Measy W2H H303 User manual

1
4x4 Multicast Wireless HDMI Extender
Model:W2H H303
I、Introduction
The Multicast HDMI Wireless Extender extends your HDMI display up to 100 feet from 4 HDMI source
devices to up to 4 separate receivers wirelessly. Easily connect HDMI source devices and up to four
receivers (connected to HDTVs) wirelessly, with crystal clear image quality capable of streaming Full
1080p with 7.1 channel HD digital audio and 3D technology. The IR remote controlallows you to switch
between HDMI source devices from the transmitter side.
II、product strength：
1. No more clutter
All the reliability of an HDMI cable without the messy wire

2
2. Free from interference
A 60GHz frequency signal means no interference from other wireless devices in the home.
3. Easy to install
can be plugged into TVs or source players, while drawing power from your TV
4. A proven technology
Stream video, cable/satellite, Blu-Ray, and even Internet content –up to 1080p60, 3D, and 7.1 surround
sound.
5. Great for gaming
“Zero latency” means no delay between your gaming console and the big screen.
III、specifications:
60GHz Wireless HDMI Technology
1080p60 HDMI Connectivity
3D Support
7.1 HD Audio
Both units USB powered
30’+ in-room connection
RF “beam” steering for auto-healing connection
Free from other Wi-Fi Interference
Lowlatency- almost zero lag time
Fast recovery

3
IV. Accessories：
User manual x1
USB power cable x2
Power adapter x2
Remote x1
V. Connection and placement：
This product can’t be used to going through walls. When placing, try best to put the fronts of both receiver
and transmitter face-to-face and avoid blocking in the middle.
Transmitter：HDMI cable connecting to HDMI Video source and using Micro USB cable to supply power.
Receive：HDMI cable to connect TV devices and using Micro USB cable to supply power.

4

5
TX / RX View
VI. Indicator light
extinguish：stand by status
Slow flash：（Interval of 1 second）in researching devices
fast flash：devices already connected
normal on：Input and output end right audio and video signal transmission
VII、Keys

6
Short press 4 seconds：searching for next device match
Long press 10 seconds：devices reset
VIII、Specification
Wireless Standard
WiHD 1.1 (60 GHz)
HDMI version
HDMI 1.4a
Max. Resolutions
1080p60
Range
35+ feet (10+ m)
Audio Formats
7.1ch HBR/PCM audio up to 192kHz, 5.1 up to 48kHz
Range Line of Sight
100 feet (30 m)
Power Supply
1 x DC Jack (Mini USB), 5V/500mA (Transmitter & Receiver)
Active Power
2.5W (Transmitter & Receiver)
Max working current
650mA
Radiated Power (EIRP)
28dBm (630mW)
Operating Temperature range
-15℃to +55℃
Transmitter’s interface
1 x HDMI Type A Female
Receiver’s interface
4 x HDMI Type A Female
Weight
333g (Transmitter + Receiver)
Housing
Aluminum(transmitter & Receiver)
Color
Black
Transmitter size
150*50*30mm
Receiver size
150*50*30mm
1. Support the input video formats

7

8

9
2.Support the input audio formats
