Cisco RV132W Instruction Manual

Cisco RV132W ADSL2+ Wireless-N VPN Router and
Cisco RV134W VDSL2 Wireless-AC VPN Router
ADMINISTRATION
GUIDE

© 2015 Cisco Systems, Inc. All rights reserved.
Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries.To view a list of Cisco trademarks,
go to this URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property oftheir respective owners. The use of the word partner does
not imply a partnership relationship between Cisco and any other company. (1110R)

Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide
Contents
Chapter 1: Getting Started 5
Run Setup Wizard 6
Chapter 2: Status and Statistics 8
Dashboard 8
System Summary 8
Active TCP/IP Services 9
Wireless Statistics 10
PPTP Server 10
IPSec Connection Status 10
View Logs 11
Connected Devices 12
Port Statistics 12
Mobile Network 13
Chapter 3: Networking 15
WAN Configuration 15
Configuring WAN Connections 15
Configuring a Mobile Network 48
Setting Failover and Recovery 51
LAN Configuration 52
Configuring LAN Connections 53
Configuring VLAN Membership 54
Configuring Static DHCP 55
Viewing DHCP Leased Clients 56
Configuring a DMZ Host 57
Port Management 57

Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide
Contents
Configuring Routing 59
Configuring Basic Routing 59
Configuring Dynamic Routing Information Protocol (RIP) 59
Viewing the Routing Table 61
Configuring Dynamic DNS 61
Configuring the IP Mode 62
Configuring IPv6 63
Configuring IPv6 LAN Connections 63
Configuring IPv6 Static Routing 65
Configuring Routing (RIPng) 66
Configuring Router Advertisement 67
Configuring Advertisement Prefixes 68
Chapter 4: Wireless Networks 70
Wireless Security 70
Basic Wireless Settings 72
Configuring Advanced Wireless Settings 80
Configuring WPS 83
Chapter 5: Firewall 85
Basic Firewall Settings 86
Schedule Management Configuration 90
Services Management Configuration 90
Access Rules Configuration 92
Internet Access Policy Configuration 95
One-to-One NAT Configuration 97
Single Port Forwarding Configuration 98
Port Range Forwarding Configuration 98

Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide
Contents
Port Range Triggering Configuration 99
Attack Protection Configuration 100
Session Settings Configuration 101
Chapter 6: VPN 102
Site-to-Site IPsec VPN 102
Configuring Basic VPN Setup 102
Configuring VPN Advanced Parameters 103
Certificate Management 112
Configuring PPTP 113
Configuring VPN Passthrough 115
Chapter 7: Quality of Service (QoS) 116
Bandwidth Management 116
Configuring Bandwidth 116
Configuring QoS Binding Policy 117
Configuring QoS Port-Based Settings 119
Configuring CoS Settings 120
Configuring DSCP Settings 120
Chapter 8: Administration 121
Password Complexity 121
Configuring User Accounts 122
Configuring User Accounts 122
Session Timeout Configuration 124
Login Banner Text 124
Configuring TR-069 Settings 125
Diagnostics 127

Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide
Contents
Network Tools 127
Port Mirroring 128
Remote Support Key Settings 129
Logging Configuration 129
Configuring Log Settings 129
Configuring E-Mail Settings 131
Discovery Bonjour Configuration 132
LLDP Properties Configuration 134
Time Settings Configuration 134
Download and Backup Configuration File 135
Firmware Upgrade 138
Firmware Recovery Steps 139
Reboot 140
Restoring the Factory Defaults 140

1
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 5
Getting Started
Thank you for choosing the Cisco RV132W ADSL2+ Wireless-N router or the
Cisco RV134W VDSL2 Wireless-AC routers. This guide describes how to
physically install and manage your Cisco RV132W/RV134W router. The Getting
Started page displays the most common configurations on your device. Click the
links on the Web page to go to the relevant configuration page.
This page appears whenever you start the Device Manager. To change this
behavior, check Don’t show on start up.
Initial Settings
Change Default
Administrator Password Displays the User Account page where you can change the administrator password and set up a
guest account. See Configuring User Accounts.
Launch Setup Wizard Launches the Router Setup Wizard. Follow the on-
screen instructions.
Configure WAN Settings Opens the Internet Setup page to modify the WAN
parameters. See Configuring WAN Connections.
Configure LAN Settings Opens the LANConfiguration page to modify the
LAN parameters. For example, the management IP
address. See Configuring LAN Connections.
Configure Wireless
Settings Open the Basic Settings page to manage the wireless settings. See Basic Wireless Settings

