A/C AIR LAUNCHERTM
Operating Instructions
P/N 101050 (120 VAC)
P/N 101051 (230 VAC)

1
Thank you for purchasing this A/C AIR LAUNCHERTM
As you will notice from the table of contents, the manual for your new
product is quite extensive.
To guarantee perfect and successful work with this machine, please
take some time to read the manual carefully.
And finally, we believe you will enjoy years of great effects if you care
for and maintain your A/C AIR LAUNCHERTM.
CITC
1420 80TH SW #D
EVERETT, WA 98203
(888) 786-CITC
www.citcfx.com

2
Contents
1. Set of Equipment Supplied 3
2. Accessories and Parts 3
3. Confetti Products 3
4. Description 4
5. Safety Instructions 4
6. Operating the A/C AIR LAUNCHERTM 5
6.1 Assembly
6.2 Loading
6.3 Optional backpressure cap
6.4 Pressurizing the tank
6.5 Firing the A/C Air LauncherTM
6.6 Troubleshooting
7. Service and Maintenance 7
8. Technical Data 7
9. Limited Warranty Conditions 8

3
1. Set of Equipment Supplied
1 A/C AIR LAUNCHERTM (120VAC: P/N 101050; 230VAC P/N 101051)
Instruction booklet
2. Accessories and Parts
Spare 2” (5cm) Barrel P/N 350020
DMX FX-15 Switchpack 120 VAC, 15A relay P/N 250051, or
DMX FX-15 Switchpack 230 VAC, 8A relay P/N 250052
Wireless Remote RF 120VAC, 15A 13ch P/N 250010
Roll of 1.5” (3.8cm) black Masking Tape (P/N 350075)
One dozen 2” (5cm) Push Caps n’ Cups set (P/N 350145)
3. Confetti Products
Also check our catalog or website (www.citcfx.com) for a complete selection of
confetti and streamer products
CONFETTI - SPEED LOAD
Confetti stacked in 1" x 18" (2.5cm x 46cm) soft-sleeve. Just slide in then pull sleeve
Multi-color mix or Solid colors in stock. Custom mix by request.
Tissue Confetti - Multicolor or solid colors; 5/8" x 2 1/4" (1.6cm x 5.7cm) (P/N 255501)
Mylar-Tissue Confetti - Silver or gold Mylar & color tissue 5/8"x 2 1/4" (1.6cm x 5.7cm)
(P/N 255651)
STREAMERS - SPEED LOAD
FlameProof, Biodegradeable Tissue Paper & Mylar 1" x 20" (2.5cm x 51cm) soft-sleeve for
quick loading of your cannons (slide in then remove sleeve - no packing)
Tissue Streamer - 1/2" x 30' (1.3cm x 9.1m) (P/N 255700)
Mylar Streamers w/ Tissue Streamer-Silver or Gold Mylar & White tissue
or rainbow mylar w/ tissue (P/N 255800)
BULK/BAGGED CONFETTI & STREAMERS
Long-Flying Tissue Confetti – Single colors or mix (P/N 255075)
Mylar - Gold, silver & rainbow confetti (P/N 255110)
Special Orders: Most products are available in single colors or stock mixes. Additional time
and/or charges may apply for custom orders or custom mixes.
Please check whether all the products you ordered are supplied.

4
4. Description of the A/C AIR LAUNCHERTM
The user has the ability to produce a spectacular simulated fireworks display, outdoors,
without the risk of fire! When loaded properly, this device will safely propel tissue
streamers and/or tissue (not paper) confetti to distances of up to 100’ in the air! The end
result resembles a cascading display of daytime firework-like effects. Note: due to wind
resistance and low weight, confetti will not travel as far as streamers. The included 7-
gallon air tank must be filled from an air compressor or be connected into a constant
replenishing CO2air cylinder tank (available from your local gas supplier), eliminating the
need for manual refills. The CO2air tank makes it economically feasible to do continuous
reloads and refills for places like circuses or theme parks. The A/C Air Launcher™
features a built-in safety release, two types of filling valves, a pressure gauge, and an
electric release solenoid valve (1/2" high-volume type). The launcher fires as soon as it
is plugged in, or if connected to an electrical switchbox, as soon as it is switched on.
Launcher comes with a 24VAC solenoid valve and 120VAC/240VAC, 24V transformer.
5.Safety instructions
WARNING: Read and understand all labels and operating instructions
before attempting installation.
oInspect all equipment and barrel before use. Do not use if barrel is cracked or chipped.
oBe sure area around launcher is dry before applying electrical power.
oNever point the muzzle directly at anyone or look over the barrel when pressurized and
loaded.
oSecure the launcher so that it will not be moved after it is aimed.
oUse a safety cable if the launcher is rigged above ground.
oWhen using, keep away from spectators and always aim straight up over everyone’s
head
oWARNING! Never use a confetti-launching product if there are open flames present.
oUse only tissue-type confetti or streamers that are flame retardant as sold by CITC.
oNever use paper dots or heavy paper confetti.
oPressurize up to maximum 100 PSI (6.9 bar) only!

