Cissell BOOSTERMAN386 Operating instructions

Page 1
Information subject to change without notice.
MAN386 8/951C
Hydraulic
Booster
Maintenance Instructions
Trouble-Shooting
THIS MANUAL MUST BE GIVEN TO THE EQUIPMENT OWNER.
CISSELL MANUFACTURING COMPANY
HEADQUARTERS PHONE: [phone]
831 SOUTH FIRST ST. SALES FAX: [phone]
P.O. BOX 32270 SERVICE/PARTS FAX: [phone]
LOUISVILLE, KY 40232-2270

Page 2
Information subject to change without notice.

Page 3
Information subject to change without notice.
TROUBLE SHOOTING LIST OF THE HYDRAULIC BOOSTER
(see also “example of assembling” Fig. 1 to 8)
What to do if: 1. Press opens too slowly.
2. Booster gives no pressure.
3. Press looses pressure during cycle.
4. Loss of oil / Loss of pressure.
When disassembling the Booster, all Packings and O-Rings have to be replaced prefer-
ably. This is less expensive than disassembling resp. reassembling of Booster every
time.
At least once a year the Hydraulic Oil in the Booster has to be replaced, because the
Oil reduces its viscosity and could be penetrated with dust or dirt.
1. Press opens too slowly
a) BOOSTER NUT 893 (see Fig. 8) has been driven in, hindering back flow of oil.
If the Booster Nut is slightly driven in, it might be sufficient to adjust Booster
Valve 10306 somewhat higher (see Fig. 7).
Otherwise a new Booster Nut has to be mounted.
b) AIR BOOSTER SPRING 50092 is broken (see Fig. 8) or has not sufficient
tension anymore. Requires replacement.
2. Booster gives no pressure
Check whether Operating Valve in resting position allows air to pass to booster, so
that this valve is already worked out before operated.
3. Press loses pressure during cycle
a) Check if air supply line is leaky.
b) It may occur that there is a leakage between Check Valve Stem 30595 and Seat
(see Fig. 1). If necessary, replace Valve and adjust Seat. Former presses have
been equipped with a metallic Valve instead of a plastic one.
Such metallic Valve has to be tightened by means of an O-Ring. Old parts can
simply be replaced by 30595.
c) BACK-UP RING 30025 and O-RING 30029 (see Fig. 2) require replacement.
Damages on Back-Up Ring can be hardly located, because of small cracks.
Check also O-Ring 30032; after longer use this )-Ring can be damaged.

Page 4
Information subject to change without notice.
d) Check if seat between Plunger 10520 and Booster Valve 10306 is damaged (see
Fig. 7) (always to be replaced at the same time).
e) Check O-Ring 30081 (damages do not occur very often) (see Fig. 8).
f) Check O-Ring 30083 (see Fig. 5).
4. Loss of oil and eventual loss of pressure
a) CHECK VALVE STEM 30595 does not work, causing that oil cannot flow back.
Oil will then accumulate in the top of the Booster at PISTON ROD GUIDE 894
(see Fig. 1 and 4).
b) BACK-UP RING 30084 and O-RING 30082 let oil pass through, so that it can
enter into the air part. In most cases to be located by a greasy oil vapour, which
blows out of the Exhaust Valve during release of air part.
(The Exhaust Valve is mounted in front of air inlet of Booster.) Check also, if
PISTON ROD 1884 has been damaged. Sometimes this Rod can be repaired by
rubbing with very fine sandpaper in longitudinal direction (only slight damages)
(see Fig. 7 and 8).
5. Press slows down badly at closing
a. Refill oil on Booster (use only oil with Pantex No. 80022).
b. In case of loss of oil, see point 4.
Please note, when mounting the Booster between the shafts, that upper and lower
fastening points must be lined out absolutely vertically.

