub 100 series, FastHub 200 series, FastHub 300 series 100BaseT hubs, and
HP 10BaseT Hub-16M hubs
•Catalyst 1900 series switches, Catalyst 2820 series switches, and Catalyst 2900
series XL switches
•Cisco 2500 series routers/access servers, Cisco 2600, 3600, and 4000 series routers
•Cisco MC3810 multiservice concentrator
AudienceThis publication is designed for people who have some experience installing networking
equipment such as routers, hubs, servers, and switches. The person installing and
troubleshooting the Cisco RPS should be familiar with electronic circuitry and wiring
practices and have experience as an electronic or electromechanical technician.
rpsprf Page xi Monday, September 14, 1998 8:20 AM

Document Organization
Cisco Redundant Power System Hardware Installation Guide
xii
Document Organization
Chapter Title Description
Preface About This Guide Discusses the objectives, audience, organization, and conventions of
this publication and describes how to get additional documentation.
Chapter 1 Overview of the
Cisco RPS Gives an overview of the Cisco RPS, supported devices, configurations, features, product specifications, safety
recommendations, and installation prerequisites.
Chapter 2 Installing the Cisco RPS Provides instructions for setting the Cisco RPS on a desktop or
rack-mounting the Cisco RPS.
Chapter 3 Connecting to External
Devices Explains how to connect the Cisco RPS to external devices and how to order cabling appropriate to each device.
Chapter 4 Connecting Cables Gives steps for connecting the Cisco RPS to the supported external
devices (see Table 1-1).
Appendix A Replacing an External
Device Provides steps for replacing a failed external device receiving power from the Cisco RPS.
Appendix B Troubleshooting the
Cisco RPS Provides specifics on troubleshooting the Cisco RPS, isolating problems to a specific subsystem, and reading front-panel LEDs.
rpsprf Page xii Monday, September 14, 1998 8:20 AM

xiii
Installation Guide Conventions
Installation Guide Conventions
Convention Description
Note Means reader take note. Notes contain helpful suggestions or references to additional
information and material.
Caution This symbol means reader be careful. In this situation, you might do something that could
result in equipment damage or loss of data.
Warning This symbol means danger. You are in a situation that could cause bodily injury. Before you
work on any equipment, you must be aware of the hazards involved with electrical circuitry
and be familiar with standard practices for preventing accidents. To see translations of the
various warnings that appear in this publication, refer to the Regulatory Compliance and
Safety Information document that accompanied this device.
Waarschuwing Dit waarschuwingssymbool betekent gevaar. U verkeert in een situatie die
lichamelijk letsel kan veroorzaken. Voordat u aan enige apparatuur gaat werken, dient u zich
bewust te zijn van de bij elektrische schakelingen betrokken risico's en dient u op de hoogte
te zijn van standaard maatregelen om ongelukken te voorkomen. Voor vertalingen van de
waarschuwingen die in deze publicatie verschijnen, kunt u het document Regulatory
Compliance and Safety Information (Informatie over naleving van veiligheids- en andere
voorschriften) raadplegen dat bij dit toestel is ingesloten.
Varoitus Tämä varoitusmerkki merkitsee vaaraa. Olet tilanteessa, joka voi johtaa
ruumiinvammaan. Ennen kuin työskentelet minkään laitteiston parissa, ota selvää
sähkökytkentöihin liittyvistä vaaroista ja tavanomaisista onnettomuuksien ehkäisykeinoista.
Tässä julkaisussa esiintyvien varoitusten käännökset löydät laitteen mukana olevasta
Regulatory Compliance and Safety Information -kirjasesta (määräysten noudattaminen ja
tietoa turvallisuudesta).
Attention Ce symbole d'avertissement indique un danger. Vous vous trouvez dans une
situation pouvant causer des blessures ou des dommages corporels. Avant de travailler sur un
équipement, soyez conscient des dangers posés par les circuits électriques et familiarisez-
vous avec les procédures couramment utilisées pour éviter les accidents. Pour prendre
connaissance des traductions d’avertissements figurant dans cette publication, consultez le
document Regulatory Compliance and Safety Information (Conformité aux règlements et
consignes de sécurité) qui accompagne cet appareil.
rpsprf Page xiii Monday, September 14, 1998 8:20 AM

