CITC ShotMax 100260 User manual

SHOTMAXTM
Operating Instructions
P/N 100260 (120 VAC)
P/N 100265 (230 VAC)

1
Thank you for your purchase of this SHOTMAXTM
To guarantee perfect and successful work with this machine, please
take some time to read the manual carefully.
We believe you will enjoy years of great confetti effects if you care for
and maintain your SHOTMAXTM.
CITC
1420 80th St. SW, #D
Everett, WA 98203
(888) 786-CITC
www.citcfx.com

2
Contents
1. Set of Equipment Supplied
ShotMaxTM (120VAC: P/N 100260; 230VAC: P/N 100265)
1. Equipment Supplied
3
2. Accessories
3
3. Confetti Products
4
4. Description
5
5. Safety Instructions
5
6. Operating the Shotmax™
6.1 Selecting The Location
6.2 Electrical Power Requirements
6.3 Hooking Things Up
6.4 Operating the Machine
6.5 Optional DMX Control
6.6 Rest Period
6.7 Troubleshooting
6
6
6
6
6
7
7
7
7. Service and Maintenance
8
8. Technical Data
8
9. Limited Warranty Conditions
9-10

3
Bracket w/ Mounting Hardware
Barrel 2” x 24” (5cm x 61cm) tube w/ Male Fitting
Tube w/ Angled Feeder Tip 2” x 24” (5cm x 61cm)
Tube w/ Angled Feeder Tip 2” x 5” (5cm x 13cm)
Suction Hose Assembly 48” flex (1.23m)
Power Cord, IEC 16AWG
Instruction Booklet
2. Accessories and Parts
C-Clamp w/ Safety Cable (P/N 250110)
DMX FX-15 Switchpack (120V P/N 250051; 230V P/N 250052)
Extension 10ft Hose (P/N 600403)
Extension 3ft Tip Tube (P/N 600404)
Extension Tubes – Added lengths for hose 2” x 24” (5cm x 61cm)
(P/N 601001)
2” (5cm) Flex Hose for longer feed mechanism (P/N 601002)

4
3. Confetti Products
Also check our website (www.citcfx.com) for a complete selection of confetti and
streamer products.
CONFETTI - SPEED LOAD
Confetti stacked in 1" x 18" (2.5cm x 46cm) soft-sleeve. Just slide in then pull sleeve
Multi-color mix or Solid colors in stock. Custom mix by request.
Tissue Confetti - Solid colors, rainbow, and Red, White & Blue 5/8" x 2 1/4" (1.6cm x 5.7cm)
(P/N 255501)
Mylar-Tissue Confetti - Silver or gold Mylar & color tissue 5/8"x 2 1/4" (1.6cm x 5.7cm)
(P/N 255651)
STREAMERS - SPEED LOAD
Flameproof, Biodegradeable Tissue Paper or Mylar 1" x 20" (2.5cm x 51cm) soft-sleeve for
quick loading of your cannons (slide in, then remove sleeve - no packing)
Tissue Streamer - 1/2" x 30' (1.3cm x 9.1m) Solid colors, rainbow, and Red, White & Blue (P/N
255700)
Mylar Streamers w/ Tissue Streamer-Silver or gold Mylar & color tissue or rainbow Mylar w/
tissue (P/N 255800)
BULK/BAGGED CONFETTI
Bulk is Fluffed & Mixed - Custom Mix Confetti Colors OK
Long-Flying Tissue Confetti – Solid colors, rainbow, and Red, White & Blue (P/N 255075)
Mylar - Gold, silver, solid colors & rainbow confetti (P/N 255110)
Special Orders: Most products are available in single colors or stock mixes. Additional time
and/or charges may apply for custom orders or custom mixes.
Please check whether all the products you ordered are supplied.

5
4. Description of the ShotMaxTM
The ShotMaxTM with its 24” x 2” (61cm x 5cm) cannon uses continuous vacuum suction
to shoot out product simultaneously and continuously. It is capable of shooting
continuous confetti to approximately 35 feet (10.7m) and streamers to 50 feet (15.2m).
Simple and uncomplicated, the product is never touched by blades or a motor, and is
built with safety standards in mind! Compared to the competition, the noise level is
reduced by 75%.
This revolutionary machine can launch artificial snow, tissue confetti, streamers, fog, wind
and more. Mix tissue confetti and tissue streamers for continuous aerial excitement!
Shoot falling snow for that evenly distributed look. It even breaks up the clumps! Shoot
low-ground fog for a powerful simulated CO2blast to 50 feet and even further when
teamed with the Hurricane fan. The possibilities are endless to match your creativity!
5.Safety Instructions
WARNING: Read and understand all labels and operating instructions
before attempting installation.
o Never open the machine without disconnecting power lead first!
o Risk of electrical shock- This device is supplied with a grounding conductor. To reduce
risk of electrical shock, connect only to properly grounded, grounding type receptacles.
Never remove the third prong from the plug.
o This machine requires a properly grounded circuit for operation. The ShotMaxTM draws
approximately 10 amps at 120 VAC (5 amps at 230VAC). During ShotMaxTM operation
this circuit should be dedicated to the ShotMaxTM. If you have any doubts about the
capacity or grounding of your existing circuits, consult a qualified electrician.
o Be sure area around the unit is dry before applying electrical power.
o WARNING: Use of this machine for soft materials only. Confetti, soft streamers and soft
SnoBiz are recommended by the manufacturer. Do not use this to launch other items.
Harmful or dangerous injury can occur if not following directions.
o Use of fluids through the tubing is prohibited.
o Shooting fog through the flex tubing will cause a build up of residue. Do not use for
confetti, snow or other items after shooting fog. Angle of machine must be pointed down
when shooting fog to insure the residue does not flow back to blower. A damp or wet
blower is not covered under the Limited Warranty.
o Make sure that your unit is pointed in a direction that leaves a 50ft (13m) open area out in
front. Place the front of the machine away from direct contact with electrical instruments
and people.
6. Operating the SHOTMAXTM