Page 5
Information subject to change without notice.
EXAMPLE OF ASSEMBLING HYDRAULIC BOOSTERS
This example of assembling is meant of those who have some technical insight in the
process of working of the above mentioned cylinders, like service technicians and simi-
lar persons.
The numbers indicated in this example of assembling may not be used for ordering
spare parts.
For this purpose you have to use the spare parts catalogue, which is delivered with
every machine.
Disassembling takes place in reversed order of succession.
The used auxiliary tools can be ordered as per the following list:
Auxiliary tools:
A. “O” Ring mounting tool 19 946
C. Chain tong 19 949
D. Auxiliary tool 19 943
E. “O” Ring mounting tool 19 945
F. Mounting Rod 19 941
H. “O” Ring mounting tool 19 944
J . “O” Ring adjusting tool 19 947
K. Special screw driver 19 950
M. Shaft clamp 19 948
N. Protection plate (2x) 19 942
Booster Revision Tools (complete set as described above) 117 847
For prices of these auxiliary tools, please see price list.

Page 6
Information subject to change without notice.
PRELIMINARY ASSEMBLING OF CYLINDER HEAD
(Figure 1)
Pinch tool “L” in a bench screw and fix to it CYLINDER HEAD 297 by means of PIVOT
CLAMP 128 and the fastening bolts.
Fix O-RING 30036 after greasing by means of special tool “A” round the CHECK
VALVE CAP 20033.
Check whether there is a sharp edging at point “B” in the CYLINDER HEAD 297; if
there is, remove it. This prevents damage to the valve.
Fix successively CHECK VALVE STEM 30595, CHECK VALVE CAP SPRING 50018,
and the already preliminary assembled CHECK VALVE.
Instead of a plastic CHECK VALVE STEM a metal one is used in older executions, on
which an extra O-RING 30036 has been mounted.
Both old parts CHECK VALVE STEM and O-RING can be replaced by the new
CHECK VALVE STEM 30595.

Page 7
Information subject to change without notice.
Figure 1

Page 8
Information subject to change without notice.
PRELIMINARY ASSEMBLING OF PISTON ROD
HYDRAULIC PART (Figure 2)
Mount NEEDLE BEARING 80011 into ROD HEAD 114 and screw this on to PISTON
ROD 10087.
Assemble successively on the PISTON ROD;
CHECK SPRING _____________________ 50 016
CHECKING RING____________________ 10 088
HYDRAULIC PISTON ________________ 20 697
BACK-UP RING ______________________ 30 025
O-RING______________________________ 30 029
PISTON PACKING RING _____________ 10 094 (check if it is damaged)
SPRING _____________________________ 50 019
PISTON ROD NUT ___________________ 10 095
After tightening the PISTON ROD NUT 10095 the hole at the bottom of PISTON ROD
10087 may be deformed somewhat. Please note, that this will not cause any difficulties
when assembling CHECKING DISC ASSY 110029 (see Figure 3).
This only appears on replacing the PISTON ROD 10087 and not on disassembling and
assembling in the normal way.

Page 9
Information subject to change without notice.
Figure 2

Page 10
Information subject to change without notice.
ASSEMBLING OF IN AND OUTSIDE CYLINDERS
HYDRAULIC PART (Figure 3)
Mount O-RING 30035 in the CYLINDER HEAD.
Provide point / / of BOOSTER CYLINDER TUBE 113996 with liquid packing and
screw it f.e. by means of a chain tong “C” into the CYLINDER HEAD.
Insert between these two parts any available SPACER RINGS. These SPACER
RINGS are necessary to fix the BOOSTER CYLINDER TUBE in the right position.
Mount O-RING 30032 after greasing round the HYDRAULIC CYLINDER (INNER)
10096.
Put the CHECKING DISC ASSY 110029 into the recess of 10096 and press the whole
thing with the aid of tool “D” into the CYLINDER HEAD.