Installation Guide Conventions
Cisco Redundant Power System Hardware Installation Guide
xiv
Warnung Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu
einer Körperverletzung führen könnte. Bevor Sie mit der Arbeit an irgendeinem Gerät
beginnen, seien Sie sich der mit elektrischen Stromkreisen verbundenen Gefahren und der
Standardpraktiken zur Vermeidung von Unfällen bewußt. Übersetzungen der in dieser
Veröffentlichung enthaltenen Warnhinweise finden Sie im Dokument Regulatory
Compliance and Safety Information (Informationen zu behördlichen Vorschriften und
Sicherheit), das zusammen mit diesem Gerät geliefert wurde.
Avvertenza Questo simbolo di avvertenza indica un pericolo. La situazione potrebbe
causare infortuni alle persone. Prima di lavorare su qualsiasi apparecchiatura, occorre
conoscere i pericoli relativi ai circuiti elettrici ed essere al corrente delle pratiche standard
per la prevenzione di incidenti. La traduzione delle avvertenze riportate in questa
pubblicazione si trova nel documento Regulatory Compliance and Safety Information
(Conformità alle norme e informazioni sulla sicurezza) che accompagna questo dispositivo.
Advarsel Dette varselsymbolet betyr fare. Du befinner deg i en situasjon som kan føre til
personskade. Før du utfører arbeid på utstyr, må du vare oppmerksom på de faremomentene
som elektriske kretser innebærer, samt gjøre deg kjent med vanlig praksis når det gjelder å
unngå ulykker. Hvis du vil se oversettelser av de advarslene som finnes i denne
publikasjonen, kan du se i dokumentet Regulatory Compliance and Safety Information
(Overholdelse av forskrifter og sikkerhetsinformasjon) som ble levert med denne enheten.
Aviso Este símbolo de aviso indica perigo. Encontra-se numa situação que lhe poderá
causar danos físicos. Antes de começar a trabalhar com qualquer equipamento, familiarize-se
com os perigos relacionados com circuitos eléctricos, e com quaisquer práticas comuns que
possam prevenir possíveis acidentes. Para ver as traduções dos avisos que constam desta
publicação, consulte o documento Regulatory Compliance and Safety Information
(Informação de Segurança e Disposições Reguladoras) que acompanha este dispositivo.
rpsprf Page xiv Monday, September 14, 1998 8:20 AM

xv
Ordering Additional Documentation
Ordering Additional Documentation
Cisco documentation and additional literature are available in a CD-ROM package, which
ships with your Cisco RPS. The Documentation CD-ROM, a member of the Cisco
Connection Family, is updated monthly. Therefore, it might be more up to date than printed
documentation. To order additional copies of the Documentation CD-ROM, contact your
local sales representative or call customer service. The CD-ROM package is available as a
single package or as an annual subscription. You can also access Cisco documentation on
the World Wide Web at http://www.cisco.com, http://www-china.cisco.com, or
http://www-europe.cisco.com. Or you can order printed copies of documentation
separately. See the section, “Cisco Connection Online” later in this preface.
¡Advertencia! Este símbolo de aviso significa peligro. Existe riesgo para su integridad
física. Antes de manipular cualquier equipo, considerar los riesgos que entraña la corriente
eléctrica y familiarizarse con los procedimientos estándar de prevención de accidentes. Para
ver una traducción de las advertencias que aparecen en esta publicación, consultar el
documento titulado Regulatory Compliance and Safety Information (Información sobre
seguridad y conformidad con las disposiciones reglamentarias) que se acompaña con este
dispositivo.
Varning! Denna varningssymbol signalerar fara. Du befinner dig i en situation som kan
leda till personskada. Innan du utför arbete på någon utrustning måste du vara medveten om
farorna med elkretsar och känna till vanligt förfarande för att förebygga skador. Se
förklaringar av de varningar som förkommer i denna publikation i dokumentet Regulatory
Compliance and Safety Information (Efterrättelse av föreskrifter och säkerhetsinformation),
vilket medföljer denna anordning.
rpsprf Page xv Monday, September 14, 1998 8:20 AM