5
6. Operating the A/C AIR LAUNCHERTM
6.1 Assembly
•Secure a good location for the machine to rest solidly on the floor.
•Secure the launcher so it will not be moved after it is aimed
•Anchor as needed with straps, screws, or sandbags.
•Use a safety cable if the launcher is rigged above ground
•Install the 2” (5cm) barrel on the valve assembly.
6.2 Loading
•If you power the transformer, the solenoid immediately releases the air. Always be sure
your power is off before loading and pressurizing. As soon as you plug it in, it will fire.
•It is a good practice to test the solenoid valve with a charge of air before loading the
barrel.
•Optional lifting cup: for 2” (5cm) barrel loading style, insert a foam plug (lifting cup) by
pushing the entire foam disk down the barrel to the bottom. You may need to squeeze
the bottom of the disk to make it fit. If lifting cups are unavailable, use paper wadding.
The lifting cup acts as a bottom expanding sealer, making the device more powerful. This
ejects your streamers for a longer distance. Now you are ready to load product on top of
the lifting cup. Hard press, packing is not necessary.
•Indoors: We recommend a minimum of 60 rolls of 30’ streamers. The more you include,
the more spectacular the effect! If your budget allows, using 120 rolls looks great. If you
want an unbelievable effect, use 240 rolls! You may fill the unit to the top if you wish or
just load it to ½ full.
•Outdoors or large arenas: the bigger and heavier streamers will travel further. For the
highest altitude and the best visual effect, load at least 36 of the 30’ streamers. Warning:
sudden cross gusts of wind and trees can be your enemy! We have found the best visual
effects when each device is loaded with the same style or type of product.
6.3 Optional backpressure cap
•A backpressure cap can also be installed over the end of the barrel to improve
performance. If the distance isn’t far, a backpressure cap is not needed. For smaller
loads, backpressure caps may be needed for added backpressure. If firing on low
pressure, the 2” (5cm) cap needs 1 – ½ rounds of black tape around the end of the
barrel. This causes a pop and develops backpressure for further launch.
•Installing the cap: Slip the cap over and snug it down. With masking tape, neatly tape 1 ½
turns around the side of the barrel and cap. After taping, roll your hand around the tape
pressing down to form an airtight seal. This will cause the backpressure to increase when
fired and blow the lid off, expelling the contents under greater pressure. Do not tape over
the top of the cap.

6
•Note: the lifting cups are sometimes reusable if you can find them, however the
backpressure caps may need replacing if they tear when blown off.
6.4 Pressurizing the tank
•Fill tank from your own air source. Use an air compressor capable of up to 100 PSI, a
tank of compressed air, or even a tire pump. For the most refills of air, use CO2 with a
regulator. Pressurize at 80 – 100 PSI (5.5 – 6.9 bar) only! The CO2tank should only
be turned on when it is time to fire the launcher. You could, in a jam, pressurize the
tank with a tire pump with a tire air fitting. See the valve illustration below.
6.5 Firing the A/C Air LauncherTM
Do not plug into power until finished reading these instructions. This unit is
equipped with a 120VAC/240VAC, 24VAC transformer (P/N 600670) to actuate the
solenoid and this will release the air pressure. Plug the transformer into the
corresponding outlet that is controlled with an off/on switch. The solenoid valve opens if
there is power to the transformer, so always have the switch “off” until ready to shoot the
product into the air.
Use of a momentary switch is recommended to help save pressure for the next shot. If
you use a regular switch or simply plug it into the wall, you'll release all of the pressure in
the tank. (With a momentary, it is possible to get two shots out of the air tank before
refilling).
When the launcher releases the air, it may make noise as the escaping air moves
through the release valve. This is normal. If the unit is to be used in a quiet environment,
locate it in an area that will create the least amount of disruption.