Getting Started
Run Setup Wizard
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 6
1
Quick Access
Device Status
Run Setup Wizard
From the Run Setup Wizard page, you can follow the instructions that guide you
through the process for configuring the device.
To open this page, select Run Setup Wizard in the navigation tree.
Follow the on-screen instructions to proceed. Refer to the information from your
ISP to enter the required settings for your Internet connection.
Upgrade Router
Firmware Opens the Firmware Upgrade page to update the device firmware. See Firmware Upgrade.
Add VPN Clients
(For RV134W only)
Opens the PPTP Server page to set up and
manage the VPN tunnels. See Configuring PPTP.
Configure Remote
Management Access Opens the BasicSettingspage to enable the basic features of the device. See Basic Firewall
Settings.
System Summary Displays the System Summary page that shows
the IPv4 and IPv6 configuration, wireless, and
firewall status on the device. See System
Summary.
Wireless Status Displays the Wireless Statistics page that shows
the state of the radio. See Wireless Statistics.
VPN Status
(For RV134W only)
Displays the IPsec VPN Server page that lists the
VPN managed by this device. See PPTP Server.

Getting Started
Run Setup Wizard
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 7
1
Connecting to Your Wireless Network
To connect a client device (such as a computer) to your wireless network,
configure the wireless connection on the client device with the wireless security
information that you configured for the router by using the Setup Wizard.
The following steps are provided as an example; you may need to configure your
device differently. For specific instructions, consult the documentation for your
client device.
STEP 1 Open the wireless connection settings window or program for your device.
Your computer might have special software installed to manage wireless
connections, or you might find the wireless connections under the Control Panel in
the Network Connections or Network and Internet window. (The location
depends on your operating system.)
STEP 2 Enter the network name (SSID) that you chose for your network in the Setup
Wizard.
STEP 3 Choose the type of encryption and enter the security key that you specified in the
Setup Wizard.
If you did not enable security (not recommended), leave the wireless encryption
fields that were configured with the security type and passphrase blank.
STEP 4 Verify your wireless connection and save your settings.

2
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 8
Status and Statistics
Dashboard
The Dashboard provides a snapshot view of the configuration settings on your
device. The dashboard page displays information about your device’s firmware
version, serial number, CPU and memory utilization, error-logging settings, LAN,
WAN, wireless, site-to-site IPsec VPN, and PPTP VPN server settings.
To access the dashboard, select Status and Statistics > Dashboard. To modify
the information displayed, click the detailed link to go to the configuration page for
that section. For more information on managing the settings displayed on the
Dashboard page, see:
•Configuring Log Settings
•Site-to-Site IPsec VPN
•Configuring WAN Connections
•Configuring LAN Connections
From the Refresh Rate drop-down list, select the rate at which the latest statistics
and parameter values are refreshed on the dashboard.
The Dashboard page also displays an interactive view of your device’s back panel
when you click Show Panel View. Mouse-over each port to view port connection
information.
System Summary
Select Status and Statistics > System Summary to view the Internet setup, LAN,
wireless, firewall, and PPTP (for RV134W).
The System Summary page displays information for the following sections:
WAN Configuration

Status and Statistics
Active TCP/IP Services
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 9
2
Displays the setting details for your WAN networks configured on the Networking
> WAN > WAN Configuration > Internet Setup page. For more information, see
Configuring WAN Connections
LAN Configuration
Displays the setting details for your LAN networksconfigured on the Networking >
LAN > LAN Configuration. For more information, see Configuring LAN
Connections
Wireless Summary
Displays the public name and settings for your wireless networks configured on
the Wireless > Basic Settings. For more information, see Basic Wireless Settings.
Firewall Setting Status
Displays the DoS, WAN request, and remote management settings configured on
the Firewall > Basic Settings > Basic Settings page. For more information, see
Basic Firewall Settings.
PPTP Server Status
Displays the available PPTP VPN connections and the connected users for each
VPN type. For more information on configuring VPN server connections and user
accounts, see Configuring PPTP.
Active TCP/IP Services
Select Status and Statistics> Active TCP/IP Services to view the IPv4 and IPv6
TCP/IP connections that are active on your device. The Active Service List section
for the IPv4 and IPv6 displays the protocols and services that are active on the
device.

Status and Statistics
Wireless Statistics
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 10
2
Wireless Statistics
Select Status and Statistics> Wireless Statistics to view the wireless statistical
data for the device radio. In the Refresh Rate field, select the rate at which you
want the latest statistics to be displayed.
To show the bytes in kilobytes (KB) and the numerical data in rounded-up values,
check the Show Simplified Statistic Data check box and click Save. By default,
byte data is displayed in bytes and other numerical data is displayed in long form.
To reset the wireless statistics counters, click Clear Count. The counters are reset
when the device is rebooted.
PPTP Server
Select Status and Statistics> PPTP Server to view a list of your PPTP VPN
connections, the duration of the connection, and the actions you can perform on
this connection. For more information about configuring PPTP VPN connections,
see Configuring PPTP.
IPSec Connection Status
IPsec VPN Connection Status
STEP 1 Select Status and Statistics > IPsec Connection Status.
STEP 2 Select the Refresh Rate from the drop-down list to display the latest IPSec
connections and the duration of the connection.
STEP 3 Select the Show Simplified Statistic Data to display the simplified statistic data.
STEP 4 Click Save.