Documentation Feedback
Cisco Redundant Power System Hardware Installation Guide
xvi
Documentation Feedback
You can send us your comments on any Cisco document by using the CCO Feedback
button. Click CCO Feedback. Then click MarketPlace and press Return to access the
feedback form. You can also use the Feedback button to send us your comments on other
CCO content.
If you are reading Cisco product documentation on the World Wide Web, you can submit
comments electronically. Click Feedback in the toolbar and select Documentation. After
you complete the form, click Submit to send it to Cisco. We appreciate your comments.
Cisco Connection Online
Cisco Connection Online (CCO) is Cisco Systems’ primary, real-time support channel.
Maintenance customers and partners can self-register on CCO to obtain additional
information and services.
Available 24 hours a day, 7 days a week, CCO provides a wealth of standard and value-
added services to Cisco’s customers and business partners. CCO services include product
information, product documentation, software updates, release notes, technical tips, the
Bug Navigator, configuration notes, brochures, descriptions of service offerings, and
download access to public and authorized files.
CCO serves a wide variety of users through two interfaces that are updated and enhanced
simultaneously: a character-based version and a multimedia version that resides on the
World Wide Web (WWW). The character-based CCO supports Zmodem, Kermit,
Xmodem, FTP, and Internet e-mail, and it is excellent for quick access to information over
lower bandwidths. The WWW version of CCO provides richly formatted documents with
photographs, figures, graphics, and video, as well as hyperlinks to related information.
You can access CCO in the following ways:
•WWW: http://www.cisco.com
•WWW: http://www-europe.cisco.com
•WWW: http://www-china.cisco.com
•Telnet: cco.cisco.com
rpsprf Page xvi Monday, September 14, 1998 8:20 AM

xvii
Cisco Connection Online
•Modem: From North America, 408 526-8070; from Europe, 33 1 64 46 40 82. Use the
following terminal settings:VT100 emulation; databits: 8; parity: none; stop bits: 1; and
connection rates up to 28.8 kbps.
Foracopy ofCCO’sFrequently AskedQuestions (FAQ),contact [email protected].For
additional information, contact [email protected].
Note If you are a network administrator and need personal technical assistance with a
Cisco product that is under warranty or covered by a maintenance contract, contact Cisco’s
Technical Assistance Center (TAC) at 800 553-2447, 408 526-7209, [email protected], or
http://www.cisco.com. Toobtain generalinformation aboutCisco Systems,Cisco products,
or upgrades, contact 800 553-6387, 408 526-7208, or [email protected].
rpsprf Page xvii Monday, September 14, 1998 8:20 AM

Cisco Connection Online
Cisco Redundant Power System Hardware Installation Guide
xviii
rpsprf Page xviii Monday, September 14, 1998 8:20 AM

CHAPTER
Overview of the Cisco RPS 1-1
1
Overview of the Cisco RPS
This chapter describes the Cisco 600W RPS, its features, and supported devices. The
Cisco RPS provides power system redundancy to external devices such as routers,
switches, or hubs.
The system includes two fully redundant AC input power modules and four DC output
power modules for connection to external devices. The Cisco RPS supports
quasi-redundant, fully redundant, and redundant-with-reboot configurations.
Table 1-1 lists the supported external devices and power configurations. Figure 1-1 shows
the front panel of the Cisco RPS, and Figure 1-2 shows the rear panel.
rps1 Page 1 Monday, September 14, 1998 8:17 AM

1-2 Cisco Redundant Power System Hardware Installation Guide
Table 1-1 Cisco RPS-Supported External Devices and Power Configurations
Note For simplicity, Cisco 2500 series access servers, such as Cisco 2509 or 2511, are
referred to as Cisco 2500 series routers throughout this guide.
Note You may need to order a power adapter plate for your router or concentrator to make
it compatible for use with the Cisco RPS. See Table 3-2, which lists adapter plates and
corresponding product order numbers. Contact Cisco Customer Service at 800 553-6387 or
408 526-7209 for ordering information. (See also the section “Cisco Connection Online”
in the “About This Guide” preface.)
External Device Quasi- Redundant Fully Redundant Redundant With Reboot
FastHub 100 series 100BaseT hubs Yes Yes Yes
FastHub 200 series 100BaseT hubs Yes Yes Yes
FastHub 300 series 100BaseT hubs Yes Yes Yes
HP 10BaseT Hub-16M hub Yes No No
Catalyst 1900 series switches Yes Yes Yes
Catalyst 2820 series switches Yes Yes Yes
Catalyst 2900 series XL switches Yes Yes Yes
Cisco 2500 series routers/access servers Yes Yes No
Cisco 2600 series routers Yes Yes No
Cisco 3600 series routers Yes Yes No
Cisco MC3810 multiservice concentrator Yes Yes No
Cisco 4000 series routers Yes Yes No
rps1 Page 2 Monday, September 14, 1998 8:17 AM

Overview of the Cisco RPS 1-3
Figure 1-1 Cisco RPS Front Panel
Figure 1-2 Cisco RPS Rear Panel
H9588
DC STATUS
12
34
FAN
TEMP
H9589
AC INPUT 1
100-200 V~ 50/60 Hz
10-5 A 1000 W
AC INPUT 2
100-200 V~ 50/60 Hz
10-5 A 1000 W
DC OUTPUT 1 DC OUTPUT 2 DC OUTPUT 3 DC OUTPUT 4
rps1 Page 3 Monday, September 14, 1998 8:17 AM

