Scion-Tech SC01.7060 User manual

User Manual
Version 1.0
SC01.7060
User ManualScion Tech SC01.7060
Tel: [phone] www.scion-tech.co.uk [email protected]
18Gbps 4K HDMI Extender
with Looped HDMI & PoC

User ManualScion Tech SC01.7060
Thank you for purchasing this product
For optimum performance and safety, please read these instructions carefully before connecting, operating or
adjusting this product. Please keep this manual for future reference.
Surge protection device recommended
This product contains sensitive electrical components that may be damaged by electrical spikes, surges, electric
shock, lighting strikes, etc. Use of surge protection systems is highly recommended in order to protect and extend
the life of your equipment.
Contents
1. Introduction....................................................................................................................................... 2
2. Product Features................................................................................................................................ 2
3. Package Contents............................................................................................................................... 2
4. Specifications.................................................................................................................................... 3
5. Front Panel Description..................................................................................................................... 4
6. Rear Panel Description...................................................................................................................... 4
7 . IR Remote......................................................................................................................................... 5
8. HDMI Cable Lengths........................................................................................................................ 5
9. Application Drawing......................................................................................................................... 6
10 . Maintenance and Warranty............................................................................................................. 7
Tel: [phone] www.scion-tech.co.uk [email protected]
Page 1

1. Introduction
The SC01.7060 extends the distance between the HDMI source and display up to 90m over a single CAT5e/6
cable with zero degredation and zero latency. The 18Gbps technology supports resolutions up to 4K/60Hz and
LPCM 7.1 digital audio. The transmitter has a looped HDMI output for connecting a local display and the return
path wide band infra-red gives smooth control of the source device.
These units support HDMI 2.0, HDCP 2.2 and HDR making them suitable for most system installations, including
Gaming, DVD, SkyHD and SkyQ™.
2. Features
●Extends up to 90m over CAT5e/6
●HDMI 2.0, HDCP 2.2, HDR
●Supports 18Gbps
●4K/60Hz, YCbCr 4:4:4
●LPCM 7.1, Dolby True HD, DTS-HD
●Looped HDMI output on transmitter
●PoC (only needs one PSU ate either end)
●Extracts analogue and digital audio
●IR Pass-Through for source control
●Advanced EDID
3. Package contents
1. 1 x Transmitter
2. 1 x Receiver
3. 1 x IR Sender Cable
4. 1 x IR Emitter Cable
5. 1 x Power Adaptor 12V/1A
6. User Manual
Page 2
User ManualScion Tech SC01.7060
Tel: [phone] www.scion-tech.co.uk [email protected]

4. Specifications
Page 3
User ManualScion Tech SC01.7060
Tel: [phone] www.scion-tech.co.uk [email protected]
Connectivity
Transmitter
HDMI Input: 1 x HDMI Type A, 19-Pin Female
HDMI Output (Looped): 1 x HDMI Type A, 19-Pin Female
CAT5e/6 Output: 1 x RJ45 Data Socket
Infra-Red Out: 1 x 3.5mm Jack Socket
Firmware Upgrade: 1 x Mini HDMI
Power: 1 x 2.1mm DC Jack
Receiver
CAT5e/6 Input: 1 x RJ45 Data Socket
Infra-Red Input: 1 x 3.5mm Jack Socket
HDMI Output: 1 x HDMI Type A, 19-Pin Female
Analogue Audio Output: 1 x 3.5mm Jack Socket
Digital Audio Output: 1 x Toslink Optical
Firmware Upgrade: 1 x Mini HDMI
Power: 1 x 2.1mm DC Jack
Signal
Signal Input: HDMI
Standards: HDMI 2.0, HDCP 2.2
Bandwidth: 18Gbps
Video Resolutions: 4K/60Hz, 4:4:4
Colour Space: RGB/YCbCr 4:4:4, YCbCr 4:2:2, YUV 4:2:0, HDR, HDR 10+, DLD, Dolby Vision
Colour Depth: 8/10/12-bit
Audio: LPCM 2.0/2.1CH, Dolby 5.1, Dolby True HD™, Dolby DD+™, DTS 5.1, DTS-ES 6, DTS-
HDMA 5.1, DTS HD-HRA 5.1
Infra-Red: Wide Bandwidth, Frequency 30KHz to 56KHz (940nm)
Performance
Cable Distance/Resolution: 4K/60Hz@70m, 4K/30Hz@80m, 1080p/60Hz@90m
Power
Type: AC to DC Mains Adaptor (only requires power at one end, Tx or Rx)
Input: 100~240V AC 50/60Hz
Output: Transmitter 12V/1A
Consumption: 3.8 Watts
Environment
Operating Temperature: -0° to 40°C
Storage Temperature: -20° to 60°C
Operating Humidity: 20 to 90% RH (no condensation)
Dimensions: Tx = (W) 76 x (D) 73 x ( H) 18, Rx = (W) 76 x (D) 73 x ( H) 18
Weight: Tx = 305g, Rx = 305g
Colour: Black
ESD: Human Body - +/-8kV, (air gap discharge) & +/-4kV (contact discharge)
Safety and Emissions: CE, FCC, RoHS