6
6.1 Selecting the Location
Secure a good location for the machine to rest solidly on the floor or suspended so that
the output of the machine will not be restricted. If suspending the unit, you must use the
optional safety cable. Make sure that your unit is pointed in a direction that leaves an
open area out in front and can travel 50ft (13m) without restriction. Point the front of the
machine away from direct contact with electrical instruments and people.
6.2 Electrical Power Requirements
The ShotMaxTM draws approximately 10 amps at 120 VAC and 5 amps at 230VAC.
During operation this circuit should be dedicated to the ShotMaxTM. If you have any
doubts about the capacity or grounding of your existing circuits, please consult a qualified
electrician. Do not add other equipment on this circuit.
6.3 Hooking Things Up
•Attach the threaded tube to the front of the machine. IMPORTANT! Make certain the
launch area in front of launch tube is clear of any obstructions or personnel prior to
operation. Aim toward open area so as not to strike objects, persons, or items. Clear
area around machine so not to block air intake around all vents.
•Adjust bracket to hold up front of machine when sitting on a surface. Be sure to secure
the unit by anchoring it down. If hanging the unit from overhead, swing the bracket
completely around to the upward position and attach the C-clamp with ½” bolt, using the
safety cable. Lock the unit in position securely.
•Plug power cord into power receptacle that provides 120VAC-10A or 220VAC-5A, power
to unit.
•Insert the straight end of the suction hose into the suction connection in the cutout on top
•Place angled drawtube into the coupling on the opposite end of the hose.
6.4 Operating the Machine
•Once you have followed all safety precautions, you may turn the power switch to the
“ON” position.
•You have the option of running the Shotmax™ at high (normal) or low speed. The lower
speed allows you to drop the normal speed by about 15 mph. Using the lower speed
enables the user to create a shorter throw distance in areas where space may be limited.
It is recommended that you test both speeds to find the appropriate speed for your
environment.
•Move the angled drawtube through material to be launched, as needed. As long as the
material is close to the inlet, it will launch continuously.
•Launch soft items such as SnoBiz™, confetti, streamers, flower petals, smoke, or even
dust. Do not stuff the product into the tube, but allow plenty of air to pass with the items
to be launched. Use the angled end of hose tip to agitate the surface of product to be

7
vacuumed. Note: The angled end allows air with the product to be drawn into tube.
This prevents clogging.
•This machine is to be used with soft materials only! Do not use this to launch any
other items. Injury can occur if improperly used. Use of any fluids through the machine
is prohibited.
•Shooting Fog through the flex tubing will cause a build up of residue. Do not use for
confetti, snow or other items after shooting fog. Angle of machine must be pointed down
when shooting fog to insure the residue does not flow back into the blower. A damp or
wet blower is not covered under the Limited Warranty.
6.5 Optional DMX Control
With optional Universal DMX control, you will be able to turn the unit on and off under
DMX control. Confetti will still need to be hand-fed into the Feeder tube.
6.6 Rest Period
Continuous operation of this machine is not recommended. After 30 minutes of operation
allow a 5-minute cool-down period.
6.7 Troubleshooting
1. Why does the nozzle clog every time I use it? The long tip of the nozzle needs to be
placed into the confetti or snow-like fluffy product so the tip just touches the top of the
product and you rake across the top of it.
2. Why is the unit not sucking very much? When the nozzle is facing in the upward
position, lots of air will flow through the unit.
3. Why is the unit not sucking very much? It used to suck a lot and now it doesn’t suck
at all. The hose may be clogged. Lift up slightly at the nozzle connection inside the unit
and pull on the tubing to remove the entire coupling. This will disconnect it from the
machine and give you an opportunity to unclog any confetti that may be stuck at the
intersection where the flexible tubing connects to the rigid tubing inside the box.