Status and Statistics
View Logs
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 11
2
View Logs
The View Logs page can only be displayed if the user enables log at Administrator
> Logging > Log Setting. Once this is enabled to view the logs, select Status and
Statistics> View Logs. Click Refresh Rate, to display latest log entries.
To filter logs or specify the severity of the logs to display, in the System Log Table,
check the boxes next to the log type and click Go. Note that all log types above a
selected log type are automatically included and you cannot deselect them. For
example, checking the Error check box automatically includes emergency, alert,
and critical logs in addition to error logs.
The event severity levels arelisted from thehighest severityto the lowest severity,
as follows:
•Emergency—Messages about events such as a system crash.
•Alert—Messages about conditions that require immediate corrective
action.
•Critical—Messages for when the system is in a critical condition.
•Error—Messages about conditions that are not critical but require
corrective action.
•Warning—System warnings.
•Notification—Messages about normal but significant conditions that may
require attention.
•Information—Messages about device information.
•Debugging—Detailed information about an event.
To refresh all entries in the log window, click Refresh Logs.
To delete all entries in the log window, click Clear Logs.
To save all log messages from the device to the local hard drive, click Save Logs.
To specify the number of entries to show per page, select a number from the drop-
down list.
To move between log pages, use the page navigation buttons.

Status and Statistics
Connected Devices
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 12
2
Connected Devices
The Connected Devices page displays information about the active client
devices connected to your router. To view connected devices, select Status and
Statistics> Connected Devices.
To specify the types of interfaces to display, select a value from the Filter:
Interface Type matches drop-down list:
•All—All devices connected to the router.
•Wireless—All devices connected through the wireless interface.
•Wired—All devices connected through the Ethernet ports on the router.
IPv4 ARP Table displays information from other routers that have responded to
the device’s Address Resolution Protocol (ARP) request. If a device does not
respond to the request, it is removed from the list.
IPv6 NDP Table displays all IPv6 Neighbor Discovery Protocol (NDP) devices
connected to the device’s local link.
Port Statistics
The Port Statistics page displays detailed port activity.
To view port statistics, select Status and Statistics > Port Statistics.
To refresh the page at regular intervals, select a refresh rate from the Refresh
Rate drop-down list.
To show the bytes in kilobytes (KB) and the numerical data in rounded-up form,
check the Show Simplified Statistic Data box and click Save. By default, byte
data is displayed in bytes and other numerical data is displayed in long form.
To reset the port statistics counters, click Clear Count.
The Port Statistics page displays this information:
Interface Name of the network interface.
Packet Number of received/sent packets.
Byte Number of received/sent bytes.

Status and Statistics
Mobile Network
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 13
2
Mobile Network
The mobile network statistics about the mobile 3G/4G network and
communication device (dongle) configured on the device.
To view the mobile network status, select Status and Statistics> Mobile
Network. The following information is displayed:
•Connection—Device connected to the guest network.
•Internet IP Address—IP address assigned to the USB device.
•Subnet Mask—Subnet mask of the USB device.
•Default Gateway—IP address of the default gateway.
•Connection Up Time—The length of time that link has been up.
•Current Session Usage—Volume of data being received (Rx) and
transmitted (Tx) on the mobile link.
•Monthly Usage—Monthly data download and bandwidth usage.
•Manufacturer—Card manufacturer name.
•Card Model—Card model number.
•Card Firmware—Card firmware version.
•SIM Status—Subscriber identification module (SIM) status.
•IMS—The unique identification associated with the GSM, UMTS, or LTE
network mobile phone users.
•Carrier—Mobile network carrier.
Error Number of received/sent packet errors.
Dropped Number of received/sent packets that were dropped.
Multicast Number of multicast packets sent over this radio.
Collisions Number of signal collisions that occurred on this port. A
collision occurs when the port tries to send data at the
same time as a port on another router or computer that is
connected to this port.

Status and Statistics
Mobile Network
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 14
2
•Service Type—Type of service accessed.
•Signal Strength—Strength of the wireless mobile network signal.
•Card Status—Status of the data card.