1-4
Quasi-Redundant Configuration
Cisco Redundant Power System Hardware Installation Guide
Quasi-Redundant Configuration
The Cisco RPS provides a quasi-redundant power source for four external devices that use
up to 150W DC each. You can use a one-to-one cable (one connector at each cable end) to
connectfour externaldevicesto thefour DC outputpowermodules, as shownin Figure 1-3.
The power source is quasi-redundant because there are two AC input power modules for
the Cisco RPS and one DC output power module for each external device. The AC input to
the Cisco RPS is fully redundant, but the DC output to the external devices is not.
Figure 1-3 Quasi-Redundant Configuration
External devices
150W or less
DC output
AC input
DC DC
AC AC
DC DC
Cisco RPS
NM3998
rps1 Page 4 Monday, September 14, 1998 8:17 AM

Overview of the Cisco RPS 1-5
Fully Redundant Configuration
Fully Redundant Configuration
The Cisco RPS can provide a fully redundant power source for two pieces of equipment.
You canuse a two-to-onecable to connect twoexternal devicesto the four DC outputpower
modules, as shown in Figure 1-4. The two-to-one cable is a Y-shaped cable with two
connectors at one end and one connector at the other end.
In this configuration, the connectors at one end of the Y-shaped cable connect two
Cisco RPS DC output power modules to one external device. The power source is fully
redundant because there are two AC input modules and two DC output power modules
connected to each external device. If any power module fails, there is a full backup.
Figure 1-4 Fully Redundant Configuration
FastHub 100 series, FastHub 200 series, FastHub 300 series,
Catalyst 1900 series and Catalyst 2820 series switches,
Catalyst 2900 series XL switches,
Cisco 2500, 2600, 3600, and 4000 series routers,
Cisco MC3810 multiservice concentrators
DC output
AC input
DC DC DC DC
Cisco RPS
11962
AC AC
rps1 Page 5 Monday, September 14, 1998 8:17 AM

1-6
Redundant With Reboot
Cisco Redundant Power System Hardware Installation Guide
Redundant With Reboot
By using a second mode of redundant operation called redundant with reboot, you can
connect more hubs and switches to the Cisco RPS and thereby extend its capacity. This
configuration also provides switches and hubs (except the HP 10BaseT Hub-16M) with
additional redundancy.
Redundancy with reboot works for the following devices only: FastHub 100 series,
FastHub 200 series, or FastHub 300 series 100BaseT hubs,Catalyst 1900 series,
Catalyst 2820 series switches, and the Catalyst 2900 series XL switches.
Note Cisco recommends that you use configurations without the AC power plug (that is,
not in redundant-with-reboot mode) connected to the external device, due to the reboot and
downtime—approximately 30 seconds.
The redundant-with-reboot configuration is shown in Figure 1-5, where a straight-through
one-to-onecable connectsan externaldevice(thefigure showsswitches,buttheycould also
be hubs) to the Cisco RPS while the device is simultaneously powered by its own internal
power supply (the device AC power plug is connected).
rps1 Page 6 Monday, September 14, 1998 8:17 AM

Overview of the Cisco RPS 1-7
Redundant With Reboot
Figure 1-5 Redundant-With-Reboot Configuration
In this configuration, one Cisco RPS can support four devices instead of two. Despite
30 seconds of downtime that occur when using redundancy with reboot, this configuration
provides additional redundancy and extends the capacity of the Cisco RPS.
In this way, the Cisco RPS and external device internal power supply can be connected
simultaneously. A sense circuit in the Cisco RPS reads that the device has its AC power
connected and shuts the Cisco RPS output off. In this way competition between the power
supplies is prevented.
Normally, the external device internal power supply always provides power. If the internal
power system of the external device fails, the device powers down briefly until the
Cisco RPS begins supplying power. When the device comes back up, the Cisco RPS is the
main power source.
External devices
150W or less
DC output
AC power cords
AC power strip
AC input
DC DC
AC AC
DC DC
Cisco RPS
12052
rps1 Page 7 Monday, September 14, 1998 8:17 AM

1-8
Redundant With Reboot
Cisco Redundant Power System Hardware Installation Guide
If the Cisco RPS fails or is disconnected, the external device will not power cycle because
its internal power supply has not been disturbed. When both the Cisco RPS and internal
power supply are powered, the LED on the Cisco RPS front panel and the RPS LED on the
external device both blink green.
If you cannot afford the 30-second interruption, unplug the external device AC power cord
and use only the Cisco RPS with the Y-cable. There is no downtime when using the
Cisco RPS with the Y-cable.
rps1 Page 8 Monday, September 14, 1998 8:17 AM