7
6.6 Troubleshooting
1. If you plug in the transformer, the solenoid immediately releases the air. Always be
sure your power is off before loading and pressurizing. As soon as you plug it in, it will
fire.
2. Air is leaking and won’t hold pressure: Check all connections with soap and water and
tighten as necessary.
3. Even at 100 PSI (6.9 bar) pressure, the confetti doesn’t launch. You have packed it
too tight. Do not pack tightly. Only the push cup should be shoved to the bottom. Add
confetti or streamers with a light pack. Never use paper dots. Always use fire retardant
lightweight tissue-type confetti or streamers.
7. Service and Maintenance
Care of your A/C AIR LAUNCHERTM will give you years of service
•It is a good practice to test the solenoid valve with a charge of air before loading the
barrel.
•When finished with use:
•Remove and inspect barrel for cracks
•Check that cord is in good condition, not pinched or broken.
8. Technical Data
A/C Air LauncherTM Technical Data
P/N 101050 (230VAC P/N 101051)
Dimensions
Assembled: 35” x 34” x 14”
(89 cm x 86 cm x 36 cm)
Weight
20 lb (9 kg)
Shipping Weight
27 lb (12.25 kg)
Shipping Box Size
24” x 17” x 20”
(61 cm x 43 cm x 51 cm)
Distance
Streamers: 100 ft (30.5m)
Confetti: 50 – 60 ft (15m – 18m)
Barrel
2” x 24” (5 cm x 60 cm)
Solenoid Valve
¾” (1.9cm), 24 VAC/0.7 A with
120VAC/230VAC Transformer
Air fittings
Quick-Disconnect, tire valve,
pressure relief, pressure gauge
Working pressure
80 -100 PSI (5.5 - 6.9 bar)
Actuation
Power on (or optional switch)
DMX
Optional Universal DMX
Electrical Supply
120 VAC, 0.2 A, 60 Hz
(or 230 VAC, 0.1 A, 50 Hz)
Limited Warranty
One year
Rev: 01/28/18

8
9. One Year Limited Warranty Conditions
Model: ________________ Purchased on (date): ________________
Serial number: ________________ Purchased from: ________________
Congratulations!
You can now look forward to many years of reliable operation and outstanding performance.
Thank you for making CITC your personal choice in special effects equipment. Please take a
moment to fill out the top of this warranty, and then keep it – with the receipt – in a safe
place.
If you would like to receive information about specials, sales, and new products, please log
on to www.citcfx.com and click on the “Contact Us” link.
We appreciate your business, and wish to provide you with a quality product that will serve
you for many years to come. Once again, thank you for choosing CITC, and enjoy your new
entertainment product!
LIMITED WARRANTY CONDITIONS
This limited warranty guarantees to the original purchaser that this product shall be free of
defects in material and workmanship, under normal use, for a period of one year from the
date of purchase shown on the sales receipt. This warranty covers parts and labor providing
the product is returned to CITC in the original shipping carton and packaging. The warranty
for electrical is a (90) NINETY DAY limited warranty.
Damage resulting from shipping, accidents, misuse, negligence, unauthorized repairs or
modification is not covered by this warranty. Using any fluid other than what is recommended
for this machine will void warranty. No liability is accepted for injury or for loss, damage or
expense resulting from any interruption whatsoever in the operation of the product or from
any consequential loss arising there from. No liability is accepted for normal wear and tear.
We wish to satisfy YOU, our customer, and have implemented many measures to prevent
problems and assure customer satisfaction. However, should you need a missing part or
have a functional problem with your product, please call:
(888) 786-CITC, from 7:30 am – 4:00 pm (Pacific Time), Monday – Friday, except for
holidays. Our customer service department will respond to your problems immediately.
Subject to the following conditions, CITC will repair any defect or fault in the unit if it is
caused by a proven factory defect within one year of delivery to the end user.
Insignificant deviations of the regular product quality does not guarantee replacement
rights, nor do faults or defects caused by water, by generally abnormal environment
conditions or Force Majeure:
1. Faulty parts or equipment will be repaired or replaced (manufacturer’s choice) with
correct parts. Faulty units must be shipped to CITC at customer’s expense. Call for
an RMA# - AN RMA# MUST COME WITH THE UNIT. Payment arrangements for
repair must be made before receiving your RMA#, in case the unit is not covered
under this limited warranty.
2. Repairs/replacements will only be made with the approval of the customer.

9
3. Exposure to outside elements voids Warranty. Unit cannot be used outdoors or in wet
weather without complete protection against the elements. Even then, high salty or
humid conditions will cause instant corrosion of connectors and will void Warranty.
4. The customer loses all rights for limited warranty services if any repairs or
adjustments are done to the units by unauthorized persons, and/or if spare parts are
used, which are not approved by CITC. The right of limited warranty service is also
lost if a fluid other than appropriate CITC fluid has been used or if units are sent in
without first emptying the equipment of fluid.
5. Freight costs to and from CITC, when under the limited warranty services, are the
responsibility of the customer. Customer must place appropriate insurance on return
of product. However, if product is returned due to factory defect within the first year,
CITC will cover the cost of returning the repaired unit to the customer.
6. Limited warranty services do not cause an extension of the limited warranty period or
the start of a new limited warranty period. The warranty of replaced parts ends with
the limited warranty period of the whole unit.
7. Further claims, especially for damages, losses etc. outside the unit are excluded.
Send unit to: CITC
RMA # XXXXXXX
1420 80th St. SW #D
Everett, WA 98203
Tel: (888) 786-CITC or [phone]
Fax: [phone]
Website: www.citcfx.com
E-mail: [e-mail]
Find us on Facebook!
www.facebook.com/CITCFX
March 16, 2018