8
7. Service and Maintenance
Care of your ShotMaxTM will give you years of service. Cleaning your
unit is going to pay off in constant good performance.
1. After use, detach hose and inspect hose and Y-connector for clogs.
2. Clear any product or debris from air vents of machine housing.
3. Inspect to make sure nothing has gotten inside the motor case. If enough confetti is
sucked into the motor, output will decrease and motor can overheat if not cleaned out.
8. Technical Data
ShotMaxTM Technical Data P/N 10260 (230V P/N 100265)
Weight
26 lbs. (12 kg)
Size
10” x 10” x 19”
(25.5cm x 25.5cm x 48cm)
Shipping Weight
31 lbs. (14 kg)
Shipping Box Size
25” x 15” x 16”
(63 cm x 38 cm x 40 cm)
Length of nozzle
24” (61cm)
Length of hose
48” (122cm)
Bracket
Hanging or standing bracket (screw
down or use C-clamp)
Operation time
Up to 30 min. w/5 min. off each use
Electrical Supply
120 VAC, 10 A, 60 Hz
230 VAC, 5 A, 50 Hz
Fuse
120VAC: 10A –250V (5x20 mm)
230VAC: 5A – 250V (5x20 mm)
Limited Warranty
One Year
Rev: 03/26/18

9
9. One Year Limited Warranty
Model: ________________ Purchased on (date): ________________
Serial number: ________________ Purchased from: ________________
Congratulations!
You can now look forward to many years of reliable operation and outstanding performance.
Thank you for making CITC your personal choice in special effects equipment. Please take a
moment to fill out the top of this warranty, and then keep it – with the receipt – in a safe
place.
If you would like to receive information about specials, sales, and new products, please log
on to www.citcfx.com and click on the “Contact Us” link.
We appreciate your business, and wish to provide you with a quality product that will serve
you for many years to come. Once again, thank you for choosing CITC, and enjoy your new
entertainment product!
LIMITED WARRANTY CONDITIONS
This limited warranty guarantees to the original purchaser that this product shall be free of
defects in material and workmanship, under normal use, for a period of one year from the
date of purchase shown on the sales receipt. This warranty covers parts and labor providing
the product is returned to CITC in the original shipping carton and packaging. The warranty
for electrical is a (90) NINETY DAY limited warranty.
Damage resulting from shipping, accidents, misuse, negligence, unauthorized repairs or
modification is not covered by this warranty. Using any fluid other than what is recommended
for this machine will void warranty. No liability is accepted for injury or for loss, damage or
expense resulting from any interruption whatsoever in the operation of the product or from
any consequential loss arising there from. No liability is accepted for normal wear and tear.
We wish to satisfy YOU, our customer, and have implemented many measures to prevent
problems and assure customer satisfaction. However, should you need a missing part or
have a functional problem with your product, please call:
(888) 786-CITC, from 7:30 am – 4:00 pm (Pacific Time), Monday – Friday, except for
holidays. Our customer service department will respond to your problems immediately.
Subject to the following conditions, CITC will repair any defect or fault in the unit if it is
caused by a proven factory defect within one year of delivery to the end user.
Insignificant deviations of the regular product quality does not guarantee replacement
rights, nor do faults or defects caused by water, by generally abnormal environment
conditions or Force Majeure:
1. Faulty parts or equipment will be repaired or replaced (manufacturer’s choice) with
correct parts. Faulty units must be shipped to CITC at customer’s expense. Call for
an RMA# - AN RMA# MUST COME WITH THE UNIT. Payment arrangements for
repair must be made before receiving your RMA#, in case the unit is not covered
under this limited warranty.
2. Repairs/replacements will only be made with the approval of the customer.

10
3. Exposure to outside elements voids Warranty. Unit cannot be used outdoors or in wet
weather without complete protection against the elements. Even then, high salty or
humid conditions will cause instant corrosion of connectors and will void Warranty.
4. The customer loses all rights for limited warranty services if any repairs or
adjustments are done to the units by unauthorized persons, and/or if spare parts are
used, which are not approved by CITC. The right of limited warranty service is also
lost if a fluid other than appropriate CITC fluid has been used or if units are sent in
without first emptying the equipment of fluid.
5. Freight costs to and from CITC, when under the limited warranty services, are the
responsibility of the customer. Customer must place appropriate insurance on return
of product. However, if product is returned due to factory defect within the first year,
CITC will cover the cost of returning the repaired unit to the customer.
6. Limited warranty services do not cause an extension of the limited warranty period or
the start of a new limited warranty period. The warranty of replaced parts ends with
the limited warranty period of the whole unit.
7. Further claims, especially for damages, losses etc. outside the unit are excluded.
Send unit to: CITC
RMA # XXXXXXX
1420 80th St. SW #D
Everett, WA 98203
Tel: (888) 786-CITC or [phone]
Fax: [phone]
Website: www.citcfx.com
E-mail: [e-mail]
Find us on Facebook!
www.facebook.com/CITCFX
March 26, 2018