Overview of the Cisco RPS 1-9
Mixed Configuration (Quasi- and Fully Redundant)
Mixed Configuration (Quasi- and Fully Redundant)
You can mix quasi-redundant and fully redundant configurations. For example, two devices
can be in quasi-redundant mode while one is in fully redundant mode (see Figure 1-6).
Figure 1-6 Mixed Configuration
Quasi-RedundantFully redundant
AC input
AC AC
DC DC
Cisco RPS
11681
DC DC
DC output
rps1 Page 9 Monday, September 14, 1998 8:17 AM

1-10
Features
Cisco Redundant Power System Hardware Installation Guide
Features The following features are standard:
•Two AC input power cords
•Two fully redundant AC input power modules
•Four 150W DC output power modules
•Four one-to-one cables (PWR600-AC-RPS-CAB)
•Rack-mountable chassis (19-inch rack-mount brackets included)
•Redundant cooling fans
•LEDs for the AC and DC fans and temperature status
•Simple Network Management Protocol (SNMP) support of error messages for
Cisco 2600 and Cisco 3600 series routers.
There is no SNMP support for error messages in the FastHub series 100,
FastHub series 200, FastHub series 300, Catalyst 1900 series, Catalyst 2820 series,
Catalyst 2900 XL switches, Cisco 2500 and 4000 series routers, and the Cisco MC3810
multiservice concentrator.
Note Optional Y-cables (for use with the PWR600-AC-RPS-NCAB—the Cisco RPS
which ships with no cables) can be ordered separately. For ordering information, Contact
Cisco Customer Service at 800 553-6387 or 408 526-7209. See also the section “Cisco
Connection Online,” in the “About This Guide” preface.
rps1 Page 10 Monday, September 14, 1998 8:17 AM

Overview of the Cisco RPS 1-11
Specifications
Specifications
The specifications for the Cisco RPS are listed in Table 1-2.
Table 1-2 Specifications
Description Specification
Dimensions (H x W x D) 3.44 x 17.5 x 16 in. (8.73 x 44.45 x 40.64 cm)
Weight 27.25 lb (12.36 kg)
Nominal input voltage
Current
Frequency
Absolute maximum input
100 to 240 VAC autoranging
10A maximum
50 to 60 Hz
1000W
Output voltage/maximum current
Output power +5@24 ADC, +12@5 ADC, –12@3 ADC 150W per module (maximum)
Operating temperature 32 to 104°F (0 to 40°C)
Nonoperating temperature –4 to 149°F (–20 to 65°C)
Operating humidity 10 to 85%, noncondensing
Nonoperating humidity 5 to 95% noncondensing
Operating altitude 0 to 10,000 ft (0 to 3,000 m)
Nonoperating altitude 0 to 30,000 ft (0 to 9,000 m)
Normal operating noise level 48 dBa
Regulatory compliance FCC Class B. For additional compliance
information, refer to the Regulatory Compliance
and Safety Information document that accompanied
the Cisco RPS and external devices.
Demonstrated MTBF In excess of 500,000 hours
rps1 Page 11 Monday, September 14, 1998 8:17 AM

1-12
Safety Recommendations
Cisco Redundant Power System Hardware Installation Guide
Safety Recommendations
Follow these guidelines to guarantee general safety:
•Keep the chassis area clear and dust-free during and after installation.
•Keep tools and chassis components away from walk areas.
•Do not wear loose clothing that could get caught in the chassis. Fasten your tie or scarf
and roll up your sleeves.
•Wear safety glasses when working under conditions that may be hazardous to your eyes.
•Do not perform any action that creates a hazard to people or makes the equipment
unsafe.
Safety Warnings
Safety warnings appear throughout this guide in procedures that, if performed incorrectly,
may harm you. A warning symbol precedes each warning statement. (For information on
safety warnings and translations, see “Installation Guide Conventions” in the “About This
Guide” section.)
Safety with Electricity
Follow these guidelines when working on equipment powered by electricity:
•Locate the emergency power-OFF switch in the room in which you are working. Then,
if an electrical accident occurs, you can quickly shut the power OFF.
Warning Read the installation instructions before you connect the system to its power
source.
Warning The device is designed to work with TN power systems.
Warning Before working on equipment that is connected to power lines, remove jewelry
(including rings, necklaces, and watches). Metal objects will heat up when connected to
power and ground and can cause serious burns or weld the metal object to the terminals.