5. Front Panel Description
User ManualScion Tech SC01.7060
Page 4
Tel: [phone] www.scion-tech.co.uk [email protected]
0
0
1
EDID
1 2
HDMI Out HDMI In CAT5e Out IR Out
FW DC/12V
51 2 3 4 6 7
Number Name Function / Description
1 EDID Switch The transmitter has default integral EDID and the ability to copy EDID. Defaults
include 4K/60Hz and 1080P/60Hz.
2 HDMI Out Looped HDMI output for connection to a local screen.
3 HDMI In Connect the HDMI source device using a Premium High Quality HDMI cable to
achieve the best results.
4 CAT5e/6 Out
Connect to CAT5e/5 cabling. This connection must be end to end and not include any
network products such as routers or switches. Connecting to these devices will cause
damage to both the transmitter and receiver.
5 Firmware Used for firmware upgrades only.
6 IR out Connect the IR Emitter cable and place the emitter over the source device IR sensor.
7 DC Jack Connect the 12V power supply (PoC - only needs 1 x PSU at either end)
6. Rear Panel Description
CAT5e In IR In
FW DC/12V
HDMI Out Analogue Toslink
Output
51 2 3 4 6 7
(00) Default 4K60YUV420-2CH (01) Copy EDID from far-end display
(10) Copy EDID from loop out display (11) Default 4K60YUV444-5.1CH
EDID Switch Settings
Number Name Function / Description
1 HDMI Out Connect the HDMI screen using a Premium High Quality HDMI cable.
2 Analogue Audio Out Line level analogue stereo audio out for connecting to speakers or amplifier
3 Digital Toslink Optical connection for amplifier or Sound Bar
4 CAT5e/6 In
Connect to CAT5e/5 cabling. This connection must be end to end and not include any
network products such as routers or switches. Connecting to these devices will cause
damage to both the transmitter and receiver.
5 Firmware Used for firmware upgrades only.
6 IR In Connect the IR Sender cable and place the receptor in line of sight of the IR remote.
7 DC Jack Connect the 12V power supply (PoC - only needs 1 x PSU at either end)

7. Application Drawing
Page 5
Audio Amplifier
Speakers
Display
User ManualScion Tech SC01.7060
Tel: [phone] www.scion-tech.co.uk [email protected]
0
0
1
EDID
1 2
HDMI Out HDMI In
CAT5e Out IR Out
FW DC/12V
CAT5e In IR In
FW DC/12V
HDMI Out Analogue Toslink
Output
Display

Page 6
8. Maintenance
Clean this unit with a soft, dry cloth. Never use alcohol, pint thinner of benzene to clean these devices.
Servicing
Damage requiring service: This product should be serviced by a qualified service engineer if:
●The DC power cord or AC adaptor has been damaged.
●Objects or liquids have entered the housings.
●The product has been exposed to rain.
●The product has stopped working or shows signs of significant change in operating performance or function.
●The unit has been dropped or severely damaged externally.
Servicing personnel: Do not attempt to service the product beyond that described in these instructions. Refer all
other servicing to authorised serving personnel.
Replacement parts: When parts need replacing ensure the service engineer uses parts specified by the manufacture
or parts that have the same characteristics as the original parts. Unauthorised substitutes may result in fire, electric
shock or other hazards.
Safety check: After a repair or service, ask the engineer to perform safety checks to confirm the product is in
proper working condition.
Warranty
If your product does not work properly because of a defect in materials or workmanship, our Company (referred to
as "the warrantor" ) will , for the length of the period indicated as below, (Parts and labour 2 years) which starts
with the date of original purchase ("Limited Warranty period"), at its option either (a) repair your product with new
or refurbished parts, or (b) replace it with a new of a refurbished product. The decision to repair or replace will be
made by the warrantor.
During the "Labour" Limited Warranty period there will be no charge for labour. During the "Parts" warranty
period, there will be no charge for parts. You must mail-in your product during the warranty period. This Limited
Warranty is extended only to the original purchaser and only covers product purchased as new. A purchase receipt
or other proof of original purchase date is required for Limited Warranty service.
Returning a Product
When shipping the unit carefully pack and send it prepaid, adequately insured and preferably in the original carton.
Include a letter detailing the complaint and provide a day time phone number and/or email address where you can
be reached.
User ManualScion Tech SC01.7060
Tel: [phone] www.scion-tech.co.uk [email protected]

Page 7
Limited warranty limits and exclusions
This Limited Warranty ONLY COVERS failures due to defects in materials or workmanship, and DOES NOT
COVER normal wear and tear or cosmetic damage. The Limited Warranty ALSO DOES NOT COVER damages
which occurred in shipment, or failures which are caused by products not supplied by warrantor, or failures which
result from accidents, misuse, abuse, neglect, mishandling, misapplication, alteration, faulty installation, set-up
adjustments, maladjustment of consumer controls, improper maintenance, power line surge, lightning damage,
modification, or service by anyone other than a Factory Service centre or other authorized service engineer, or
damage that is attributable to acts of God.
THERE ARE NO EXPRESS WARRANTIES EXCEPT AS LISTED UNDER "LIMITED WARRANTY
COVERAGE".THE WARRANTOR IS NOT LIABLE FOR INCIDENTAL OR CONSEQUENTIAL DAMAGES
RESULTING FROM THE USE OF THIS PRODUCT, OR ARISING OUT OF ANY BREACH OF THIS
WARRANTY. (As examples, this excludes damages for lost time, cost of having someone remove or re-install an
installed unit if applicable, travel to and from the service, loss of or damage to media or images, data or other
recorded content. The items listed are not exclusive, but are for illustration only).
PARTS AND SERVICE, WHICH ARE NOT COVERED BY THIS LIMITED WARRANTY, ARE YOUR
RESPONSIBILITY. This returns policy does not affect your legal rights. Details of your legal rights are available
from Trading Standards or Citizens Advice Consumer Service.