3
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 15
Networking
WAN Configuration
Configuring WAN Connections
Configuring WAN properties for an IPv4 network differs based on which type of
Internet connection you have.
To configure the Global Settings follow these steps:
STEP 1 Select Networking > WAN> WAN Configuration.
STEP 2 In the Global Settings > Connect Mode, select one of the following:
•Auto (DSL->Ethernet): the device will check if the DSL link is up. If it is up, the
devicewillusethe DSLlinkastheWANinterface;if itisdown,the devicewill
check ifthe Ethernetlinkisup,andifit isup,it willuse theEthernetlinkasthe
WAN interface.
•DSL: the device will use the DSL link as the WAN interface.
•Ethernet: the device uses Ethernet link as the WAN interface.
STEP 3 Click Edit (RV132W) or Add Row (RV134W) and configure the settings for the
xDSL WAN or Ethernet WAN.
Configuring xDSL WAN
When the Internet Connection Type is in Bridged Mode Only:
In the DSL Settings for ATM transfer mode enter the following information:
Transfer Mode ATM

Networking
Configuring LAN Settings
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 16
3
Multiplexing Defines the way in which different
protocols are handled within a DSL
virtual circuit. You can choose
between a Logical Link Control (LLC)
encapsulation andVirtualChannel (VC)
multiplexing.
QoS Type Select the DSL Quality of Service
(QoS): Unspecified Bit Rate (UBR),
Constant Bit Rate (CBR), Variable Bit
Rate - real time (VBR-rt), Variable Bit
Rate - non-real time (VBR-nrt). CBR
provides the best guarantee of low
latency; UBR provides none, but is
typically used for most broadband
data services.
PcrRate- Whenthe QoS isset toCBR,
VBR-rt, or VBR-nrt, enter the Peak Cell
Rate (PCR) in cells per second.
Scr Rate - When the QoS is set to
VBR-nrt or VBR-rt, enter the Sustained
Cell Rate (SCR) in cells per second.
Auto Detect Check Enable to enable or Disable to
disable automatic detection of the VPI
and VCI values that identify your line to
the ATM network.
Virtual Circuit The Virtual Path Identifier (VPI) and
Virtual Channel Identifier (VCI) are
values used to identify your line toyour
ISP’s ATM network.
SRA (Seamless Rate Adaption) Check Enable or Disable to enable or
disable the SRA, a protocol which, by
decoupling the modulation and
framing layer, can change the
transmission data rate parameters
(applied by the modulation layer).

Networking
Configuring LAN Settings
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 17
3
In the DSL Settings for PTM transfer mode (RV134W) enter the following
information:
In the Bridged Settings section for both the ATM and PTM (RV134W) transfer
modes, enter the following information:
In the Other Settings section for both the ATM and PTM (RV134W) transfer
modes, enter the following information:
DSL Modulation Select the DSL modulation from the
drop-down list. The default DSL
modulation is Multimode
(recommended).
Transfer Mode PTM
SRA (Seamless Rate Adaption) Check Enable or Disable to enable or
disable the SRA, a protocol which, by
decoupling the modulation and
framing layer, can change the
transmission data rate parameters
(applied by the modulation layer).
DSL Modulation Select the DSL modulation from the
drop-down list. The default DSL
modulation is Multimode
(recommended).
Ethernet LAN Ports Select the Ethernet LAN ports. (LAN1,
LAN2, LAN3 or LAN4 - [RV134W only]).
2.4G Wireless Ports Select SSID1 (default).
5G Wireless Ports (RV134W only) Select SSID1 (default).
VLAN & VLAN ID If enabled, all outbound traffic through this interface is
tagged with the configured VLAN ID.
MTU (Maximum
Transmission Unit) MTU is an advanced configuration that allows you to determine the largest data size permitted on your
connection. Select Auto (default) or Manual to
configure manually.

Networking
Configuring LAN Settings
Cisco RV132W ADSL2+ Wireless-N and RV134W VDSL2 Wireless-AC VPN Router Administration Guide 18
3
When the Internet Connection Type is RFC2684 Bridged (DHCP or
Static mode)
In the DSL Settings for the ATM transfer mode, enter the following information:
Size Enter the size of bytes. (Range 576 - 1500, Default
1500).
Transfer Mode ATM
Multiplexing Defines the way in which different
protocols are handled within a DSL
virtual circuit. You can choose
between a Logical Link Control (LLC)
encapsulation andVirtualChannel (VC)
multiplexing.
QoS Type Select the DSL Quality of Service
(QoS): Unspecified Bit Rate (UBR),
Constant Bit Rate (CBR), Variable Bit
Rate - real time (VBR-rt), Variable Bit
Rate - non-real time (VBR-nrt). CBR
provides the best guarantee of low
latency; UBR provides none, but is
typically used for most broadband
data services.
PcrRate- Whenthe QoS isset toCBR,
VBR-rt, or VBR-nrt, enter the Peak Cell
Rate (PCR) in cells per second.
Scr Rate - When the QoS is set to
VBR-nrt or VBR-rt, enter the Sustained
Cell Rate (SCR) in cells per second.
Auto Detect Check Enable to enable or Disable to
disable automatic detection of the VPI
and VCI values that identify your line to
the ATM network.