Page 11
Information subject to change without notice.
Figure 3

Page 12
Information subject to change without notice.
ASSEMBLING OF IN PISTON ROD
HYDRAULIC PART (Figure 4)
Screw ROD HEAD 114 from the PISTON ROD 10087.
Fix HYDRAULIC PISTON SPRING 50015 round the already preliminary assembled
piston rod and push round it auxiliary tool “D”, so that 50015 cannot jump away.
Press the piston part into HYDRAULIC CYLINDER (INNER) 10096 and remove
auxiliary tool “D”.
Fit O-RING 30034 round PISTON ROD GUIDE 894, after the first has been greased.
Then also mount SCRAPER RING 30783 into Piston Rod Guide.
Mount successively into the cylinder:
PISTON ROD GUIDE____________________ 894 (incl. O-Ring and Scraper Ring)
SPLASH RING _______________________ 94 154
CYLINDER HEAD RING_________________ 126
ROD HEAD _____________________________ 114

Page 13
Information subject to change without notice.
Figure 4

Page 14
Information subject to change without notice.
PRELIMINARY ASSEMBLING OF AIR CYLINDER PISTON
(Figure 5)
Tighten PISTON ROD 18847 into a bench screw, whereby you MUST make use of tool
“N” (aluminum sheets or another similar material), so that damages of the PISTON
ROD in any way are prevented.
Provide O-RINGS 30026 and 30080 with grease and push the latters round the
PISTON ROD with the aid of tools “E” and “H”.
Check whether the O-RING groove of BOOSTER PISTON 296 is free from damages,
slight damages may sometimes be corrected with the aid of very fine emery-cloth. (Rub
in longitudinal direction)
Fix successively BOOSTER PISTON 296, PLAINWASHER and SECURITY NUT.
Provide O-RING 30083 with grease and mount it round the BOOSTER PISTON.

Page 15
Information subject to change without notice.
Figure 5

Page 16
Information subject to change without notice.
PRELIMINARY ASSEMBLING OF AIR CYLINDER PART
(Figure 6)
Screw PISTON ROD GUIDE 10522 into the preliminary assembled CYLINDER HEAD
297.
Screw AIR VALVE INLET 20747 onto the PISTON ROD GUIDE ASSY (groove
downwards) after the first has been provided with liquid packing on both sides.
Use tool “F” for this purpose.
Angle “a” is about 15° for normal presses.
Fix BOOSTER AIR CYLINDER 205 f.e. by means of a chain tong “G”.
Pinch this tong around the bottom side / of the cylinder in order to prevent impressing.
Screw now the complete assembled part again out of the CYLINDER HEAD to
assemble the inner work.

Page 17
Information subject to change without notice.
Figure 6

Page 18
Information subject to change without notice.
ASSEMBLING OF THE PACKING BETWEEN HYDRAULIC AND
AIR CYLINDER PART
(Figure 7)
Fix BACK-UP RING 30084 on the seat at the bottom of the preliminary assembled
cylinder part; the flat side has to be directed downward and press this with the aid of
tool “J”.
Then fix O-RING 30082 and now mount the next BACK-UP RING 30084 directed with
the hollow side to the O-Ring, after which all parts can be locked away by means of
RING 18846. Use tool “K” for this purpose.
Put some oil on the preliminary assembled PISTON ROD 18847 and on the inner side
of the BOOSTER AIR CYLINDER 205.
Now press the piston rod through the back-up rings upwards.
Mount successively Spring Holder 199882, Spring 50209, Plunger 10520, Booster
Valve 10306, and guard the latter by means of a cotter pin.
The lower side of the hole in PISTON ROD 18847 and the lower side of the groove in
PLUNGER 10306 must be in line with each other (see point A).

Page 19
Information subject to change without notice. Figure 7

Page 20
Information subject to change without notice.
ASSEMBLING OF AIR CYLINDER AND PLUNGER PART IN THE
CYLINDER HEAD
(Figure 8)
Mount after greasing successively BACK-UP RING 30085 (flat side downward, see
picture), O-RING 30081 and O-RING 30031 in the CYLINDER HEAD 297.
Mount the preliminary assembled plunger and air cylinder part in the CYLINDER
HEAD, after having put some oil on the plunger / /. Use f.e. a chain tong “C” (bottom
side cylinder /).
Fit successively in the BOOSTER AIR CYLINDER 205:
AIR BOOSTER SPRING ______________ 50 092
SPRING SEAT __________________________ 376
CYLINDER DISC_____________________ 12 208 and guard the latter by
REATINING SPRING_________________ 50 040
Mount after having applied liquid packing next parts:
SPACER _____________________________ 12 207
BOOSTER NUT _________________________ 893
